Sealey VS7019 Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to Wear eye
instructions protection
1. SAFETY
1.1. IMPORTANT Read the instructions carefully. Be familiar with the controls and the correct use of the machine.
Keep these instructions in a safe accessible place.
9
WARNING! Ensure health & safety, local authority, and general workshop practice regulations are strictly adhered to when using this
‰
equipment.
Familiarise yourself with product application and limitations, as well as the specific potential hazards peculiar to this product.
9
Maintain the product in good condition (use an authorised service agent).
9
Replace or repair damaged parts. Use genuine parts only. Non authorised parts will invalidate the warranty.
9
Ensure safety eye protection and protective clothing are worn when using this product.
9
Keep the work area clean, uncluttered and ensure there is adequate lighting.
9
Maintain correct balance and footing. Ensure the floor is not slippery and wear non slip shoes.
9
Keep children and unauthorised persons away from the working area.
9
Dispose of waste liquids in accordance with local authority regulations.
9
DO NOT use to extract corrosive fluids.
8
DO NOT dismantle, tamper with or adapt the pump for any purpose other than for which it is designed.
8
DO NOT use the unit if it has been dropped or mishandled, check the unit to ensure there is no damage.
8
Keep the pump clean and store in a safe, dry, childproof location.
9
WARNING! DO NOT allow uncontrolled discharge of fluids thus polluting the environment.
‰
WARNING! Always pay attention to the pressure control since it's a pressurised unit.
‰
2. INTRODUCTION
Pneumatic operated oil dispensing unit with 10L capacity. Large visual measurement container will identify the amount dispensed.
Supplied with a range of eight transmission fluid adaptors. Features a safety valve to stop over-pressurising. Supplied with a storage
case for the adaptor to minimise oil leakage when not in use.
3. SPECIFICATION
Model No: VS7019
Capacity: 10L
Maximum Pressure: 100psi (7bar)
Nett Weight: 3.02kg
4. CONTENTS
Item Part no. Description
1 VS7009.A05 Adaptor VW Audi
2 VS7009.A04 Adaptor VW Audi
3 VS7009.A03 Adaptor VW Audi
4 VS7009.A02 Adaptor universal
© Jack Sealey Limited
10L PNEUMATIC TRANSMISSION OIL FILLING
SYSTEM
MODEL NO:
Wear protective
clothing
1
6
2
7
3
8
4
5
5 VS7009.A01
6 VS70090.02
7 VS70090.03
8 VS70090.01
Original Language Version
VS7019
Adaptor Ford
Audi/VW CVT
Audi/VW DSG
Mercedes
VS7019 Issue 2 16/02/24
