Installation and Operation Manual
KX 200 NAV/COM Transceiver
Part Number
89000002-120
Export Control
These items are controlled by the U.S. government and authorized for export only to the country of ultimate destination for use
by the ultimate consignee or end-user(s) herein identified. They may not be resold, transferred, or otherwise disposed of, to
any other country or to any person other than the authorized ultimate consignee or end-user(s), either in their original form or
after being incorporated into other items, without first obtaining approval from the U.S. government or as otherwise authorized
Publication Number D202411004595, Revision 0
© Honeywell International Inc. Do not copy without express permission of Honeywell.
Legal Notice
by U.S. law and regulations.
ECCN: 7E994.
CAGE
55939
34-24-61
Initial 23 Jan 2025
Page T-1
