COMPONENTS
CHARGING AND USE
BATTERY CHARGING METHOD
The lithium battery must be fully charged before its first time using, even if the battery has some power. Connect the Type-C charging cable to the vacuum cleaner, and connect the USB terminal to the 5V 2A charger.
STATUS DISPLAY OF BATTERY IN USE
NOTE
After fully charge, make sure use up the battery power in the first time and then fully charge it again to activate the best state of battery. The some power about 3 hours.
USE OF THE UNIT
Rotate and take out the lid of vacuum cleaner
Press the power key
Note:
First press: Turn on
Second press: Turn off
Align vacuum nozzle with the Cleaning object to make sure best suction.
MAINTENANCE
CLEAN THE DUSTBIN
Press to open the dust box cover
Pour out rubbish
Twist out the dust box, and take out the filter element.
Rinse with water or detergent, dry all parts completely, and then re-install
If you met any problem during use, please read this manual carefully and check the following points first.
| STATUS | PROBLEM REASONS | SOLUTIONS |
| Power off | Battery died | Charging the vacuum cleaner |
| Suction power turns weaker |
| Charging the vacuum cleaner |
| Adjust and assemble the suction parts correctly | |
| Weak suction but loud noise |
| Dump the dust |
| Rinse & clean the filter | |
| Short operation time even after charging |
| Please charge the battery in a place where the temperature is between 0 and 40°C and away from direct sunlight |
| Contact MOOKA customer service | |
| Unable to charge | Adapter is not plugged into socket firmly | Check and make sure that the charging adapter is firmly plugged into socket |
| Charging not completed (3 lights are not on) | Charging may take longer, depending on room temperature, time of use, etc. | If the 3 lights still not on after 6 hours charging, please contact Mooka Family customer service |
| Unit or adapter gets hot during charging | Battery and circuit gets hot slightly due to charging current | This is a normal situation |
| Unit becomes hot during use | Because the battery and motor will generate | Please take a rest for 5-10 minutes and then vacuum again if the unit get too hot |
If the problem is still unresolved, please contact Mooka Customer Service.
PRODUCT SPECIFICATION SHEET
| Product model | A2 |
| Operating voltage of main engine | 7.4 V |
| Rated power of main engine | 55W |
| Battery capacity | 4000mAH |
| Charging time | 3,5H |
IMPORTANT SAFETY INSTRUCTIONS
In order to reduce the risk of injury, fire, electric shock and property damage caused by improper use, please read the following instructions carefully before use. This product contains live parts and detachable parts that may pose risks to users.
HAND-HELD VACUUM CLEANERS ARE LIVE PARTS
- The machine has no repairable parts.
- Do not use a hand-held vacuum cleaner to suck any liquid.
- Do not immerse it in water or other liquids.
- If the hand-held vacuum cleaner is damaged, please stop using it.
![burn hazard]()
To avoid fire, explosion or injury, please check the hand-held vacuum cleaner before use.- Do not use on wet surfaces, but only on dry surfaces.
- Do not touch the hand-held vacuum cleaner with wet hands.
- Do not leave the activated hand-held vacuum cleaner unattended.
- Keep the hand-held vacuum cleaner away from the heated surface.
- Please turn off the hand-held vacuum cleaner before charging it.
- Even if the hand-held vacuum cleaner is seriously damaged, don't burn electrical appliances, because lithium electronic batteries may explode in the fire.
DAILY USE
- Keep the charging wire away from the heated surface.
- Use only in accordance with this instruction manual.
- When using a hand-held vacuum cleaner, please keep your work area well illuminated.
- Do not use if any suction port is blocked; Please remove dust, cotton wool, hair or any foreign matter that may obstruct the airflow.
- Children are forbidden to operate hand-held vacuum cleaners or use them as toys. When any electrical appliances are used around children, they must be closely supervised.
- It is forbidden to use the dust collecting cup and filter screen without installation and in place.
- It is forbidden to use it when the airflow is obstructed; If the air duct is blocked, please turn off the hand-held vacuum cleaner. Clean up all the blockage, and then reopen it.
- Keep the suction nozzle away from hair, face, fingers, bare feet or loose clothes.
![burn hazard]()
Do not charge at temperatures below 50 F (10 C) or above 104 F (40 C). Incorrect charging or charging at temperatures beyond the specified range may damage the battery and increase the risk of fire.
DUST COLLECTING CUP/FILTER SCREEN
- Please ensure that the filter screen is completely dry after daily cleaning.
- Please ensure that the dust collecting cup and filter screen are installed in place after routine maintenance.
- Please make sure that all accessories are not blocked and keep all openings away from the face and body.
DAILY CLEANING
- It is forbidden to suck hard or sharp objects, such as glass, nails, screws or coins, which may be damaged.
- It is forbidden to absorb drywall ash, fireplace ash or burned ash.
- It is forbidden to use hand-held vacuum cleaners as vacuum accessories for electric tools.
- It is forbidden to suck smoking or burning objects, such as hot coal, cigarette butts or matches.
- It is forbidden to suck flammable or combustible materials (such as lighter fluid, gasoline or kerosene) or use hand-held vacuum cleaners in places where these materials may exist.
- It is forbidden to absorb toxic solutions (such as chlorine bleach, ammonia or sewer cleaner).
- It is forbidden to use in enclosed space. Such as the presence of paint, paint thinners, mothproof materials, flammable dust, or other explosive, toxic substances in the environment.
LITHIUM ION BATTERY
![]()
Under improper use, the battery liquid may leak. Avoid contact with battery liquid to cause irritation or burns. If the liquid contact with skin, rinse with plenty of water. If the liquid contact with eyes, please seek medical treatment immediately.
Please keep these instructions and read them carefully before using them.
CUSTOMER SERVICE
Our customer service team always ready to assist if you have any questions or concerns.
www.mookashops.com
support@mookashops.com
1-855-666-9955
m.me/MookaOnlineShop
