Multi Type Air Conditioner

OWNER'S MANUAL

MODELS: L8UC100BFA0 / L8UH100BFA0

L8UC150BFA1 / L8UC150BFE1

LMNC092LQL0 / LMNC092LQA0 / LMNH092L(G)QL(A)0

LMNC122L(G)RL(A)0 / LMNH122L(G)RL(A)0

LMNC182L(G)TL(A)0 / LMNH182L(G)TL(A)0

LMNC242L(G)TL(A)0 / LMNH242L(G)TL(A)

LMNC122DUR0 / LMNC122DUW0

LMNC122DUB0 / LMNC122DUD0

LMNC122DUM0 / LMNC122DUC0

LMNH122DUR0 / LMNH122DUW0

LMNH122DUB0 / LMNH122DUD0

LMNH122DUM0 / LMNH122DUC0

LMNC182D3R0 / LMNC182D3W0

LMNC182D3B0 / LMNC182D3D0

LMNC182D3M0 / LMNC182D3C0

LMNH182D3R0 / LMNH182D3W0

LMNH182D3B0 / LMNH182D3D0

LMNH182D3M0 / LMNH182D3C0

LMNC242D3R0 / LMNC242D3W0

LMNC242D3B0 / LMNC242D3D0

LMNC242D3M0 / LMNC242D3C0

LMNH242D3R0 / LMNH242D3W0

LMNH242D3B0 / LMNH242D3D0

LMNH242D3M0 / LMNH242D3C0

LMNC092BTG0 / LMNH092BTG0

LMNC122BTG0 / LMNH122BTG0

LMNC182BTG0 / LMNH182BTG0

LMNC242BYG0 / LMNH242BYG0

LMNC482BEG0 / LMNH482BEG0

LMNC182BHA0 / LMNH182BHA0

LMNC242BHA0 / LMNH242BHA0

LMNC302BGA0 / LMNH302BGA0

LMNC362BGA0 / LMNH362BGA0

LMNC482BRA0

LMNC122TEA(C)0 / LMNH122TEA(C)0

LMNC182TEA(C)0 / LMNH182TEA(C)0

LMNC242TFA(C)0 / LMNH242TFA(C)0

LMNC302TFA(C)0 / LMNH302TFA(C)0

LMNC362TDA(C)0 / LMNH362TDA(C)0

LMNC482TDA(C)0 / LMNH482TDA(C)0

L2UC242FA0

L3UC302FA0

L3UC362FA0

L3UC242FA0

L4UC302FA0

L5UC362FA0

L6UC502FA0

L6UW502FA0

L3UQ242FA0

LMNC092DZB0

LMNC092DZM0

LMNC092DZR0

LMNH092DZB0

LMNH092DZM0

LMNH092DZR0

LMNC092TCA0

LMNC092TCL0

LMNH092TCA0

LMNH092TCL0

IMPORTANT

• Please read this owner's manual carefully and thoroughly

before installing and operating your room air conditioner.

• Please retain this owner's manual for future reference after

reading it thoroughly.

LMNC122TCA0

LMNC122TCL0

LMNH122TCA0

LMNH122TCL0

LMNC092APB1

LMNC092APG1

LMNC092APD1

LMNH092APB1

LMNH092APG1

LMNH092APD1

LMNC122APB1

LMNC122APG1

LMNC122APD1

LMNH122APB1

LMNH122APG1

LMNH122APD1

Table of Contents

Need help?

Do you have a question about the LMNH242L TL Series and is the answer not in the manual?

Questions and answers

Summary of Contents for LG LMNH242L TL Series

Page 1 Multi Type Air Conditioner OWNER'S MANUAL MODELS: L8UC100BFA0 / L8UH100BFA0 L8UC150BFA1 / L8UC150BFE1 LMNC092LQL0 / LMNC092LQA0 / LMNH092L(G)QL(A)0 LMNC122L(G)RL(A)0 / LMNH122L(G)RL(A)0 LMNC182L(G)TL(A)0 / LMNH182L(G)TL(A)0 LMNC242L(G)TL(A)0 / LMNH242L(G)TL(A) LMNC122DUR0 / LMNC122DUW0 LMNC122DUB0 / LMNC122DUD0 LMNC122DUM0 / LMNC122DUC0 LMNH122DUR0 / LMNH122DUW0 LMNH122DUB0 / LMNH122DUD0 LMNH122DUM0 / LMNH122DUC0 LMNC182D3R0 / LMNC182D3W0 LMNC182D3B0 / LMNC182D3D0...
Page 2: Table Of Contents
Multi Type Air Conditioner Owner’s Manual TABLE OF CONTENTS FOR YOUR RECORDS Write the model and serial numbers here: Safety Precautions....3 Model # Prior to Operation ....8 Serial # Operating Instructions...9 You can find them on a label on the side of each unit. Dealer's Name Preparation before operation Date Purchased...
Page 3: Safety Precautions
Safety Precautions Safety Precautions To prevent injury to the user or other people and property damage, the following instructions must be followed. Incorrect operation due to ignoring instruction will cause harm or damage. The seriousness is classified by the following indications. WARNING This symbol indicates the possibility of death or serious injury.
Page 4: Operation
Safety Precautions Do not modify or extend the Do not install, remove, or re- Be cautious when unpacking power cable. install the unit by yourself and installing the product. (customer). • There is risk of fire or electric • There is risk of fire, electric •...
Page 5 Safety Precautions Do not allow water to run Do not store or use flammable Do not use the product in a into electric parts. gas or combustibles near the tightly closed space for a product. long time. • There is risk of fire, failure of the •...
Page 6: Installation
Safety Precautions When the product is not be used for a long Take care to ensure that nobody could step time, disconnect the power supply plug or on or fall onto the outdoor unit. turn off the breaker. • There is risk of product damage or failure or •...
Page 7 Safety Precautions Do not block the inlet or Use a soft cloth to clean. Do Do not touch the metal parts of outlet of air flow. not use harsh detergents, the product when removing the solvents, etc. air filter. They are very sharp! •...
Page 8: Prior To Operation
Prior to operation Prior to operation Preparing for operation 1. Contact an installation specialist for installation. 2. Connect the power cable between indoor unit and outdoor unit properly. 3. Use a dedicated circuit. 4. If the cord/plug is damaged, replace it with only an authorized replacement part. Usage 1.
Page 9: Operating Instructions
Operation Instructions Preparation before operation How to Insert the Batteries Remove the battery cover by pulling it according to the arrow direction. Insert new batteries making sure that the (+) and (-) of battery are installed correctly. Reattach the cover by sliding it back into position. NOTICE •...
Page 10: About The Remote Control On The System
Operation Instructions About the remote control on the system The remote control transmits the signals to the system. Features of the Remote Control START/STOP BUTTON Signal transmitter Operation starts when this button is pressed and stops when the button is pressed again. OPERATION MODE SELECTION BUTTON Used to select the operation mode.
Page 11: How To Use The Operation Mode Selection Button
Operation Instructions How to use the Operation Mode Selection button Cooling Operation Press the Start/Stop button. The unit will respond with a beep. Open the door on the remote control. To select Cooling Operation, press the Operation Mode Selection button. Each time the button is pressed, the operation mode is shifted in the direction of the arrow.
Page 12: Auto Operation
Operation Instructions Auto Operation Press the Start/Stop button. The unit will respond with a beep. Open the door on the remote control. To select Auto Operation, press the Operation Mode Selection button. Each time the button is pressed, the operation mode is shifted in the direction of the arrow.
Page 13: Healthy Dehumidification Operation
Operation Instructions Healthy Dehumidification Operation Press the Start/Stop button. The unit will respond with a beep. Open the door on the remote control. To select Healthy Dehumidification Operation, press the Operation Mode Selection button. Each time the button is pressed, the operation mode is shifted in the direction of the arrow.
Page 14 Operation Instructions Heating Operation(Heat pump model only) Press the Start/Stop button. The unit will respond with a beep. Open the door on the remote control. To select Heating Operation, press the Operation Mode Selection button. Each time the button is pressed, the operation mode is shifted in the direction of the arrow.
Page 15: Jet Cool Operation
Operation Instructions Jet Cool Operation Press the Start/Stop button. The unit will respond with a beep. Press the Jet Cool button to operate the speed cooling mode and the unit will operate in super high fan speed on cooling mode for 30 minutes.
Page 16: Plasma Purification Operation(Optional)
Operation Instructions PLASMA Purification Operation(Optional) Press the Start/Stop button. The unit will respond with a beep. Open the door on the remote control. Press the PLASMA air purifying operation ON/OFF button. Operation will start when the button is pressed and stop when the button is pressed again.
Page 17 Operation Instructions 2nd F Operation Press the Start/Stop button. The unit will respond with a beep. Open the door of the remote control and press the 2nd Function button to operate functions printed in blue at bottom of buttons. (Check the indication of 2nd function on remote control display.) These buttons operate the timer setting as follows: CANCEL...
Page 18: Additional Features
Additional features Additional features Sleep Mode Press the Sleep Mode Auto button to set the time To cancel the Sleep Mode, press the sleep you want the unit to turn off automatically. Mode Auto button several times until the star ) disappears from the operation display.
Page 19: Vertical Airflow Direction Control
Additional features Vertical Airflow Direction Control The up/down airflow (Vertical Airflow) can be adjusted NOTICE by using the remote control. If you press the CHAOS swing button, the horizontal airflow direction is changed automatically based on the CHAOS algorithm to distribute the air in the room evenly and at the same time to make the human body feel most comfortable, as if enjoying a natural breeze.
Page 20: Forced Operation
Additional features Forced Operation Operation procedures when the remote control can't be used. The operation will be started if the power button is pressed. If you want to stop operation, re-press the button. Power button Open the front panel upward Heat pump Model Cooling Model Room Temp.
Page 21: Care And Maintenance
Care and Maintenance Care and Maintenance CAUTION: Before performing any maintenance, turn off the main power to the system. Indoor Unit Grille, Case, and Remote Control Turn the system off before cleaning. Never use any of the followings: To clean, wipe with a soft, dry cloth. Do not use •...
Page 22: Outdoor Unit
Care and Maintenance Replacement of Purifying Filter(Option) • Recomended use period : About 2 years Open front panel and remove air Remove air purifying filters. filters. Insert new air purifying filters. Air filter Reinsert air filters and close front panel. Air purifying filter Outdoor Unit The heat exchanger coils and panel vents of the outdoor unit should be checked regularly.
Page 23: Operation Tips
Care and Maintenance When the air conditioner is not going to be used for a long time. When air conditioner is not going to be When the air conditioner is to be used again. used for a long time. Clean the air filter and install it in the Operate the air conditioner on Air indoor unit.
Page 24: Troubleshooting
Care and Maintenance Troubleshooting Check the following points before requesting repairs or service..If the fault persists, please contact your dealer or service center. Case Explanation See page The air conditioner does not • Check room temperature setting? operate. • Check if circuit breaker is on? The room has a peculiar •...
Page 25 LG ELECTRONICS MEXICO, S.A. DE C.V. Sor Juana Ines de la Cruz No. 555, San Lorenzo Tlalnepantla Estado de Mexico C.P. 54033 TEL. (55) 5321-1994 01800-3471919 P/No.: 3828A20478C Printed in Korea After reading this manual, keep it in a place easily accessible to the user for future reference.
