INSTALLATION AND
ADJUSTMENT MANUAL
M000261
230-001-42 SMS Func M Motor Flipster EU
DE Handbuch für Installation und Anpassung
IT Manuale per l'installazione e la regolazione
ES Manual de instalación y ajuste
FI Asennus- ja säätöohje
FR Manuel d'installation et de réglage
NL Handboek voor installatie en instellingen
PL
RUS
ARB
SE Monterings- och justeringsmanual
GR
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SMS Func M Motor Flipster
Summary of Contents for SMS Func M Motor Flipster
- Page 1 INSTALLATION AND ADJUSTMENT MANUAL M000261 230-001-42 SMS Func M Motor Flipster EU DE Handbuch für Installation und Anpassung IT Manuale per l'installazione e la regolazione ES Manual de instalación y ajuste FI Asennus- ja säätöohje FR Manuel d’installation et de réglage...
- Page 2 Advertencia Avertissement El montaje del producto no es responsabilidad de SMS Smart Media Solutions AB y es muy Le montage doit impérativement être effectué de façon correcte et ne relève pas de la importante que el producto sea montado correctamente. El montaje incorrecto puede responsabilité...
- Page 3 Sulla ricevuta devono essere chiaramente leggibili nome be clearly legible on the receipt. The owner is to pay the cost of returning the product to SMS, while del fornitore e data d’acquisto. Le spese di spedizione a SMS sono a carico dell’acquirente;...
- Page 4 4 SMS FUNC M MOTOR FLIPSTER EU Declaration of conformity Declaración de conformidad DICHIARAZIONE DI CONFORMITÁ Manufacturer: SMS - Smart Media Solutions AB El fabricante: SMS - Smart Media Solutions AB Produttore : SMS Smart Media Solutions AB Hästholmsvägen 32, 5th Floor Hästholmsvägen 32, plan 5...
-
Page 5: When Using
SMS FUNC M MOTOR FLIPSTER EU 5 Instructions for use Caution! Risk of crushing To heighten the display, Attenzione! Rischio di schiacciamento ¡Precaución! Riesgo de aprisionamiento press arrow up! Attention ! Risque d'écrasement Achtung! Risiko des Zerquetschens Varoitus! Puristumisvaara Down... -
Page 6: You Will Need
6 SMS FUNC M MOTOR FLIPSTER EU ASSEMBLY INSTRUCTIONS YOU WILL NEED No. 3 No. 4 No. 5 17 mm NOT INCLUDED Max. weight 50 kgs Display (1x) NUMBER OF PERSONS REQUIRED... -
Page 7: List Of Parts
SMS FUNC M MOTOR FLIPSTER EU 7 LIST OF PARTS (1x) (4x) (4x) (1x) (1x) (2x) -
Page 8: Screw List
8 SMS FUNC M MOTOR FLIPSTER EU LIST OF PARTS (cont.) (1x) (2x) (1x) (1x) [M6x10] [M8x30] [M6x10] (12x) (4x) (6x) SCREW KIT SCREW LIST K1 SCREW KIT Wheel pin Double sided tape 2x Cable hook Screw M6x10 Screw M8x30... - Page 9 SMS FUNC M MOTOR FLIPSTER EU 9 Mount wheels (4x) Dismount storage cover...
-
Page 10: Front View
10 SMS FUNC M MOTOR FLIPSTER EU Mount main frame to stand S1 [M6x10] S1 [M6x10] (6x) [M6x10] Front view Back view... -
Page 11: Attach Handles
SMS FUNC M MOTOR FLIPSTER EU 11 Loosen Dismount motor cover Prepare bracket for mounting Attach handles (6x) (6x) [M6x10]... - Page 12 12 SMS FUNC M MOTOR FLIPSTER EU Mount bracket on display Ensure arrow on display bracket points towards top of display Hole pattern for mounting [Vesa 400x400] [Vesa 300x300] No cable obstruction for display bracket installation S2 (4x) (4x) [M8x30]...
- Page 13 SMS FUNC M MOTOR FLIPSTER EU 13 Mount S3 (2x) in upper holes S3 (2x) Up (4x) [M6x10] Mount display on floor stand...
- Page 14 14 SMS FUNC M MOTOR FLIPSTER EU Tighten all S1 (2x) bottom holes Tighten all (4x) Secure display S1 [M6x10]...
- Page 15 SMS FUNC M MOTOR FLIPSTER EU 15 Mount cover S1 [M6x10] (2x) [M6x10] Mount tablet/ laptop shelf E2 (1x) S1 [M6x10] (2x) [M6x10]...
- Page 16 16 SMS FUNC M MOTOR FLIPSTER EU Mount cover Padlock optional Close cover Storage Use space for cable storage...
- Page 17 SMS FUNC M MOTOR FLIPSTER EU 17 Attach remote holder Attach 2-sided tape to underside of remote D2 (2x) D1 (1x) (2x) Guide cable (i) Attach cable hook (ii) Guide cable Ensure cable is long enough for display run...
-
Page 18: Display Rotation
18 SMS FUNC M MOTOR FLIPSTER EU DISPLAY ROTATION Landscape - Portrait +/- 90°... - Page 19 SMS FUNC M MOTOR FLIPSTER EU 19 Set Motors to Zero (optional) Caution Caution Caution DOWN DOWN DOWN 6-7 sec Proceed to next step...
-
Page 20: Product Dimensions
20 SMS FUNC M MOTOR FLIPSTER EU PRODUCT DIMENSIONS 23,62 43,23 1098 All dimensions in mm. Dimensions in [brackets] are in inches. SMS Smart Media Solutions AB Hästholmsvägen 32, 5th floor, SE-131 30 Nacka, Sweden www.smartmediasolutions.se...
