Sealey HT110R Instructions

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
instructions
1. SAFETY
1.1. GENERAL
DO NOT shine directly into your, another person's or an animal's eyes.
8
DO NOT allow children to use the torch.
8
DO NOT use the torch if you suspect that the battery or the torch casing is damaged.
8
DO NOT leave batteries in a discharged state.
8
1.2. BATTERY SAFETY
WARNING! To reduce the risk of burns or fire:
‰
DO NOT attempt to open the batteries.
8
DO NOT crush, puncture, short contacts or dispose of in fire or water.
8
DO NOT expose to temperatures above 60°C (140°).
8
Replace only with the batteries designed for this product.
9
Recycle or dispose of used batteries as stipulated by local regulation.
9
If the electrolyte in the batteries gets on your skin, thoroughly wash with soap and water. If it gets in your eyes, rinse thoroughly with
9
cool water and seek immediate medical attention.
2. INTRODUCTION
Super bright 10W SMD LED produces up to 1000 lumens with a wide spread of light, illuminating the whole work area. Easy to adjust
one-size fits all headband is made from comfortable, breathable elastic. Head torch features 180° of rotation, allowing the light to be
directed at the optimal angle for hands free working. Easy to read charge indicator displays the current battery level while charging.
Charges via a USB Type-C cable (supplied). Rechargeable 3.7V 2.2Ah lithium-ion battery for extended battery life with a long run time
of 4.5 hours.
3. SPECIFICATION
Model No:
Battery:
Charging Time:
LED Type:
Lumen Output:
Nett Weight:
Operating Time:
4. OPERATION
4.1. CHARGING (fig.2).
4.1.1. Unscrew end cap to access the charging socket.
4.1.2. Connect supplied charger cable into charging socket,
a red indicator illuminates to indicate charging. Allow
4-5hrs to fully charge. A green light illuminates when
the head torch is charged.
4.2. LIGHT MODES
4.3. 3 different operational modes are available. By
depressing the light mode switch fig.2
Function.
1st press: Full power.
2nd press: Half power.
3rd press: Low power.
4.4. HEAD STRAP ADJUSTMENT
4.4.1. Adjust the head strap using the adjustment buckles to
fit the circumference of your head.
© Jack Sealey Limited
LED RECHARGEABLE HEAD TORCH, 10W SMD
LED, 1000LM, 2.2AH BATTERY
MODEL NO:
HT110R
3.7V 2.2Ah Lithium-ion
4hr
10W SMD
High/Med/Low: 1000/500/50lm
0.13kg
High/Med/Low: 4.5/8/18hr
HT110R
fig.1
Battery
compartment
fig.2
Original Language Version
Adjustable head
strap
Turn to angle
LED light
SMD LED
Charging socket
ON/OFF light
mode switch
HT110R Issue 1 05/09/24
