ADI PRO 0E-DRWD319 User Manual

DOOR/WINDOW SENSOR
USER MANUAL
Specifications
Frequency
Battery
Battery Life
Operating Temperature
Operating Humidity
Magnet Gap
Supervisory Signal Interval
Compatibility
Overview
The 0E-DRWD319 door window sensor is designed for compatibility with
Interlogix, GE and Qolsys control panels that receive 319.5MHz RF protocol.
Enrolling
To enroll the sensor, set your panel into program mode. Then go to the Learn Sensors menu. Refer to your specific alarm panel manual for details
on these menus. With the battery installed, activate the case tamper by loosening the screws, turning them counterclockwise, and then to
remove the top cover, grasp it from the sides of the cover near the screws and lift up then set back down. See battery replacement section for
reference as needed. You will hear a click when the case latches are engaging and disengaging. Repeat until the panel responds to the sensor.
Then select the appropriate sensor group and number.
Mounting
One side of the sensor is marked with 3 lines; this indicates the location of the reed switch. The magnet should be mounted facing this side of
the sensor, and it must be no further than 5/8" (15.875mm) from the sensor.
Included with this device is double sided tape for the contact and the magnet. Choose a suitable location for the sensor by following the
procedure in the section "Testing the Sensor" ensuring desired signal strength is achieved. For reliable bonding, ensure the surface is clean and
dry. Apply the tape to the sensor and then to the desired location. Apply firm pressure for several seconds.
Note: When mounting with double sided tape, ensure temperatures are above 50°F and will remain above 50°F for at least 24 hours to ensure proper
bond. After 24 hours, the bond will hold at lower temperatures.
Where possible, install sensors within 100 ft. (30m) of the panel. While a transmitter may have an open-air range of 500 ft. (150m) or more,
the environment at the installation site may have a significant effect on operational range. Changing a sensor location may improve wireless
communication.
Interchangeable Covers
The contact comes from the factory assembled with a white cover but included are optional brown covers. To open or change the cover, loosen
the screws by turning them counterclockwise, and then to remove the top cover, grasp it from the sides of the cover near the screws and lift.
Replace with the brown cover ensuring the Top (as marked on the inside of the cover) points away from the battery. You should hear a click when
the cover engages and disengages from the sensor. You do not need to replace the back plastic. To replace the magnet cover, you will need to
gently pry the white cover off with a flat head screwdriver and snap the brown cover in place.
Testing the Sensor (Test Weekly)
The sensor test verifies proper communication between the sensor and the panel/receiver. To test the sensor, refer to the specific panel/receiver
documentation and do the following:
1. Put the panel/receiver into sensor test mode.
2. Open the door/window the sensor is protecting. The sensor transmits a signal.
3. Listen for siren beeps from the control panel to determine the appropriate response.
4. Exit sensor test mode.
Note: Removing the cover will trigger a zone tamper signal to the control panel.
ADI PRO TECHNICAL SUPPORT: 1.833.574.9124 | WEBSITE: adiglobal.com/adiexclusivebrands
319.5MHz
3V lithium CR2032
5-8 years
32° to 120°F (0° to 49°C)
5-95% RH non-condensing
5/8" (15.875mm) max
60 min. (approximately)
Interlogix, GE and Qolsys receivers
0E-DRWD319
© 2024 ADI Global
