DUAL FUEL RANGE Read this owner’s manual thoroughly before operating the appliance and keep it handy for reference at all times. The complete owner’s manual can be found on the LG website at: http://gscs-manual.lge.com/CVZ/MFL68920541/main.html or by scanning the QR code.
Page 2
Safety for a Gas Range WARNING: If the information in these instructions is not followed exactly, a fire or explosion may result causing property damage, personal injury or death. Do not store or use gasoline or other flammable vapors and liquids in •...
TABLE OF CONTENTS IMPORTANT SAFETY 22 Connecting the Power Cord / Conduit INSTRUCTIONS Surface Burners 26 Assembling the Surface Burners READ ALL INSTRUCTIONS BEFORE USE 26 Checking Ignition of the Surface Burners 5 Safety Messages 26 Adjusting the Surface Burner to the Low 5 Anti-tip Device Flame (Simmer) Setting WARNING...
Page 4
55 Wireless LAN Module Specifications 55 FCC Notice 55 FCC RF Radiation Exposure Statement 56 Open Source Software Notice Information Smart Diagnosis Feature 56 Using LG ThinQ to Diagnose Issues 56 Using Audible Diagnosis to Diagnose Issues 57 MAINTENANCE Cleaning 57 General Cleaning Tips...
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE Download this owner's manual at http://www.lg.com Safety Messages Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and follow all safety messages.
IMPORTANT SAFETY INSTRUCTIONS WARNING • Do not step or sit on the oven door. The range could be tipped and injury might result from spilled hot liquid, food, or the range itself. • Never remove the oven legs. The range will not be secured to the anti-tip bracket if the legs are removed.
IMPORTANT SAFETY INSTRUCTIONS Operation WARNING NEVER cover any slots, holes or passages in the oven bottom or cover an entire rack with materials such as aluminum foil. Doing so blocks air flow through the oven and may cause carbon monoxide poisoning. Aluminum foil linings may also trap heat, causing a fire hazard.
IMPORTANT SAFETY INSTRUCTIONS • Do not leave children alone or unsupervised near the appliance when it is in use or is still hot. Children should never be allowed to sit or stand on any part of the appliance as they could be injured or burned. •...
IMPORTANT SAFETY INSTRUCTIONS • Do not attempt to repair or replace any part of your range unless it is specifically mentioned in this manual. All other service should be referred to a qualified technician. • For your safety, do not use high-pressure water cleaners or steam jet cleaners to clean the product. Risk of Fire and Flammable Materials •...
10 IMPORTANT SAFETY INSTRUCTIONS • Do not place food or cookware on the bottom of the oven cavity. Doing so will cause permanent damage to the oven bottom finish. • When using cooking or roasting bags in the oven, follow the manufacturer’s directions. •...
PRODUCT OVERVIEW PRODUCT OVERVIEW Product Features Exterior & Interior Cooktop Cooktop controller Oven door Storage drawer Oven mode knob Gasket Broil heater Convection heater Model & serial number plate Product Specifications The appearance and specifications listed in this manual may vary due to constant product improvements. Oven Range Models LSDL6336* Description...
Optional Accessories Included Accessories Anti-tip Kit Grid Broiler pan NOTE • Contact LG Customer Service at 1-800-243-0000 (1-888-542-2623 in Canada) if any accessories are missing. Anti-tip bracket (1ea) • For your safety and for extended product life, only use authorized components.
INSTALLATION INSTALLATION Before Installing Installation Overview Please read the following installation instructions first after purchasing this product or transporting it to another location. The images in this guide may be different from the actual components and accessories, which are subject to change by the manufacturer without prior notice for product improvement purposes.
14 INSTALLATION Tools Needed Anti-tip bracket kit (1) Anchor sleeves (6) Lag bolts (6) Parts Not Provided 4-Wire cord or 3-Wire cord (UL approved 40 or 50 AMP) Strain relief (for conduit installations only) Parts You May Need • Gas line shut-off valve •...
INSTALLATION • When using ball type gas shut-off valves, they • Do not use sharp instruments, rubbing alcohol, must be the T-handle type. flammable fluids, or abrasive cleaners to remove tape or glue. These products can damage the • When using a flexible gas connector, it must not surface of your range.
16 INSTALLATION Flooring CAUTION • Use an insulated pad or 1/4 in. (0.64 cm) plywood under the range if installing the range over carpeting. • When the floor covering ends at the front of the range, the area that the range will be installed on should be built up with plywood to the same level or higher than the floor covering.
INSTALLATION Dimensions and Clearances • Provide proper clearance between the range and adjacent combustible surfaces. • These dimensions must be met for safe use of your range. • The location of the electrical outlet and pipe opening (see "Gas Pipe and Electrical Outlet Locations" below) may be adjusted to meet specific requirements.
Page 18
18 INSTALLATION Clearances Minimum Minimum clearance to left/right wall Maximum depth for cabinets above countertops Front edge of the range side panel forward from cabinet To cabinets below cooktop and at the range back Gas Pipe and Electrical Outlet Locations Acceptable electrical outlet area Normal counter top depth Counter top height...
INSTALLATION Center A (Cabinet opening) = 30" (76.2 cm) For U.S.A = 30" (76.2 cm) ~ 31" (78.7 cm) For CANADA NOTE • Important – Save for the use of the local electrical inspector. • For installation in Canada, a free-standing range is not to be installed closer than 15/32" (12 mm) from any adjacent surface.
Page 20
20 INSTALLATION Install and use in accordance with the WARNING installation instructions. • The appliance and its individual shut-off valve must be disconnected from the gas supply WARNING piping system during any pressure testing of • Do not use a flame to check for gas leaks. that system at test pressures in excess of 1/2 psi (3.5 kPa).
INSTALLATION Specified Power Cord Kit Rating Pressure regulator Case 1 Connecting Electricity • Voltage: 120/240 volts (3-wire) • Range rating: 8,750 W - 16,500 W Electrical Requirements • Specified rating of power supply-cord kit, This appliance must be installed and grounded on amperes: 40 A or 50 A a branch circuit by a qualified technician in •...
22 INSTALLATION Connecting the Power Cord / Ring Conduit Body The rear access cover must be removed. Loosen Cord/Conduit connection plate the two screws with a screwdriver. The terminal Conduit block will then be accessible. 3-Wire Connection: Power Cord WARNING •...
Page 23
INSTALLATION Tighten the 3 screws securely into the Insert the power cord through the strain relief terminal block. and tighten it. CAUTION CAUTION • Do not remove the ground strap connections. • Do not install the power cord without a strain relief.
Page 24
24 INSTALLATION Insert the bare wire (white/neutral) end Cord/Conduit connection plate through the center terminal block opening. Bend strap up and attach. Do not remove the ground strap connections. 3-Wire Connection: Conduit Insert the two side bare wire ends into the lower left and the lower right terminal block WARNING openings.
Page 25
INSTALLATION Conduit Installations Attach the ground (green) bare wire end to the range frame and secure it in place with the ground screw. CAUTION • Do not install the conduit without a strain relief. Insert the bare wire (white/neutral) end through the center terminal block opening.
26 INSTALLATION Surface Burners Checking Ignition of the Surface Burners Assembling the Surface Burners Electric Ignition CAUTION Select a surface burner knob and simultaneously push in and turn to the Lite position. You will hear • Do not operate the burners without all parts in a clicking sound indicating proper operation of the place.
INSTALLATION Insert a small, flat-blade screwdriver into the • If the countertop depth is less than 24 3/4 ", the opening marked below. control panel will not sit flush with the countertop. Using a screwdriver, remove the three screws holding the rear top plate in place. Simmer on dual burner Simmer on other burners Rear Top Plate...
28 INSTALLATION Engaging the Anti-tip Device WARNING • Engage the range to the anti-tip device by following the guide on the anti-tip bracket template. Ensure the anti-tip device is re- engaged when the range is moved by following the guide on the anti-tip bracket template. •...
Page 29
INSTALLATION Remove all packing materials from inside the oven cavity. Turn oven mode knob to select Broil. Hi appears in the display. • Make sure the door is closed. Press START. NOTE • It may take between 30 and 90 seconds for the burner to start heating.
30 OPERATION OPERATION Control Panel Control Panel Features Smart Diagnosis Use during the Smart Diagnosis feature. Control Lock Press and hold the button for 3 seconds to lock the control panel. Cook Time Press the button to set the desired amount of time for food to cook. The oven shuts off when the set cooking time runs out.
OPERATION NOTE • Flashing Clock If the colon in the clock display flashes, press Clock and reset the time, or press any key to stop the flashing. • Press any button on the control panel to activate the display. • Setting the Time, Timer and Temperature If you enter one digit of a number incorrectly, enter the entire number again to correct it.
Press Settings repeatedly until Auto appears in the display. Connect the appliance to the Wi-Fi network using the LG ThinQ smartphone app. Press 1 to disable or enable auto conversion. To disconnect the appliance from the network, delete it from the connected Press START to accept the change.
OPERATION Control Lock Press START to accept the change. The Control Lock feature locks the control panel NOTE and oven mode knob. • This adjustment does not affect the broiling or • When the Control Lock feature is activated, the Self Clean temperatures.
34 OPERATION Set the start time: Press 4, 3 and 0 for 4:30. Press START. The oven will continue to cook for the set amount of time and then turn off automatically. When the Press START. A short beep sounds and Timed cooking time has elapsed: Delay and the start time appear in the display.
OPERATION Gas Surface Burners Min. Max. Temp. Temp. Feature Default Before Using the Gas Surface Burners Time Time Read all instructions before using. 0:01 11:59 Hr. / Hr. / WARNING min. min. Cook • Even if the top burner flame goes out, gas is still Time 0:01 11:59...
36 OPERATION and all grates are cool before attempting to CAUTION remove them. • Control the top burner flame size so it does not • If you smell gas, turn off the gas to the range extend beyond the edge of the cookware. and call a qualified service technician.
OPERATION caps can be assembled and removed for cleaning. Follow the guide below. NOTE • The electric spark ignition system makes a clicking noise. Medium and large burners Turn the control knob to control the flame The medium and large burners are the primary size.
38 OPERATION NOTE CAUTION • After LP gas conversion, flames can be bigger • Do not use a wok support ring. Placing the ring than normal when you put a pot on the surface over the burner or grate may cause the burner burner.
OPERATION • Do not place or store items on the griddle. - Cook Setting: HI • Type of Food : Bacon - Preheat Conditions: HI 5 min. - Cook Setting: HI • Type of Food : Breakfast Sausage Links - Preheat Conditions: HI 5 min. - Cook Setting: HI •...
40 OPERATION • Only arrange oven racks when the oven is cool. NOTE • The heat turns off if the door is left open during baking. If the door is left open for longer than 30 Removing Racks seconds during baking, the heat turns off. The heat turns back on automatically once the door Pull the rack straight out until it stops.
OPERATION • Tapping the edges of the glass panel may not • Use metal bakeware (with or without a nonstick activate the InstaView function. finish), heatproof glass-ceramic, ceramic or other bakeware recommended for oven use. • The taps on the glass panel must be hard enough to be audible.
42 OPERATION Recommended Baking and Tips for Convection Baking Roasting Guide • Use Convection Bake for faster and more even multiple-rack cooking of pastries, cookies, Baking results will be better if baking pans are muffins, biscuits, and breads of all kinds. centered in the oven as much as possible.
OPERATION Rack CAUTION Food position • Do not use a broiler pan without a grid. Oil can cause a grease fire. Pastry From scratch Crust Refrigerated • Do not cover the grid and broiler pan with aluminum foil. Doing so will cause a fire. Biscuit, canned Breads Biscuit, from scratch...
Page 44
44 OPERATION • Always use a broiler pan. Do not use saute pans or regular baking sheets for safety reasons. • The broiler pan should always be thoroughly cleaned and at room temperature at the beginning of cooking. • Always run your cooktop ventilation system or vent hood during broiling.
OPERATION Recommended Broiling Guide The size, weight, thickness, starting temperature, and your preference of doneness will affect broiling times. This guide is based on meats at refrigerator temperature. For best results when broiling, use a pan designed for broiling. Grid (sold separately) Broiler pan (sold separately) First Second...
46 OPERATION First Second Quantity and/or Rack Food Side Side Comments Thickness Position (min.) (min.) " thick) Pork Chops Well done 2 (1" thick) about 1lb. 2 (1" thick) Medium about 10 to 12 Well done Lamb Chops Medium 2 (1 "...
OPERATION Proof has finished using a Timed Cook or a Delayed Timed Cook. This feature maintains a warm oven for rising yeast-leavened products before baking. (Set Setting the Warm Function temperature: 92 °F) Turn the oven mode knob to select Proof/ Setting the Proof Function Warm until Proof appears in the display.
• Use either the optional air fry tray available from The Air Fry function is specially designed for oil- LG or a dark baking tray with no sides or short free frying. sides that does not cover the entire rack. This allows for better air circulation.
OPERATION as aluminum foil. Doing so blocks airflow • Keep the oven free from grease buildup. Wipe through the oven and can result in carbon down the interior of the oven before and after monoxide poisoning. Aluminum foil can also air frying (once the oven has cooled).
50 OPERATION Quantity Rack Recommended Items Temp. (°F) Time Guide (oz) Position Frozen Hot Wings, Bone- 30-40 CHICKEN-Fresh, Skin on 30-35 Brush or lightly spray with † Fresh Chicken Wings 1 tbsp. of oil. Add salt and Fresh Chicken 35-45 pepper to taste.
OPERATION perfect texture when cooking meat and Turn the oven mode knob to select Air Sous- poultry. The low temperatures used retain Vide mode. more of the moisture in food than conventional cooking methods. After cooking, Set the desired oven temperature. (Range: a final sear in a frying pan adds the perfect 100 °F ~ 205 °F) crisp finish.
52 OPERATION Turn the oven mode knob to select Remote Start. When ON appears in the display, the Remote Start function is ready to use. Follow the directions in the smart phone application to set the cook mode, temperature, and run time (preheating time The meat probe icon flashes in the display if plus holding time).
OPERATION avoid breaking the probe, make sure food is Press START. completely defrosted before inserting. Press and hold Settings for three seconds. CAUTION appears in the display when the Sabbath • Always use an oven mitt to remove the mode is activated. temperature probe.
LG ThinQ • LG ThinQ is not responsible for any network application and connect it again. connection problems or any faults, malfunctions, • This information is current at the time of or errors caused by network connection.
Connecting to Wi-Fi technician for help. This device complies with part 15 of the FCC Rules. The Wi-Fi button, when used with the LG ThinQ Operation is subject to the following two application, allows the appliance to connect to a conditions: home Wi-Fi network.
Follow the instructions below to use the audible follow the specific operating instructions for diagnosis method. satisfying RF exposure compliance. • Launch the LG ThinQ application and select the Smart Diagnosis feature in the menu. Follow Open Source Software Notice the instructions for audible diagnosis provided in the LG ThinQ application.
MAINTENANCE MAINTENANCE Cleaning • To clean the knobs, make sure that they are in the OFF position and pull them straight off the stems. CAUTION • To replace the knobs, make sure the knob has • Do not clean this appliance with bleach. the OFF position centered at the top, and slide the knob directly onto the stem.
58 MAINTENANCE Oven Door • Both the broiler pan and grid may be cleaned with a commercial oven cleaner or in the dishwasher. CAUTION • Do not use harsh cleaners or harsh abrasive Oven Racks cleaning materials on the outside of the oven Remove the oven racks before operating the Self door.
MAINTENANCE Grates and burner heads/caps can be removed for cause injury. Hitting an electrode with a hard care and cleaning. object may damage it. • To remove burnt-on food, soak the burner heads in a solution of mild liquid detergent and hot water for 20–30 minutes.
Remove grates, burners and burner caps windows to provide ventilation. Compared to the from the cooktop. more intense Self Clean process, your LG oven gives you the option of cleaning with LESS HEAT, LESS TIME, and virtually NO SMOKE OR FUMES.
Page 61
MAINTENANCE Benefits of EasyClean covered by water at the beginning of the EasyClean cycle. • Helps loosen light soils before hand-cleaning • For best results, use distilled or filtered water. • EasyClean only uses water; no chemical cleaners Tap water may leave mineral deposits on the •...
62 MAINTENANCE should be fully covered to submerge all soils. Once the oven cavity is cleaned, wipe any Add water if necessary. excess water with a clean dry towel. Replace racks and any other accessories. NOTE • If cleaning multiple ovens, use an entire bottle of If some light soils remain, repeat the above water to clean each oven.
Page 63
MAINTENANCE cookware, aluminum foil or any other material • Do not line the oven walls, racks, bottom or any from the oven. other part of the range with aluminum foil or any other material. Doing so will destroy heat - If oven racks are left in the oven cavity during distribution, produce poor baking results and the Self Clean cycle, they will discolor and cause permanent damage to the oven interior...
64 MAINTENANCE Self Clean Soil Guide NOTE Soil Level Cycle Setting • Once the door has been locked, the lock indicator light stops flashing and remains on. Lightly Soiled Oven 3-Hour Self Clean Allow about 15 seconds for the oven door lock to Cavity activate.
MAINTENANCE Press Start Time. Firmly grasp both sides of the door at the top. Set the time of day you would like the Self Close the door to the removal position Clean to start by pressing numbers. (approximately five degrees) which is halfway between the broil stop position and fully closed.
66 MAINTENANCE Lock the hinge locks, rotating them back toward the slots in the oven frame until they lock. Lever Push down with finger Hinge arm Pull up with finger Hinge lock Pull the drawer away from the range. Close the oven door. Assembling Drawers Removing/Assembling Drawers Pull the bearing glides to the front of the...
MAINTENANCE WARNING • Make sure that the oven and lamp are cool. • Disconnect the electrical power to the range at the main fuse or circuit breaker panel. Failure to do so can result in severe personal injury, death, or electrical shock. Unplug the range or disconnect power.
68 TROUBLESHOOTING TROUBLESHOOTING FAQs Frequently Asked Questions What types of cookware are recommended for use with the cooktop? • The pans must have a flat bottom and straight sides. • Only use heavy-gauge pans. • The pan size must match the amount of food to be prepared and the size of the surface element.
Page 69
TROUBLESHOOTING Can I leave my racks in the oven when running a Self Clean cycle? (On some models) No. Although it will not damage the racks, it will discolor them and may make them hard to slide in and out during use. Remove all items from the oven before starting a Self Clean cycle. What should I do if my racks are sticky and have become hard to slide in and out? Over time, the racks may become hard to slide in and out.
70 TROUBLESHOOTING Yes. The convection fan or heater element may get a little wet during cleaning. However, direct spray onto the broil burner and heater elements is not necessary because these are self-cleaning during regular use. Do I need to use all 1 ¼ cups (10 oz or 300 ml) of water for EasyClean? Yes.
Page 71
TROUBLESHOOTING Problem Possible Cause & Solution Surface burners light Shut-off valve is not fully open. but the oven does • Make sure that the oven gas shut-off valve, located behind the range, is fully open. not. Food does not bake Oven controls improperly set.
Page 72
72 TROUBLESHOOTING Problem Possible Cause & Solution Oven will not work Plug on range is not completely inserted in the electrical outlet. • Make sure electrical plug is plugged into a live, properly grounded outlet. A fuse in your home may be blown or the circuit breaker tripped. •...
TROUBLESHOOTING Parts & Features Problem Possible Cause & Solution Range is not level. Poor installation. • Place oven rack in center of oven. Place a level on the oven rack. Adjust leveling legs at base of range until the oven rack is level. •...
74 TROUBLESHOOTING Problem Possible Cause & Solution Oven door does not Oven is too hot. open after a Self • Allow the oven to cool below locking temperature. Clean cycle (On some models) The control and door may be locked. •...
Should your LG Dual Fuel Range ("Product") fail due to a defect in materials or workmanship under normal and proper use, during the warranty period set forth below, LG will, at its option, repair or replace the Product. This limited warranty is valid only to the original retail purchaser of the Product (“You”) and applies only when purchased lawfully and used within the United States including U.S.
Page 76
• Damage or failure of the Product resulting from misuse, abuse, improper installation, repair, or maintenance. Improper repair includes the use of parts not authorized by LG. Improper installation or maintenance includes installation or maintenance contrary to the Product owner’s manual.
Page 77
LIMITED WARRANTY Problem Possible Cause & Prevention Uneven flame Improper burner cap installation Burner cap is properly seated. Burner cap is NOT properly seated. • Check installation of burner head and cap. Burner ports clogged by food residue Ports blocked by dirt Flames uneven •...
Page 78
78 LIMITED WARRANTY Problem Possible Cause & Prevention Oven or racks are Aluminum foil has melted in the oven stained after using aluminum foil • Never cover the oven bottom or cover an entire rack with materials such as aluminum foil. •...
Page 79
LIMITED WARRANTY Problem Possible Cause & Prevention Surface is not level Range not leveled Oven is tipping • Check with installer first. • Use carpenter’s level to check level. Anti-tip device not installed correctly Approximately 0.65" (16.5 mm) Level both sides of range Screw must enter wood or concrete Anti-tip bracket Wall plate...
Notice of Dispute. In the event you intend to commence an arbitration proceeding, you must first notify LG in writing at least 30 days in advance of initiating the arbitration by sending a letter to LG at LG Electronics, USA, Inc. Attn: Legal Department- Arbitration 111 Sylvan Avenue, Englewood Cliffs, NJ 07632 USA.
Page 81
LIMITED WARRANTY subject of the claim; and describe the nature of the claim and the relief being sought. If you and LG are unable to resolve the dispute within 30 days, either party may proceed to file a claim for arbitration.
Page 82
82 LIMITED WARRANTY You may only opt out of the dispute resolution procedure in the manner described above (that is, by e-mail or telephone); no other form of notice will be effective to opt out of this dispute resolution procedure. Opting out of this dispute resolution procedure will not affect the coverage of the Limited Warranty in any way, and you will continue to enjoy the full benefits of the Limited Warranty.
Page 85
LG Customer Information Center For inquiries or comments, visit www.lg.com or call: U.S.A. 1-800-243-0000 1-888-542-2623 CANADA Register your product Online! www.lg.com...
