  • Page 1 EN User Manual | Washing Machine LR7BI6480 aeg.com\register...

  • Page 2: Table Of Contents

    Welcome to AEG! Thank you for choosing our appliance. Get usage advice, brochures, troubleshooting, service and repair information: www.aeg.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................4 3. PRODUCT DESCRIPTION................6 4. TECHNICAL DATA..................7 5.

  • Page 3: General Safety

    • Children between 3 and 8 years of age and persons with very extensive and complex disabilities shall be kept away from the appliance unless continuously supervised. • Children of less than 3 years of age should be kept away from the appliance unless continuously supervised.

  • Page 4: Safety Instructions

    • The appliance must be connected to the water mains using the new supplied hose sets, or other new hose sets supplied by the Authorised Service Centre. • Old hose sets must not be reused. • If the mains power supply cable is damaged, it must be replaced by the manufacturer, its Authorised Service Centre or similarly qualified persons to avoid an electrical hazard.

  • Page 5: Water Connection

    • Make sure that the parameters on the • Follow the safety instructions on the rating plate are compatible with the detergent packaging. electrical ratings of the mains power • Do not put flammable products or items supply. that are wet with flammable products in, •...

  • Page 6: Product Description

    These lamps are intended to withstand • Disconnect the appliance from the mains extreme physical conditions in household electrical and water supplies. appliances, such as temperature, • Cut off the mains electrical cable close to vibration, humidity, or are intended to the appliance and dispose of it.

  • Page 7: Technical Data

    The rating plate reports the model name (A), product number (B), electrical ratings (C) and serial number (D). Mod. xxxxxxxxx Prod.No. 910000000 00 000V ~ 00Hz 0000 W 00000000 4. TECHNICAL DATA Dimension Width/ Height/ Total depth 59.6 cm /81.9 cm /55.3 cm Electrical connection Voltage 230 V...
  • Page 8 5.2 The appliance is equipped with ... 5.3 Unpacking WARNING! Use the gloves. WARNING! Remove all the packaging and the transit bolts before installing the appliance. 1. Put two packaging elements on the floor under the appliance. WARNING! It is strongly recommended that this action is carries out by two persons.
  • Page 9 3. Remove the protection from the bottom. 4. Return the appliance in vertical position and remove the socket protection. 5. Remove the power supply cable and the drain hose from the hose holders. It is possible to see water flowing from the drain hose.

  • Page 10: Positioning And Levelling

    7. Close the holes with the plastic caps you find in the user manual bag. Put the smallest cap F in upper hole and the two bigger caps G in lower holes. We recommend that you keep the packaging and the transit bolts for any movement of the appliance.

  • Page 11: Hose And Cable Connection

    5.5 Hose and cable connection 1100 mm 1450 mm 1230 mm 960 mm 1360 mm 900 mm The inlet hose Nur für Deutschland Stellen Sie gemäß der Deutschen Trinkwasserverordnung sicher, dass Sie beim Anschluss des Wasserzulaufschlauches eine Sicherheitsvorrichtung anbringen (gemäß DIN EN 1717 Flüssigkeitskategorie 2 Typ EC oder ED und EN 13959) die den Rückfluss in den Wasserschanschluß...
  • Page 12 Requirements: 3/4’’ thread. Flow direction indicated by the arrow. 1. Remove the inlet hose from inside the drum. 2. To connect the water inlet hose towards the proper direction and with the proper inclination, check the position of the water tap before connecting it to the back of the appliance.

  • Page 13: Water Drainage

    5. Connect the valve to the cold water tap with 3/4" thread. The check valve must not be assembled on the appliance. WARNING! The inlet water shall not exceed 25 °C. WARNING! Make sure that there are no leaks from the couplings.
  • Page 14 To a stand pipe with vent-hole Directly into a drain pipe at a height of not less Ø 40 mm than 60 cm (23.6”) and not more than 100 cm (39.3”). The end of the drain hose must always be ventilated , i.e.
  • Page 15 5.6 Building in This appliance has been designed to be built into the kitchen furniture. See the minimum recess min. 600 mm dimensions in the drawings. min. 560 mm min. 820 mm 16-22 mm 596 mm 553 mm If hoses run behind the appliance, make sure that nothing closes the small recess indicated with the measures 50 x 50 mm.

  • Page 16: Preparation And Assembly Of The Cupboard Door

    5.7 Preparation and assembly of the cupboard door The dimensions of the cupboard door should be: • width min. 595 - max. 598 mm; • thickness 16-22 mm. Factory pre setting The appliance is originally pre set for the assembly of a cupboard door opening from right to left.
  • Page 17 Make sure that the plate with magnet is on the upper position. Cupboard door preparation For countersinking the door, it is recommended to call a professional. Align the cupboard door to the furniture correctly. Measure the distance X to fix the height of the hole to countersink the upper hinge.
  • Page 18 To align the door perfectly, make sure that the edge of cupboard door is parallel with the appliance edge and to respect the proper opening angle (max. 105 °). max. 105° Mounting the door Fix the hinges to the hinge supports on the appliance by means of the two supplied screws The hinges can be adjusted to compensate for possible uneven thickness...

  • Page 19: Control Panel

    5.8 Electrical connection The power supply cable must be easily accessible after installing the appliance. At the end of installation you can connect the For any electrical work required to install this mains plug to the mains socket. appliance, contact our Authorised Service The rating plate and the 'Technical Data' Centre.
  • Page 20 Plus Dampf touch button and permanent • Rinse Hold option Child Lock option • No spin option Soft Plus touch button and permanent • Silent option Extra Rinse option Temperatur touch button Vorwäsche touch button and permanent Ein/Aus push button Stain option Schleudern reduction options touch button...

  • Page 21: Dial And Buttons

    Add garments indicator. it lights at the beginning of the washing phase, when it is still possible to pause the appliance and add more laundry. Child safety lock indicator. Machine clean indicator. This is a recommendation to perform the drum cleaning. Anti-crease phase indicator.

  • Page 22: Permanent Extra Rinse

    more water for some washing programmes • Silent . The related indicator comes on. This option increases the programme The intermediate and the final spinning duration. phases are suppressed and the This option is not available with a programme ends with water in the drum. temperature lower than 40 °C.

  • Page 23: Child Lock

    The display shows the indicator and the selected delay time. After touching the Start/ This option can increase the programme Pause button, the appliance begins the duration. countdown and the door is locked. When the programme stops the display 7.13 Zeit Sparen shows , the indicator goes off and...

  • Page 24: Programmes

    • : minimum. indicator In some appliances the programme duration is reduced without showing any dashes. 7.14 Start/Pause ■ ■ Touch the Start/Pause button to start, pause the appliance or interrupt a running Default duration for all programmes. programme. Zeit Sparen with steam programmes When setting a steam programme, this button allows to chose three steam levels and the icon means that you can pause...
  • Page 25 Programme Reference Maxi‐ Programme description Default tempera‐ spin speed (Type of load and level of soiling) ture load Temperature range 1200 rpm 2.0 kg Outdoor 1.0 kg Do not use fabric softener and make sure that 30 °C 40 °C - Cold there is no softener residue in the detergent dispenser.
  • Page 26 The AEGSteam Fragrance allows you to refresh even your delicate clothes, removing wrinkles and adding fresh‐ ness with a gentle fragrance developed exclusively by AEG. By refreshing your garments with steam, rather than running full wash cycles, you will keep your clothes looking and feeling new longer. You can even safely use the fragrance with Cashmere and Steam programmes - if they are available - for delicate fabrics like cashmere and wool.
  • Page 27 Programme Reference Maxi‐ Programme description Default tempera‐ spin speed (Type of load and level of soiling) ture load Temperature range 1400 rpm 8.0 kg All fabrics, except woollens and delicate fabrics. To spin the laundry and to drain the water in the drum. Schleudern/ Abpumpen 1400 rpm...

  • Page 28: Programme Options Compatibility

    Programme Reference Maxi‐ Programme description Default tempera‐ spin speed (Type of load and level of soiling) ture load Temperature range 1200 rpm 1.5 kg Machine washable wool, hand washable wool and other fabrics with «hand washing» care symbol Wolle/Seide 40 °C 40 °C - Cold According to Commission Regulation EU 2019/2023, this programme at 40 °C is able to clean normally soiled cotton laundry declared to be washable at 40 °C or 60 °C, together in the same cycle.
  • Page 29 Programme ■ ■ Dampf ■ ■ ■ Schleudern/Abpumpen ■ ■ ■ ■ ■ Spülen ■ ■ ■ ■ ■ ■ ■ ■ Hygiene ■ ■ ■ Daunen ■ ■ ■ 20 Min.- 3 kg ■ ■ ■ ■ ■ ■ Sport ■...

  • Page 30: Settings

    Programme Universal Liquid Univer‐ Liquid for col‐ Delicates Special oureds woollens powder 1) ▲ ▲ ▲ Hygiene Daunen ▲ ▲ 20 Min.- 3 kg ▲ ▲ Sport ▲ ▲ ▲ Denim ▲ ▲ ▲ Wolle/Seide ▲ ▲ At temperature higher than 60 °C the use of powder detergent is recommended. ▲...

  • Page 31: Factory Reset

    9.3 Factory Reset pauses, delayed start time). To visualise this value, proceed as follows: This function allows to restore the factory 1. Switch the appliance on by pressing default options. To activate this option follow Ein/Aus button. steps below: 2. Turn the programme knob to the Eco 1.

  • Page 32: Filling The Detergent And Additives

    Always follow the instructions that you find on the packaging of the detergent products, but we recommend that you do not exceed the maximum indicated level ). This quantity will however guarantee the best washing results. After a washing cycle, if necessary, remove any detergent residue from the detergent dispenser.

  • Page 33: Starting A Programme With The Delay Start

    • Do not exceed to liquid detergent dose The related indicator stops flashing and stays indicated on the flap. • Do not set the prewash phase. The programme starts, the door is locked. • Do not set the delay start function. The display shows the indicator and the 5.

  • Page 34: Cancelling A Running Programme

    11.8 The ProSense System load 3. Touch the Start/Pause button again. detection The washing programme continues. 11.10 Cancelling a running programme The programme duration in the display is referred to a medium/high load. 1. Press the button Ein/Aus to cancel the programme and to deactivate the After touching the Start/Pause button, the...

  • Page 35: End Of The Programme

    The programme or the delay start continues. 2. Press the Start/Pause button: the appliance drains the water and spins. 11.12 End of the programme The option indicator Rinse Hold When the programme has finished, the disappears. appliance stops automatically. The acoustic signals operate (if they are active).

  • Page 36: Hints And Tips

    12. HINTS AND TIPS WARNING! Refer to Safety chapters. 12.1 The laundry load • Divide the laundry into: white, coloured, synthetics, delicates and wool. • Follow the washing instructions on the laundry care labels. • Empty pockets and unfold the items. •...

  • Page 37: Water Hardness

    • Use only detergents and other treatments • inadequate rinsing, specially made for washing machines. • a greater impact for the environment. First, follow these generic rules: 12.4 Savings tips – powder detergents (also tablets and single-dose detergents) for all types of To save water, energy and detergent we fabric, excluding delicate.

  • Page 38: Removing Foreign Objects

    After each cycle, keep the door and the CAUTION! detergent dispenser slightly open to get air circulation and dry the humidity inside the Do not clean the metal surfaces with appliance: this will prevent mildew and chlorine-based detergent. odours. 13.4 Descaling If the appliance is not used for a long time: close the water tap and unplug the appliance.

  • Page 39: Cleaning The Drum

    Occasionally, at the end of a cycle the display may show the icon : this is a recommendation to perform the “drum cleaning”. Once the drum cleaning has been performed, the icon disappears. 13.8 Cleaning the detergent dispenser Clean it when needed, using ammonia cream To prevent possible deposits of dried cleanser agent without scratching the seal detergent or clotted fabric softener and/or...

  • Page 40: Cleaning The Drain Pump Filter

    13.9 Cleaning the drain pump filter the recess. Use a small brush to clean the recess. WARNING! Disconnect the mains plug from the mains socket. Regularly check the drain pump filter and make sure that it is clean. Clean the drain pump if: •...
  • Page 41 2. Place a suitable bowl below the drain pump access to collect the water that flows out. Always keep a rag nearby to dry up any water spillages when removing the filter. 180˚ 3. Turn the filter 180 degrees in anti-clockwise direction to open it, without removing.
  • Page 42 7. If it is necessary, remove fluff and objects from the filter recess. Make sure that the impeller of the pump can rotate. If it does not rotate, contact the Authorised Service Centre. 8. Clean the filter under the water tap. 9.

  • Page 43: Cleaning The Inlet Hose And The Valve Filter

    When you drain the water with the emergency drain procedure, you must activate the drain system again: 1. Put 2 litres of water in the main wash compartment of the detergent dispenser. 2. Start the programme to drain the water. 13.10 Cleaning the inlet hose and remove any deposit, collected over the time.

  • Page 44: Troubleshooting

    WARNING! Make sure that the temperature is higher than 0 °C before you use the appliance again. The manufacturer is not responsible for damages caused by low temperatures. 14. TROUBLESHOOTING WARNING! Refer to Safety chapters. 14.1 Alarm Codes and Possible failures The appliance does not start or it stops during operation.
  • Page 45 • Make sure that the water tap is open. • Make sure that the pressure of the water supply is not too low. For this infor‐ The appliance does not fill mation, contact your local water authority. with water properly. •...
  • Page 46 Problem Possible solution • Set the spin programme. • Make sure that the drain filter is not clogged. Clean the filter, if necessary. Re‐ The spin phase does not op‐ erate or the washing cycle fer to "Care and cleaning". lasts longer than usual.

  • Page 47: Emergency Door Opening

    14.2 Emergency door opening To open the door, proceed as follows: 1. Press the Ein/Aus button to switch the In case of power failure or functioning failure appliance off. the appliance door remains locked. The 2. Disconnect the mains plug from the washing programme continues when the mains socket.

  • Page 48: Environmental Concerns

    15.2 According to Commission Regulation Eu 2019/2023 Eco 40-60 pro‐ rpm 1) Litres hh:mm °C gramme Full load 0.800 55.0 03:20 53.00 42.0 1351 Half load 0.500 45.0 02:30 53.00 33.0 1351 Quarter load 0.300 35.0 02:20 54.00 31.0 1351 Maximum spin speed.
