Vectronix VECTOR X User Manual page 89

Measurement menu – HUD screen without ballistics
a
943
ULM
BT
YARDS
EHR
940
YARDS
23°
N NE
b c
INCLINATION
5.0
DEGREES
SE S
d
a. "EHR"/horizontal range
b. Target distance
c. "Inclination"/angle of inclination to target
d. Azimuth
Only a HUD screen without ballistic data is shown in
the following cases:
▪ If the entry "Ballistics" is set to "OFF" in the
"Settings" [} 96] menu
▪ Or if no "gun profile" was selected – see "Gun
Profiles" [} 95] menu
89 / 144
