- Page 1 User’s Guide AGK600 Mechanical Gaming Keyboard Ver.:1.00 Caution: Read the user's guide for proper installation instructions.
-
Page 2: Table Of Contents
Contents 1 Package Contents and System Requirements ............. 3 2 Technical Specifications ....................3 3 Device Layout ......................4 4 Windows Installation ....................6 5 Open Methods ......................9 6 Software Update ......................9 7 Home ......................... 10 8 Device setting ......................11 8.1 Keyboard Settings .................. -
Page 3: Package Contents And System Requirements
Free online technical support at www.aoc.com 2 Technical Specifications Cherry mechanical switches with up to 50 million clicks lifespan ◼ Customizable RGB lighting effect syncing with other AOC gaming devices ◼ All key programmable ◼ Up to 1000Hz/ms report rate ◼... -
Page 4: Device Layout
Length: 294 mm/ 11.57 in ◼ Width: 104 mm/ 4.09 in ◼ Height: 40 mm/ 1.57 in ◼ Weight: 680 g/1.5 lbs ◼ Cable Length: 1.8 m/ 5.9 ft ◼ Operating Environment Operating Temperature: 0 ° C (32 ° F) to 40 ° C (104 ° F) ◼... -
Page 5: Media Control
FN + = End FN + =Pause Break FN + = Insert FN + = Page Up FN + = Page Down FN + = Home FN + = Arrow Up FN + = Arrow Down FN + =Arrow Left FN + =Arrow Right →Media control... -
Page 6: Windows Installation
3 seconds, after keyboard LED flashed, the device will back to factory default settings. 4 Windows Installation 1. Download the AOC G-Menu executable, and double click the EXE file to start the installation. 2. Accept the license agreement by selecting the I Agree radio button, and clicking the Next button. - Page 7 Selecting the Browse button will open a Browse for Folder dialog box. 4. Confirm Installation by pressing the Next button.
- Page 8 5. Complete the installation by pressing the Close button. Congratulations on installing G-menu! To uninstall G-Menu: For Windows 10: Go to Windows Settings > Apps > Apps and Features > select G- Menu and press the Uninstall button. For Windows 7/8/8.1: Go to Control Panel > Programs > Programs and Features > select G-Menu and press the Uninstall button.
-
Page 9: Open Methods
5 Open Methods There are 3 ways to access the G-Menu application. ① Start Menu>G-Menu ② Taskbar>Right click on the taskbar icon ③ Shortcut on Desktop 6 Software Update ⚫ When you enter the G-Menu home page, the software will automatically check for updates, if there is a new version, it will be downloaded in the background. -
Page 10: Home
7 Home ⚫ Open AOC G-Menu application and enter the home page. 1） Application name: Displayed on the top left, not clickable. 2） Brand logo, Software version: Displayed at the bottom right, not clickable. 3） Minimize/Restore: Displayed at the top right. Click to switch the interface to zoom in/restore the display. -
Page 11: Device Setting
7） Close: Click the Close button to close the application interface, the actual application is still running in the background. 8 Device setting 1. Top Navigation ⚫ G-Menu navigation options: Home, Monitor, Mouse, Keyboard, Mouse mat, Headset, and Macro. ⚫ The names of unconnected devices are greyed out. - Page 12 5. More Profile Management ⚫ Click the Meatball menu to expand the profile selection item: Add, Import, Export, Rename, and Associate. A) Add ⚫ Enter the name of the new profile. ⚫ Click the File button to open the local executable file or enter the execution path in the input box directly.
- Page 13 ⚫ Click the Save button to save the exported profile. D) Rename ⚫ Change the name of the current profile. It cannot be a duplicate of an existing profile name. ⚫ Click the Save button to save the new name. ⚫...
- Page 14 ⚫ Click the Save button to add the application to the profile. ⚫ Click the Cancel button to close the pop-up box. 7. On board memory Click the icon to open the On-Board Memory pop-up interface 1. The left side of the interface is the current device onboard, the right side is list of all local profile files.
-
Page 15: Keyboard Settings
8.1 Keyboard Settings 8.1.1 Customize 1. Buttons on keyboard ⚫ Defined: Hover the mouse over a key to see what function has been defined to that key. Default, the marked value. ⚫ Undefined: Hover the mouse over a key to highlight it. Select the key to change the function of that key. - Page 16 ⚫ Click the Apply button to save this setting. 6. Reset ⚫ Click the Reset button to restore the default factory settings. 8.1.1.1 Macro select 1. Click the drop-down box to select an existing macro. 2. Add ⚫ Click the Add button to display the macro editing interface. 3.
- Page 17 ⚫ Repeat Times: Enter the number of times to repeat the macro action, default 1. ⚫ Repeat Until You Press Any Macro Key to End: Repeat the macro action until you press any macro key to end replay of the macro. ⚫...
-
Page 18: Sensitivity
⚫ Single-key input box: Press the key on the keyboard to set the Smart Key. The last key pressed will be entered. Default, empty. ⚫ Reset ◼ Click the Reset button to restore the default factory settings. ◼ OKClick the OK button to save the settings, when the input box and check box are empty, the button is grayed out and cannot be clicked. -
Page 19: Light Fx
⚫ Click the OK button to save the settings. 7. Cancel ⚫ Click the Cancel button to cancel this setting and return to the last saved state. 8.1.3 Light FX 1. Light FX ⚫ Click the Light FX drop-down menu to select a light effect. ⚫... -
Page 20: Light Fx Sync
⚫ Lighting effect stop time, calculated from lighting effect activation time. ⚫ Fixed options: 0/15minutes/30minutes/1hour/2hours/4hours/6hours/12hours. 7. Cancel ⚫ Click the Cancel button to cancel this setting and return to the last saved state. 8. Apply ⚫ Click the Apply button to save this setting. 10. -
Page 21: Macro
5. Brightness ⚫ Select the brightness the color will glow or turn off. 6. Device ⚫ Not clickable, the currently connected devices are highlighted. 7. Cancel ⚫ Click the Cancel button to cancel this setting and return to the last saved state. 8. - Page 22 ⚫ Select the delay time for running the macro. ⚫ Recording: Follow the delays between actions exactly as recorded. Default. ⚫ Fixed: The trigger time between each action is fixed. Default, 20ms. ⚫ Ignore: Do each action in order, without delay. 3）...
- Page 23 4. Import ⚫ Click the Import button to open a File Explorer dialog box. ◼ Find the macro file to import. ◼ Click the Open button to import the macro file. ◼ Click the Cancel button to cancel the import, and close the dialog box. 5.Export ⚫...
-
Page 24: Discover
◼ Click the Save button to export the macro file. ◼ Click the Cancel button to cancel the export, and close the dialog box. 8.3 Discover Discover and share profiles with others on the G-Menu network. 1. Back ⚫ Click the < (Back) button to return to the main menu. 2. - Page 25 3. Search Bar ⚫ Click in the Search bar to find profiles containing the search term in the publisher, title or description. 4. Upload ⚫ Click on the Upload button to open the upload interface. ⚫ If not logged in, the login interface opens. 5.
- Page 26 ◼ Upload Date: When the profile was uploaded, in year-month-day (yyyy-mm-dd) format. ◼ Downloads: Shows how often the profile was downloaded. ◼ Download Icon: Click on the Download button to download the profile. ◼ Once the profile has been downloaded, the profile will be available for configuration. Click the Configure button to enter the configuration dialog box.
-
Page 27: Download Profile
8.3.1 Download profile 1. Click the Download button to start downloading the selected profile. ⚫ This display will change to 'Downloading...'. 2. After the download is complete. ⚫ Click the Apply button to begin configuration. ⚫ Click the Dismiss button to configure later. -
Page 28: Configure Profile
3. Abnormal situation ⚫ If the download is interrupted, the software will attempt to continue or you may re-download later. 8.3.2 Configure Profile 1. When the profile download is complete, click the Apply button. ⚫ Enter the Profile Configuration. ⚫ If there is currently no compatible device available an error will appear. -
Page 29: Upload
⚫ Enter a name for the configuration. 2) Devices ⚫ Select your specific device models. 3) Profile ⚫ The current profile is displayed by default, and the selection cannot be switched. 4) Close ⚫ Click the Close button to cancel the configuration. 5) Next ⚫... -
Page 30: Search
⚫ With the checkboxes, select the connected devices and device models for this profile. 5. Select a profile ⚫ Select an existing profile to use with each device. 6. Share with Other Users ⚫ Enabled: Shares this profile with the public. ⚫... - Page 31 1. Email ⚫ Enter your Email address. 2. Password ⚫ Enter your password. 3. Login ⚫ Click the Login button to log into your account. 4. Forgot Password ⚫ Click the Forgot Password button to reset your password. For more information, see below. 5.
- Page 32 2. Email ⚫ Enter your email address. 3. Password and Confirm Password ⚫ Enter and confirm a password. From 6-18 characters (letters, digits or special characters ). 4. Click the Next button to receive a verification code email. The code will expire in 15 minutes. 5.
- Page 33 ◼ If the verification code is wrong, the error "The verification code is wrong" will appear. ◼ If the verification code is expired, the error "Verification code has expired" will appear. 8.3.5.2 Forgot Password 1. To reset your password: Enter the email address associated with your account. A recovery link will be sent.
- Page 34 ⚫ Alternatively, copy and paste the link into your browser to open it there. ⚫ Link valid time: 2 hours. 2） Password reset interface ⚫ Enter and confirm a password containing between 6 to 18 characters (numbers or letters). ⚫ Click the Reset Password button: ◼...
-
Page 35: My Account
3） Error message: The reset password link has expired ⚫ The link sent in the email was not clicked on within the 2-hour reset period. 8.3.6 My Account Prerequisite: You must be logged in to access your account information. Click on the My Account button to display the account information. 1) Account options:... - Page 36 ⚫ Click the My Uploads button to enter the My Uploads interface. ⚫ Click the My Downloads button to enter the My Downloads interface. ⚫ Click the Account Setting button to enter the Account Settings interface. ⚫ the Log out button to log the account out of the device. Click 8.3.6.1 My uploads 1.
- Page 37 8.3.6.2 My downloads 1. Display the profile information and download time of profiles that have been downloaded and saved locally. 2. Click the Configuration button to enter the configuration interface. 3. Click the Delete button to delete the profile file locally and return to the Profile list.
- Page 38 8.3.6.3 Account settings 1. The Email address cannot be changed, to change the email address create a new account. 2. Profile picture ⚫ Click to open a File Explorer dialog box to change the picture. 3. Edit Name 4. Edit password ⚫...
-
Page 39: Setting
8.4 Setting Change the setting for G-Menu. Switch Language ⚫ Displays all currently supported languages, among which the currently used language is highlighted. ⚫ Click the appropriate language button to switch languages immediately. Back ⚫ Click the < (Back) button to return to the previous interface. 8.5 Tray Exit ◼... -
Page 40: Safety Guide And Maintenance
4. Warranty void, if disassembled. Do not attempt to repair the device. 5. Troubleshoot by unplugging the device and plugging it back in. If this does not resolve the issue, unplug the device and visit www.aoc.com for support. Maintenance... - Page 41 Monthly maintenance: Unplug the device and wipe with a soft cloth or cotton swab. Moisten the cloth with warm water for stubborn dirt. Do not use soap or harsh detergents.
