Owner's Manual
Before using this LED work light, please read the following safety and
mounting instructions carefully. Keep this manual for future reference.
Package Includes:
1 LED work light with adjustable base, mounting bracket
1 AC charging cable
1 DC charging cable
1 Owner's manual
Getting Started:
To charge the LED work light, plug the included AC charging cable into a
Ground Fault Circuit Interrupter (GFCI) protected outlet. Charge the LED
work light until the indicator light on the rear of the unit turns green
indicating a full charge. Press the quick adjust button on the side of the LED
work light (Fig. 1). While the button is pressed, adjust the base forward or
backward to the desired angle. Aim the light away from direct eye contact.
Press the sealed on/o switch on the back of the unit to turn on the light.
(Fig.2). Press once for high setting, press twice for low setting. When the
indicator light turns red the work light has 5% charge remaining. When the
indicator light is ashing red the work light has 1% charge remaining.
Fig. 1
Fig. 2
Speci cations:
Model
Electrical
Light Body Size (in)
rating
(Length*width*height)
LEDS01
100-120V~, 60Hz, 10W
7.48 * 9.06 * 1.81
LEDRS01
100-120V~, 60Hz, 10W
7.48 * 9.06 * 1.81
LEDS02
100-120V ~, 60Hz, 20W
7.48 * 9.06 * 1.81
LEDS03
100-120V ~, 60Hz, 30W
9.37 * 10.63 * 1.81
LEDTS03
100-120V ~, 60Hz, 30W
17.32 * 10.63 * 1.81
LEDTS04
100-120V ~, 60Hz, 50W
17.32 * 10.63 * 1.81
This LED work light is suitable for use in wet locations, and is intended
for use in combination with a designated tripod or bracket.
Cleaning & Maintenance
Before cleaning, make sure the power cord is unplugged from the
electrical outlet. Wipe the work light with a soft, damp cloth. Do not use
ammable substances or solvents to clean the unit.
If the clear protective lens is broken, or the power cord is cut exposing
the inner wires, do not use this work light.
CAUTION-RISK OF SHOCK.
DISCONNECT POWER BEFORE SERVICING.
Troubleshooting:
If the light does not work check the following:
1. Check that the light is charged.
a. The indicator light on the rear of the housing should be green,
yellow or red if the unit has any charge when turned on.
b. If the indicator light turns on but the work light does not, try
charging for 20 minutes. If the light still does not turn on, the unit is
defective.
2. When charging, the indicator light should turn yellow. If no light turns
on, be sure the power is on at the source and the charging cable is
properly plugged into the power source.
3. If the work light is plugged into a GFCI outlet, check that the outlet
has not been tripped.
a. Unplug the work light from the GFCI receptacle.
b. Press the "reset" button on the GFCI receptacle.
c. Plug the work light back into the GFCI receptacle and press the
on/o switch on the back of the xture to turn on the light.
IC REGULATORY STATEMENT
Under Industry Canada regulations, this radio transmitter may only operate
using an antenna of a type and maximum (or lesser) gain approved for the
transmitter by Industry Canada. To reduce potential radio interference to other
users, the antenna type and its gain should be so chosen that the equivalent
Weight
Maximum
Luminous Area (in)
(lbs)
isotropically radiated power (e.i.r.p.) is not more than that necessary for
2.24
4.8 * 1.97
successful communication.
2.00
4.8 * 1.97
This device complies with Industry Canada licence-exempt RSS standard(s).
2.24
4.8 * 1.97
Operation is subject to the following two conditions: (1) this device may not
2.92
6.42 * 2.76
cause interference, and (2) this device must accept any interference, including
3.76
6.42 * 2.76
interference that may cause undesired operation of the device.
6.42 * 2.76
3.77
+2.76 * 1.97
+2.76 * 1.97
FCC REGULATORY STATEMENT
WARNING: Changes or modi cations to this unit not expressly approved by the party
responsible for compliance could void the user authority to operate the equipment. This device
complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause
undesired operation.
Notes: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by
turning the equipment o and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit di erent from that to which the receiver
is connected.
4. Consult the dealer or an experienced radio/TV technician for help.
LIMITED 3 YEAR WARRANTY
Prime warrants this product to be free from manufacturing defects for a period of three years
from the original date of purchase ("warranty period"). This warranty is limited to the
repair or replacement of this product only and Prime is not liable for any consequential or
incidental damage to other products that may be used with this unit. This warranty is
e ective only if such unit is returned to Prime not later than thirty (30) days after the expiration
of the warranty period. Warranty is void if damage is due to neglect, misuse,
alteration, modi cation, improper installation, or repair by other than Prime. This warranty is in
lieu of all other warranties express or implied. Some states do not allow limitations on
how long an implied warranty lasts or permit the exclusion or limitation of incidental or
consequential damages, so the above limitations may not apply to you. It is our experience that
a product that fails prematurely due to a manufacturing defect in materials or workmanship,
will generally do so very early in the product's life cycle, often the rst or second time the
product is used. Products that are returned for warranty inspection after months or years of
continuous reliable service are usually the result of normal wear and tear, which is not
considered a defect in materials or workmanship and therefore is not covered by the warranty.
This warranty gives the customer speci c rights, and you may also have other rights which vary
from state to state. If unit should prove defective within the warranty period, return within the
time period set forth above prepaid with the original purchase receipt to:
Prime Wire & Cable, Inc.
ATTN: Quality Assurance Department
1330 Valley Vista Drive
Diamond Bar, CA 91765
©2017 Prime Wire & Cable, Inc. • Diamond Bar, CA 91765
Service (888) 445-9955 • www.primewirecable.com
rev. 04-10062021
