Kohler VEIL K-77070T Installation Instructions

·
Thank you for choosing the Bold Look of Kohler. Kohler
craftsmanship offers you a rare combination of proven
performance and graceful sophistication that will satisfy
you for years to come. The quality and dependability of
your Kohler toilet seat will surpass your highest
,
expectations. We re very proud of our products here at
Kohler and we know you will be too.
·
Please take a few minutes to study this manual. Pay
special attention to the Care and Cleaning instructions.
·
All information in this manual is based upon the latest
product information available at the time of publication. At
Kohler, we constantly strive to improve the quality of our
products. We reserve the right to make changes in product
characteristics, packaging or availability at any time
without notice.
·
This product complies with JC/T764-2008.
Reference Value
INSTALL SEAT INSTALL SEAT
·
Install the hinge baseboard to the toilet
with screw kit, keep the arrows mark
forward.
·
Align two holes on the hinge mainboard
with the posts on the hinge baseboard.
·
Push the seat downward till the hinge
mainboard is installed on the hinge
baseboard.
