H2MIDI PRO
USER MANUAL V01
Hello, thank you for purchasing CME's professional products!
Please read this manual completely before using this product. The
pictures in the manual are for illustration purposes only, the actual product
may vary. For more technical support content and videos, please visit this
page: www.cme-pro.com/support/
IMPORTANT
Warning
⚫
Improper connection may result in damage to the device.
Copyright
⚫
Copyright 2025 © CME Corporation. All rights reserved. CME is a
registered trademark of CME Pte. Ltd. in Singapore and/or other countries.
All other trademarks or registered trademarks are the property of their
respective owners.
Limited Warranty
⚫
CME provides a one-year standard Limited Warranty for this product
only to the person or entity that originally purchased this product from an
authorized dealer or distributor of CME. The warranty period starts on the
date of purchase of this product. CME warrants the included hardware
1 / 20
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for CME H2MIDI PRO
Summary of Contents for CME H2MIDI PRO
- Page 1 CME provides a one-year standard Limited Warranty for this product only to the person or entity that originally purchased this product from an authorized dealer or distributor of CME. The warranty period starts on the date of purchase of this product. CME warrants the included hardware...
- Page 2 CME does not warrant against normal wear and tear, nor damage caused by accident or abuse of the purchased product. CME is not responsible for any damage or data loss caused by improper operation of the equipment. You are required to provide proof of purchase as a condition of receiving warranty service.
- Page 3 Quick Start Guide INTRODUCTION H2MIDI PRO is a USB dual-role MIDI interface which can be used as a USB host to independently connect plug-and-play USB MIDI devices and 5- pins DIN MIDI devices for bidirectional MIDI transmission. At the same time,...
- Page 4 USB power supply (bus or power bank) and a DC 9V power supply (sold separately). H2MIDI PRO uses the latest 32-bit high-speed processing chip, which enables fast transmission speeds over USB to meet the throughput of large data Messages and to achieve the best latency and accuracy on sub millisecond level.
- Page 5 The USB-A port can distribute power from the DC or USB-C port to the connected USB devices, with a maximum current limit of 5V-500mA. The USB host port of H2MIDI PRO can be used as a stand-alone interface without a computer.
- Page 6 USB MIDI device can perform MIDI transmission with other connected MIDI devices. Note 1: If H2MIDI PRO cannot recognize the connected device, it may be a compatibility issue. Please contact support@cme-pro.com to get technical support. Note 2: If you need to change the routing configuration between connected MIDI devices, connect your computer to the USB-C port of the H2MIDI PRO and reconfigure using the free HxMIDI Tools software.
- Page 7 USB-C client port and indicator The H2MIDI PRO has a USB-C port for connecting to a computer to transmit MIDI data or connecting to a standard USB power supply (such as a charger, power bank, computer USB socket, etc.) with a voltage of 5 volts for standalone use.
- Page 8 Please choose a power adapter with a positive terminal on the outside of the plug, a negative terminal on the inner pin, and an outer diameter of 5.5 mm. WIRED MIDI CONNECTION ⚫ Use H2MIDI PRO to connect an external USB MIDI device to a MIDI device 8 / 20...
- Page 9 USB-A port of H2MIDI PRO. If you want to connect multiple USB MIDI devices at the same time, please use a USB Hub. Use a MIDI cable to connect the MIDI IN port of the H2MIDI PRO to 9 / 20...
- Page 10 Multiple H2MIDI PROs can be connected to a computer via a USB Hub. Use a MIDI cable to connect the MIDI IN port of the H2MIDI PRO to ⚫ the MIDI Out or Thru of other MIDI device, and connect the MIDI OUT port of the H2MIDI PRO to the MIDI IN of other MIDI device.
- Page 11 Open the music software, set the MIDI input and output ports to H2MIDI PRO on the MIDI settings page, and get started. See the manual of your software for further details. ⚫ H2MIDI PRO Initial signal flow chart:...
- Page 12 Android) and the user manual. You can use it to upgrade the firmware of your H2MIDI PRO at any time to get the latest advanced features. At the same time, you can also perform a variety of flexible settings. All router, mapper and filter settings will be automatically saved to the internal memory of the device.
- Page 13 MIDI Mapper Settings The MIDI mapper is used to reassign (remap) the selected input data of the connected device so that it can be output according to custom rules that are defined by you. 13 / 20...
- Page 14 MIDI Filter settings The MIDI filter is used to block certain types of MIDI messages in a selected input or output from passing through. 14 / 20...
- Page 15 View full settings & Reset all to factory defaults The View Full settings button is used to view the filter, mapper, and router settings for each port of the current device - in one convenient overview. The Reset all to factory defaults button is used to reset all parameters of the unit to the default state when the product leaves the factory.
- Page 16 If the firmware cannot be updated automatically, you can manually update it on the Firmware page. Note: It is recommended to restart H2MIDI PRO every time after upgrading to a new firmware version. Settings The Settings page is used to select the CME USB Host MIDI hardware device model and port to be set up and operated by the software.
- Page 17 Product and Ports. If you have multiple CME USB Host MIDI hardware devices connected at the same time, please select the product and port you want to set up here. You can also enable remote switching of user presets via MIDI note, program change, or control change message in the Presets settings area.
- Page 18 1x DC power socket (External 9V-500mA DC adapter not included) Indicator Lights 4x LED indicators Button 1x button for presets and other function Compatible Device with plug-and-play USB MIDI socket, or standard MIDI devices socket (including 5V and 3.3V compatibility) Computer and USB MIDI host device which supports USB MIDI plug-and-play Compatible OS...
- Page 19 The computer does not receive MIDI messages when playing a MIDI ⚫ keyboard. Please check if the H2MIDI PRO is correctly selected as the MIDI input ‐ device in your music software. Please check if you ever set up custom MIDI routing or filtering ‐...
- Page 20 The external sound module is not responding to MIDI messages ⚫ played by the computer. Please check if the H2MIDI PRO is correctly selected as the MIDI ‐ output device in your music software. Please check if you ever set up custom MIDI routing or filtering ‐...
