  • Page 1 EN User Manual | Washer Dryer EW7W467WCI...

  • Page 2: Table Of Contents

    Welcome to Electrolux! Thank you for choosing our appliance. Get usage advice, brochures, troubleshooting, service and repair information: www.electrolux.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................5 3. PRODUCT DESCRIPTION................7 4. TECHNICAL DATA..................8 5.

  • Page 3: General Safety

    • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved.
  • Page 4 similar accommodation where such use does not exceed (average) domestic usage levels. • Do not change the specification of this appliance. • Do not install the appliance behind a lockable door, a sliding door or a door with a hinge on the opposite side, that would prevent the appliance door from being fully open.

  • Page 5: Safety Instructions

    • Items that have been soiled with substances such as vegetable or mineral oil, acetone, alcohol, petrol, kerosene, spot removers, turpentine, waxes and wax removers should be washed separately with an extra amount of detergent before being dried in the washer dryer. •...

  • Page 6: Electrical Connection

    • Do not install or use the appliance where has been carried out or new devices fitted the temperature can be less than 0°C or (water meters, etc.), let the water flow until where it is exposed to the weather. it is clean and clear.

  • Page 7: Product Description

    • Do not use a detergent ball if setting a • Please note that some of these spare non-stop programme. parts are only available to professional repairers, and that not all spare parts are 2.5 Service relevant for all models. •...

  • Page 8: Technical Data

    Access your appliance details, documentation and articles on how to use the best features (User Manual also available at electrolux.com/manuals ) • Get usage advice, troubleshooting, service and repair information (also available at electrolux.com/ support ) • Buy accessories, Consumable and Original Spare parts for you appliance (also available at electro‐...

  • Page 9: Installation

    5. INSTALLATION 5.2 The appliance is equipped WARNING! with ... Refer to Safety chapters. 5.1 Be prepared for installation It is recommended that installation is carried out by two persons. 5.3 Unpacking WARNING! Use the gloves. WARNING! Remove all the packaging and the transit bolts before installing the appliance. 1.
  • Page 10 3. Remove the protection from the bottom. 4. Return the appliance in vertical position and remove the socket protection. 5. Remove the power supply cable and the drain hose from the hose holders. It is possible to see water flowing from the drain hose.

  • Page 11: Positioning And Levelling

    7. Close the holes with the plastic caps you find in the user manual bag. Put the smallest cap F in upper hole and the two bigger caps G in lower holes. We recommend that you keep the packaging and the transit bolts for any movement of the appliance.
  • Page 12 5.5 Hose and cable connection 1100 mm 1450 mm 1020 mm 760 mm 1360 mm 900 mm The inlet hose 1. Remove the inlet hose from inside the drum. 2. To connect the water inlet hose towards the proper direction and with the proper inclination, check the position of the water tap before connecting it to the back of the appliance.

  • Page 13: Water Drainage

    5. Connect the water inlet hose to the cold water tap with 3/4 thread. WARNING! The inlet water shall not exceed 25 °C. WARNING! Make sure that there are no leaks from the couplings. Use the hose supplied with appliance. Do not use an extension hose if the inlet hose is too short.
  • Page 14 To a wall-pipe Directly to a built-in drain pipe in the room wall and tighten it with the supplied cable tie L. You can extend the drain hose to maximum 400 cm. Contact the service centre for the other drain hose and the extension. 5.6 Building in This appliance has been designed to be built into the kitchen furniture.
  • Page 15 The appliance is also equipped with an adhesive sponge pad H that you can find inside the drum. Attach it on the top of the appliance where indicated in the drawing. When levelling the appliance under the furniture, DO NOT squeeze the sponge pad. Before proceeding with appliance building in, bring it near the recess and preposition the inlet hose, the drain hose and the mains cable.
  • Page 16 Reversibility of the cupboard door Carry out the cupboard door reversibility before the appliance is built in completely. If the cupboard door has to be opened from left to right, invert the position of the hinge supports M with the magnetic plate N and lower plate O. Make sure that the plate with magnet is on the upper position.
  • Page 17 Set the position of the lower hole respecting dimensions and distances shown in the drawing 16-22 mm (449 mm). Countersink the holes. Ø 35 mm 12,5 - 14 mm 22±1,5 mm 595-598 mm Hinges To mount the hinges it is necessary to drill two holes (dia.
  • Page 18 Counter-magnet The appliance is pre set for a magnetic closure. For a correct closure: 1. Position the screw C and the counter-magnet D on the magnetic plate N. Lean the cupboard door against the screw until it leaves a mark. 2.

  • Page 19: Control Panel

    6. CONTROL PANEL 6.1 Control panel description Time Manager touch button and permanent Child Lock option The permanent options are set by Prewash touch button and permanent holding pressed the relative button for at Extra Rinse option least 3 seconds. Spin touch button Programme dial Temperature touch button...

  • Page 20: Dial And Buttons

    Door locked indicator. The digital indicator can show: • Programme duration (e. g. , washing and/or drying phase). • Delay time (e. g. • Cycle end ( • Warning code (e.g. • Error indicator ( Time Manager indicator. Extra Rinse indicator. The spin area: Spin speed indicator No Spin indicator.

  • Page 21: Permanent Extra Rinse

    7.3 Mode Thanks to this button, a cycle can perform: The appliance empties the water out • Only washing: Wash Mode indicator is on automatically after 18 hours (default mode). approximately. • Washing and drying: Wash Mode and Dry Mode indicators are on. 7.6 Prewash •...

  • Page 22: Child Lock

    duration and a number of dashes will 7.10 Time Dry decrease accordingly: When the drying mode is activated, touch this button to set the time that suits the fabrics suitable for a full load of normally soiled you have to dry (refer to "Timed drying" garments.

  • Page 23: Programmes

    8. PROGRAMMES 8.1 Programme Chart Programme Reference Maxi‐ Programme description Default tempera‐ spin speed (Type of load and level of soiling) ture Spin speed load Temperature range range 1600 rpm 7.0 kg 1600 rpm - Eco 40-60 (Wash 400 rpm only mode) 40 °C White cotton and fast-coloured cotton.
  • Page 24 Programme Reference Maxi‐ Programme description Default tempera‐ spin speed (Type of load and level of soiling) ture Spin speed load Temperature range range Steam programme Steam programme can be used for reducing wrinkles and odours of garments that just need to be refreshed, avoiding washing.
  • Page 25 Programme Reference Maxi‐ Programme description Default tempera‐ spin speed (Type of load and level of soiling) ture Spin speed load Temperature range range 1600 rpm 5.0 kg Programme to treat mixed fabrics (cotton and synthetic (1600 - 400 items) up to 5 kg. Complete washing programme that washes MixLoad 69min rpm) the daily soiled laundry efficiently at 30 °C and ensures a...
  • Page 26 Programme Reference Maxi‐ Programme description Default tempera‐ spin speed (Type of load and level of soiling) ture Spin speed load Temperature range range Reset position. The display shows dashes only. According to Commission Regulation EU 2019/2023. This programme at default temperature and spin speed, in washing only mode, with rated capacity 7.0 kg is able to clean normally soiled cotton laundry declared to be washable at 40 °C or 60 °C, together in the same cycle.
  • Page 27 Programme ■ ■ Steam ■ ■ ■ Spin/Drain ■ ■ ■ ■ ■ Rinse ■ ■ ■ Machine Clean ■ ■ ■ ■ ■ MixLoad ■ ■ ■ ■ ■ ■ Sportswear ■ ■ ■ ■ ■ Outdoor ■ ■ ■...

  • Page 28: Automatic Drying

    ▲ ▲ Delicates ▲ ▲ ▲ Hygiene ▲ ▲ MixLoad ▲ ▲ ▲ Sportswear ▲ ▲ Outdoor ▲ ▲ Wool ▲ ▲ Quick 20’ Wash&Dry 60’ At temperature higher than 60 °C the use of powder detergent is recommended. ▲ = Recommended Woolmark Company for the washing of wool garments labelled as “hand wash”...

  • Page 29: Timed Drying

    Dryness Level Type of fabric Load Cottons and Linen up to 4.0 kg (bathrobes, bath towels, etc) Extra Dry For towelling materials Denim garments up to 3.0 kg Cottons and Linen up to 4.0 kg (bathrobes, bath towels, etc) Cupboard Dry For items to be stored Synthetics and mixed fabrics up to 3.0 kg...

  • Page 30: Settings

    Dryness Level Type of fabric Load Spin Suggested du‐ (kg) speed ration (mins) (rpm) Synthetics and mixed fabrics 1200 135 - 150 (jumpers, blouses, underwear, household and bed linen) 1200 45 - 55 Delicates 1200 155 - 165 (acrylics, viscose and delicate mixed fabrics) 1200 95 - 105 Wool...

  • Page 31: Before First Use

    10. BEFORE FIRST USE 1. Make sure that the electrical power is 4. Set and start a programme for cotton at available and the water tap is open. the highest temperature without any 2. Pour 2 litres of water into the detergent laundry in the drum.

  • Page 32: Setting A Programme

    With the flap in the position DOWN: • Do not use gelatinous or thick liquid - Flap for powder or liquid detergent. detergents. • Do not exceed to liquid detergent dose indicated on the flap. • Do not set the prewash phase. Always follow the instructions that you •...

  • Page 33: Starting A Programme With The Delay Start

    11.6 Starting a programme 2. Touch the Delay Start button repeatedly until the display shows the desired delay Touch the Start / Pause button to start time. the programme. It is not possible to start the 3. Touch the Start / Pause button again programme when the indicator of the button to start the new countdown.

  • Page 34: Interrupting A Programme And Changing The Options

    11.11 Opening the door - Adding garments The SensiCare detection is carried out If the icon is on, you can always open the with complete washing programmes only door. and if the programme duration has not been reduced by means of the Time Manager button.

  • Page 35: Draining Water Out After End Of Cycle

    11.13 Draining water out after end 4. Press the On/Off button for a few of cycle seconds to deactivate the appliance. If you have chosen a programme or an option 11.14 Stand-by function that does not empty out the water of the last The Stand-by function automatically rinse, the programme is completed, but: deactivates the appliance to reduce the...

  • Page 36: Washing And Timed Drying

    12.3 Washing and Timed Drying 4. Turn the programme dial to the washing programme. The appliance defaults to the 1. Tap on the Time Dry button repeatedly to washing only mode and the indicator of set the desired time value (see the the Wash Mode button is on.

  • Page 37: Preparation To Drying

    13.1 Preparation to drying "Timed drying" table in the "Programmes" chapter). The drying level indicator 1. Press the On/Off button for some seconds to activate the appliance. goes off and the indicator comes on. 2. Load the laundry one item at a time. Each time you tap on this button the time 3.

  • Page 38: Hints And Tips

    This inconvenient increases with technical • Empty the drum. fabrics. • Clean the drum, the gasket and the door with a wet cloth. To prevent the fluff in your laundry, we • Set the Machine Clean programme and recommend that you: the Dry Mode together to activate the anti- •...

  • Page 39: Stubborn Stains

    15.2 Stubborn stains • Do not mix different types of detergents. • Use less detergent if: For some stains, water and detergent is not – you are washing a small load, sufficient. – the laundry is lightly soiled, We recommend that you pre-treat these –...

  • Page 40: Drying Cycle Duration

    In areas where the water is soft it is not • = The drying cycle is at high necessary to use a water softener. temperature To find out the water hardness in your area, • = The drying cycle is at reduced contact your local water authority.

  • Page 41: Removing Foreign Objects

    16.4 Descaling Indicative periodic cleaning schedule: Descaling Twice a year Maintenance wash Once a month If the water in your area is hard or Clean door seal Every two months medium hard, we recommend that you use a water softener for washing Clean drum Every two months machines.

  • Page 42: Cleaning The Detergent Dispenser

    16.8 Cleaning the detergent dispenser To prevent possible deposits of dried detergent or clotted fabric softener and/or formation of mould in the detergent dispenser drawer, every two months carry out the following cleaning procedure how explained in the following diagrams: 1.

  • Page 43: Cleaning The Drain Pump Filter

    16.9 Cleaning the drain pump filter WARNING! Disconnect the mains plug from the mains socket. Regularly check the drain pump filter and make sure that it is clean. Clean the drain pump if: • The appliance does not drain the water. 4.
  • Page 44 2. Place a suitable bowl below the drain pump access to collect the water that flows out. Always keep a rag nearby to dry up any water spillages when removing the filter. 180˚ 3. Turn the filter 180 degrees in anti-clockwise direction to open it, without removing.
  • Page 45 7. If it is necessary, remove fluff and objects from the filter recess. Make sure that the impeller of the pump can rotate. If it does not rotate, contact the Authorised Service Centre. 8. Clean the filter under the water tap. 9.

  • Page 46: Cleaning The Inlet Hose And The Valve Filter

    When you drain the water with the emergency drain procedure, you must activate the drain system again: 1. Put 2 litres of water in the main wash compartment of the detergent dispenser. 2. Start the programme to drain the water. 16.10 Cleaning the inlet hose and remove any deposit, collected over the time.

  • Page 47: Troubleshooting

    WARNING! Make sure that the temperature is higher than 0 °C before you use the appliance again. The manufacturer is not responsible for damages caused by low temperatures. 17. TROUBLESHOOTING WARNING! Refer to Safety chapters. 17.1 Alarm Codes and Possible failures The appliance does not start or it stops during operation.
  • Page 48 • Make sure that the water tap is open. • Make sure that the pressure of the water supply is not too low. For this infor‐ The appliance does not fill mation, contact your local water authority. with water properly. •...
  • Page 49 Problem Possible solution • Set the spin programme. • Make sure that the drain filter is not clogged. Clean the filter, if necessary. Re‐ The spin phase does not op‐ erate or the washing cycle fer to "Care and cleaning". lasts longer than usual.

  • Page 50: Emergency Door Opening

    Problem Possible solution The fabrics washed in the previous cycle released fluff of a different colour: • The drying phase helps to eliminate some fluff. The laundry is full of different • Clean the clothes with a fluff remover. colours fluff. In case of an excessive amount of fluff in the drum refer to “Fluff in the fabrics"...

  • Page 51: Consumption Values

    18. CONSUMPTION VALUES 18.1 Introduction See the web link www.theenergylabel.eu for detailed information about Energy Label. The QR code on the energy label supplied with the appliance provides a web link to the information related to the performance of the appliance in the EU EPREL database. Keep the energy label for reference together with the user manual and all other documents provided with this appliance.
  • Page 52 Eco 40-60 pro‐ rpm 1) Litres hh:mm °C gramme Half load 0.440 43.0 02:30 52.00 32.0 1551 Quarter load 0.300 33.0 02:20 54.00 31.0 1551 Maximum spin speed. Wash and dry cycle Eco 40-60 pro‐ rpm 1) gramme and Cup‐ Litres hh:mm °C...

  • Page 53: Environmental Concerns

    Programme rpm 1) Litres hh:mm °C Wool 0.200 55.0 01:05 30.00 30.0 1200 30°C Reference indicator of the spin speed. Suitable for washing heavily soiled textiles. Suitable for washing lightly soiled cottons, synthetic and mixed fabrics. It also performs as quick washing cycle for lightly soiled laundry. 18.5 Common programmes - Wash and dry These values are indicative only.
