- Page 1 Intelligent Vacuum Cleaner USER MANUAL Thank you for purchasing the product. Please read the manual carefully before using.
- Page 2 Warnings Instructions for use shall be provided with the appliance so that appliance can be used safely. The plug must be removed from the socket-outlet before cleaning or maintaining the appliance. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the...
- Page 3 Only use the original adaptor, battery and charging station, or else it will damage the machine and cause fire because of electric shock and high voltage. If you find that the main body and accessories are damaged, Please do not use the cleaner and keep contact with the after-service department. Anyone is not allowed to disassemble, maintenance or remould t he Pull off the plug before doing the maintenance.
- Page 4 Don’t use this product without the protective guard if it is suspended in the air so as to prevent the vacuum cleaner from falling accidentally and causing personal injury. Do not put the machine behind the fire, inflammable, explosive and corrosive materials.
-
Page 5: Exception Clause
1. The machine will only be used with the original battery. 2. Please turn off the power switch before taking out the battery. 3. The battery must be taken out before abandoning it. 4. If you wnt to replace the battery,please keep contact with our after service department. - Page 6 Main Body Charging Station Battery Adaptor *1pc *1pc *1pc Intelligent Vacuum Cleaner USER MANUAL Filter Thank you f or purchasing t he product . P lease read the manual carefully bef ore using.
- Page 7 Front Wheel Side Brush Battery Left Wheel Right Wheel Middle Brush Rubber Brush...
- Page 8 Please install the battery before using the cleaner. Aim at the terminal and insert it during wiring. Unplug it in the reverse Adapter Socket direction during unwiring. Black Charging Terminal 1. Connect the terminal of the battery pack to the machine; then press the battery pack downforwad into the battery box.
-
Page 9: Product Usage
4.Product Usage 4.1 Main body’s Usage 4.1.1 Introduction to Control Button Introduction Button Recharge Button Power Button 4.1.2 Work Mode 4.1.2.1 Manual Mode 1. Shortly-press the Power key and the indicator will light. The cleaner will enter the standby state. And then start cleaning automatically. -
Page 10: Charging Methods
4.1.3 Operation guideline of indicators State Display Operation Long-press" "4S and enter the Turn-off Light-off OFF state. Short-press " " and enter the Turn-on Light-on Standby state. Short-press " " and enter the Cleaning Light-on Auto Cleaning mode. Short-press " "... -
Page 11: Use Of Remote Control
4.3 Use of Remote Control Introduction of remote control buttons Forward button Left-turn button Start/Stop Auto cleaning Right-turn button Back button Auto cleaning button Edge cleaning button Single Room Cleaning Set the current time Button of scheduling to clean Auto charging Tips: 1. - Page 12 Function Guidelines Function Information 1. Press the button to change the cleaner’s cleaning state to standby. Auto Cleaning button 2. When the cleaner is standby, press the button to let it shift to auto cleaning mode. After finishing the sweeping will turns into recharging mode. 3.
-
Page 13: Product Maintenance
5. Product Maintenance 5.1 Daily Storage If do not use the cleaner for a long time please fully charge the battery first and store it in a dry place. 5.2 Cleaning of Charging Plate Charging 1. Please turn off the power switch or disconnect the Pole Piece power plug first. -
Page 14: Cleaning Dustbin
5.3.2 Cleaning dustbin 2. Please clean the dustbin with the cleaning 1. Open the baffle first, and then pour out the dust. brush. Recommendation:the dustbin should be cleaned periodically. cold air hot air 4.The dustbin can be washed. Note: the dust box should be completely air-dried before re-inserting 5. -
Page 15: Clean The Main Brush
5.4 Clean the Main Brush 5.4.1 Disassemble the Main Brush 1. Push the locking-bar buckle and lift it upward. 2. Clutch the main brush and lift it upward. 3. Take out the middle brushes and its scraper assembly. 5.4.2 Cleaning the main brush and the rubber brush 1. -
Page 16: Clean The Wheels
5.5 Clean the Side Brush 1. Unscrew the screws on the side brush 2. Take out the side brush, tidy the hair and trash with a screwdriver. on and inside the cell. 5.6 Clean the Wheels Clean the front, left and right wheels regularly with a cleaning brush. 5.7 Clean the Sensors Ground Monitoring Sensor... - Page 17 6. Common Error-flash Fault Names Fault Forms Solutions indicator Flash blue light The left wheel doesn’t rotate and is Please check if there are twisters on twice with one overloaded. the left wheel of the device. sound Flash blue light Please check if there are twisters on Failure of right The right wheel doesn’t rotate and...
-
Page 18: Technical Parameters
7.Technical Parameters Main Body Parameters Accessories Parameters Adaptor Working Voltage DC14.8 V Rated Power 24 W Output Voltage DC19V Battery Output Current 600mA Lithium battery Battery Capacity 2600mAh Charging Station Charging Time About 3-5H DC 19V Working Time Input Voltage Work Temp Range Work Humidity Range Voice... - Page 19 This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présentappareilestconforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
- Page 20 Shenzhen Silver Star Intelligent Electronic Co., Ltd Address: Block D, Huiqing Technical Park, Dafu Industrial Zone, Aobei Community, Guanlan Street, Baoan District, Shenzhen City Http://www. yxrobot.com...
