Prime LEDWLS03 Owner's Manual

Owner's Manual
Before using this LED work light, please read the following safety and mounting
instructions carefully. Keep this manual for future reference.
Package Includes:
1 LED work light with adjustable H-base
1 Owner's manual
Getting Started:
Use the knobs on the sides of the work light (Fig. 1) to adjust the LED panel to the
desired angle. Aim the light away from direct eye contact and then plug the work
light into a Grounded Fault Circuit Interrupter (GFCI) protected outlet. Press the
sealed on/o switch on the back of the unit to turn on the light. (Fig. 2)
Fig. 1
Specifications:
Model Electrical Light Body Size (in)
rating (length*width*height)
LEDWLS03 120V-60Hz-35W 6.00 * 5.00 * 10.00
LEDWLS06 120V-60Hz-55W 7.75 * 7.25 * 11.50
This LED work light is suitable for outdoor use and can be used with a designated
tripod if needed.
Cleaning & Maintenance
Before cleaning, make sure the power cord is unplugged from the electrical outlet.
Wipe the work light with a soft, damp cloth. Do not use ammable substances or
solvents to clean the unit. If the clear protective lens is broken, or the power cord
is cut exposing the inner wires, do not use this work light. Please ensure unit is
unplugged from the wall before cutting o the power cord and properly dispose
of the damaged unit.
Warnings
Use only a three-wire outdoor rated extension cord that has a three-prong
grounding plug and grounding receptacle that accepts the work light's 3-prong
plug.
Use only with an extension cord, minimum gauge 16/3, rated for outdoor use,
made with one of the following wire types: SJTW, SJTOW, SJTOOW, SJEW, SJEOW,
SJEOOW, STW, STOW, STOOW, SJW, SEW, SEOW, SEOOW, SOW, SOOW.
The LED work light is to be plugged into a Ground Fault Circuit Interrupter (GFCI)
protected outlet.
Do not touch hot lens, guard or enclosure.
Do not look directly at lighted lamp.
CAUTION-RISK OF SHOCK. DISCONNECT POWER BEFORE SERVICING.
Troubleshooting:
ON/OFF
If the light does not work check the following:
1. Be sure the power is on at the source and the work light is properly plugged
into the power source.
2. If the work light is plugged into a GFCI outlet, check that the outlet has not
been tripped.
a. Unplug the work light from the GFCI receptacle.
b. Press the "reset" button on the GFCI receptacle.
c. Plug the work light back into the GFCI receptacle and press the on/o
Fig. 2
switch on the back of the xture to turn on the light.
IC REGULATORY STATEMENT
Under Industry Canada regulations, this radio transmitter may only operate using an
Weight Maximum
antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry
(lbs) Luminous Area (in)
Canada. To reduce potential radio interference to other users, the antenna type and its gain
1.8 2.0 * 1.5
should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more
2.8 2.5 * 1.5
than that necessary for successful communication.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is
subject to the following two conditions: (1) this device may not cause interference, and (2)
this device must accept any interference, including interference that may cause undesired
operation of the device.
FCC REGULATORY STATEMENT
WARNING: Changes or modi cations to this unit not expressly approved by the party
responsible for compliance could void the user authority to operate the equipment. This
device complies with part 15 of the FCC rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may
cause undesired operation.
Notes: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit di erent from that to which the
receiver is connected.
4. Consult the dealer or an experienced radio/TV technician for help.
LIMITED 3 YEAR WARRANTY
Prime warrants this product to be free from manufacturing defects for a period of three
years from the original date of purchase ("warranty period"). This warranty is limited to the
repair or replacement of this product only and Prime is not liable for any consequential or
incidental damage to other products that may be used with this unit. This warranty is
e ective only if such unit is returned to Prime not later than thirty (30) days after the
expiration of the warranty period. Warranty is void if damage is due to neglect, misuse,
alteration, modi cation, improper installation, or repair by other than Prime. This warranty
is in lieu of all other warranties express or implied. Some states do not allow limitations on
how long an implied warranty lasts or permit the exclusion or limitation of incidental or
consequential damages, so the above limitations may not apply to you. It is our
experience that a product that fails prematurely due to a manufacturing defect in
materials or workmanship, will generally do so very early in the product's life cycle, often
the rst or second time the product is used. Products that are returned for warranty
inspection after months or years of continuous reliable service are usually the result of
normal wear and tear, which is not considered a defect in materials or workmanship and
therefore is not covered by the warranty. This warranty gives the customer speci c rights,
and you may also have other rights which vary from state to state. If unit should prove
defective within the warranty period, return within the time period set forth above
prepaid with the original purchase receipt to:
Prime Wire & Cable, Inc.
ATTN: Quality Assurance Department
1330 Valley Vista Drive
Diamond Bar, CA 91765
©2023 Prime Wire & Cable, Inc. • Diamond Bar, CA 91765
Service (888) 445-9955 • www.primewirecable.com
rev. 01-06282023 EB
