LG
Window-Type Air Conditioner
OWNER'S MANUAL
IMPORTANT
Please read through this manual. It contains valuable
information about your air conditioner. This manual may help
save time and money by explaining proper product
maintenance and preventing improper use.
PRECAUTIONS
Pay close attention to precautions in order to prevent
potential hazards and damage from misuse or improper
installation. LG is not responsible for any damages caused by
misuse of the product.
Model: W06LC W06LH W06LCR W06LHR W06AC W06ACR
W07LC W07LH W07LCR W07LHR W07AC W07ACR
W08LC W08LH W08LCR W08LHR W08AC W08ACR
W09LC W09LH W09LCR W09LHR W09AC W09ACR
W10LC W10LH W10LCR W10LHR W10AC W10ACR
W12LC W12LH W12LCR W12LHR W12AC W12ACR
W14LC W14LH W14LCR W14LHR W14AC W14ACR
W18LC W18LH W18LCR W18LHR W18AC W18ACR
W22LC W22LH W22LCR W22LHR W22AC W22ACR
W24LC W24LH W24LCR W24LHR W24AC W24ACR
Prior to installation, this air-conditioning
unit must be submitted for approval by the
utility service which provides electricity
(EN 61000-3 Norm.)
LG
Advertisement
Table of Contents
Related Manuals for LG W06AC
Summary of Contents for LG W06AC
- Page 1 PRECAUTIONS Pay close attention to precautions in order to prevent potential hazards and damage from misuse or improper installation. LG is not responsible for any damages caused by misuse of the product. Model: W06LC W06LH W06LCR W06LHR W06AC W06ACR W07LC W07LH W07LCR W07LHR W07AC W07ACR...
-
Page 2: Table Of Contents
Window-Type Air Conditioner Owner’s Manual TABLE OF CONTENTS or Your Records Write the model and serial numbers here: Model # Serial # 1. Safety Precautions You can find them on a label on the side of each unit. 2. Operating Instructions Dealer's Name 3. -
Page 3: Safety Precautions
Safety Precautions Precautions To prevent injury and property damage, follow these instructions. Incorrect operation due to ignoring instructions will cause harm or damage, the seriousness of which is indicated by the following symbols. WARNING This symbol shows the possibility of death or serious injury. CAUTION This symbol indicates the possibility of injury or damage to property. - Page 4 WARNING WARNING Ventilate before operating air conditioner Do not disassemble or modify products when gas goes out. randomly. • It may cause explosion, fire and, burn. • It may cause failure and electric shock. CAUTION CAUTION Never touch the metal parts Do not clean the air Ventilate well when used of the unit when removing...
-
Page 5: Prior To Operation
Safety Prior to Operation Precautions Preparing for operation Contact an installation specialist for installation. Plug in the power plug properly. Do not use a damaged or non-standard power cord. Do not share the same outlet with other appliances Do not use an extension cord. Do not start/stop operation by plugging/unplugging the power cord. -
Page 6: Operating Instructions
Operating Location and Function of Controls Instructions Controls The controls will look like one of the following. Auto Swing HIGH COOL COOL LOW COOL Thermostat Operation Thermostat Operation Auto Swing HIGH COOL COOL LOW COOL Thermostat Operation Auto Swing High Cool Cool Low Cool... -
Page 7: Auto Swing
OPERATION High Cool ( ), Med Cool ( ) and Low Cool ( ) provide cooling with different fan speeds. Med Fan ( ) or Low Fan ( ) provides air circulation and filtering without cooling. Off ( ) turns the air conditioner off. NOTE: If you move the switch from a cool setting to off or to a fan setting, wait at least 3 minutes before switching back to a cool setting. -
Page 8: Operation
Controls THERMOSTAT The controls will look like one of the following. Turn the thermostat control to the desired setting. The control position is a normal setting for average conditions. You can change this setting, if necessary, in accordance with your temperature preference. -
Page 9: Remote Control Operations
Operating Remote Control Operations Instructions The remote control and control panel will look like one of the following pictures. POWER Operation starts when this button is pressed and stops when you press the button again. OPERATION MODE SELECTOR Heating function is only available in some models. Select cooling mode to cool the room. -
Page 10: Fan Speed Selector
FAN SPEED SELECTOR For increased power while cooling or heating, select a higher fan speed. Cooling Model: 3 steps{High[F3] Low[F1] Med[F2] Heating Model: 2 steps{High[F2] Low[F1] TEMPERATURE CONTROL The thermostat monitors room temperature to maintain the desired temperature. The thermostat can be set between 16°C~30°C (61°F~81°F). The unit takes an average of 30 minutes to adjust the room temperature by 1°C (1.8°F). -
Page 11: Vent Control
Operating Adjusting the Air Flow Direction Instructions Vent Control The vent control is located above the control knobs. For maximum cooling efficiency, CLOSE the vent. This will allow internal air circulation. OPEN the vent to discharge stale air. CLOSE VENT OPEN To open the vent, pull the lever toward you. -
Page 12: Air Filter
Air Filter The air filter behind the inlet grille should be checked and cleaned at least once every 2 weeks (or as necessary) to maintain optimal performance of the air conditioner. How to remove the air filter The grille may be opened from the top or bottom for easy maintenance after installation. -
Page 13: Product Features
Hardware Hardware Installation Installation Product Features CAUTION This appliance should be installed in accordance with national wiring regulations. This guide acts as a guide to help to explain product features. 11 12 14 13 11 12 1. CABINET 8. HORIZONTAL AIR DEFLECTOR (VERTICAL LOUVER) 2. - Page 14 Circuit Breaker Installation and Parts for Installation Read thoroughly and follow all directions provided. A circuit breaker must be installed between the power source and the unit if the plug is not used (see illustration below). Main Power source Circuit Breaker Use a circuit breaker or time delay fuse.
-
Page 15: Installation Steps
Hardware Installation Steps Installation Select the Best Location FENCE FOAM AWNING Measure the space for installation to assure a good fit. The air conditioner must be installed firmly into place to HEAT prevent vibration and noise. RADIATION COOLED Avoid exposure to direct sunlight. Remove all obstacles from the rear of the unit. -
Page 16: Installation Of The Housing
Installation of the Housing Step 1 NOTE: UNIT MAY BE SUPPORTED BY A SOLID FRAME FROM BELOW OR Remove the air conditioner from it’s packaging and slide the air conditioner BY A HANGER FROM A SOLID OVERHEAD SUPPORT. out of it’s housing. FLASH OR SEAL AROUND EXTERNAL WALL FRAME OR ARCHITRAVE Step 2... -
Page 17: Install The Air Conditioner In The Case
Install the Air Conditioner in the Case Slide the air conditioner into the case. Attach the front grille to the case by inserting the Reinstall the 2 screws removed earlier on each tabs on the grille into the slots on the front of the side of the case. - Page 18 Hardware Reversible Inlet Grille Installation Using the Reversible Inlet Grille (on some models) Opening the front grille from the top of the unit: Disassemble the inlet grille from the front grille. Separate the hinged part by removing the screws using a flat-head screwdriver.
-
Page 19: Common Issues
Common Common Problems and Solutions Issues Before calling for service, please review the following list of common problems and solutions. The air conditioner is operating normally when: • You hear a pinging noise. This is caused by water being picked up by the condenser on rainy days or in highly humid conditions. - Page 20 Memo...
- Page 21 P/No.: 3828A20141Y Printed in Korea After reading this manual, keep it in a place easily accessible to the user for future reference.
