Page 1 Color Laser Printer CLP-600 Series CLP-600N/DSL Basic Model : CLP-600 SERVICE Manual Samsung Color Laser Printer The keynote of Product - Speed: A4, 20/20ppm(Color/Mono) Up to 2400dpi x 600dpi - Paper Path: FISO(Front-In Side-Out), Single Pass(Tandem) - Emulation: SPL-C(GDI) - System Controller: V320...
Page 2: Table Of Contents
Contents 1. Precautions 1.1 Safety Warning 1.2 Caution for safety 1.3 ESD Precautions 1.4 Super Capacitor or Lithium Battery Precautions 2. Product Specification 2.1 Product Overview 2.2 Specifications 2.3 Model Comparison Table 3. System Overview 3.1 System Structure 3.2 H/W Structure and Descriptions 3-13 3.3 Driver Board 3-15...
Page 3 Continued 4. S/W Structure and Descriptions 4.1 Architecture 4.2 Language Monitor 4.3 Status Monitor 4.4 Network Interface 4.5 Printer Driver <-> Status Monitor 4.6 System F/W Flow 4.7 Alarm Shortage 4.8 Error status 4.9 CRUM Overview 4.10 FW Upgrade 5. Disassembly and Reassembly 5.1 Precautions When Replacing Parts 5.2 Parts for Maintenance and Repair 5.3 Information Related in Disassembly and Assembly...
Page 4 Continued...
Page 5: Exploded Views And Parts List
Continued 7. Troubleshooting 7.1 Procedure of Checking the Symptoms 7.2 Solution of Image Problem 7.3 Paper Feeding Problems and Troubleshooting 7-10 7.4 Symptoms of Bad Operation and Troubleshooting 7-13 7.5 Treatment of Error Message 7-17 8. Exploded Views & Parts List 8.1 Exploded Views and Parts List 9.
Page 6: Precautions
High voltages and lasers inside this product are dangerous. This printer should only be serviced by a suitably trained and qualified service engineer. (2) Use only Samsung replacement parts There are no user serviceable parts inside the printer. Do not make any unauthorized changes or additions to the printer, these could cause the printer to malfunction and create electric shock or fire hazards.
Page 7: Caution For Safety
Take care not to cut or damage the power cable or plugs when moving the machine. (9) Use caution during thunder or lightening storms. Samsung recommend that this machine be disconnected from the power source when such weather conditions are expected. Do not touch the machine or the power cord if it is still connected to the wall socket in these weather conditions.
Page 8: Handling Precautions
1.2.4 Assembly / Disassembly Precautions Replace parts carefully, always use Samsung parts. Take care to note the exact location of parts and also cable routing before dismantling any part of the machine. Ensure all parts and cables are replaced correctly.
Page 9: Disregarding This Warning May Cause Bodily Injury
Failure to do so could cause the printer to tip or fall possibly causing personal injury or damaging the printer. (5) Do not install the printer on a sloping or unstable surface. After installation, double check that the printer is stable. Service Manual Samsung Electronics...
Page 10: Esd Precautions
2. Be sure to replace the battery with the same or equivalent type recommended by the manufacturer. 3. Super capacitor or Lithium batteries contain toxic substances and should not be opened, crushed, or burned for disposal. 4. Dispose of used batteries according to the manufacture’s instructions. Service Manual Samsung Electronics...
Page 11: Product Specification
5. Control/UI - LCD : SPLC-LED(9), 7Keys PDL-LCD, 6Keys - CMM : ICC, sRGB Pantone(PDL) 6. Other - Inferface : USB 2.0 USB 2.0 + P1284(PDL) - Util : MS Family, Mac/Linux, Smart Monitor, Local&NW RDS Service Manual Samsung Electronics...
Page 12: Specifications
Mono : More than 300K pages, Color : More than 300K pages * Print speed will be affected by Operating System used, computing performance, application software, connecting method, media type, media size and job complexity. * Cardstock/Envelope : Half Speed ** Sound Pressure Level, ISO 7779 Service Manual Samsung Electronics...
Page 13: Controller Specification
180-264 VAC/ 90~132VAC Input frequency 50/60 MHz Frequency tolerance +3Hz Power Consumption Printing : 55Wh(AVG) Power Save : Less than 35Wh 2.2.4 Environmental Range Items Operating Storage Temperature 15~32.5 ˚C(50-90 ˚F) -20~40 ˚C (-4~104 ˚F) Humidity 20~80%RH 10~80%RH Service Manual Samsung Electronics...
Page 14: Accessory Items
2 steps for install/replacing Dime screw Pick-up Roller Yield 50,000 pages None Life detect None Replace method 3 steps for install/replacing Options CLP-600 CLP-600N Memory Second Cassette Network Option Standard Wireless Network Dealer option Hard Disk Duplex Unit Accessory Items Service Manual Samsung Electronics...
Page 15: Paper Handling Specifications
O : Supported 2.2.6.2 Input Capacity Items Descriptions Remarks Cassette(FCT) 250 sheets Paper 100 sheets Transparencies Envelopes 10 sheets Labels 10 sheets Option Cassette(SCT) 500 sheets 2.2.6.3 Output Capacity Items Descriptions Remarks Face Down 250 sheets Service Manual Samsung Electronics...
Page 16: Model Comparison Table
SuSE 8.2~9.2 and Fedora Core 1~3) Mac OS X 10.3 and above Mac OS X 8.6 and above Default Driver SPL-C (Samsung Printer Language Color) SPL-C (Samsung Printer Language Color) for Win WHQL Windows 2000/XP/2003 Windows 2000/XP/2003 Language SPL-C: Win(English, German, French, Spanish, Italian,...
Page 17: System Overview
Fuser Color Regi Color Regi Sensor Sensor DEV. - Black LSU:4Beam LSU:4Beam Waste Tank Waste Tank MPF Path Paper Paper SMPS SMPS Charge Roll Charge Roll Feeder Feeder Cassette Path Cassette Path Cassette Cassette SCT Path Service Manual Samsung Electronics...
Page 18 System Overview 3.1.2 Sensor Exit Thermostat Thermistor Color Regi (2EA) CRUM (4EA) CRUM Temperature MPF paper empty FCF paper empty Service Manual Samsung Electronics...
Page 19 * Capacity : 500 Sheets (Standard paper 75mg/m bond) * Paper Size : A4, Letter * Paper Weight (average) : 75 to 90g/m (20 to 24lb) * Paper Type : General Printing Paper * Additional Function : Paper Empty Sensor Service Manual Samsung Electronics...
Page 20 * Drives : Toner Cartridge, PTB unit, Fuser, Feeder 11) DEVE Drive Unit This motor drives, by way of a gearbox, the toner cartridges and PTB cleaning cam. > Spec. * Power : 20W Max (24V) * Drives : DEV (4 Color)/PTB Cleaning) Service Manual Samsung Electronics...
Page 21 These are activated in sequence as required by the printing process. 16) DEVE CRUM PBA This detects new or used toner cartridges and also checks that cartridges are approved parts. If a toner cartridge is not suitable for the machine an error message is displayed. Service Manual Samsung Electronics...
Page 22 Polygon Motor Motor LSU energy : ~ 0.5uJ/cm^2 C OPC Collimating Collimating OPC exposed potential : ~ 50V Lens Lens M OPC Y OPC Laser Laser Cylindrical Cylindrical Diode Diode (Dual (Dual Mirror Mirror Beam) Beam) Service Manual Samsung Electronics...
Page 23: Developing Roller
Roller diameter : •’14mm Roller resistivity : ~ 10^7 ohm-cm Belt resistivity : 10^9 ~ 10^11 ohm-cm Paper sensing by attraction roller Environment sensing by Y-transfer roller Transfer unit life : 35K Waste Tank Transfer Belt Attraction Roller Service Manual Samsung Electronics...
Page 24 System Overview 5)Fusing E-coil fusing system -> short warm-up time (45sec) Pressure roller Warm- up time (80sec) Heat roller CLP- 500 CLP- 600 Service Manual Samsung Electronics...
Page 25: Toner Cartridge
Waste toner tank Cleaning Blade Charge Roller OPC Drum Shaft OPC Dr. Blade Gap maintenance (200um) pressure Spring(driving part) Supply belt Developing roller Supply roller supporter Supply belt Supply belt LSU Beam Toner tank Driving shaft Service Manual Samsung Electronics...
Page 26 Maintenace of developing gap : Maintenace of developing gap by Gap-ring which is located at the ends of developing roller Pressure Spring Cam-Gear Driving Gear Case Developing Roller Sheet Waste Sus. Blade Gap-Ring High voltage contact point High voltage contact (Developing Roller) point (Supply Roller) Service Manual 3-10 Samsung Electronics...
Page 27: Drive Roller
Management of waste toner : The Waste Toner Tank Be equipped Cleaning Blade Cleaning Blade Transfer Roller Bk Transfer Roller C Cleaning Backup Roller Cleaning Blade Transfer Roller M Transfer Roller Y Waste Toner Tank Waste Toner Tank Tension Roller Service Manual 3-11 Samsung Electronics...
Page 28 System Overview Transfer Voltage Control : ADC Control on Electric Sponge Roller Accomplishing Auto Color Registration By sensor in Handle-Unit PTB Drive Gear Handle-Unit Terminals in Transfer Roller PTB Draw Connector Terminal in PCR Service Manual 3-12 Samsung Electronics...
Page 29: H/W Structure And Descriptions
Standard SDRAM capacity is 32MB 5. Interface USB 2.0 6. Option Interface PCI ETHERNET 10/100BASE-TX by SAMSUNG PCI ETHERNET 10/100BASE-TX + W-LAN(IEEE 802.11b) by SAMSUNG 7. Control Panel 16 x 2 LCD Panel LED7+Key3 8. H/W RM7065 - 466MHz, CPU BUS 64-BIT 100MHz...
Page 30 BITSTREAM ENGLISH for PCL5C None for KOREAN 18. OPTION None 19. HOST INTERFACE IEEE1284(including ECP) B-TYPE STANDARD PARALLEL 20. SERIAL USB2.O 21. OPTION PCI-Based Ethernet 10/100BASE-TX by SAMSUNG NETWORK PCI-Based Ethernet 10/100BASE-TX + W-LAN(IEEE 802.11b) Service Manual 3-14 Samsung Electronics...
Page 31: Driver Board
It also activates sensors and transmits their signals to the main board. Driver Board Fan Driver Fuser/ SMPS Fan Solenoid Pickup/MP/DUP Driver Solenoid Clutch Feed/Y_DEVE Clutch Driver Stepping Stepping Motor Main Motor Driver MP_EMPT/ Sensor EXIT/EMPT/ Driver FEED Sensor Service Manual 3-15 Samsung Electronics...
Page 32: Description Of Operation
3.3.2.4 FAN Drive The driver board drives the fans for Fuser and SMPS. 3.3.2.5 Sensor Activation The driver board activates MP_EMPT / EXIT / EMPT / FEED Sensors and transmits their signals to the Main Board. Service Manual 3-16 Samsung Electronics...
Page 33: Deve Crum
- Through "device select code" and "chip enable input", it judges whether a correct developer with correct color is mounted or not. 3.4.2.3 Measurement of the amount of toner used - The Deve CRUM records the information of dot count into EEPROM, informing the amount of toner used and left over. Service Manual 3-17 Samsung Electronics...
Page 34: Belt Crum
3.5.2.2 Measurement of belt usage - By recording the rotation number of the belt into EEPROM, the belt CRUM lets you know the number used and the number that may be used. Service Manual 3-18 Samsung Electronics...
Page 35 System Overview Developer CRUM Interface Board DEVE CRUM Main Service Manual 3-19 Samsung Electronics...
Page 36 System Overview Developer CRUM Interface Board DEVE CRUM Main Service Manual 3-20 Samsung Electronics...
Page 37 System Overview HRS, 2.0mm,2R, 22PIN, Straight Service Manual 3-21 Samsung Electronics...
Page 38 System Overview Fusible +24V +24VF Cover S/W Fusible +5VL +24VF GNDA Service Manual 3-22 Samsung Electronics...
Page 39 AC_Duty,f PWM AC_Enable ENB_Deve_AC_K PWM_Deve_DC_K AC_Enable PWM_Charger PWM_Charger PWM_Trasfer PWM_T_Y PWM_T_M PWM_Trasfer PWM_Trasfer PWM_T_C PWM_T_K PWM_Trasfer PWM_Attraction PWM_ATTR+ ENB_ATTR- ENB_Attraction Description Description Trasfer_Read A_READ_T_Y A_READ_Charger Charger_Read_BK Charger_Read_Color DGND A_READ_ATTR Attraction_Read Ground DGND DGND Ground Power Power Service Manual 3-23 Samsung Electronics...
Page 40: Hvps
System Overview HVPS +24V Engine Board Pull Up /PWM_T ? DM7407N /PWM_Attr DM7407N /PWM_Deve DM7407N /PWM_Charge DM7407N /PWM_AC DM7407N /PWM_AC Vp-p DM7407N 73.7㎲ Service Manual 3-24 Samsung Electronics...
Page 41 System Overview HVPS +24V Pull Up Engine Board /Enb_Attr(-DC) DM7407N /Enb_Deve AC DM7407N Service Manual 3-25 Samsung Electronics...
Page 42 System Overview Voltage Read Analog Port Analog Port 300Ω Analog Port 300Ω 300Ω Hvps Board Engine Board 2KΩ 2KΩ 2KΩ Service Manual 3-26 Samsung Electronics...
Page 43: S/W Structure And Descriptions
S/W Structure and Descriptions 4. S/W Structure and Descriptions Printer Driver Language Monitor Status Monitor Printer F/W Network Card F/W Service Manual Samsung Electronics...
Page 44 Status Monitor Request Job Status Job Table Status Monitor Data Flow Set option value enable/disable Set last error status polling interval System Status Monitor Printer Driver Registry Get option value Get last error status enable/disable polling interval Service Manual Samsung Electronics...
Page 45 Auto Color Registration ACR module pattern printing H Sync. Video data Color Registration adjustment P Sync. Page Sync. modify Video signal L Sync. Line Sync. modify generator clock Video Clock Freq. modify temperat SMPS Fan temperature control sensor Service Manual Samsung Electronics...
Page 46 100 ~ 110 % 110 %~ Toner (C,M,Y,K) Ready Yellow Toner Low Replace Yellow Toner Yellow Toner Empty Transfer Belt Replace Transfer Belt Soon Replace Transfer Belt Fuser Replace Fuser Soon Replace Fuser Pickup Rollers Replace MP Pick-Roller (MP/Tray1/Tray2) Service Manual Samsung Electronics...
Page 47 S/W Structure and Descriptions Service Manual Samsung Electronics...
Page 48: Disassembly And Reassembly
5.4.10 HVPS (High Voltage Power Supply) page(5-29) 5.4.11 Main PBA page(5-32) 5.4.12 PBA Sub-Driver page(5-35) 5.4.13 CRUM Unit page(5-37) 5.4.14 SMPS page(5-39) 5.4.15 Holder AC Unit page(5-40) 5.4.16 LSU page(5-41) 5.4.17 MPF Unit page(5-43) 5.4.18 Housing-M-Pick up page(5-46) Service Manual Samsung Electronics...
Page 49: Precautions When Replacing Parts
5.1.1 Precautions when assembling and disassembling * Use only approved Samsung spare parts. Ensure that part number, product name, any voltage, current or temperature rating are correct. Failure to do so could result in damage to the machine, circuit overload, fire or electric shock.
Page 50: Parts For Maintenance And Repair
When a part is replaced it is necessary to reset the 'life used' that is stored in memory. * How to initialize a the value of part's life span: From the control panel, select the following items in order: Menu-Setup - Maintenance - Check other - (Select a desired part) - Reset Service Manual Samsung Electronics...
Page 51: Printer Cleaning
* Do not touch transfer roller when cleaning inside of machine. If transfer roller gets dirty, printing quality could be low. * Please refer to the User Manual for cleaning instructions. Service Manual Samsung Electronics...
Page 52: Information Related In Disassembly And Assembly
(hot water sets the toner). Do not ing the fuser. touch the developer roller surface as cont- amination will reduce print quality. Take care not to damage the roller's surface when installing or removing a toner car- tridge. Service Manual Samsung Electronics...
Page 53: Screws Used In The Printer
The screws listed in the table below are used in this printer. Please ensure that, when you disassemble the printer, you keep a note of which screw is used for which part and that, when reassembling the printer, the correct screws are used in the appropriate places. Service Manual Samsung Electronics...
Page 54 Disassembly and Reassembly Service Manual Samsung Electronics...
Page 55 Disassembly and Reassembly Service Manual Samsung Electronics...
Page 56 Disassembly and Reassembly Service Manual Samsung Electronics...
Page 57 1. Pull the side handle to open the Right Cover Ass'y and then press down firmly unit the Toner Cartridges are ejected. Right Cover Ass’y 2. Removing a Toner Cartridge(K, C, M, Y) NOTICE : Take care not to damage the rollers. Keep the Toner Cartridge on the flat surface. Service Manual 5-10 Samsung Electronics...
Page 58 3. The Toner Cartridges are located, as shown below. Black Toner Cartridge Cyan Toner Cartridge MargentaToner Cartridge YellowToner Cartridge 4. PTB Unit by releasing the PTB Lock Lever on left side of the Right Cover Ass'y. PTB Unit Lock Lever Service Manual 5-11 Samsung Electronics...
Page 59 Disassembly and Reassembly 5. Take out the PTB Unit, as shown below. Service Manual 5-12 Samsung Electronics...
Page 60: Disassembly Procedure
Disassembly and Reassembly 5.4 Disassembly Procedure 5.4.1 Front Cover Ass'y 1. Pull the Cassette out of the printer. Cassette 2. Carefully release the three Hooks using a flat bladed screwdriver, as shown below. Hook Service Manual 5-13 Samsung Electronics...
Page 61 Disassembly and Reassembly 3. Remove the Cover-M-Front in the direction of arrow, as shown below. Cover-M-Front 4. Remove the three screws located inside the Cover-M-Deco. Screw Screw Screw Service Manual 5-14 Samsung Electronics...
Page 62 5. First lift the printer, carefully release the Hooks on the both side using a flat bladed screwdriver and then remove the Cover- M-Deco. Cover-M-Deco 6. Take care to unplug the one connector from the LCD PBA. Connector (LCD PBA) Cover-M-Deco Service Manual 5-15 Samsung Electronics...
Page 63 1. Remove the four screws from the OP Cover Ass'y and remove it. OP Cover Ass’y 2. Remove the nine screws from the LCD PBA and then remove the Keys and LCD PBA, as shown below. Cap2 LCD PBA OPE Key2 Cap1 OPE Key1 Service Manual 5-16 Samsung Electronics...
Page 64: Rear Cover
1. Remove the four screws, as shown below. Rear Cover Screw Screw Screw Screw 2. First lift the printer, carefully release the Left Side Hook using a flat bladed screwdriver, as shown below. Left Side Hook Service Manual 5-17 Samsung Electronics...
Page 65 Disassembly and Reassembly 3. Release the Middle Hook and then carefully release the Right Side Hook in the direction of arrow, as shown below. Right Side Hook Middle Hook Service Manual 5-18 Samsung Electronics...
Page 66: Right Cover
* Remove the Rear Cover (Refer to 5.4.3) 1. Remove the one screw from the left side hinge, as shown below. Right Cover Ass’y Screw 2. Remove the one screw from the right side hinge, as shown below. Hinge Screw Service Manual 5-19 Samsung Electronics...
Page 67 Disassembly and Reassembly 3. First lift the left side of the Right Cover Ass'y and then pull the right side of the Right Cover Ass'y in the direction of arrow, as shown below. Right Cover Ass’y Service Manual 5-20 Samsung Electronics...
Page 68: Left Cover
* Remove the Rear Cover (Refer to 5.4.3) 1. Remove the four screws, as shown below. Screw Screw Screw Screw 2. Release the Left Cover in the direction of arrow, as shown below. Left Cover Service Manual 5-21 Samsung Electronics...
Page 69 >> Before disassembling it : * open the Right Cover Ass'y (Refer to 5.3.3) 1. Open the Exit Cover. Exit Cover 2. Release the two Handle-Fix-Fuser on the both end, as shown below. Handle-Fix-Fuser Handle-Fix-Fuser Service Manual 5-22 Samsung Electronics...
Page 70 Disassembly and Reassembly 3. Pull the Fuser out of the Printer. Fuser Service Manual 5-23 Samsung Electronics...
Page 71: Top Cover
* Remove the Left Cover (Refer to 5.4.5) 1. Open the Exit Cover. Exit Cover 2. Remove the two screws located left side the Top Cover Ass'y, as shown below. Top Cover Ass’y Screw Screw Service Manual 5-24 Samsung Electronics...
Page 72 Disassembly and Reassembly 3. Remove the three screws located top and right side the Top Cover Ass'y, as shown below. Then remove the Top Cover Ass'y. Top Cover Ass’y Screw Screw Screw Service Manual 5-25 Samsung Electronics...
Page 73: Exit Cover
Disassembly and Reassembly 5.4.8 Exit Cover >> Before disassembling it : * Remove the Top Cover Ass'y (Refer to 5.4.7) 1. If necessary, remove the Exit Cover in the direction of arrow, as shown below. Exit Cover Service Manual 5-26 Samsung Electronics...
Page 74: Main Drive Ass'y
NOTICE : Be aware of the E-Ring and Pin to ensure they are not lost. 2. Unplug the four connectors from the two OPC Drive Motors, Fuser Drive Motor and DEVE Drive Motor, as shown below. OPC Drive Fuser Drive Motor Motor DEVE Drive Motor OPC Drive Motor Service Manual 5-27 Samsung Electronics...
Page 75 Disassembly and Reassembly 3. Remove the six screws from the Main Drive and then pull the Main Drive Ass'y, as shown below. Main Drive Ass’y Screw Screw Screw Screw Screw Screw Service Manual 5-28 Samsung Electronics...
Page 76: Hvps (High Voltage Power Supply)
* Remove the Front Cover Ass'y (Refer to 5.4.1) 1. Remove the five screws from the HVPS. HVPS Screw Screw Screw Screw Screw 2. Unlatch the four Hooks in the direction of arrow, as shown below. Hook Hook Hook Hook Service Manual 5-29 Samsung Electronics...
Page 77 Disassembly and Reassembly 3. Unplug the one connector from the HVPS. HVPS 4. Carefully remove the HVPS from the Main Frame. Main Frame Service Manual 5-30 Samsung Electronics...
Page 78 Disassembly and Reassembly 5. The connectors are located, as shown below. To Main PBA <HVPS> Service Manual 5-31 Samsung Electronics...
Page 79 1. Remove the five screws from the Bracket Conn and remove it, as shown below. Bracket-Conn Screw Screw Screw Screw Screw 2. Unplug the all connectors and then remove the four screws from the Main PBA. Main PBA(with PCB Sub-PCI NPC) Screw Screw Screw Screw Service Manual 5-32 Samsung Electronics...
Page 80 3. Remove the two screws securing the Bracket-NPC from the Bracket-Cont Lower and then remove the Main PBA(with PCB Sub-PCI NPC), as shown below. Screw Bracket-Cont Lower Bracket-NPC Screw 4. Pull the PCB Sub-PCI NPC from the Main PBA, as shown below. Main PBA PCB Sub-PCI NPC Service Manual 5-33 Samsung Electronics...
Page 81: Cover Open
CRUM BD BLDC DEVE YM PTB Drawer Con Driver To PCI NPC CN200 Cover Open n24V_EN_Out Temp_Out SMPS <Main PBA> 6. The connectors are located PCB Sub-PCI NPC. To Main PBA Line <PCB Sub-PCI NPC> Service Manual 5-34 Samsung Electronics...
Page 82 1. Remove the three screws from the Bracket-Cont Lower and then remove it. Braket-Cont Lower Screw Screw Screw 2. Unplug the all connectors and remove the three screws from the PBA Sub-Driver and then remove it, as shown below. Screw Screw Screw PBA Sub-Driver Service Manual 5-35 Samsung Electronics...
Page 83 Disassembly and Reassembly 3. The connectors are located, as shown below. Exit SMPS Step Motor Fan Fuser To Main PBA Sol_MP Sol_Pickup Feed MP EMPT EMPT <PBA Sub-Driver> Service Manual 5-36 Samsung Electronics...
Page 84 * Remove the Bracket Conn (Refer to 5.4.11) 1. Unplug the connector from the Main PBA. CRUM BD Main PBA 2. First release the Hook and then remove the CRUM Unit in the direction of arrow. CRUM Unit Hook Service Manual 5-37 Samsung Electronics...
Page 85 Disassembly and Reassembly 3. Remove the PBA Sub-DEVE_CRUM from the Cover-CRUM BD, as shown below. PBA Sub-DEVE_CRUM Cover-CRUM BD Service Manual 5-38 Samsung Electronics...
Page 86 * Remove the Top Cover Ass'y (Refer to 5.4.7) 1. Remove the two screws from the SMPS and then pull the SMPS. Screw Screw SMPS 2. Unplug the all connectors from the SMPS and then remove the SMPS, as shown below. Service Manual 5-39 Samsung Electronics...
Page 87 1. Remove the two screws securing the Holder AC Unit and then remove the Holder AC Unit in the direction of arrow. Holder AC Harness Holder AC Unit Screw Screw 2. Unplug the Holder AC Unit connector from the SMPS, as shown below. Connector(Holder AC Unit) SMPS Service Manual 5-40 Samsung Electronics...
Page 88 1. Remove the four screws from the Housing-Middle Part and then remove it(with Duct Left Ass'y). Housing-Middle Part (with Duct Left Ass’y) Screw Screw Screw Screw 2. Remove the two screws from the LSU. Screw Screw Service Manual 5-41 Samsung Electronics...
Page 89 Disassembly and Reassembly 3. Unplug the three connectors from the LSU, as shown below. 4. Remove the LSU in the direction of arrow. Service Manual 5-42 Samsung Electronics...
Page 90: Gear Cover
* Open the Right Cover Ass'y (Refer to 5.3.3) 1. Unplug the Solenoid connector from the PBA Sub-Driver. PBA Sub-Driver MP Solenoid Connector 2. Remove the one screw from the Gear Cover and then remove it, as shown below. Screw Gear Cover Service Manual 5-43 Samsung Electronics...
Page 91 Disassembly and Reassembly 3. Remove the four screws from the MPF Unit and then remove it. Screw Screw Screw Screw MPF Unit 4. Remove the one screw securing the Solenoid-MP and then remove it. MPF Unit Solenoid-MP Service Manual 5-44 Samsung Electronics...
Page 92 5. When if only remove the Pick up Unit, first push the Idle toward the ends of shaft and take out the Pick up Unit in the direction of arrow, as shown below. Pickup Unit Idle Pickup Unit Service Manual 5-45 Samsung Electronics...
Page 93 1. First turning over, remove the Extension Spring using a Pincette, as shown below. Exension Spring 2. Pull the Housing-M-Pick up from the Bushing Feed and then remove it in the direction of arrow. Housing-M-Pickup Bushing Bushing Service Manual 5-46 Samsung Electronics...
Page 94 Disassembly and Reassembly NOTICE : When you reassemble the Housing-M-Pick up make sure that the let and of the Housing-M-Pick up fits into the Pick up Shaft, as shown below. Pickup Shaft Housing-M-Pickup Service Manual 5-47 Samsung Electronics...
Page 95: Alignment And Adjustments
Fuser Color Regi Color Regi Sensor Sensor DEV. - Black LSU:4Beam LSU:4Beam Waste Tank Waste Tank MPF Path Paper Paper SMPS SMPS Charge Roll Charge Roll Feeder Feeder Cassette Path Cassette Path Cassette Cassette SCF Path Service Manual Samsung Electronics...
Page 96 * The paper drive motor has been driving for longer than the time needed for the longest paper size and the exit sensor is not off. MPF Path Service Manual Samsung Electronics...
Page 97 * Paper could not be picked up from the MPF tray. * After pickup, a paper has been fed, but it doesn't reach the feed sensor in a certain time. * Feed sensor is faulty and does not detect paper. MPF Path Service Manual Samsung Electronics...
Page 98: Jam Removal
By selecting the correct paper types, most paper jams can be avoided. If a paper jam occurs, follow the steps outlined below: • Ensure that the adjustable guides are positioned correctly. • Do not overload the tray. Ensure that the paper is below the paper capacity mark on the right inside the tray. Service Manual Samsung Electronics...
Page 99 Close the access door should the installation paper which may be jammed in other parts of need to be halted for any reason. the printer. 7. Close the access door firmly. The printer will resume printing. Service Manual Samsung Electronics...
Page 100 2. Remove the jammed paper by pulling in the CAUTION: direction shown. To avoid tearing the paper, pull If the access door is not completely closed, the it out gently and slowly. printer will not operate. Service Manual Samsung Electronics...
Page 101 6. Close the access door firmly. The printer will resume printing. The fuser is hot! CAUTION: • If the top cover and access door are not completely closed, the printer will not operate. Service Manual Samsung Electronics...
Page 102 • If you leave the access door open for more than a few minutes, the OPC drum can be exposed to light. This will cause damage to the OPC drum. Close the access door should the installation need to be halted for any reason. Service Manual Samsung Electronics...
Page 103 6. After making sure that the access door is open, close the top cover. Make sure that it is secure- ly latched. CAUTION: • Do not touch the green surface, the OPC drum, Service Manual Samsung Electronics...
Page 104 • If you leave the access door open for more than a few minutes, the OPC drum can be exposed to light. This will cause damage to the OPC drum. Close the access door should the installation need to be halted for any reason. Service Manual 6-10 Samsung Electronics...
Page 105 5. Open the inner cover of Tray2. 7. Close the two jam covers. If you cannot find the jammed paper, or if there is any resistance removing the paper, stop pulling and continue. Service Manual 6-11 Samsung Electronics...
Page 106 12. After making sure that the access door is open. Close the top cover. 9. If you see the jammed paper, remove the paper from the printer by gently pulling it straight out as shown below. Service Manual 6-12 Samsung Electronics...
Page 107 Alignment and Adjustmens 13. Close the access door firmly. The printer will resume printing. CAUTION: If the top cover and access door are not completely closed, the printer will not operate. Service Manual 6-13 Samsung Electronics...
Page 108: Sample Pattern
Menu. 3. Press the scroll button until you see “Configuration ” on the bottom line. 4. Press the Enter button A demo page showing the printer ’s features and capabilities prints out. Service Manual 6-14 Samsung Electronics...
Page 109: Checking The Remaining Toner And Others
5 When ‘Check Others ’ displays on the bottom line,,press the Enter button 6 Press the scroll button until the item you want to check displays on the bottom line. 7 Press the Enter button The display shows the Page Count/Reset of item. Service Manual 6-15 Samsung Electronics...
Page 110: Understanding The Control Panel
•The printer is in Power Save mode, using less power.When a print job is received from the computer or if any button is pressed,the printer switches to on-line. •To deactivate the Power Save mode or change the power-saving time. Service Manual 6-16 Samsung Electronics...
Page 111 Or, if you have installed an invalid toner cartridge, a corresponding lamp turns on. Install only Samsung toner cartridges, designed for your printer. Otherwise, if you have installed the toner cartridge into improper cartirdge slot, a corresponding lamp turns on. Install the toner cartridge into each proper cartridge slot.
Page 112 If you want to ignore this warning, press this button. • The printer is off-line and cannot print. • The printer is in Power Save mode. When data is received, it switches to on-line automatically. Service Manual 6-18 Samsung Electronics...
Page 113: Using Control Panel Menus
Print PS Error Typeface LCD Language Calibration Reset Network Symbol Emulation Custom Color Default Set Lines Power Save Print Net CFG itch Auto Continue Point Size Jam Recovery Courier Altitude Adj. Auto CR Job Time Out Maintenance Service Manual 6-19 Samsung Electronics...
Page 114: Periodic Defective Image
Transfer Roller 43.90 mm periodic band Gap-ring 39.00 mm periodic band Pressure Roller 114.6 mm white/black spot Cleaning blade 1. OPC drum 2. Charger roller Doctor blade 4. Developing roller 3. Supply roller Service Manual 6-20 Samsung Electronics...
Page 115: How To Use Edc (Engine Diagnostic Control) Mode
1. In the driver for CLP-600 and CLP-600N on printers firmware V1.29 and above. - After installing driver, go to folder as following direction; C:\Program Files\Samsung\Samsung CLP-600 Series\SPanel\RCP -Then you will find "EDC.exe" - notice) If the driver is old, there maybe no folder as above. In that case, please install new driver after downloading from Web site.
Page 116 Cyan Dev DC Print Menu Map Black Dev DC Yellow Dev AC Magenta Dev AC Cyan Dev AC Black Dev AC Yellow Tr Magenta Tr Cyan Tr Black Tr Paper Charger + Paper Charger - Service Manual 6-22 Samsung Electronics...
Page 117: Motor Test
Press the "Enter" key to run the test. The test is stopped by pressing the "Upper Level" key. e) Pressing the "Upper Level" key when the test is already stopped will return to step 'c' above. f) Pressing the "Upper Level" key again will return to the EDC main menu. Service Manual 6-23 Samsung Electronics...
Page 118: Actuator Test
Press the "Enter" key to run the test. The test is stopped by pressing the "Upper Level" key. e) Pressing the "Upper Level" key when the test is already stopped will return to step 'c' above. f) Pressing the "Upper Level" key again will return to the EDC main menu. Service Manual 6-24 Samsung Electronics...
Page 119: Sensor Test
Press the "Enter" key to display the sensor status. If the sensor actuator is moved the displayed status will change to reflect the new sensor position.. e) Pressing the "Upper Level" key will return to step 'c' above. f) Pressing the "Upper Level" key again will return to the EDC main menu. Service Manual 6-25 Samsung Electronics...
Page 120 • The LSU Motor Lock Time is a maximum 15 seconds depending on the environment. It may take over 15 seconds until the <Succeed> or <Failed> message is displayed. • For safety - after printing a test pattern if you need to return to EDC mode turn the printer off and then re-enter EDC. Service Manual 6-26 Samsung Electronics...
Page 121: Test Print
For safety - after printing a test pattern if you need to return to EDC mode turn the printer off and then re-enter EDC Mode by turning power on whilst holding in the "Enter" key. Service Manual 6-27 Samsung Electronics...
Page 122 Pressing the "Upper Level" key again will return to the EDC main menu. * The allowed tolerance is commonly +/- 3%, this is the value Displayed, in case of "Dev AC", it is the value of Vpp. Service Manual 6-28 Samsung Electronics...
Page 123 → [Samsung CLP-600 Series] → [SmartPanel] → [set up printer] -. When PSU is executed, click on [Ctrl + A]. After that EDC program will be executed. -. After installing PSU, execute [EDC.exe] on [C:\Program Files\ Samsung\ Samsung CLP-600 Sereis\ Spanel\ PSU]. After that EDC program will be executed.
Page 124 6.9 PSU for Printer Settings Utility -. PSU lets you view and change printer settings from your computer’s screen. -. PSU window allows you to access all the information you need when using your printer. -. When you finish changing the settings, click send. a)Setting Tab -.Power Save: Determine how long it will take for the printer to go from standby to low power mode.
Page 125 b)Color Tab -.Manual Color Adjustment: Allows you to manually adjust the color contrast for each cartridge -.Auto Color Registration: Allows you to adjust the position of color texts or graphics to match the position of the printed colors to those on your screen...
Page 126 c)Check Tab -.Check items: Display the printednumber using items (Read Only) -.Configuration Print: Prints the current configuration of printer -.Test Print: Prints the Demonstration Page. (The demo page allows you to check to see if your printer is printing properly)
Page 127: Troubleshooting
"7.1.1 Basic Check List" OP Panel - No Power - LCD Module - Main PBA Ready Indicate Refer to "Error Message" Power Save "7.5 Error Message" Print Printing Refer to guality is "7.2 Solution of Image Problem" normal? Service Manual Samsung Electronics...
Page 128: Basic Check List
--> Refer to section 7.2 6. Check consumables (toner etc.). •Using the keys print the Information Page. --> Refer to 7.1.4 below for expected life of various consumable parts, compare this with the figures printed and replace as required Service Manual Samsung Electronics...
Page 129: Initial Inspection
1. Use only paper which is of a suitable quality, weight and size? See the user guide. 4. Check the overall condition of the printer 1. Is the printer properly maintained ? Clean the Paper Transport Passages. Any rollers with dirt surfaces should be cleaned or replaced. Service Manual Samsung Electronics...
Page 130 2. In order to calculate the number of images printed 1 is added to the appropriate counter every 30 seconds. The amount of waste toner is calculated based on the number of pixels in the image. 3. When the user replaces any of the consumable parts and resets the appropriate counter it starts again from 0. Service Manual Samsung Electronics...
Page 131: Solution Of Image Problem
Replace the Toner Cartridge. toner cartridge OPC Drum surface contaminated or damaged. Replace the Toner Cartridge. PTB Unit belt is contaminated or damaged. Replace the PTB Unit Belt. Fuser Unit is contaminated. Clean or replace the Fuser Unit. Service Manual Samsung Electronics...
Page 132 If problem persists replace the OPC Drum Poor toner transfer to PTB Unit Check and clean PTB Unit contacts. Re-install or replace the PTB Unit. PTB Bias voltage incorrect. Check and clean PTB Unit contact. Replace the HVPS. Service Manual Samsung Electronics...
Page 133 Open the covers, check and clean the Paper Path. Problem transferring intermediate image onto Check and clean T2 roller contacts paper Check T2 Solenoid and cam operation - ensure T2 comes properly into contact when solenoid operates. Service Manual Samsung Electronics...
Page 134 1) Creases : Replace the Guide Input. 2) Replace the Fuser Unit. 3) Check OPC, Drum, Toner Cartridge and PTB Unit for contamination and replace as required. Fault occurs in the MPF Tray Printing only. Replace the MPF Tray Unit. Service Manual Samsung Electronics...
Page 135 Replace T2 roller - Mark every 27.00 mm Replace Toner cartridge Laser Unit damaged Line repeats every 1~2 mm- Replace the LSU Unit. Damage or contemination of OPC drum Random line spacing- Replace the OPC Drum. Service Manual Samsung Electronics...
Page 136: Paper Feeding Problems And Troubleshooting
Roller with IPA or water. 4. Check the Feed Sensor is not 4. Replace the main PBA or Sensor. sticking by using the EDC Mode (When “JAM-0” occurs even though the paper feeds into the printer.) Service Manual 7-10 Samsung Electronics...
Page 137 • Check that the Exit unit is assem- bled properly and full functioning 4. If the Exit Sensor is defective. a and replace if necessary. Jam In Exit Area will occur and printing will stop. 4. Replace the Exit Sensor. Service Manual 7-11 Samsung Electronics...
Page 138 Exit Roller. 3. If the Bearing - Fuser or Gear - Fuser is damaged or 3. Check the SMPS and Main PBA if the Bearing Gear melted by excessive heat. is melted. Service Manual 7-12 Samsung Electronics...
Page 139: Symptoms Of Bad Operation And Troubleshooting
The fuser gears melt and the roller drive fails. Check and Cause Solution 1. The Fuser makes a noise and fails to operate, rollers - Replace the Fuser. may not rotate. - Replace the Main PBA. - Replace the SMPS. Service Manual 7-13 Samsung Electronics...
Page 140: Paper Empty Without Indication
2. Check the Cover Open sensor, connectors and cable 2. Replace the harness or microswitch as necessary. harness. Ensure that a signal reaches the main PBA 3. Use the EDC mode to test the actuator. 3. Replace the Sensor Board. Service Manual 7-14 Samsung Electronics...
Page 141 2. Replace cables or LCD Panel Ass'y. Replace the work check the display connectors and cable harness Main PBA. 3. Check if +24VDC or other Power Supplies are shorted 3. Replace the components used for +24VDC. out. Service Manual 7-15 Samsung Electronics...
Page 142 1. Replace the OPC Drum. Image Count value is over 50,000. Image Density may be reduced. It is possible to continue to print one Page at a time by pressing the “On-Line” button when it flashes. Service Manual 7-16 Samsung Electronics...
Page 143: Treatment Of Error Message
[Color] installed. designed for your printer. Or install the toner cartridge into each proper cartridge slot. Invalid An invalid paper transfer belt has been Only install Samsung paper transfer belts, Transfer Belt installed. designed for your printer. Service Manual 7-17...
Page 144 The printer is waiting for the user’s Load a sheet of print material and press the action before printing from the On Line/Continue button. You need to press Multi-purpose Tray using the manual the button for each page. feed mode. Service Manual 7-18 Samsung Electronics...
Page 145 After turn the printer off and then back on, installed or connected to the printer. reinstall the optional Tray2. Tray2 Jam Cover The optional Tray2 jam cover is open. Close the Tray2 cover firmly. Open Service Manual 7-19 Samsung Electronics...
Page 146 Exploded Views & Parts List 8. Exploded Views and Parts List (CLP-600N/DSL) Contents Main Front Cover Top Cover Right Cover Base Frame Main Frame Fuser Main Drive 8.10 Pick Up 8.11 Guide Paper 8.12 Cassette Unit...
Page 147: Main
Exploded Views & Parts List 8.1 Main...
Page 148: Front Cover
Exploded Views & Parts List 8.2. Front Cover (CLP-600N) (CLP-600)
Page 149: Top Cover
Exploded Views & Parts List 8.3. Top Cover...
Page 150: Right Cover
Exploded Views & Parts List 8.4. Right Cover...
Page 151: Base Frame
Exploded Views & Parts List 8.5. Base Frame...
Page 152: Main Frame
Exploded Views & Parts List 8.6. Main Frame...
Page 153: Fuser
Exploded Views & Parts List 8.7. Fuser...
Page 154: Main Drive
Exploded Views & Parts List 8.8. Main Drive...
Page 155: Mpf
Exploded Views & Parts List 8.9. MPF...
Page 156: Pick Up
Exploded Views & Parts List 8.10. Pick Up...
Page 157: Guide Paper
Exploded Views & Parts List 8.11. Guide Paper...
Page 158: Cassette Unit
Exploded Views & Parts List 8.12. Cassette Unit...
Page 159 Parts List Service Parts List (Model code : CLP-600N/DSL) SA : SERVICE AVAILABLE SNA : SERVICE not AVAILABLE DNA : DELIVERY not AVAILABLE Drawer# SEC-Code Description & Specification Location Service 8.1-1 JC97-02187A MEA UNIT-FRAME BASE;CLP-600,SEC,EXPORT,- M0013 8.1-2 JC97-02151A MEA UNIT-FRAME MAIN;CLP-600,SEC,EXPORT,- M0015 8.1-3...
Page 160 Parts List SA : SERVICE AVAILABLE SNA : SERVICE not AVAILABLE DNA : DELIVERY not AVAILABLE Drawer# SEC-Code Description & Specification Location Service 8.2-7 JC72-01197C PMO-M OPE KEY 1;CLP-600,ABS,SOLITARY BLU P0045 8.2-3 JC63-00613A COVER-_M_OP FRAME LCD;CLP-600,HIPS,T2.5, C0035 8.2-4 JC63-00642A SHEET-COVER OP LCD;CLP-600,PC SHEET,T0.5 S0011 8.2-8 JC72-01198C...
Page 161 M0020 8.6-15-1 JC61-01011A GUIDE-_M_PTB TERMINAL;CLP-600,ABS,2.0,23 G0044 8.6-15-2 JC70-00508A ELECTRODE-HV F;CLP-600,SUS304WPB,¥Õ5,L32 E0026 8.6-15-3 JC61-01010A GUIDE-_M_TERMINAL CH;CLP-600,ABS,2.0,15. G0053 8.6-15-4 JC97-01401A MEA UNIT-TERMINAL:TR;ML-5000A,SAMSUNG,KO 8.6-15-6 JC70-00513A ELECTRODE-HV E;CLP-600,SUS304WPB,¥Õ5,L32 E0025 8.6-16 JC61-01264A SPRING ETC-OPC F;CLP-600,SUS304 ,1.5,6.5 S0026 8.6-17 JC97-02403A MEA UNIT-DEV TERMINAL;CLP-600,SEC,EXPORT M0011 8.6-17-1 JC61-01008A GUIDE-_M_TERMINAL UPPER;CLP-600,ABS,2.0,...
Page 162 HOLDER-M-SPRING PR;CLP-600,PET+GF30%,-,W H0022 8.7-42 6107-001248 SPRING-CS;SWP-B,-,PI1.3,D6.8,L19.5,-,-,I S0040 8.7-44 6601-001341 BEARING-BALL;688ZZ,ID8,OD16,L5,SUJ2,- B0002 8.7-45 JC61-01126A HOLDER-_M_FUSER GEAR;CLP-600,PPS+PTEE+GF H0007 8.7-46 JC68-01581A LABEL(P)-CAUTION HOT;COMMON,SAMSUNG,PET, 8.7-48 JC63-00592A COVER-_M_SIDE L;CLP-600,PET GF30%,T2.5,W C0038 8.7-49 JC63-00593A COVER-_M_SIDE R;CLP-600,PET GF30%,T2.5,W C0039 8.7-50 JC61-01063A FRAME-_M_LOWER FUSER;CLP-600,PET+GF30%,B F0006 8.7-51 JC61-01066A GUIDE-_M_INPUT;CLP-600,PET+GF30%,5V,T3.0 G0041 8.7-52...
Page 163 Parts List SA : SERVICE AVAILABLE SNA : SERVICE not AVAILABLE DNA : DELIVERY not AVAILABLE Drawer# SEC-Code Description & Specification Location Service 8.8-11 6031-001002 WASHER-PLAIN;M17.5,ID6.1,OD17.5,T0.13,BL 8.8-12 JC66-01197A SHAFT-DEVE K CLUTCH;CLP-600,SUM24L,L75.6 8.8-13 JC47-00006C MEP-CLUTCH SPRING;-,CLP-600,4.0W,DC24V,0 8.8-14 JC66-00834A SHAFT-DEVE DRV KMCY;CLP-600,SUM24L,L72.1 S0002 8.8-15 JC66-00833A...
Page 164 Parts List SA : SERVICE AVAILABLE SNA : SERVICE not AVAILABLE DNA : DELIVERY not AVAILABLE Drawer# SEC-Code Description & Specification Location Service 8.9-31 JC61-00003A SPRING ETC--CAM MP;ML-6100,SUS304-WPB,0. S0020 8.9-32 JC66-00766A GEAR-_M_HOLDER CAM;CLP-600,POM,M0.8,SPUR G0008 8.9-33 JC66-10202A BEARING-PICK UP;ML-80,POM,-,-,- B0003 8.9-34 JC61-01045A BRACKET-P-HODLER PICKUP;CLP-600,SECC,T1.
Page 165 JC96-03334A ELA UNIT-MAIN LINE;CLP-600,SEC,EXPORT,-, #N/A JC96-03370A ELA UNIT-FUSER 110V;CLP-600,SEC,EXPORT,- #N/A JC96-03371A ELA UNIT-FRAME SMPS 110V;CLP-600,SEC,EXP #N/A JC97-02211A MEA UNIT-MAIN FRAME;CLP-600,SEC,EXPORT,- #N/A JC99-01855A PAA WOOD-PACKING;CLP-600,SAMSUNG,-,-,-,- #N/A JC99-01856A PAA-LABEL_XAA;CLP-600,SEC,-,LABEL ASS'Y, #N/A 0201-001162 ADHESIVE-CYA;LOCTITE403,NTR,1250,20G #N/A 0201-001183 ADHESIVE-AA;ARON ALPHA #202F,NTR,100,20G #N/A 0201-001833 ADHESIVE-HM;30-NF,WHITE,200-600,- #N/A 0202-001240 SOLDER-WIRE;HSE-01,-,D3,SN/0.5CU/0.03NI/...
Page 166 Parts List SA : SERVICE AVAILABLE SNA : SERVICE not AVAILABLE DNA : DELIVERY not AVAILABLE Drawer# SEC-Code Description & Specification Location Service #N/A JB68-00073A LABEL(R)-BAR CODE;SF-3000,PY,38X6.5,T0.1 #N/A JB68-00916A LABEL RATING-BLANK;SF-340,SEC,TETRON,0.0 #N/A JC02-00048A TONER-GRINDED BLACK;CLP-600,SAK-79JG-K1, #N/A JC02-00049A TONER-GRINDED CYAN;CLP-600,SAC-79JI-K1,C #N/A JC02-00050A TONER-GRINDED MAGENTA;CLP-600,SAM-79GZ-K #N/A...
Page 167 Parts List SA : SERVICE AVAILABLE SNA : SERVICE not AVAILABLE DNA : DELIVERY not AVAILABLE Drawer# SEC-Code Description & Specification Location Service #N/A JC62-00161A SEAL-BRKT PTB,F;CLP-600,URETHANE SM55,-, #N/A JC62-00162A SEAL-BRKT PTB,R;CLP-600,URETHANE SM55,-, #N/A JC62-00163A SEAL-WASTE BOTTOM;CLP-600,URETHANE SM55, #N/A JC62-00164A SEAL-BLADE,PTB;CLP-600,URETHANE SM55,-,5 #N/A JC62-00166A...
Page 168 Parts List SA : SERVICE AVAILABLE SNA : SERVICE not AVAILABLE DNA : DELIVERY not AVAILABLE Drawer# SEC-Code Description & Specification Location Service #N/A JC66-00795A GEAR-M-SUPPLY;CLP-600,POM,M0.6,Z20,12.77 #N/A JC66-00796A SHAFT-M-AGI,B;CLP-600,PC,221.6,10.5,BLAC #N/A JC66-00797A SHAFT-M-AGI,A;CLP-600,ABS,252.3,14,BLACK #N/A JC66-00832A SHAFT-OPC DRIVE C,M;CLP-600,SUM24L,L58.7 S0007 #N/A JC66-00837A SHAFT-OPC DRIVE K,Y;CLP-600,SUM24L,L58.7 S0008 #N/A...
Page 169 Parts List SA : SERVICE AVAILABLE SNA : SERVICE not AVAILABLE DNA : DELIVERY not AVAILABLE Drawer# SEC-Code Description & Specification Location Service #N/A JC97-02617A MEA UNIT-PR;CLP-600,SEC,EXPORT,-,-,-,- #N/A 0201-001235 ADHESIVE-TS;DEH-390D,RED,400,- #N/A 0202-001459 SOLDER-CREAM;S3X58-M405,-,D20~38§-,96.5SS #N/A 0402-001189 DIODE-RECTIFIER;M4,400V,1A,TS-1,TP #N/A 0501-000294 TR-SMALL SIGNAL;KSA708-Y,PNP,800mW,TO-92 #N/A 0505-001592 FET-SILICON;SI4542DY,N/P,30V/-30V,6.9A/6...
Page 170 Parts List SA : SERVICE AVAILABLE SNA : SERVICE not AVAILABLE DNA : DELIVERY not AVAILABLE Drawer# SEC-Code Description & Specification Location Service #N/A 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 #N/A 2203-000332 C-CER,CHIP;0.012nF,5%,50V,C0G,1608 #N/A 2203-000815 C-CER,CHIP;0.033nF,5%,50V,C0G,1608 #N/A 2203-001071 C-CER,CHIP;0.056nF,5%,50V,C0G,1608 #N/A 2203-001086 C-CER,CHIP;0.0050nF,0.25pF,50V,NP0,1608 #N/A 2203-001598 C-CER,CHIP;2200nF,+80-20%,16V,Y5V,2012 #N/A 2203-001607...
Page 171 Parts List SA : SERVICE AVAILABLE SNA : SERVICE not AVAILABLE DNA : DELIVERY not AVAILABLE Drawer# SEC-Code Description & Specification Location Service #N/A JC63-00186A SHEET-GUIDE ADF;SCX-6320F,PET,0.125T,-,- #N/A JC63-00896A FILTER-TONER;CLP-600,POLYESTERE,10.0T,W2 #N/A JC63-00904A SHEET-FILTER TONER;CLP-600,PET,T0.125,W2 #N/A JC63-01029A SHEET-PTB CLEANING;CLP-600,PET,T0.188,W1 #N/A JC66-01300A LEVER-FUSER FRAME;CLP-600,PET GF30%,T2.0 #N/A JC71-00051A...
Page 172 Parts List SA : SERVICE AVAILABLE SNA : SERVICE not AVAILABLE DNA : DELIVERY not AVAILABLE Drawer# SEC-Code Description & Specification Location Service #N/A 2007-000539 R-CHIP;200ohm,5%,1/10W,TP,1608 #N/A 2007-000608 R-CHIP;240ohm,5%,1/10W,TP,1608 #N/A 2007-000839 R-CHIP;39ohm,5%,1/10W,TP,1608 #N/A 2007-000965 R-CHIP;5.1Kohm,5%,1/10W,TP,1608 #N/A 2007-001002 R-CHIP;510ohm,5%,1/10W,TP,1608 #N/A 2007-007226 R-CHIP;49.9ohm,1%,1/10W,TP,1608 #N/A 2007-007276...
Page 173 Parts List SA : SERVICE AVAILABLE SNA : SERVICE not AVAILABLE DNA : DELIVERY not AVAILABLE Drawer# SEC-Code Description & Specification Location Service #N/A JC39-00430A CBF HARNESS-FCF_EMPT;CLP-600,CBF HARNESS #N/A JC41-00169A PCB-TEMPERATURE;CLP-500,FR-1,1L,-,1.6,22 #N/A JC41-00225A PCB SUB-GINKGO_ITB;CLP-500,FR-4,2L,-,1.6 #N/A JC41-00266A PCB SUB-COLOR_REGI;CLP-600,FR-1,1L,-,1.6 #N/A JC61-00705A HOLDER-M-PICKUP MP;ML-2150,POM,-,-,-,BLK P2062...
Page 174: Block Diagram
Block Diagram 9. Block Diagram 9.1 System Block Diagram Service Manual Samsung Electronics...
Page 175 Block Diagram 9.2 16ppm Block Diagram Service Manual Samsung Electronics...
Page 176: Gid H/W Block Diagram
Block Diagram 9.3 GID H/W Block Diagram Service Manual Samsung Electronics...
Page 177 Block Diagram 9.4 N/C & Wireless Block Diagram Service Manual Samsung Electronics...
Page 178: Connection Diagram
Connection Diagram 10 10 10. Connection Diagram 10.1 CLP-600/600N connection diagram Service Manual 10-1 Samsung Electronics...
Page 179: Power Distribution Diagram
Connection Diagram 10.2 Power distribution diagram Service Manual 10-2 Samsung Electronics...
Page 180 Connection Diagram 10.3 Main SMPS Service Manual 10-3 Samsung Electronics...
Page 181: Main(Driver)
Connection Diagram 10.4 Main(Driver) HVPS 28 pin Service Manual 10-4 Samsung Electronics...
Page 182 Connection Diagram 10.5 Main(Driver) HVPS 8 pin Service Manual 10-5 Samsung Electronics...
Page 183 Connection Diagram 10.6 Main Driver DF11 28 pin Service Manual 10-6 Samsung Electronics...
Page 184 Connection Diagram 10.7 Main System thermistor 2 pin Service Manual 10-7 Samsung Electronics...
Page 185 Connection Diagram 10.8 Main SET CTD, CR, CRUM sensor Service Manual 10-8 Samsung Electronics...
Page 186 Connection Diagram 10.9 Main Temp/Hum sensor 4 pin Service Manual 10-9 Samsung Electronics...
Page 187 Connection Diagram 10.10 Main LSU 24 pin Service Manual 10-10 Samsung Electronics...
Page 188 Connection Diagram 10.11 Main LSU 5 pin motor Service Manual 10-11 Samsung Electronics...
Page 189 Connection Diagram 10.12 Main LSU 24 pin-idea mock up SET Service Manual 10-12 Samsung Electronics...
Page 190 Connection Diagram 10.13 Joint LSU 6 pin-idea mock up SET Service Manual 10-13 Samsung Electronics...
Page 191 Connection Diagram 10.14 Main BLDC 10 pin Service Manual 10-14 Samsung Electronics...
Page 192 Connection Diagram 10.15 Driver OPC Step motor 8 pin Service Manual 10-15 Samsung Electronics...
Page 193 Connection Diagram 10.16 Driver Exit, FCF Empt, Feed sensor Service Manual 10-16 Samsung Electronics...
Page 194 Connection Diagram 10.17 Driver MP Empt sensor Service Manual 10-17 Samsung Electronics...
Page 195 Connection Diagram 10.18 Main OP Panel 5 pin Service Manual 10-18 Samsung Electronics...
Page 196 Connection Diagram 10.19 Main Deve CRUM I/F 3 pin Service Manual 10-19 Samsung Electronics...
Page 197 Connection Diagram 10.20 SMPS +24V micro switch 2 pin Service Manual 10-20 Samsung Electronics...
Page 198 Connection Diagram 10.21 Main/SMPS Fuser Drawer Connector Service Manual 10-21 Samsung Electronics...
Page 199: Schematic Diagrams
DC- DC converter 05.09.10 05.09.10 CLP-600 CLP-600 daVinci Vinci M ain in G DI DI Re Rev v 1. 1. 0 IN INDE DE X 1/21 Service Manual 11-1 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 200: Main Board
Power On Reset 05.09.10 DG ND CLP-600 CLP-600 daVinci Vinci M AIN IN G DI DI Re Rev v 1. 1. 0 ICS9248-81& RESET ICS9248-81& RESET 2/21 2/21 Service Manual 11-2 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 201 * P l ace as clo se as p ossib l e to the C PU daVinci Vinci M AIN IN G DI DI Re Rev v 1. 1. 0 RM5231A RM5231A 3/21 3/21 Service Manual 11-3 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 202 Vinci M AIN IN G DI DI nW RI Re Rev v 1. 1. 0 V320 & BOOT ROM V320 & BOOT ROM 4/21 4/21 DG ND Service Manual 11-4 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 203 DG ND LATCH 05.09.10 CLP-600 CLP-600 da daVi nci ma mai n G GD I Re Rev v 1. 1. 0 Lat ch&PLD h&PLD 5/21 5/21 Service Manual 11-5 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 204 R616 1105-001405 05.09.10 SDRAM DG ND CLP-600 CLP-600 daVinci Vinci M AIN IN G DI DI Re Rev v 1. 1. 0 Memory Memory 6/21 6/21 Service Manual 11-6 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 205 DG ND DE BUG CO NN 05.09.10 CLP-600 CLP-600 daVinci Vinci M AIN IN G DI DI Re Rev v 1. 1. 0 UAR T 7/21 7/21 Service Manual 11-7 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 206 2. 2uF 2012 2203-001598 DG ND DG ND 05.09.10 CLP-600 CLP-600 daVinci Vinci M AIN IN G DI DI Re Rev v 1. 1. 0 8/21 8/21 Service Manual 11-8 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 207 Vinci M AIN IN G DI DI DG ND Re Rev v 1. 1. 0 PC PC I I Net w or k 9/21 9/21 Service Manual 11-9 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 208 DG ND 63mW CLP-600 CLP-600 DG ND daVinci Vinci M AIN IN G DI DI DG ND Re Rev v 1. 1. 0 HYP ER-C 10/21 Service Manual 11-10 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 209 PWM _AC_2 PWM _ATTR+ PWM _AC_3 PWM _CHARG ER Rev 1. 1. 0 PWM _AC_4 PWM _T_4 PWM _T_3 LPEC 2 PWM _T_2 11/21 11/21 PWM _T_1 Service Manual 11-11 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 210 CLP-600 CLP-600 daVinci Vinci M AIN IN G DI DI Re Rev v 1. 1. 0 SCF & CRUM IF SCF & CRUM IF 12/21 12/21 Service Manual 11-12 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 211 Vinci M AIN IN G DI DI DG ND Re Rev v 1. 1. 0 RE RESE SET T & & CLOCK CLOCK 13/21 13/21 Service Manual 11-13 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 212 DGND nSTART_LSU_4 +24V_3 05.09.10 05.09.10 U10-3 FG ND CLP-600 CLP-600 DGND FG ND daVinci Vinci M AIN IN G DI DI Rev 1. 0 14/21 14/21 Service Manual 11-14 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 213 Vinci M AIN IN G DI DI Re Rev v 1. 1. 0 DG ND SMP S & HV & HV PS FGN D DG ND 15/21 15/21 Service Manual 11-15 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 214 05.09.10 DGND CLP-600 CLP-600 daVinci Vinci M AIN IN G DI DI Rev 1. 0 BLD C * * H I H I NTERFACE 16/21 16/21 Service Manual 11-16 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 215 Vinci M AIN IN G DI DI Re Rev v 1. 1. 0 D RI VER ER I I N T NTER ERFACE FACE 17/21 17/21 Service Manual 11-17 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 216 C667 05.09.10 DG ND CLP-600 CLP-600 daVinci Vinci M AIN IN G DI DI Re Rev v 1. 1. 0 ANAL ANAL O G 18/21 18/21 Service Manual 11-18 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 217 DG ND DG ND DG ND 05.09.10 CLP-600 CLP-600 daVinci Vinci M AIN IN G DI DI Re Rev v 1. 1. 0 FUSER FUSER 19/21 19/21 Service Manual 11-19 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 218 Vinci M AIN IN G DI DI Re Rev v 1. 1. 0 DG ND DG ND COLOR COLOR RE REGI GI I/ I/ F 20/21 20/21 Service Manual 11-20 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 219 C587 DG ND 05.09.10 CLP-600 CLP-600 daVinci Vinci M ain in G DI DI Re Rev v 1. 1. 0 IN INDE DE X 21/21 21/21 Service Manual 11-21 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 220 11.2 CR_Sensor Schematic Diagram Service Manual 11-22 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 221 CN1-5 CN3-1 CN5-1 CN7-1 CN9-1 SCL_3 CN1-6 CN3-2 CN5-2 CN7-2 CN9-2 SCL_4 SCL_3 SCL_2 SCL_1 SCL_4 CN1-7 CN3-3 CN5-3 CN7-3 CN9-3 CN3-4 CN5-4 CN7-4 CN9-4 35303-0750 Service Manual 11-23 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 222 11.4 DEVE-CRUM Schematic Diagram +3.3V_CRUM SDA _DE VE +3.3V_CRUM +3.3V_CR UM DG ND DG ND DG ND SCL_DE VE DG ND DG ND DG ND DG ND Service Manual 11-24 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 223 100nF 2005.10.28 R134 FGND FGND FGND 220nF CLP-600 CLP-600 daVinci Vinci DRIVE DRIVER G DI DI RESERVED Re Rev v 1. 1. 6 FGND FGND FGND Service Manual 11-25 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 224 Driver (2/3) Schematic Diagram Service Manual 11-26 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 225 0. 22 100nF R135 FGND 220nF FGND FGND FGND FGND FGND 2005.10.28 CLP-600 CLP-600 daVinci Vinci DRIVE DRIVER G DI DI Re Rev v 1. 1. 6 Service Manual 11-27 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 226: Lcd Panel
KEY2 KEY3 25 LCD_D7 SENSOR KEY4 D_DET KEY5 D_SCAN KEY6 KEY7 29 HT48R50 DGND MMSD914T1 05.10.1 DATE SIGN J.I.Kim Davinci Panel rev 0.5 Panel REF NO Service Manual 11-28 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 227 KSA1182-Y LED6 LED7 LED8 LED9 DGND 100nF DGND MMBT2222ALT1 DGND KSA1182-Y LED10 SPR-39 DGND 05.10.1 DATE SIGN J.I.Kim KSA1182-Y Davinci Panel rev 0.4 Panel REF NO Service Manual 11-29 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 228 CN1-3 KEY7 CN1-2 HT48R50 22pF 22pF 22pF DGND DGND 100nF CN1-1 DGND DGND MMSD914T1 MMSD914T1 05.10.31 DATE SIGN J.I.Kim Davinci Panel rev 0.6 Panel REF NO Service Manual 11-30 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 229 KSA1182-Y LED6 LED7 LED8 LED9 DGND 100nF DGND MMBT2222ALT1 DGND KSA1182-Y LED10 SPR-39 DGND 05.10.31 DATE SIGN J.I.Kim KSA1182-Y Davinci Panel rev 0.6 Panel REF NO Service Manual 11-31 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 230 6,10 6.8_C2012 10KF_C2012 CON4-#18,20,22,24,26 PC72-1 43_C2012 FGND 68pF_2012 LTV817 (3216) C2012 +5V1_4A 35V47uF +5V2_2A EER2525 T12 FS1M 1K_C2012 STANDBY 50V 1uF 35V100uF FGND KA431 AGND 1K_C2012 Service Manual 11-32 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 231 50V 1uF 35V100uF FGND 3565 KA431 AGND 1K_C2012 250V152 250V152 AGND 220VAC(H)LINE B+LINEAFTERRECTIFIER(100VTO400V) PRIMARYDC(0VTO50V) SECONDARYDC(0VTO50V) Title 220VAC(L)LINE 0V REFERENCE Type5-V2C_Ver1.3-2005-10-10 Size Document Number <Doc> Date: Sheet Service Manual 11-33 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 232 C628 R622 12KF R627 D609 470K Title ATTR DONGYANG E&P INC. 1N4148 C630 ATTRRD DESIGNED CHECKED APPROVED C632 Drw.No DAVINCI-HVPS Rev. Ref. No Size Date 2005.09.05 Service Manual 11-34 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 233 C511 C508 2.7V C509 R520 CHGRD 470K D506 1N4148 C510 Title CHARGER DONGYANG E&P INC. DESIGNED CHECKED APPROVED Drw.No DAVINCI-HVPS Rev. Ref. No Size Date 2005.09.05 Service Manual 11-35 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 234 R332 R323 R330 MGR1W6M-F 1/2W2K C311 C306 R326 12KF C308 Title SUPPLY-C DONGYANG E&P INC. DESIGNED CHECKED APPROVED Drw.No DAVINCI-HVPS Rev. Ref. No Size Date 2005.09.05 Service Manual 11-36 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 235 R432 R423 R430 MGR1W6M-F 1/2W2K C411 C406 R426 12KF C408 Title SUPPLY-K DONGYANG E&P INC. DESIGNED CHECKED APPROVED Drw.No DAVINCI-HVPS Rev. Ref. No Size Date 2005.09.05 Service Manual 11-37 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 236 R230 MGR1W6M-F U3/A 1/2W2K C211 C206 R226 12KF KA358A C208 Title SUPPLY-M DONGYANG E&P INC. DESIGNED CHECKED APPROVED Drw. DAVINCI-HVPS Rev. Ref. No Size Date 2005.09.05 Service Manual 11-38 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 237 R123 R130 R132 1/2W2K C111 C106 R126 MGR1W6M-F 12KF C108 Title SUPPLY-Y DONGYANG E&P INC. DESIGNED CHECKED APPROVED Drw.No DAVINCI-HVPS Rev. Ref. No Size Date 2005.09.05 Service Manual 11-39 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 238 CN23____PWM_T_Y CN24____PWM_T_M CN25____PWM_T_C CN26____PWM_T_K CN27____PWM_ATTR+ CN28____ENB_ATTR- CN29____A_READ_T_Y CN30____A_READ_CHARGER CN31____DGND CN32____A_READ_ATTR Title T-Y_PWM DONGYANG E&P INC. DESIGNED CHECKED APPROVED Drw.No DAVINCI-HVPS Rev. Ref. No Size Date 2005.09.05 Service Manual 11-40 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 239 R1014 BLR1/2W200MG C1004 R1007 C1003 D1003 ZD1002 330K 1N4148 7.5V Title T-C,K_PWM DONGYANG E&P INC. DESIGNED CHECKED APPROVED Drw.No DAVINCI-HVPS Rev. Ref. No Size Date 2005.09.05 Service Manual 11-41 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 240 24VS +18V +5VS KA7818 KA7805 35V47uF 100nF 100nF 35V47uF 100nF Title T-M_PWM DONGYANG E&P INC. DESIGNED CHECKED APPROVED Drw.No DAVINCI-HVPS Rev. Ref. No Size Date 2005.09.05 Service Manual 11-42 Samsung Electronics This Document can not be used without Samsung’s authorization.
Page 241: Reference Information
• Brush • Tweezers Standard : For general home use, small type. • Cotton Swab Standard : For general home use, for medical service. • Software (Driver) installation CD ROM Install Driver CD Network S/W CD Service Manual 12-1 Samsung Electronics...
Page 242: Acronyms And Abbreviations
Enhanced Capability Port Inter Process CommunicationEPP Enhanced parallel Port Engine Control Unit Images Per Minute EEPROM Electronically Erasable Programmable Read Only Memory Image Transfer Belt Electro Magnetic Interference local area network Electro photographic Laser Beam Printer Service Manual 12-2 Samsung Electronics...
Page 243 SCF/SCT Second Cassette Feeder/Second Purpose Tray Cassette Tray Network Interface Card SMPS Switching Mode Power Supply Network Printer Card SPGP Samsung Printer Graphic Processor NVRAM Nonvolatile Random Access Memory Samsung Printer Language Organic Photo Conductor SPL-C Samsung Printer Language-Color Printed Board Assembly...
Page 244: Select A Location For The Printer
• Provide the proper environment : - A firm, level surface - Away from the direct airflow of air conditioners, heaters, or ventilators - Free of extreme fluctuations of temperature, sunlight, or humidity - Clean, dry, and free of dust Service Manual 12-4 Samsung Electronics...
Page 245 Reference Information 12.4 A4 ISO 19752 Standard Pattern This test page is reproduced at 70% of the normal A4 size Service Manual 12-5 Samsung Electronics...
Page 246: Wireless Lan
Most of the main wireless networking companies are attending including such companies as Lucent Technologies, Cisco, Intel/Symbol, 3Com, Enterasys (Cabletron), Compaq, IBM, Nokia, Dell, Philips, Samsung Electronics, Sony, Intersil, etc.. This mark certifies mutual compatibility amongst the product of these companies. Wi-Fi (IEEE 802.1) is certified as a standard of the wireless LAN market.

This manual is also suitable for:

Clp-600Clp-600 series

Samsung CLP-600N/DSL Service Manual

Quick Links

Troubleshooting

Need help?

Questions and answers

Related Manuals for Samsung CLP-600N/DSL

Summary of Contents for Samsung CLP-600N/DSL

This manual is also suitable for:

Table of Contents
