INSTALLATION AND
ADJUSTMENT MANUAL
M000214
SMS Casing Complete Top Mounted Back to Back
DE Handbuch für Installation und Anpassung
IT Manuale per l'installazione e la regolazione
ES Manual de instalación y ajuste
FI Asennus- ja säätöohje
FR Manuel d'installation et de réglage
NL Handboek voor installatie en instellingen
PL
RUS
ARB
SE Monterings- och justeringsmanual
GR
Advertisement
Table of Contents
Related Manuals for SMS M000214
Summary of Contents for SMS M000214
- Page 1 INSTALLATION AND ADJUSTMENT MANUAL M000214 SMS Casing Complete Top Mounted Back to Back DE Handbuch für Installation und Anpassung IT Manuale per l'installazione e la regolazione ES Manual de instalación y ajuste FI Asennus- ja säätöohje FR Manuel d’installation et de réglage...
- Page 2 Advertencia Avertissement El montaje del producto no es responsabilidad de SMS Smart Media Solutions AB y es muy Le montage doit impérativement être effectué de façon correcte et ne relève pas de la importante que el producto sea montado correctamente. El montaje incorrecto puede responsabilité...
- Page 3 Sulla ricevuta devono essere chiaramente leggibili nome be clearly legible on the receipt. The owner is to pay the cost of returning the product to SMS, while del fornitore e data d’acquisto. Le spese di spedizione a SMS sono a carico dell’acquirente;...
-
Page 4: You Will Need
4 SMS CASING COMPLETE TOP MOUNTED Back to Back ASSEMBLY INSTRUCTIONS YOU WILL NEED Allen key Torx Key, T15 No.6,5,4 NOT INCLUDED Support cable Display NUMBER OF PERSONS REQUIRED... -
Page 5: List Of Parts
SMS CASING COMPLETE TOP MOUNTED Back to Back LIST OF PARTS A1 (1x) A2 (1x) A3 (1x) B1 (4x) -
Page 6: Optional Items
6 SMS CASING COMPLETE TOP MOUNTED Back to Back OPTIONAL ITEMS SCREW LIST OPTIONAL ITEMS OPTIONAL ITEMS (SCREW LIST) (8x) (4x) (2x) (2x) (2x) (1x) (1x) (2x) (4x) (4x) (8x) (8x) (8x) (8x) SCREW LIST (4x) - Page 7 SMS CASING COMPLETE TOP MOUNTED Back to Back Prepare casing for mounting Remove front and back cover Remove S10 (8x)
- Page 8 8 SMS CASING COMPLETE TOP MOUNTED Back to Back Procedure for Mounting Casing using Cables (Cables not included) Support Cut 4x pieces cable Ensure strength of cable before mounting Pass one end of each cable through each corner plate...
- Page 9 SMS CASING COMPLETE TOP MOUNTED Back to Back Casing can be hung floor-ceiling/ wall-ceiling or between wall-wall Unit between floor-ceiling Unit between wall-wall H-min. H-min. H-min. Follow product dimensions (page18) for dimensions...
- Page 10 10 SMS CASING COMPLETE TOP MOUNTED Back to Back Ensure strength of ceiling/ wall-anchors Min 70 mm Min 70 mm Continue from page 15, step 14...
- Page 11 SMS CASING COMPLETE TOP MOUNTED Back to Back Procedure for Mounting Casing using Ceiling Pipe (Ceiling Pipe not included) (4x) (2x) (2x) (4x) (2x) (4x)
- Page 12 12 SMS CASING COMPLETE TOP MOUNTED Back to Back Mount ceiling-plate according to direction of display Edge parallel to display Min 70 mm Min 70 mm...
- Page 13 SMS CASING COMPLETE TOP MOUNTED Back to Back (4x)
- Page 14 14 SMS CASING COMPLETE TOP MOUNTED Back to Back Adjust height (1x) (1x) (2x)
- Page 15 SMS CASING COMPLETE TOP MOUNTED Back to Back Mount brackets on display Display No. 1 S13/ Mount brackets on display Display No. 2 S13/...
- Page 16 16 SMS CASING COMPLETE TOP MOUNTED Back to Back Guide and attach cable Centre and mount display No.1 and display No.2 on frame...
- Page 17 SMS CASING COMPLETE TOP MOUNTED Back to Back (8x)
- Page 18 18 SMS CASING COMPLETE TOP MOUNTED Back to Back Procedure for Tilt Adjustment in Cable-mounted Casing Loosen Adjust Tighten...
-
Page 19: Product Dimensions
SMS CASING COMPLETE TOP MOUNTED Back to Back PRODUCT DIMENSIONS Technical drawing (mm/inch) Casing Complete Top Mounted Back to Back 42-43" 4,05 6,69 25,23 All dimensions in mm. Technical drawing (mm/inch) Casing Complete Top Mounted Back to Back 48-49" 4,05... - Page 20 SMS CASING COMPLETE TOP MOUNTED Back to Back PRODUCT DIMENSIONS 4,05 6,69 All dimensions in mm. SMS Smart Media Solutions AB Högbergsgatan 26B, 116 20 Stockholm, Sweden www.smartmediasolutions.com mailto:info@smartmediasolutions.com...
