UAV/RTK User Manual 2- LED Indication SATELLITE POWER SUPPLY SIGNAL ■ Green: ■ Yellow: ■ Red: Solid: Tracked, fixed Solid: Normal Solid: Data link open Flash: Tracking, non-fixed power supply Flash: Diff Tx Slow Flash: Acquiring ■ Red: ■ Green:...
UAV/RTK User Manual 3- Signal Interface USB: U Disk Micro USB USB A PWR : COM1: EVENT: COM2: Position Data Event Input / PPS Output Differential Data Power Input EVENT1 EVENT2 XT60 Male COM1 and COM2 is CMOS 3.3V level.
Page 5
UAV/RTK User Manual 4- RF Interface GSM: GNSS2: GNSS1: RADIO: 3G Communication GNSS Antenna Input 2 GNSS Antenna Input 1 Radio Communication 820~960MHz; Dual Band;> 26dB Dual Band;> 26dB 840~845MHz; ≥2dBi 1700~2200MHz; ≥2dBi [Directional Use] (Location Only)
Page 6
• After the configuration is completed, connect the relevant input/output COM ports on the UAV/RTK sensor to the corresponding ports on hardware such as a flight controller. Important Note: Signal interface electrical characteristic is CMOS 3.3V level. Pay attention to the connection signal level match to prevent burning the equipment.
If you do not follow instructions when operating the receiver, or fail to understand the requirements of the specification and the proper use of this product, any resulting loss or damages resulting from the misuse are limited to the terms of SatLab’s International Warranty ‘Limitation of Liability’ clause.
Page 8
Headquarters: Datavägen 21B SE-436 32 Askim,SWEDEN info@satlabgps.com | www.satlabgps.com Regional O ces: Jičín, CZECH REPUBLIC Ankara, TURKEY Scottsdale, USA Singapore, SINGAPORE Warsaw, POLAND...
