Silver-Line SL-8 Floor Sander
Turn off the sander & unplug from outlet
Bend the Silver-Line SL-8 sheet in the paper bender located on the drum cover
(pictured)
Tilt the SL-8 back onto the handle and lift the drum cover for easy installation
Roll the drum until the paper slot is facing you and adjust the cams so the arrows
printed on the cams are facing you. The left arrow should point down, while the right
arrow points up.
Insert one end of the paper into the slot (pictured) and turn the drum around so
that the paper wraps around the drum. Insert the other end into the slot and
push both ends into the slot until the paper is snug on the drum. When using 20
grit or coarser paper, insert the top of the sheet first and then install the bottom
half, it will insert easier.
Using a 7/16" open wrench turns the left cam down ¼ turn, then turn the right cam
up ¼ turn (pictured). As you turn the second cam you will see the paper pull tight
into the drum. You must turn both cams a full ¼ turn to secure the paper.
Turning the cams more than the ¼ turn will not make the paper any tighter on the
drum, ¼ turn on each cam is all you need to attach the sheet. Turning the cams
too much can cause the cams to come completely around and loosen the paper.
Lower the drum cover and return the sander to its upright position resting on the
rear of the chassis.
Plug the machine into an outlet, turn it on and slowly lower the drum to the surface being sanded as you
walk forward. Lift the drum off the floor as you reach the end of the room, walk backwards on the same
path and lower the drum to sand the floor as you return to the other end of the room. Sand in both
directions with the Silver-Line SL-8 floor sander!
To remove used paper, reverse the process.
For very coarse paper, (12 & 16 grit) it may be necessary to remove grit to insert the paper into the slot.
First, bend the paper as instructed. Second, put on safety glasses and remove the grit by placing the
paper on a hard surface (grit up) and hammering the grit off the flaps until manageable. Continue
installation of the paper.
Problem: The SL-8 is not holding paper correctly.
Solution: Clean out cam slot for full operation!
Installation of paper on the
Troubleshooting your SL-8:
