LL6270 Carbon Monoxide Monitor
QUICK START GUIDE
Display CO Level
Button
Test/Reset/Mute
Button
The UL2034 standard for residential carbon monoxide (CO) alarms does not permit
listed CO alarms to automatically display or alarm at CO levels below 30 ppm. The
Defender LL6270 is designed to provide added protection for older adults, pregnant
women, young children, and persons with medical conditions who may be more
vulnerable to lower CO levels, and is not UL listed.
applications, this monitor should supplement, not replace, a UL listed CO alarm.
R
85dB Horn
Mounting Screw
- 1 -
Large Alpha-Numeric LCD
Secure-Lock Mounting Plate
Alarm LED
Power LED
Service LED
When installed in residential
OM5-6270-00 2025-01-20

Advertisement

loading
Need help?

Need help?

Do you have a question about the LL6270 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Defender LL6270

Summary of Contents for Defender LL6270

  • Page 1 The UL2034 standard for residential carbon monoxide (CO) alarms does not permit listed CO alarms to automatically display or alarm at CO levels below 30 ppm. The Defender LL6270 is designed to provide added protection for older adults, pregnant women, young children, and persons with medical conditions who may be more vulnerable to lower CO levels, and is not UL listed.

  • Page 2: Locations To Avoid

    1. RECOMMENDED LOCATION OF MONITORS CO poisoning can happen anywhere in the building. CO monitors should be installed onto an interior wall, five feet off the floor, and on every conditioned level of the building. At the minimum, install CO monitors: Monitor 1.

  • Page 3: Installation Instructions

    3. INSTALLATION INSTRUCTIONS Follow these steps in this order to install the CO monitor: 1. Fasten the mounting plate to the wall at eye level, about 5’ off the floor. Slide monitor down onto mounting plate. Connection between mounting plate and monitor will turn activation switch ON.
  • Page 4 4. CONDENSED OPERATION INSTRUCTONS OPERATION: The CO monitor is operational once the activation switch is slid to ON position. If the monitor’s power is active, the LCD readout will display 0 PPM, or the current CO level if 5 PPM or more is detected.

  • Page 5: Lcd Display Function

    LCD DISPLAY FUNCTION: When monitor is operating normally, the LCD will display 0 PPM or the current CO level if 5 PPM or more is detected. Above 500 PPM, the LCD will flash “500 PPM”. The LCD will display symbol if batteries have low voltage. Continuously Displays 0 PPM Auto.
