WI-GPS-XX User Manual V1.0 2012 Table of Contents Chapter 1: Introduction ........................... 4 What to Expect ........................4 Required References ........................ 5 Ordering Information ....................... 6 Chapter 2: Getting Started ......................... 7 Unpacking ..........................7 Development Tools / Software ....................8 Device Diagram ........................ - Page 3 WI-GPS-XX User Manual V1.0 2012 Default Settings ........................22 Modifying Settings ......................... 23 Chapter 5: Technical Support & Warranty ..................25 Technical Support ........................25 Limited Warranty ........................25 Chapter 6: History..........................26...
- Page 4 Hard copies may be produced for personal use. Saiko Systems Ltd. products are not tested for use in life support or life critical devices. If this product is used for such applications, the developer/integrator/user agrees to perform further testing to ensure the reliability of the product in such applications.
-
Page 5: Chapter 1: Introduction
WI-GPS-XX User Manual V1.0 2012 Chapter 1: Introduction 1.1 What to Expect The WI-GPS-XX is a highly robust and modular Global Positioning System (GPS) Board which delivers proven performance and quality for a new generation of position enabled products, allowing OEMs to quickly and easily add GPS support for virtually any application. -
Page 6: Required References
WI-GPS-XX. The manual also assumes the reader has basic understanding of GPS and how it functions. If an introduction to GPS is required, Saiko Systems recommends reading the Trimble GPS Tutorial available http://www.trimble.com/gps/ Copernicus II GPS Receiver Ref. Manual http://support.saikosystems.com... -
Page 7: Ordering Information
WI-GPS-XX User Manual V1.0 2012 1.3 Ordering Information WI-GPS-00 GPS Module Only Part Number Description WI-GPS-01 GPS Module /w Magnetic Mount Antenna WI-GPS-02 GPS Module /w Compact Embedded Antenna WI-GPS-03 GPS Module /w Bulkhead Antenna WI-GPS-CS Cable Set Includes: USB Cable (3ft) [CA-USB-AM-MICBM] ... -
Page 8: Chapter 2: Getting Started
WI-GPS-XX User Manual V1.0 2012 Chapter 2: Getting Started 2.1 Unpacking Please ensure that all necessary Electrostatic Discharge (ESD) precautions are taken before removing the WI-GPS-XX from its packaging. These may include touching a grounded object, using a grounded wrist strap, and using a grounded table mat to eliminate any stored static energy. -
Page 9: Development Tools / Software
WI-GPS-XX User Manual V1.0 2012 2.2 Development Tools / Software The table below lists the software/hardware required in order to configure and use the module. The development PC must have the following specs: • A PC equivalent to an Intel Pentium or higher. •... -
Page 10: Device Diagram
WI-GPS-XX User Manual V1.0 2012 2.3 Device Diagram... - Page 11 WI-GPS-XX User Manual V1.0 2012 Section 3.6 Indicator Function Reset Section 3.10 RS232 Section 3.7 Antenna (MCX Female) Section 3.4 Power Section 3.1 UART/PPS Connector Section 3.7 & 3.8 Power LED Section 3.9 D2-D4 GPS Status LEDs Section 3.9 D5-D6 USB Activity LEDs Section 3.9 W1-W3...
-
Page 12: Default Configuration
WI-GPS-XX User Manual V1.0 2012 2.4 Default Configuration The WI-GPS-XX is shipped ready to use out of the box. No programming or configuration is required to use the module out of the box. Simply connect the module to a USB port to power the device. Warning: Please install the USB drivers BEFORE connecting the WI-GPS-XX to a host for the first time. -
Page 13: Chapter 3: Setup And Operation
WI-GPS-XX User Manual V1.0 2012 Chapter 3: Setup and Operation 3.1 Input Power Requirements (TB1) The WI-GPS-XX requires a +5VDC (±5%) input of at least 220mA. Depending on the configuration of jumper W1, this can be provided through either the Micro-A/B USB port (J1), or the power terminal block (TB1). -
Page 14: Jumper Configuration (W1, W2, W3)
WI-GPS-XX User Manual V1.0 2012 3.2 Jumper Configuration (W1, W2, W3) The WI-GPS-XX contains three jumper blocks. Their functions are as follows: Enable +5VDC power input from Power Header (TB1). 1 - 2 Jumper Block Pins Connected Function (Power Input) Enable +5VDC power input through Micro-A/B USB (J1). -
Page 15: Trimble Copernicus Ii Gps Receiver
WI-GPS-XX User Manual V1.0 2012 Jumper Block Pins Connected Function GPS Status LEDs are disabled. (GPS Status LEDs) 1 – 2 GPS Status LEDs are enabled. +3V3 GPS_LEDs 3.3 Trimble Copernicus II GPS Receiver The core of the WI-GPS-XX is the 12-Channel Trimble Copernicus II GPS Receiver featuring the TrimCore firmware which enables extremely fast startup times and high performance in foliage canopy and urban canyon environments. -
Page 16: Antenna (J4)
If the antenna will have a long cable, or will be placed far away from the module, Saiko Systems highly recommends the use of an Active antenna. This will greatly help in reducing noise and acquiring a signal faster. -
Page 17: Vid / Pid
The Serial Number is used to differentiate multiple instances of the same product connected to a single host. Each WI-GPS-XX is factory programmed with the following VID, PID, and a unique Serial Number which can be found printed on the PCB. Saiko Systems Ltd. 0x260C WI-GPS-XX 0x1005... -
Page 18: Driver
If a warning is issues that the driver has not passed Windows Logo testing to verify compatibility, click Continue Anyway. 7. Click Finish. 8. Windows will now detect a second new hardware called “Saiko FTDI Port”. Follow steps 3-7 to install the driver. 9. Your WI-GPS-XX is now ready to use. -
Page 19: Protocol
Transceiver to provide a RS232 port with 15kV ESD protection. The RS232 Port can be accessed by connecting a RS232 Cable (Saiko Systems Ltd. Part #: CA-RS232-S-M) and a DB9 Null Modem Cable to J3. The RS232 transceiver can also be bypassed, and Port A UART can be accessed directly via the TB2 screw terminal. -
Page 20: Pulse-Per-Second (Pps) (Tb2)
WI-GPS-XX User Manual V1.0 2012 3.8 Pulse-Per-Second (PPS) (TB2) The Copernicus II receiver provides a reliable GPS timing signal called Pulse-Per-Second (PPS). The signal can be accessed via Pin 1 of the screw terminal TB2. The PPS signal is also connected to LED D4 as a visual reference. -
Page 21: Reset Header (J2)
WI-GPS-XX User Manual V1.0 2012 3.10 Reset Header (J2) The WI-GPS-XX contains a standard 0.100” pitch 2-pin locking header (Molex 22-12-2024) which can be used to externally reset the board. Under normal operating conditions, the contacts on the header should remain open. To reset the device, short the two contacts on the header for a brief period of time and then release the short. -
Page 22: Chapter 4: Gps Settings & Configuration
WI-GPS-XX User Manual V1.0 2012 Chapter 4: GPS Settings & Configuration 4.1 Trimble Studio The WI-GPS-XX can be easily configured and tested using the Trimble Studio Application. Trimble Studio is a free application which allows developers to easily interface with Trimble GPS receivers allowing easy testing and configuration. -
Page 23: Default Settings
WI-GPS-XX User Manual V1.0 2012 4.2 Default Settings Each WI-GPS-XX module is factory configured with the following settings: Receiver Mode Auto (2D/3D) GPS Configuration Dynamics Land SBAS Mode Datum WGS-84 Sensitivity Indoor (High) Elevation Mask 4.99 Baud Rate 4800 Port A Parity None Data Bits... -
Page 24: Modifying Settings
WI-GPS-XX User Manual V1.0 2012 SV1 through SV32 SV Masks WAAS SV133, SV135, SV138 MSAS SV129, SV137 GAGAN SV127, SV128 EGNOS SV120, SV124, SV126, SV131 4.3 Modifying Settings To modify any of the default settings described in section 4.2, simply follow the instructions below: 1. - Page 25 WI-GPS-XX User Manual V1.0 2012 5. After a connection is established, click on Receiver > Configure 6. All of the GPS Receiver’s configuration bits can be modified using this window. Please Note: The query button may need to be clicked to retrieve the settings currently stored in the module.
-
Page 26: Chapter 5: Technical Support & Warranty
Technical Support & Warranty 5.1 Technical Support If you run into any trouble with your Saiko Systems Ltd. product, or need further assistance than is provided in this User Manual or other resources, rest assured that we are here to help! The Saiko Systems Ltd. -
Page 27: Chapter 6: History
WI-GPS-XX User Manual V1.0 2012 Chapter 6: History Date Version Action 4/5/2012 Original Released...
