Anker A83B6 Manual

A83B6_V1_EN_UM_Web_20240619
At a Glance
No. Item
USB-C Upstream Port
AC Power Plug
Power Indicator
Ethernet Port
HDMI 2.0 Port x2
USB-A Data Transfer Port x3
Power Button
LCD Display
USB-C Charging Port x2
USB-A Charging Port
USB-C 3.1 Gen 2 Port x2
USB 3.1 Gen 2 Port
Audio Jack
· All USB ports do not support screen mirroring.
· When using multiple USB charging ports simultaneously, the maximum total USB output power is 160W.
· Place the charging docking station vertically on a flat surface.
Video Output Mode
A/B/C only means the different content displayed on the screen.
System
Windows OS
https://salesforce-knowledge.s3.us-west-2.amazonaws.com/A83B6_V1_EN_UM_Web_20240619/A83B6_V1_EN_UM_Web_20240619.html
Description
· Connect to your laptop using the included USB-C cable.
· Provides charging for your laptop at up to 100W PD.
· Output: 5V 3A / 9V 3A / 15V 3A / 20V 5A (100W Max)
Connect to a power outlet.
Power plug varies by country or region.
Turns white when the docking station is powered on.
Connect to a router or modem at 1 Gbps.
Connect two HDMI-enabled monitors for dual 4K HDMI display output.
· Supports up to 4K@60Hz output to a single display.
· Supports up to 4K@30Hz output to dual displays.
Actual display output performance will vary based on the host device
specifications.
480Mbps data transfer.
· Press to power on or activate the LCD display.
· Press and hold for 4 seconds to power off.
· When powered on, press to toggle between two homepages (total USB
output page and individual front-ports status page); press and hold for 2
seconds to turn off the LCD display.
Displays charging output power, data transfer status, firmware upgrade
status, and warnings.
· Charge your phone or tablet at up to 100W with Power Delivery 3.0.
· Output: 5V 3A / 9V 3A / 15V 3A / 20V 5A (100W Max)
· Charge your phone, watch, or earphones at up to 12W.
· Output: 5V 2.4A (12W Max)
10 Gbps data transfer.
10 Gbps data transfer.
Connect to earphones or other devices with a 3.5 mm AUX connector.
Laptop Screen
A
HDMI 1
B
HDMI 2
C
