Summary of Contents for Kicker 51KMC4
- Page 1 KMC4 Media Center 51KMC4 Owner’s Manual | English Manual del Propietario | Español KMC4 Receptor Multi-Media Benutzerhandbuch | Deutsch KMC4 Multi-Media-Receiver Manuel d’utilisation | Française KMC4 Multi-Media Receiver...
- Page 2 FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 3 mounting hole cutout template (also available online): 3 inches, 76.2 mm gabarit de montage trou découpé: 3 pouces, 76,2 mm plantilla de recorte del agujero de montaje: 3 pulgadas, 76.2 mm montageloch ausschnittschablone : 3 Zoll, 76,2 mm 3 inches, 76.2 mm 3 pouces, 76,2 mm 3 pulgadas, 76.2 mm 3 Zoll, 76,2 mm...
- Page 4 mounting hole cutout template (also available online): 3 inches, 76.2 mm gabarit de montage trou découpé: 3 pouces, 76,2 mm plantilla de recorte del agujero de montaje: 3 pulgadas, 76.2 mm montageloch ausschnittschablone : 3 Zoll, 76,2 mm 3 inches, 76.2 mm 3 pouces, 76,2 mm 3 pulgadas, 76.2 mm 3 Zoll, 76,2 mm...
-
Page 5: Table Of Contents
KMC4 OWNER’S MANUAL Contents Specs Overview Installation Microphone Installation Operation Troubleshooting Warranty... -
Page 6: Specifications
500mV With a KICKER KXM amplifier, a pair of KICKER KM USB Playback MP3/WMA/FLAC/AAC/WAV speakers, and a few KICKER cables, you’re looking at a full system upgrade that will dominate! KICKER amplifiers and USB Charging DC 5V, 1A accessories make upgrading a snap. Ask your dealer about... -
Page 7: Overview
OVERVIEW If the battery voltage is low (<+10.5V), an on-screen warning will appear. Recharge battery and avoid becoming stuck or marooned. •power on/off (long press) •change input source (short press) KMC4 SOURCE •save/select favorite presets FAVORITES •digital display •enter Audio Settings (short press) MENU •enter Device Settings (long press) •next track/fast forward... -
Page 8: Installation
KMC4 INSTALLATION MIC input front RCA out (gray) AUX input rear RCA out (black) (green) wired remote sub RCA out (KRC12 sold separately) (red) USB input zone 2 RCA out USB charging (purple) fuse radio antenna input (Motorola-style plug, antenna sold separately) fuse: 15A ATM positive negative... - Page 9 Remember to cap unused wires and avoid electrical shorts! Remote Turn-On sends a low voltage signal to power up a connected marine amplifier or other compatible device. +12V (switched) ≤7” 18cm ground (black) fuse remote turn-on output (blue) (12V, 500mA) battery dimmer (orange) (leave disconnected if no...
- Page 10 Securely fasten the KMC4 to the mounting surface using the including screws. Attach the snap-on trim ring to the front of the KMC4.
-
Page 11: Microphone Installation
MICROPHONE INSTALLATION Microphone is not waterproof and MUST be mounted in a dry location and aimed towards the user. Microphone Clip-On Attach the microphone socket to the ball joint of the microphone clip-on, Adhesive Microphone Block Remove the adhesive from the flexible microphone paste block and apply the block to the surface to which the microphone will be mounted. -
Page 12: Operation
(1–10) you wish to set, and pressing and holding the VOLUME KNOB for 2 seconds. The KMC4 will automatically switch to USB input when a USB device is connected and detected. KICKER recommends SANDISK drives for the best performance. Drives must be formatted in FAT32 file system. USB hubs are not compatible. High-bit rate files (320kbps) may experience errors. - Page 13 Device Settings Press & Hold the MENU button to enter the Device Settings menu. The available settings are: Beep, Loud, Area, Zone2, Z2 VOL, Hands-Free, Hands-Free VOL, Ringtone, High-Pass Filter, and Dimmer. Use the VOLUME KNOB to change the available values for each setting.
-
Page 14: Troubleshooting
If you have more questions about the installation or operation of your new KICKER product, see the Authorized KICKER Dealer where you made your purchase. Please E-mail support@kicker.com or call Technical Services (405) 624-8583 for unanswered or specific questions. - Page 15 Defective merchandise should be returned to your local Authorized Stillwater Designs (KICKER) Dealer for warranty service. Assistance in locating an Authorized Dealer can be found at www.kicker.com or by contacting Stillwater Designs directly. You can confirm that a dealer is authorized by asking to see a current authorized dealer window decal.
-
Page 16: International Warranty
Sea precavido cuando controle el volumen. La frase “combustible para vivir la vida Livin’ Loud™ a todo volumen” se refiere al entusiasmo por la vida que la marca Kicker de estéreos de automóvil representa y a la recomendación a nuestros clientes de que vivan lo mejor posible (“a todo volumen”) en todo sentido. - Page 17 ©2020 Stillwater Designs...
