  • Page 1 Gas Free-Standing Range User manual NX60*61**S*...

  • Page 2: Anti-Tip Device

    c) If you move the range and then move it back into place, ensure WARNING: If the information in this manual is not followed exactly, the Anti-Tip device is re-engaged at the right or left rear of the a fire or explosion may result causing property damage, personal range bottom.

  • Page 3: Regulatory Notice

    Regulatory Notice 1. FCC Notice FCC STATEMENT: This equipment has been tested and found to comply within the CAUTION limits for a Class B digital device, pursuant to Part 15 of the FCC FCC CAUTION: Any changes or modifications not expressly approved Rules.
  • Page 4 Regulatory Notice FCC RADIATION EXPOSURE STATEMENT: IC RADIATION EXPOSURE STATEMENT: This equipment complies with FCC radiation exposure limits set This equipment complies with IC RSS-102 radiation exposure limits forth for an uncontrolled environment. This equipment should be set forth for an uncontrolled environment. This equipment should be installed and operated so there is at least 8 inches (20 cm) between installed and operated so there is at least 8 inches (20 cm) between the radiator and your body.

  • Page 5: Key Features

    General safety instructions Bigger is better With a capacity of 6.0 cubic feet, this Samsung gas oven range offers more space This unit has been tested and found to comply with the limits for than many other leading brands in the United States and Canadian markets. The a class B digital device, pursuant to Part 18 of the FCC rules.

  • Page 6: Table Of Contents

    Contents Maintenance Important safety information Cleaning Overview Replacing the oven light Removing and reinstalling the oven door Layout What’s included Troubleshooting Control panel Checkpoints Before you start Information codes Clock Warranty (U.S.A) Oven vent/cooling vent Warranty (CANADA) Cooktop Open Source Announcement Ignition Cookware Griddle...

  • Page 7: Important Safety Information

    Important safety information Read all instructions before using this appliance California Proposition 65 Warning • All electrical and gas equipment with moving parts can be dangerous. Please WARNING read the important safety instructions for this appliance in this manual. The instructions must be followed to minimize the risk of injury, death, or property Cancer and Reproductive Harm - www.P65Warnings.ca.gov damage.

  • Page 8: Fire Safety

    Important safety information • Do not store any object of interest to children on the cooktop or backguard of the Fire safety range. Children climbing on the range to reach items could be killed or seriously injured. WARNING • Do not operate the range if the range or any part of the range is damaged, To reduce the risk of fire, electric shock, personal injuries, and/or death, observe malfunctioning, or missing parts.

  • Page 9: Gas Safety

    Gas safety Electrical and grounding safety WARNING WARNING To reduce the risk of fire, electric shock, personal injuries, and/or death, observe To reduce the risk of fire, electric shock, personal injuries, and/or death, observe the following precautions. the following precautions. •...

  • Page 10: Installation Safety

    Important safety information Installation safety • Installation of this range must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA.54, latest edition. In Canada, installation must conform with the current Natural Gas Installation Code, WARNING CAN/CGA-B149.1, or the current Propane Installation Code, CAN/CGA-B149.2, and To reduce the risk of fire, electric shock, personal injuries, and/or death, observe...

  • Page 11: Cooktop Safety

    • Make sure the wall coverings around the range can withstand heat up to 200 °F • This cooktop is designed for use with a wok or wok ring attachment. (93 °C) generated by the range. • To flame food, you must have a ventilation hood. When you flame food, the hood •...

  • Page 12: Oven Safety

    Important safety information • To prevent delayed eruptive boiling, always allow heated liquids to stand at least Oven safety 20 seconds after you have turned off the burner so that the temperature in the liquid can stabilize. In the event of scalding, follow these first aid instructions: WARNING 1.

  • Page 13: Storage Drawer Safety

    Storage drawer safety Self-cleaning oven safety WARNING WARNING To reduce the risk of fire, electric shock, personal injuries, and/or death, observe To reduce the risk of fire, electric shock, personal injuries, and/or death, observe the following precautions: the following precautions. •...

  • Page 14: Overview

    (2) * and caps (5) * griddle (1) * NOTE If you need an accessory marked with an asterisk (*), you can buy it from the Samsung Contact Center (1-800-SAMSUNG (726-7864)). 01 Display 02 Oven vents 03 Surface burners 04 Surface burner...

  • Page 15: Control Panel

    Before you start Control panel You should know about the following features and components before you use your range for the first time. Clock You must set the clock correctly to ensure the automatic features work properly. To set the clock time 01 Oven modes: Activates each oven 08 Oven Light: Turn on/Turn off the mode (Bake or Broil).

  • Page 16: Cooktop

    Cooktop STEP 1 Gas burners Put all ingredients into a cooking container Each burner has a corresponding knob (pan, pot, etc.). that lets you to set the flame level from LO to HI. In addition, each burner knob has a Lite setting.

  • Page 17: Ignition

    Ignition Flame level The flames on the burners should always stay under the cookware, and should not CAUTION extend beyond the cookware bottom at any time. Make sure all surface burners are properly WARNING installed. To light a burner: • Flames larger than the cookware bottom may result in a fire or physical injury. 1.

  • Page 18: Cookware

    Cooktop Cookware Size limitations CAUTION Requirements • Do not place a small pan or pot with a bottom diameter of about 6 inches or less. • Flat bottom and straight sides. • Do not use an oversized pan. The burner flames may spread out, causing damage •...

  • Page 19: Griddle

    Griddle CAUTION • Do not remove the griddle until the cooktop grates, surfaces, and griddle itself The removable coated griddle provides an extra cooking surface. This is useful cool down. especially when cooking meat, pancakes, or other foods requiring a large cooking •...

  • Page 20: Gas Oven

    Gas oven STEP 1 Using the oven racks Put all ingredients in a heat-safe container. The rack positions Your oven range comes with 2 racks and 7 rack positions. The rack positions are delineated by rack guides which support the racks. Each rack guide has a stop STEP 2 that prevents the rack from loosening during the oven's operation.
  • Page 21 Rack and Pan placement NOTE • The Oven Rack Settings table is for reference only. Centering the baking pans in the oven • We recommend cooking pizza and pies using the 2nd rack position for crispy as much as possible will produce better bottoms.

  • Page 22: Cooking Mode

    Gas oven Cooking mode Baking • Make sure to close the door before you start cooking. • If you leave the door open for 20-30 seconds while the oven is in baking, or broiling modes, the oven burner shuts off. To restart the burner, close the door.
  • Page 23 Broiling Broiling guide Broiling uses the oven broil burner at the top of the oven to cook and brown NOTE food. Meat or fish must be put on a broiling grid in a broiling pan. Preheating for • This is for reference only. 5 minutes before broiling is recommended.

  • Page 24: Cooking Options

    Gas oven Cooking options Cook Time Timed cooking sets the oven to cook foods at a set temperature for a set length of CAUTION time. The oven automatically turns off when it finishes. Food that can easily spoil, such as milk, eggs, fish, poultry, and meat, should be Mode: Bake chilled in a refrigerator before they are placed in the oven.

  • Page 25: Special Features

    Delay Start Special features The Delay Start function lets you use the kitchen timer to automatically start and stop another cooking program. You can set Delay Start so that it delays the Keep Warm automatic start of a cooking operation you select by up to 12 hours. Keep cooked food warm at a low temperature for up to 3 hours.
  • Page 26 Gas oven Bread Proof The Sabbath Option The Bread Proof function automatically provides the optimum temperature for the (For use on the Jewish Sabbath and Holidays) bread proof process, and therefore does not have a temperature adjustment. Use this option only for baking on the Jewish Sabbath and Holidays. If you press Bread Proof when the oven temperature is above 100 ˚F, Hot will For more information, visit the website at http://www.star-k.org appear in the display.
  • Page 27 To enable the Sabbath option • After a power failure, the oven will not resume operation automatically. "SAb" will appear in the control panel, but the oven will not turn back on. Food can be safely removed from the oven, but you should not turn off the Sabbath option and turn the oven back on until after the Sabbath/Holidays.

  • Page 28: Changing The Settings

    Gas oven Temperature adjust Changing the settings The oven temperature has been calibrated at the factory. When first using the oven, follow the recommended recipe times and temperatures. If it appears that Demo mode the oven is too hot or too cool, you can recalibrate the oven temperature. Before This is used by retailers for display purposes only.
  • Page 29 Temperature Unit (°F / °C) Sound Change the temperature unit of the oven to Fahrenheit or Celsius. The default is Mute/unmute the range. Fahrenheit. 1. Press and hold for 3 seconds. 1. Press and hold for 3 seconds. 2. Press to set the number to 4.

  • Page 30: Smart Control

    Gas oven Smart Control To control the oven remotely 1. Press Smart Control appears in the display. The oven can now be controlled How to connect the oven remotely with a connected device. 2. Select the oven icon on the SmartThings app to open the Oven Control app. 1.

  • Page 31: Voice Control

    Here’s how to link SmartThings account into Amazon Alexa or Google Assistant. Bixby SmartThings App and Alexa App(or Google Assistant App) Should be installed on Start conversation with Bixby on SAMSUNG mobile by saying “Hi Bixby” or by your phone. pressing the side key.

  • Page 32: Maintenance

    Gas oven Maintenance Cleaning Function “Alexa” “Ok Google” Temp Control • Set oven[Device name] to 300 • Set oven[Device name] to 300 CAUTION degrees [Temp]. degrees [Temp]. Wear the glove during cleaning. Oven Timer • Set oven[Device name] to 3 •...
  • Page 33 Do not remove the inner gasket of the oven door for cleaning. • To purchase the graphite lubricant, contact us at 1-800-SAMSUNG (726-7864). • Use soap and water to thoroughly clean • For online shopping, visit http://www.samsungparts.com/Default.aspx and search Don’t hand...
  • Page 34 Maintenance Door outer side Cooktop surface • Outer surface: Follow the cleaning instructions for the stainless steel surface in The porcelain-enameled cooktop surface needs to be kept clean. We recommend the previous section. that you remove food spills immediately after they take place. •...
  • Page 35 Burner grates and components NOTE • After cleaning, confirm that the burner port openings aren't plugged. Turn off all surface burners and make sure they have all cooled down. • Shake out any excess water and then let burner heads and caps dry thoroughly. 1.
  • Page 36 Maintenance Oval burner CAUTION Burner Head 1. Orient the burner head so that the Make sure all burner components (heads opening for the electrode lines up with and caps) are reinstalled properly. They the electrode. will be stable and rest flat when correctly installed.

  • Page 37: Replacing The Oven Light

    Replacing the oven light Removing and reinstalling the oven door Oven light How to remove the door The oven light is a standard 40-watt appliance bulb. It comes on when you open CAUTION the oven door. • The door is very heavy. Be careful when removing and lifting the door. Do not 1.
  • Page 38 Maintenance How to reinstall the door How to remove and reinstall the Storage drawer 1. Firmly grasp both sides of the door at the top. 1. Slide open the drawer until it stops. 2. With the door at the same angle as the removal position, slide the indentations 2.

  • Page 39: Troubleshooting

    Troubleshooting Surface burner If you encounter a problem with the range, check the tables starting below, and then try the suggested actions. Problem Cause Action Checkpoints All burners do not The power cord is Make sure the electrical plug light. not plugged into the is plugged into a live, properly Gas safety...
  • Page 40 Troubleshooting Problem Cause Action Problem Cause Action Very large or The wrong burner orifice Check the burner orifice size. The oven will not The oven is not Make sure the electrical plug yellow surface is installed. Contact your installer if you turn on.
  • Page 41 Problem Cause Action Problem Cause Action The oven light The oven door lock is The display will show the Cooking is The fan automatically This is not a product (lamp) will not turn turned on. Lock icon. Hold the oven door finished, but the runs for a certain amount malfunction.
  • Page 42 Troubleshooting Problem Cause Action Problem Cause Action Excessive smoking This is the first time the This is normal. The oven will There is steam This is normal. The oven vent is located there. during a self- oven has been cleaned. always smoke more the first or smoke coming More steam is visible when...
  • Page 43 Others Problem Cause Action Food does not The wrong cooking mode See page 22. Problem Cause Action bake or roast was selected. The product is not The appliance has been Make sure the floor is level, properly in the The oven racks have not See page 20.

  • Page 44: Information Codes

    SAMSUNG authorized service center. The original dated blocked by aluminum foil bill of sale must be presented upon request as proof of purchase to SAMSUNG or or others, remove that and SAMSUNG’s authorized service center to receive warranty service.
  • Page 45 All replaced parts and products are the property of SAMSUNG and you to you. This warranty gives you specific rights, and you may also have other rights, must return them to SAMSUNG.

  • Page 46: Warranty (Canada)

    Warranty service can only be performed by a SAMSUNG-authorized service center, and any unauthorized service will void this warranty. The original dated bill of sale must be presented upon request as proof of purchase to SAMSUNG or SAMSUNG’s authorized service center. Samsung will provide in-home service during the one (1) year warranty period at no charge subject to availability within the contiguousCanada.
  • Page 47 SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES CAUSED BY THE USE, MISUSE, OR INABILITY TO USE THIS PRODUCT, REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

  • Page 48: Open Source Announcement

    The following URL http://opensource.samsung.com/opensource/SMART_TP2_0/ For questions about features, operation/performance, parts, accessories, or service, call seq/0 leads to open source license information as related to this product. 1-800-SAMSUNG (726-7864), or visit our Web site at www.samsung.com/ca/support (English), or www.samsung.com/ca_fr/support (French). Model # Serial # Please attach your receipt (or a copy) to this manual.
  • Page 49 Memo...
  • Page 50 How-to Videos and Live Shows * Requires reader to be installed on your smartphone Please be advised that the Samsung warranty does NOT cover service calls to explain product operation, correct improper installation, or perform normal cleaning or maintenance. QUESTIONS OR COMMENTS?
