Canon LBP811C Series Manual

LBP811Cx 在 Windows 透過
Driver installation procedure for LBP811Cx in Windows (Via Wireless LAN)
以下步驟及畫面僅供參考，實際操作畫面可能因裝置型號、系統或軟件版本而有所不同。
The following steps and screens are for reference only, and the actual operation screens may vary
depending on the device model, system, or software version.
先將打印機連接到網路，詳細可參考以下步驟
Connect printer to network firs
開啟印表機
1.
Turn on the printer
選擇 [首頁] 畫面中的 [設定]
2.
Select <Set> on the <Home> screen
選擇 [參數選擇] [網路] [無線區域網路設定] [SSID 設定]
3.
Select <Preferences> <Network>
選擇 [選擇存取點] 選擇想要連線的無線區域網路的 SSID，然後按下
4.
Select <Select Access Point> select the SSID of the wireless LAN to which you want to connect, and
press
輸入網路金鑰，然後選擇 [套用]
5.
Enter the network key, and choose <Apply>
選擇
6. [是]
Select <Yes>
操作面板上顯示 [已連線。] 時，按下
7.
When [Connected.] is displayed on the operation panel, press
等待約 2 分鐘，直到本機的 IP 位址設定完成
Wait approximately 2 minutes until IP address settings of the machine complete
無線 LAN 連線
t, please refer to following procedure
<Wireless LAN Settings> <SSID Settings>
1
連接印表機之驅動程式步驟
