- Page 1 APUS-MX User Manual www.satlab.com.se...
- Page 2 APUS-MX User Manual Manual Revision SATLAB GEOSOLUTIONS AB Revision Date Revision Level Description Aug. 2024 APUS-MX User Manual www.satlab.com.se...
- Page 3 APUS-MX User Manual APUS-MX UAV LiDAR for Mapping & Surveying www.satlab.com.se...
-
Page 4: Table Of Contents
4.2 Data Copy Method ..........................20 4.3 Upgrade Firmware ........................... 21 Chapter 5..............................22 Packing List ............................23 5.1 Host and Accessories ..........................23 5.2 Other Items ............................... 24 Chapter 6..............................25 Appendix .............................. 26 6.1 Common Problems ..........................26 www.satlab.com.se... -
Page 5: Chapter 1
APUS-MX User Manual Chapter 1 Product Overview - Product Weight and Dimensions - Specification - Product Appearance & Interface Description www.satlab.com.se... - Page 6 APUS-MX User Manual Product Overview The APUS-MX is the latest member of Satlab's APUS series of UAV LiDAR systems. Satlab is dedicated to providing efficient and user-friendly LiDAR solutions with stable flight platforms, delivering data that meets the accuracy standards required for various applications such as engineering surveys, topographic surveys, and power line inspections.
-
Page 7: Specification
1.65 kg(3.64 lbs) camera antenna hanger include -20°C～+50°C (operation) Temperature range -20°C～+65°C (storage) Protection class IP64 System SSD 1 TByte Data storage (expandable 512 GByte SD Card) Data transmission mode Type-C, up to 160 M/S Mounting interface DJI skyport Manipulation M300/M350 remote control www.satlab.com.se... -
Page 8: Product Appearance & Interface Description
APUS-MX User Manual 1.3 Product Appearance & Interface Description Cooling DJI SKYPORT V2 Interface Function keys and LEDs GNSS antenna Interface Type-C and TF card slot www.satlab.com.se... - Page 9 Power indicator 0.5-second Blinking During firmware upgrade, the power indicator (green) green light blinks for 0.5 sec. Steady On The device is ready and can start data collection 3-second Blinking The project is active and data collection is in progress www.satlab.com.se...
-
Page 10: Installation And Removal Of Accessories
APUS-MX User Manual Chapter 2 Installation and Removal of Accessories This chapter contains: - Install Antenna Bracket and GNSS Antenna - Replacement of Vibration Damper www.satlab.com.se... - Page 11 2. Snap the antenna bracket onto the top and bottom of the Skyport connector as shown in the picture below, and screw in the back screws. (Note: Ensure to refer to the provided image for correct placement and installation of the antenna bracket.) www.satlab.com.se...
- Page 12 APUS-MX User Manual 3. Remove the antenna connecting rod from the packaging. Insert the threaded end through the designated fixing port on the antenna bracket. Secure it firmly with a nut to complete the GNSS antenna installation. www.satlab.com.se...
- Page 13 This will adversely affect the quality of the data collected. If any wear or looseness is observed in the vibration dampers during use, replace them promptly. Failure to do so will compromise data quality and may even result in the laser falling off during flight. www.satlab.com.se...
-
Page 14: Data Collection
APUS-MX User Manual Chapter 3 Data Collection This chapter contains: - Preparation - Device Installation - Start & Stop Collection Operation - Device Disassembly www.satlab.com.se... -
Page 15: Device Installation
2. With your right hand, support the device from below, align the white dot on the Skyport interface of the device with the red dot on the mount interface, and insert it upwards into the mount interface. 3. Rotate the device counterclockwise until a "click" sound is heard, completing the device installation. www.satlab.com.se... - Page 16 � Note: For flat terrain at a flight height of 150m, if image coloring is required, a lateral overlap of � � 60% is recommended; if no image coloring is needed, a lateral overlap of 40% is recommended. The Apus-MX camera parameters need to be customized during the first connection. www.satlab.com.se...
- Page 17 After the indicator light goes out, press the gimbal camera unlock button on the side of the mount with your left hand, support the radar host with your right hand, and rotate it clockwise to remove the device. 2. Store the device in the box for convenient future use. www.satlab.com.se...
- Page 18 APUS-MX User Manual � Note: The antenna rod assembly should be removed when storing the drone, but the antenna � � mount and locknut do not need to be removed. www.satlab.com.se...
-
Page 19: Data Transmission
APUS-MX User Manual Chapter 4 Data Transmission This chapter contains: - Data Structure Overview - Data Copy Method - Upgrade Firmware www.satlab.com.se... - Page 20 1) Remove the device from the packaging box, and open the rubber plug on the side interface of the host, as described in section 1.3. 2) Connect the host Type-C port to the computer USB port using the supplied Type-C data cable. 3) Copy the required project data from the Data folder to the computer. www.satlab.com.se...
-
Page 21: Upgrade Firmware
10-20 seconds. 4. Once the update is complete, the device will automatically power off and restart, and the update package in the update folder will be automatically deleted, indicating a successful firmware upgrade. www.satlab.com.se... -
Page 22: Chapter 5
APUS-MX User Manual Chapter 5 Packing List www.satlab.com.se... -
Page 23: Host And Accessories
○ ○ ○ ○ 5.1 Host and Accessories Item Name Quantity Image Apus-MX LiDAR 1 Unit USB3.0 1 pcs cable Antenna Mount 1 pcs Antenna Mount Locknut 1 pcs Antenna Rod Assembly 1 pcs Vibration Damper balls 8 pcs www.satlab.com.se... -
Page 24: Other Items
APUS-MX User Manual 5.2 Other Items Item Name Quantity Screws *10 (Phillips M2*10) and Screwdriver 1 packs USB Dongle 1 pcs User Manual 1 pcs Packing Box 1pcs Lens Cleaning Paper 5 packs Desiccant 2 packs www.satlab.com.se... -
Page 25: Chapter 6
APUS-MX User Manual Chapter 6 Appendix This chapter contains: - Common problems & Solutions - Use and precautions www.satlab.com.se... - Page 26 3. No laser data or incomplete data from the current flight After completing data collection, wait about 20 seconds for the indicator light to stay on continuously before turning off the drone power. Prematurely turning off the drone will cause the Apus-MX to shut down early. www.satlab.com.se...
- Page 27 APUS-MX User Manual Headquarter: Stora Åvägen 21, 436 34 ASKIM, Sweden info@satlab.com.se Regional Offices: Warsaw, Poland Jičín, Czech Republic Ankara, Turkey Scottsdale, USA Singapore Hong Kong Dubai, UAE www.satlab.com.se www.satlab.com.se...
