    Contents HP E1401B User’s Guide and Service Manual Edition 3 Warranty ........................3 Safety Symbols ......................4 WARNINGS ......................... 4 Declaration of Conformity.................... 5 Reader Comment Sheet ....................7 Chapter 1 Using the Mainframe ..................... 9 Mainframe Description ....................9 Line Voltage and Input Power ..................
  • Page 2 Notes: Contents www.valuetronics.com...
  • Page 3: Hp E1401B User's Guide And Service Manual Edition

    This Hewlett-Packard product is warranted against defects in materials and workmanship for a period of three years from date of shipment. Duration and conditions of warranty for this product may be superseded when the product is integrated into (becomes a part of) other HP products.
  • Page 4: Safety Symbols

    Documentation History All Editions and Updates of this manual and their creation date are listed below. The first Edition of the manual is Edition 1. The Edition number increments by 1 whenever the manual is revised. Updates, which are issued between Editions, contain replacement pages to correct or add additional information to the current Edition of the manual.
  • Page 5: Declaration Of Conformity

    815 14th Street S.W. Manufacturer’s Address: Loveland, Colorado 80537 declares, that the product: C-Size High Power VXI Mainframe Product Name: HP E1401B Model Number: Product Options: conforms to the following Product Specifications: IEC 1010-1 (1990) Incl. Amend 1 (1992)/EN61010-1 (1993) Safety: CSA C22.2 #1010.1 (1992)
  • Page 6 Notes: www.valuetronics.com...
  • Page 7: Reader Comment Sheet

    Please fold and tape for mailing Reader Comment Sheet HP E1401B User’s Guide and Service Manual Edition 3 You can help us improve our manuals by sharing your comments and suggestions. In appreciation of your time, we will enter you in a quarterly drawing for a Hewlett-Packard Palmtop Personal Computer (U.S. government employees are not eligible for the drawing).
  • Page 8 www.valuetronics.com...
  • Page 9: Using The Mainframe

    Chapter 1 Using the Mainframe Mainframe Description The HP E1401B mainframe is designed in full compliance with the VXIbus specification (Rev. 1.4) and VMEbus system specification (Rev. C.1). The mainframe contains 13 slots for plug-in modules and can be rack mounted in either the forward or reverse position.
  • Page 10: Air Flow

    Air Flow The air flow into the plug-in module slots in the HP E1401B mainframe is significantly more than previous HP mainframes. The mainframe supplies each of the 13 slots with enough air to cool 60 Watts while maintaining only a 10°C rise across a typically dense module.
  • Page 11: Variable Speed Fan

    Variable Speed Fan Normally, the speed of the four internal circulation fans is determined by the ambient temperature of the air drawn into the mainframe. One fan cools the power supply module and three fans cool the VXI modules inserted into the mainframe.
  • Page 12: Rear Panel Auxiliary Connector

    Rear Panel Auxiliary Connector A 25-pin “D” connector is provided on the rear panel of the mainframe to allow monitoring of power supply voltages and other functions. The pinouts for this connector are shown in the following table. 12 Using the Mainframe Chapter 1 www.valuetronics.com...
  • Page 13 The +5 volt output lets you power external TTL circuitry if required. The maximum current allowed from this supply is 1.0A. The +12 volt output lets you power a battery charging circuit to provide a +12V source for the +5V STDBY input. The maximum current allowed from this supply is 1.0A.
  • Page 14: Remote Standby Switch

    Remote Standby The remote standby switch connection is provided to let you turn the mainframe ON or put it in STANDBY mode remotely. These two Switch connections are wired in parallel with the front panel ON/STANDBY switch. This means that the front panel switch must be in STANDBY position for the remote switch to function correctly.
  • Page 15: Installing The Power Line Fuse

    Installing the Power Line Fuse The mainframe is shipped with a 15A fast blow (15AF) fuse (HP Part Number 2110-0054) already installed. This fuse is suitable for all line voltages. Figure 1-5 shows how to replace the fuse if necessary.
  • Page 16: Power Cords

    15 A Right Angle Connector Power Cords supplied by HP have polarities matched to the power input socket on the instrument: L = Line or Active Conductor (also called “live” or “hot”), N = Neutral or identified conductor, E = Earth or safety Ground * CSA Certification includes only this power cord.
  • Page 17: Hp E1401B Safety Grounding Information

    HP E1401B Safety Grounding Information WARNING For protection from electrical shock when operating at mains frequencies greater than 66 Hz, connect the chassis ground terminal to permanent earth ground. AVERTISSMENT Risque de Choch électrique. Si la fréquence du secteur est supérieure à...
  • Page 18 Notes: 18 Using the Mainframe Chapter 1 www.valuetronics.com...
  • Page 19: Replaceable Parts And Assemblies

    Chapter 2 Replaceable Parts and Assemblies There are no user sevicable parts in the HP E1401B. Repair is limited to replacing the power supply module, the backplane module, or other mechanical parts only. Module The power supply is available on an exchange basis. The backplane...
  • Page 20: Hp E1401B Replaceable Parts List

    HP E1401B Replaceable Parts List Reference HP Part Total Designator Number Qty. Description E1401-66511 PC Backplane Assembly E1401-69202 Power Supply; Power-650 Watts; 8 Outputs B1-B4 3160-0864 Fan - Tubeaxial - 12 VDC BZL1 E1401-04306 Front Bezel - Bottom BZL2 E1401-04304...
  • Page 21 Figure 2-1. Mainframe Replaceable Parts Chapter 2 Replaceable Parts and Assemblies www.valuetronics.com...
  • Page 22 Figure 2-2. Power Supply and Rear Panel Replaceable Parts 22 Replaceable Parts and Assemblies Chapter 2 www.valuetronics.com...
  • Page 23 Figure 2-3. Fan Assembly and Rear Panel Replaceable Parts Chapter 2 Replaceable Parts and Assemblies www.valuetronics.com...
  • Page 24 Notes: 24 Replaceable Parts and Assemblies Chapter 2 www.valuetronics.com...
  • Page 25: Hp E1401B Specifications

    The HP E1401B High-Power mainframes are 100% compatible with VXIbus specification revision 1.4. Overall Mainframe Size HP E1401B: 22 Kg (48.5 lbs) with no modules installed. Mainframe Weight Thirteen (13) C-Size slots. The mainframes also accept A- or B- Size Module Size modules using the optional HP E1403 Module Carrier.
  • Page 26 -5.2V will cause shutdown at the lower edge of the band. Heavy loading of the +12V, -12V, +24V, or -24V will cause shutdown at the higher edge of the band. Low line voltage (90Vac) will cause shutdown at the lower edge of the band. 26 HP E1401B Specifications Appendix A www.valuetronics.com...
  • Page 27 Maximum 3.5 Kg (7.7 lbs) per slot to comply with vibration and shock Module Weight specifications. Heavier modules may be installed if vibration and shock environment is less severe. IEC 348, UL 1244, and CSA C22.2 #231. Safety Appendix A HP E1401B Specifications www.valuetronics.com...
  • Page 28 Notes: 28 HP E1401B Specifications Appendix A www.valuetronics.com...
  • Page 29: Index

    Index HP E1401B User’s Guide and Service Manual Power Supply Outputs Air Flow Rear Panel Auxiliary Connector – Remote Standby Switch Certification Replaceable Parts List Cleaning Fan Filters Cooling Provided Safety Grounding Information Safety Warnings Declaration of Conformity Specifications –...
  • Page 30 30 Index www.valuetronics.com...
