- Page 1 NK180 PRO ELECTRIC KAYAK MOTOR OWNER’S MANUAL ELECTRIC KAYAK MOTOR OWNER’S MANUAL...
- Page 3 Newport’s pioneering technology redefines electric power to reduce the hassle, cost and harmful impact on our environment associated with traditional gas-fueled motors. At Newport, the way forward is electric. Visit newportvessels.com. (866) 721-0002 support@newportvessels.com newportvessels.com...
-
Page 4: Table Of Contents
CONTENTS General Information 1.1 Product Identification 1.2 Included in your Box Technical Data Safety Information Critical Safety Information Before Use During Use After Use Installation 4.1.1 Installation Using Existing Threaded Inserts 4.1.2 Installation With Drilling Holes Using a Template 4.1.3 Installation With an Adapting Plate Setting Up Your Steering 4.2.1... - Page 5 5.2.1 Estimated Percent of Remaining Battery Power 5.2.2 Switching Between Battery Types Error Status Display Error Codes and Solutions Operation Start the Motor Travel Forward/Reverse Steering the Motor Emergency Stop Stopping the Motor Titling the Motor Finishing the Trip Stow and Park the Motor Remove the Motor From the Kayak Care and Services Care of Motor Components...
-
Page 6: General Information
GENERAL INFORMATION Thank you for purchasing the NK180 PRO Electric Kayak Motor. We hope that you enjoy it! The NK180 PRO Kayak Motor is designed with direct-drive and field- oriented-control technology to deliver the ultimate efficiency in a compact package. The propulsive power of the NK180 PRO is roughly equivalent to a 1.8hp petrol outboard motor, but with silent and emission free power delivery. -
Page 7: Included In Your Box
INCLUDED IN YOUR BOX Here is what should be included in your NK180 PRO. Please contact us directly if something is missing from this list of contents. Items Figure Motor Unit Electric Outboard Motor Controller Rated Power - 600W Rated Input Voltage - 24V S/N - XXXXXXXXXXX Serial No. -
Page 8: Technical Data
TECHNICAL DATA Rated Input Power(static) 600W Comparable Petrol Outboard 1.8HP Deep Cycle Marine Battery Battery Type LFP Lithium Battery Lithium Cobalt Oxide Battery 24V-Deep Cycle Marine Battery Battery Input Voltage 24V-LFP Lithium Battery 24V-Lithium Cobalt Oxide Battery Rated Rotation Speed 1600 rpm Total Weight 14 lbs (10kg) - Page 9 • If the battery becomes submerged in water deeper than one meter for a short period of time, do not attempt to recover the battery, and refer to the safety instructions provided by the battery manufacturer. • If the battery has been submerged in shallow water, less than a meter, for more than 30 minutes, do not attempt to recover the battery, and refer to the safety instructions provided by the battery manufacturer.
-
Page 10: Before Use
BEFORE USE • This motor should only be operated by an adult who has thorough understanding and command of the motor, including steering functions, emergency stop switch, and throttle. • Always operate your boat and this motor in compliance with local safety regulations. -
Page 11: Installation Using Existing Threaded Inserts
If your kayak requires installation hardware other than what is included in this kit, please find it at your local hardware store. Newport does not carry every possible hardware combination necessary to fit all brands and models of kayaks; however any additional mounting hardware needed for your individual craft should be standard, easy to find, and low-cost. -
Page 12: Installation With An Adapting Plate
4.1.3 INSTALLATION WITH AN ADAPTING PLATE Place the bracket above M8 screw the adapting plate and align the holes on the adapting plate with the M8 washer holes on the bracket. Place four M8 screws and four washers over the holes, four washers and four nuts beneath the holes, and tighten M8 nut... -
Page 13: Setup With Control Cords At The Top
See Our Product Quick Start Videos for more information 4.2.1 SETUP WITH CONTROL CORDS AT THE TOP If you have a kayak setup with control cords running on the top of the kayak, follow the steps below to finish the motor control cords setup: Swing arm Steering triangle... -
Page 14: Adjusting Motor Depth Of Water After Setup
4.2.2 ADJUSTING MOTOR DEPTH OF WATER AFTER SETUP Hold the motor firmly and loosen the screw on either the clamping ring or the steering triangle, whichever is topmost on the shaft in your set up. Adjust shaft position to find the optimum motor depth in water. Tighten the screws on the clamping ring or the steering triangle (whichever you have on the top of the shaft). - Page 15 The cable to perform reverse lock: The reverse lock secures the Cord to perform the motor when it is being used in reverse lock reverse. It needs to be activated when motor is used in reverse to Cable guide keep the motor from rotating up and out of water.
-
Page 16: Complete The Cord Setup
COMPLETE THE CORD SETUP This is the overall setup of the motor after all control cables have been installed: Motor lift cord Cords to control the direction Reverse lock cord USING EXTERNAL STEERING SYSTEM Fixing pin If you are planning on using the motor only for forward/reverse propulsion and are using other methods to steer such as a paddle, you can fix the motor direction with the following... -
Page 17: Adjust The Motor Trim Angle
ADJUST THE MOTOR TRIM ANGLE You can adjust the angle between water surface and the motor using the motor trim Trim rod angle adjustment design. Follow the steps Clip ring below if you would like to change the angle of the motor. Tilt the motor up and hold it firmly. -
Page 18: Controller Display
Make sure the battery cables are connected to the correct terminal. The motor will not operate if battery cables are installed incorrectly. Tighten the connection of the battery cables to the battery terminals. Make sure the connection is solid and secure. To power the motor, plug the connectors from the motor and cable extension together. -
Page 19: Estimated Percent Of Remaining Battery Power
5.2.1 ESTIMATED PERCENT OF REMAINING BATTERY POWER The battery bar has 6 different status levels to display the estimated remaining battery percentage. CAUTION: Do not overestimate the remaining battery range; this could result in severe harm or even death. • Before you leave the dock, know the area you are traveling, how far you plan to go, and make sure to have an alternate plan for safely getting back if anything goes wrong with your motor or battery. -
Page 20: Error Status Display
ERROR STATUS DISPLAY The icons indicated on the LCD screen above show three possible error statuses of the motor. When a fault occurs, there will be a corresponding code on screen to help diagnose the problem. See section 5.4 Error Codes and Solutions. Motor overvoltage: If the input voltage is too high, this icon will light up and keep flashing. -
Page 21: Error Codes And Solutions
ERROR CODES AND SOLUTIONS If there is an issue with the motor function, the display will show an error code to help diagnose the problem and find the solution. Error Code Description Solution The motor drive PCB is overheated. Press the Power button for 2 seconds to reset E-01 the system. -
Page 22: Operation
OPERATION START THE MOTOR To start the motor please follow the steps below: Place the magnet kill switch on the tiller. Select the battery mode according to the battery type used. Please follow 5.2.2 Switching Between Battery Types to operate correctly. Press the power button on the panel. -
Page 23: Steering The Motor
STEERING THE MOTOR While the motor is operating, pull the steering cords to control the vessel’s direction: • To turn left, pull the left cord on the steering triangle. • To turn right, pull the right cord on the steering triangle. Pull the left cable Pull the right cable to turn left... -
Page 24: Tilting The Motor
TILTING THE MOTOR When needed, the motor can be tilted up to stow away or to avoid underwater obstacles. To do this, pull the cord on the swing arm shown in the figure to the right until the motor pulls out of the water and secure the cord in the forward position, keeping the motor out of water. -
Page 25: Remove The Motor From The Kayak
REMOVE THE MOTOR FROM THE KAYAK It is very easy to remove the motor from the bracket for travel, however you will want to leave the mount installed. Follow the steps below: Move the accelerator lever to the neutral position, and turn off the motor. -
Page 26: Corrosion Protection
CORROSION PROTECTION • After the motor is used in the saltwater, rinse the motor thoroughly with fresh water. • Before storing the motor, make sure the motor is completely dry and clean. • Keep cable connectors and plugs in good condition. •... -
Page 27: Replacing The Propeller
REPLACING THE PROPELLER You can replace the propeller if it is damaged. To do this, follow the steps below with the assembly diagram: Attach the washer. Insert the drive pin into the hole on the motor output shaft. Rotate the propeller until the drive pin is seated correctly in the corresponding channel on the backside of the propeller. -
Page 28: Recalibrate The Throttle
RECALIBRATE THE THROTTLE You can recalibrate the throttle when the throttle display is inaccurate. To do this, follow the steps below: • Press and the MODE button for 5 seconds, the controller will enter the throttle recalibration mode. You will notice the CALIBRATING sign starts to flash. -
Page 29: Declaration Of Conformity For Recreational Craft
CUSTOMER SUPPORT If you have questions that are not answered in this manual or troubleshooting is not successful, please contact Newport! Our California based customer service team is standing by to assist you. 8:30 AM - 7:00 PM ET (866) 721-0002 support@newportvessels.com... -
Page 30: With Accessories
THE WAY FORWARD IS WITH ACCESSORIES Newport designs innovative accessories crafted to elevate your time on the water, propelling you further. - Page 31 Bluetooth Lithium Battery Battery Quick Disconnect...
- Page 32 SHARE YOUR ADVENTURES @newportvessels REV AX19X249...
