Fridgemaster MS91547DFE Instructions For Use Manual

Upright fridge freezer
Hide thumbs

Advertisement

Quick Links

Download this manual
INSTRUCTIONS FOR USE
OF AN UPRIGHT FRIDGE
FREEZER

Advertisement

loading
Need help?

Need help?

Do you have a question about the MS91547DFE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fridgemaster MS91547DFE

Summary of Contents for Fridgemaster MS91547DFE

  • Page 1 INSTRUCTIONS FOR USE OF AN UPRIGHT FRIDGE FREEZER...
  • Page 2 We thank you for the trust you have shown by purchasing our appliance which is designed to simplify your life. This instruction manual is supplied to make the use of this product easier. The instructions should allow you to learn about your new appliance as quickly as possible.

  • Page 3: Table Of Contents

    Contents Important notes and precautions ..................Before using the appliance for the first time ................Important safety instructions ....................Important information on the use of appliance ................. Environment protection ......................Advice for saving power with refrigeration appliances ............Installation and connection ....................Selecting the room ........................

  • Page 4: Important Notes And Precautions

    Important notes and precautions Before using the appliance for the first time Before connecting the appliance to the power mains, please read carefully the instructions for use which describe the appliance and its correct and safe use. The instructions apply to several appliance types/models;...

  • Page 5: Electric Shock

    ELECTRIC SHOCK! WARNING! If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. ELECTRIC SHOCK! WARNING! When positioning the appliance, ensure the supply cord is not trapped or damaged. ELECTRIC SHOCK! If LED lighting does not work, call a service technician.
  • Page 6 Safety of children and vulnerable persons The appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

  • Page 7: Important Information On The Use Of Appliance

    Children aged from 3 to 8 years are allowed to load and unload refrigerating appliances. Warning regarding the refrigerant The appliance contains a small amount of an environmentally friendly yet flammable gas R600a. Make sure that no parts of the cooling system are damaged. A gas leak is not hazardous to the environment, but it could cause eye injury or fire.
  • Page 8 WARNING! WARNING! Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. The appliance may not be used outdoors and it may not be exposed to rain. Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.

  • Page 9: Environment Protection

    Environment protection Packaging is made of environmentally friendly materials that can be recycled, disposed of, or destroyed without any hazard to the environment. Removing an obsolete appliance To protect the environment, take the obsolete appliance to an authorized home appliance collection centre.

  • Page 10: Advice For Saving Power With Refrigeration Appliances

    Advice for saving power with refrigeration appliances • Install the appliance as specified in the instruction manual. • Do not open the door more often than necessary. • Occasionally make sure air circulation underneath the appliance is unobstructed. • If the gasket is damaged or does not provide a perfect seal for any reason, have it replaced as soon as possible.

  • Page 11: Installation And Connection

    Installation and connection Selecting the room • Install the appliance in a dry and well ventilated room. The appliance will operate correctly if the environment temperature is in the interval specified in the table. The appliance class is indicated on the rating plate / label with the basic information on the appliance. Description Class Ambient temperature range °C...

  • Page 12: Appliance Placement

    Appliance placement Appliance installation should be carried out by at least two persons to avoid any personal injury or damage to the appliance. • The appliance is intended for free-standing installation. To reach the rated/minimum power consumption, always provide 50 mm of clearance between the wall and the back of the appliance, and 100 mm above the appliance.

  • Page 13: Appliance Setup

    Appliance setup • To ensure that the appliance will stand horizontally and that sufficient air circulation is provided behind the appliance, the feet at the bottom of the appliance may need to be adjusted. The height of the feet can be adjusted with your fingers or using an appropriate wrench.

  • Page 14: Connecting The Appliance

    Connecting the appliance • Connect the appliance to the power mains using the power cord. The wall outlet should be fitted with a ground contact (safety socket). Nominal voltage and frequency are indicated on the rating plate/label with basic information on the appliance. •...

  • Page 15: Description Of The Appliance

    Description of the appliance Appliance interior equipment may change according to the appliance model. This product contains a light source of energy efficiency class G. 1. LED light in the freezer compartment 2. Freezer door shelf 3. Freezer air circulation duct cover 4.

  • Page 16: Operating The Appliance

    Operating the appliance Temperature setting key Display Refrigerator/freezer compartment switch Refrigerator compartment display Freezer compartment display Key to set additional functions Intensive freezing (fast freeze) function indicator Long absence function indicator (holiday mode) Eco function indicator Function indicator convert Switching the appliance on/off Power on: To switch on the appliance, plug the power cord into the power mains outlet.

  • Page 17: Adjusting The Temperature In The Appliance

    Adjusting the temperature in the appliance INFORMATION! • Appliance temperature is preset at the factory to the recommended setting, i.e. 4°C for the refrigerator compartment and -18°C for the freezer compartment. • After the appliance is switched on, it may take several hours for the set temperature to be reached.

  • Page 18: Control Unit/Display Standby Mode

    INFORMATION! 10 seconds after the most recent key is pressed, the freezer compartment display automatically switches back to refrigerator compartment display. B1 will light up and the temperature set for the refrigerator compartment is displayed on the A1 display unit. Control unit/display standby mode INFORMATION! 30 second after you have pressed the most recent key, the control unit switches to standby...

  • Page 19: Intensive Freezing (Freezer Compartment)

    Intensive freezing (freezer compartment) ( ) • Use this setting after switching on the appliance for the first time, before cleaning, or before inserting a large amount of food. Power on: switch on the intensive freezing mode by pressing the key C as many times as it takes for the display to show C1.

  • Page 20: Eco Function(Recommended Setting )

    Eco function ( ) (Recommended setting Power on: the Eco function is turned on by pressing the C key as many times as it takes for the display to show C3. Power off: the Eco function can be switched off by pressing the C key again until the symbol C3 goes out.

  • Page 21: Convert Function

    Convert function ( The entire freezer compartment can be converted into a ZeroZone compartment. The temperature in this compartment is at or slightly below 0°C. Therefore, do not store food that is sensitive to low temperature in this compartment as such food may freeze. Before switching to ZeroZone function, empty the freezer compartment to prevent the frozen food from defrosting and perishing.

  • Page 22: Holiday Mode (Prolonged Absence)

    Holiday mode (prolonged absence) Use this function when you are away for a long period of time, for example when you are going on holiday or taking a long business trip. Power on: turn on the function by pressing the C key as many times as it takes for the display to show C2.

  • Page 23: High Temperature Alarm

    High temperature alarm If the temperature inside the appliance is too high, the acoustic alarm will be activated (intermittent tone), and the set temperature of the compartment where the temperature is too high will flash on the display unit. • Every time you switch on the appliance, a 24-hour delay in alarm operation is activated.

  • Page 24: Open Door Alarm

    Open door alarm If the refrigerator or freezer compartment door is open for too long, an acoustic alarm (repetitive beep) will be activated and B1 or B2 icon on user interface will start to blink, depending on which door is open.

  • Page 25: Power Outage/Power Supply Failure Alarm

    Power outage/power supply failure alarm If the temperature in the appliance reaches the alarm level during a power failure, then the high temperature alarm will be activated once power supply is restored. The alarm will sound and the display will flash PF. Deactivate the alarm by pressing any of the keys.

  • Page 26: Appliance Interior Equipment

    Appliance interior equipment ( * Equipment depends on the model) Shelves Empty shelves can be rearranged as you see fit across the guides in the appliance interior without having to remove them from the appliance. To move or remove a shelf from the appliance, pull it towards you, lift it up at the front and then move or pull it out of the appliance.

  • Page 27: Water Dispenser

    Water dispenser * (Only in some models) The water dispenser installed in the door of the refrigeration compartment is designed for storing drinking water. With a water dispenser, you can easily get chilled water without having to open the door of the refrigeration compartment. Before using the appliance for the first time Before using the water dispenser for the first time, it must be cleaned according to the instructions below:...

  • Page 28: Filling With Water

    Filling with water Before filling the container with drinking water, make sure that the water container is firmly placed in the intended position. Attention! Pour up to 3 liters of water into the container (as recommended), but make sure that the water does not exceed the maximum level, otherwise it may spill over the edge when the lid is closed.

  • Page 29: Storing Food In The Refrigerator

    Storing food in the refrigerator Important warnings regarding food storage INFORMATION! Correct use of the appliance, appropriate packaging, maintaining the right temperature, and observing the food hygiene standards have a decisive impact on the quality of food storage. Observe the expiry dates for the food, indicated on the packaging. Food stored in the refrigerator should be kept in closed containers or in appropriate packaging to prevent it from emitting or receiving odours and humidity.

  • Page 30: Freezing And Storing Frozen Food

    Freezing and storing frozen food Freezing procedure INFORMATION! Maximum amount of fresh food that may be inserted at once is specified on the appliance rating plate. If the amount of food to be frozen exceeds the indicated amount, the quality of freezing will be inferior;...

  • Page 31: Thawing Frozen Food

    Table continued from last page Type of food Storage life Pork from 4 to 6 months Finely chopped or minced meat 4 months Bread, pastas, cooked dishes, whitefish 3 months Offal 2 months Smoked sausage, bluefish 1 month Thawing frozen food •...

  • Page 32: Defrosting The Appliance

    Defrosting the appliance Automatic refrigerator defrosting Refrigerator does not need defrosting because the ice on the back interior wall is thawed automatically. Any accumulated ice will melt when the compressor unit is inactive. Drops will flow through an opening in the refrigerator rear wall into a tray fitted above the compressor, from where they will evaporate. Make sure the opening in the back wall in the refrigerator interior is never blocked by food or any other object.

  • Page 33: Cleaning The Appliance

    Cleaning the appliance WARNING! Before cleaning, unplug the appliance from the mains - unplug the appliance and remove the connection cable from the socket. • Use a soft cloth to clean all surfaces. Cleaners that contain abrasive substances, acids, or solvents are not suitable for cleaning as they may damage the surface.

  • Page 34: Troubleshooting

    Troubleshooting Problem: Cause or remedy: Appliance is connected to • Make sure there is voltage in the power outlet and that the the power mains but it does appliance is switched on. not work. Cooling system operates • Too high environment temperature. continuously for a long •...
  • Page 35 Table continued from last page Problem: Cause or remedy: Door is difficult to open: • If you are trying to open the freezer door after just having closed it, this could be difficult to do. As you open the door, some cool air escapes from the appliance and it is replaced by warm air from the environment.
  • Page 36 Table continued from last page Problem: Cause or remedy: E7 will appear on the display • Ambient temperature sensor is malfunctioning. Call a service unit: center to fix the problem. The appliance will operate in safe mode until it is repaired by a service technician. The appliance will automatically maintain the most suitable temperature for each compartment.

  • Page 37: Information About Appliance Noise

    Information about appliance noise Cooling in refrigerator freezers is made possible by a cooling system that also includes a compressor (and a fan with some appliances), which generates some noise. The level of noise depends on installation, proper use, and age of the appliance. •...
  • Page 38 902971-a1...
