Model Number
223B
Performance
Sensitivity(± 15 %)
Measurement Range(Compression)
Measurement Range(Tension)
Maximum Static Force(Compression)
Maximum Static Force(Tension)
Broadband Resolution(1 to 10,000 Hz)
Low Frequency Response(-5 %)
Upper Frequency Limit
Non-Linearity
Environmental
Temperature Range
Temperature Coefficient of Sensitivity
Electrical
Discharge Time Constant(at room temp)
Excitation Voltage
Constant Current Excitation
Output Impedance
Output Bias Voltage
Output Polarity(Compression)
Physical
Stiffness
Size (Diameter x Height)
Weight
Housing Material
Sealing
Electrical Connector
Electrical Connection Position
Mounting Thread
[5]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Group, Inc.
ICP® FORCE SENSOR
ENGLISH SI
0.42 mV/lb 94.42 mV/kN
12,000 lb 53.38 kN
4000 lb 17.79 kN
12,500 lb 55.60 kN
4500 lb 20.02 kN
0.40 lb-rms 1.78 N-rms
0.0003 Hz 0.0003 Hz
10,000 Hz 10,000 Hz
≤ 1.5 % FS ≤ 1.5 % FS
-65 to +250 °F -54 to +121 °C
≤ 0.03 %/°F ≤ 0.054 %/°C
≥ 2000 sec ≥ 2000 sec
20 to 30 VDC 20 to 30 VDC
2 to 20 mA 2 to 20 mA
≤ 100 Ohm ≤ 100 Ohm
8 to 14 VDC 8 to 14 VDC
Positive Positive
4 lb/µin 0.70 kN/µm
1.10 in x 2.00 in 27.94 mm x 50.8 mm
4.2 oz 120 gm
Stainless Steel Stainless Steel
Hermetic Hermetic
10-32 Coaxial Jack 10-32 Coaxial Jack
Side Side
1/2 - 20 Female 1/2 - 20 Female
OPTIONAL VERSIONS
Optional versions have identical specifications and accessories as listed for the standard model
except where noted below. More than one option may be used.
- Ground Isolated
J
[1] - Metric Mount
M
[2]
Mounting Thread
[3]
[4]
- Negative Output Polarity
N
Output Polarity(Compression)
W - Water Resistant Cable
Electrical Connector
Electrical Connection Position
NOTES:
[1] Typical.
[1]
[2] Calculated from discharge time constant.
[3] Estimated using rigid body dynamics calculations.
[4] Zero-based, least-squares, straight line method.
[5] See PCB Declaration of Conformance PS023 for details.
Entered: LK Engineer: BAM
Date: 10/7/2016 Date: 10/7/2016
3425 Walden Avenue, Depew, NY 14043
Revision: L
ECN #: 46037
M12 x 1.25 Female
Negative Negative
Sealed Cable Sealed Cable
Side Side
Sales: KWW Approved: BAM Spec Number:
Date: 10/7/2016 Date: 10/7/2016
Phone: 716-684-0001
Fax: 716-684-0987
E-Mail: info@pcb.com
