Contacta FR-RX1-865 User Manual

Version: 9080-015-D4-1124
1 Flexible Antenna (Fixed. Do not attempt to remove)
RF-RX1 LED colour indication status:
Steady blue = Indicates a successful pairing to a transmitter, and also indicates when a battery is full during a charging cycle.
Flashing blue = Indicates RX1 receiver disconnected from a transmitter when a battery is full during a charging cycle.
Steady red = Indicates a succesful pairing to a transmitter, and indicates low battery - charge soon.
Flashing red = Indicates a failure pairing to a transmitter, and indicates low battery - charge soon.
General operation
Power on
Press and hold the power button for 1 second to turn the receiver on.
Adjust channel manually
Channel lock is activated
The screen will automatically be locked ( ) when the receiver is on and idle for 5 seconds.
To unlock the receiver, press both and buttons for 1 second until
Now, press the or button to select another preferred channel. Once the newly selected channel is
determined, press the set button again to confirm the selection and then
Channel lock is de-activated
Simply short press the or button to select another preferred channel. The newly selected channel
will automatically be determined after the receiver is idle for 1 second.
Check channel frequency
Short press the set button to check the frequency of selected channel. The receiver will return
back to the Home Screen after being idle for 2 seconds.
symbol disappears.
symbol will display again.
