Handling and ESD tips General handling of your TQ-products The TQ-product may only be used and serviced by certified personnel who have taken note of the information, the safety regulations in this document and all related rules and regulations. A general rule is: do not touch the TQ-product during operation. This is especially important when switching on, changing jumper settings or connecting other devices without ensuring beforehand that the power supply of the system has been switched off.
The electronic components of your TQ-product are sensitive to electrostatic discharge (ESD). Always wear antistatic clothing, use ESD-safe tools, packing materials etc., and operate your TQ- product in an ESD-safe environment. Especially when you switch modules on, change jumper settings, or connect other devices.
TQMLS1028A, and the BSP provided by TQ-Systems GmbH. See also chapter 6. The TQMLS1028A is a universal Minimodule based on the NXP Layerscape CPUs LS1028A / LS1018A / LS1027A / LS1017A. ®- These Layerscape CPUs feature a Single, or a Dual Cortex A72 core, with QorIQ technology.
• EEPROM • Boar-to-Board connectors All essential CPU pins are routed to the TQMLS1028A connectors. There are therefore no restrictions for customers using the TQMLS1028A with respect to an integrated customised design. The functionality of the different TQMLS1028A is mainly...
The output HRESET_REQ# is driven internally by the CPU and can be set by software by writing to RSTCR register (bit 30). By default, RESET_REQ# is fed back via 10 kΩ to RESIN# on the TQMLS1028A. No feedback on the carrier board is required.
The RCW source of the TQMLS1028A is determined by the level of the analogue 3.3 V signal RCW_SRC_SEL. The RCW source selection is managed by the system controller. A 10 kΩ Pull-Up to 3.3 V is assembled on the TQMLS1028A.
This state can only be exited with a PORESET_B or Hard Reset. System Controller The TQMLS1028A uses a system controller for housekeeping and initialization functions. This system controller also performs power sequencing and voltage monitoring. The functions are in detail: •...
System Clock The system clock is permanently set to 100 MHz. Spread spectrum clocking is not possible. SDRAM 1, 2, 4 or 8 GB of DDR4-1600 SDRAM can be assembled on the TQMLS1028A. Flash Assembled on TQMLS1028A: • QSPI NOR Flash •...
The LS1028A provides two SDHCs; one is for SD cards (with switchable I/O voltage) and the other is for the internal eMMC (fixed I/O voltage). When populated, the TQMLS1028A internal eMMC is connected to SDHC2. The maximum transfer rate corresponds to the HS400 mode (eMMC from 5.0).
The accuracy of the RTC is primarily determined by the characteristics of the quartz used. The type FC-135 used on the TQMLS1028A has a standard frequency tolerance of ±20 ppm at +25 °C. (Parabolic coefficient: max. –0.04 × 10 / °C –6...
4.12 Power consumption TQMLS1028A The power consumption of the TQMLS1028A strongly depends on the application, the mode of operation and the operating system. For this reason the given values have to be seen as approximate values. Current peaks of 3.5 A may occur. The carrier board power supply should be designed for a TDP of 13.5 W.
C buses of the LS1028A (I2C1 to I2C6) are routed to the TQMLS1028A connectors and not terminated. The I2C1 bus is level shifted to 3.3 V and terminated with 4.7 kΩ Pull-Ups to 3.3 V on the TQMLS1028A. The I C devices on the TQMLS1028A are connected to the level-shifted I2C1 bus.
Page 26
1.8 V Ethernet EC1_GTX_CLK EMI1_MDC Ethernet 1.8 V 1.8 V Ethernet EC1_GTX_CLK125 EMI1_MDIO Ethernet 1.8 V Power DGND DGND Power Default on TQMLS1028A revision 01xx. Default on TQMLS1028A revision 02xx. Backward compatibility with revision 01xx is possible by assembly option.
The TQMLS1028A is held in the mating connectors with a retention force of approximately 24 N. To avoid damaging the TQMLS1028A connectors as well as the carrier board connectors while removing the TQMLS1028A the use of the extraction tool MOZI8XX is strongly recommended. See chapter 5.8 for further information.
Both can be purchased separately for larger quantities. Please contact your local sales representative. Structural requirements The TQMLS1028A is held in its mating connectors by the 240 pins with a retention force of approximately 24 N. Notes of treatment To avoid damage caused by mechanical stress, the TQMLS1028A may only be extracted from the carrier board by using the extraction tool MOZI8XX that can also be obtained separately.
TQ. TQ is not liable for any delivery delays due to national or international export restrictions or for the inability to make a delivery as a result of those restrictions.
Page 28 Warranty TQ-Systems GmbH warrants that the product, when used in accordance with the contract, fulfills the respective contractually agreed specifications and functionalities and corresponds to the recognized state of the art. The warranty is limited to material, manufacturing and processing defects. The manufacturer's liability is void in the following cases: •...
By environmentally friendly processes, production equipment and products, we contribute to the protection of our environment. To be able to reuse the TQMLS1028A, it is produced in such a way (a modular construction) that it can be easily repaired and disassembled. The energy consumption of the TQMLS1028A is minimised by suitable measures. The TQMLS1028A is delivered in reusable packaging.
