Vectronix VECTOR X User Manual

Laser rangefinder binoculars
Hide thumbs

Advertisement

Quick Links

Download this manual
USER MANUAL: VECTOR X
Laser rangefinder binoculars

Advertisement

loading
Need help?

Need help?

Do you have a question about the VECTOR X and is the answer not in the manual?

Questions and answers

Related Manuals for Vectronix VECTOR X

Summary of Contents for Vectronix VECTOR X

  • Page 1 USER MANUAL: VECTOR X Laser rangefinder binoculars...
  • Page 3 Thank you for purchasing this product from VECTRONIX SHOOTING SOLUTIONS. We hope you enjoy using your new VECTOR X. Read this user manual before use to ensure that you can take full advantage of all the features of this versatile, high-quality laser rangefinder.
  • Page 4 TABLE OF CONTENTS 1 INTRODUCTION ....................10 2 GENERAL INFORMATION ..................11 2.1 Meaning of symbols ..........................11 2.2 User documentation and software....................... 12 3 SAFETY INFORMATION ..................13 3.1 Personal responsibility........................14 3.2 Intended use ............................15 3.2.1 Intended use (detail)....................... 15 3.2.2 Usage restrictions........................
  • Page 5 3.8.1 Allergens ..........................24 3.9 Environmental hazards........................25 4 PROTECTION AGAINST DAMAGE ................26 4.1 Storage and transport instructions ....................26 4.2 Instructions for use ..........................27 4.3 Extreme environmental conditions ...................... 27 4.4 Notes on the lenses..........................28 4.5 Notes on the battery .......................... 29 5 DEVICE DESCRIPTION..................
  • Page 6 6.1 Using the case effectively........................54 6.1.1 Fastening the neck strap ......................57 6.2 Changing the battery ......................... 58 6.2.1 Suitable batteries........................58 6.2.2 Inserting/replacing a CR123A primary lithium-ion battery ............. 60 6.2.3 Preparing, inserting, and replacing the 18650 rechargeable lithium-ion battery ....61 6.2.3.1 Replacing the battery compartment cover............
  • Page 7 Activating/deactivating Bluetooth ...................75 6.6.4 Creating a target card ......................76 6.7 Downloading the VECTRONIX SHOOTING SOLUTIONS app and connecting it to the VECTOR X ...... 78 7 MENU DESCRIPTION ..................82 7.1 Menu symbols and abbreviations ......................82 7.2 Measurement menu ........................... 83 7.2.1...
  • Page 8 7.7.3 Factory Reset submenu ......................103 8 MEASUREMENTS ..................... 104 8.1 Measurement parameters ........................ 104 8.2 Preparing for measurement......................105 8.3 Factors influencing measurement accuracy ..................106 8.3.1 Factors influencing distance measurement ................106 8.3.2 Factors influencing azimuth measurement accuracy and compass calibration ...... 107 8.4 Single measurement .........................
  • Page 9 11.4 Attaching the tripod adapter......................122 12 MAINTENANCE ....................124 12.1 Care and cleaning..........................124 12.1.1 Cleaning the lenses....................... 124 12.1.2 Cleaning the housing/rubber reinforcement ................. 125 12.1.3 Cleaning/replacing the eyecups .................... 126 12.2 Troubleshooting ..........................127 12.3 Spare parts............................131 12.4 Customer service ..........................
  • Page 10 Please read the enclosed safety information for the laser rangefinder or the safety chapter in this user manual before using the VECTOR X. VECTRONIX SHOOTING SOLUTIONS We produce state-of-the-art optronic observation devices for discerning precision shooters and hunters. Through our products, we help our customers quickly and reliably achieve first-shot accuracy when hunting or competing.
  • Page 11 2 GENERAL INFORMATION For simplicity, this manual shows the VECTOR X 8×42 model from the VECTOR X series. Operations with multiple steps are written in numbered order (1, 2, 3, etc.). This symbol indicates the result of an action or additional information regarding operation. This symbol indicates countermeasures to avoid danger.
  • Page 12 (optional accessory) Incorporated: www.armament.com VECTRONIX SHOOTING SOLUTIONS app Smartphone app available for download. VECTOR X operating system The VECTRONIX SHOOTING SOLUTIONS app makes it possible to run updates. NOTICE Our website has the latest downloads and information related to the VECTOR X: www.vectronix-shooting-solutions.com...
  • Page 13 3 SAFETY INFORMATION The safety information for laser rangefinders, which comes with the VECTOR X, contains all the basic safety information from this chapter. NOTICE We recommend keeping the safety information for laser rangefinders together with the VECTOR X. Safety notices in the user manual are marked with a warning symbol (see "Meaning of symbols" [} 11]) and iden- tified by specific signal words and colors based on the hazard level.
  • Page 14 ▪ Using the VECTOR X in any manner not described in the user documentation or for any purpose outside of the intended purpose described is strongly discouraged. Safran Vectronix AG assumes no liability for injuries or damages caused by such use.
  • Page 15 3.2 Intended use The VECTOR X is intended for use as ▪ A binocular laser rangefinder with digital magnetic compass and inclinometer ▪ A portable or stationary observation and measuring device 3.2.1 Intended use (detail) The VECTOR X is also used with other devices or apps to ▪...
  • Page 16 3.2.3 Foreseeable misuse Misuse of the VECTOR X can cause serious injury, damage to property, malfunction of equipment, or measurement errors. Safran Vectronix AG assumes no liability for any such occurrences. 16 / 144...
  • Page 17 "Technical specifications" [} 43] ▪ Unauthorized changes and modifications ▪ Use of accessories that are not expressly approved by Safran Vectronix AG ▪ Continued use of a defective device, such as misuse with obvious damage or defects ▪ Opening of the device (except the battery compartment) and repairs by unauthorized personnel and workshops ▪...
  • Page 18 3.3 Eye safety The VECTOR X has a laser diode and magnifying lenses. 3.3.1 Laser safety instructions Class 1M laser product CLASS 1M The VECTOR X is categorized as a Class 1M laser product per IEC/EN 60825-1. LASER PRODUCT Note for the US This product corresponds to the requirements for laser products per 21 CFR 1040.10 and 1040.11, except for the deviations necessary for compliance with IEC 60825-1 Ed. 3.0 –...
  • Page 19 CAUTION Risk of eye injury from the invisible laser beam Due to the use of optical components (e.g., lenses), Class 1M lasers can be dangerous for the eyes. SAFETY INSTRUCTIONS Never aim at people. ð This is especially important for people who are currently using an optical instrument (binoculars, scope, telescopic sight, surveying instrument, etc.).
  • Page 20 3.4 Mechanical hazards WARNING Risk of injury from mechanical hazards ▪ Risk of injury to the eyes and face from the eyepieces ▪ Risk of strangulation and injury from the neck strap ▪ Risk of choking and injury by swallowing small parts (e.g., battery) SAFETY INSTRUCTIONS Be careful when holding the VECTOR X in front of your face.
  • Page 21 3.5 Battery hazards DANGER Risk of thermal and chemical burns The rechargeable or non-rechargeable lithium-ion battery in the VECTOR X can overheat if it be- comes damaged. This will release toxic fumes and caustic electrolyte and, in extreme cases, cause explosion. Lithium reacts with water and humidity at high temperatures and releases toxic fumes.
  • Page 22 After contact with the eyes, immediately rinse the affected eye with large amounts of water and seek medical care. After contact with the skin, first remove contaminated clothing. Thoroughly cleanse the af- fected skin with soap and water. Seek medical care if skin irritation or pain persists. ð...
  • Page 23 3.7 Outdoor hazards WARNING Weather-related hazards When using the VECTOR X with the VECTRONIX SHOOTING SOLUTIONS app for navigation Take the current environmental conditions and related risks into account before commencing outdoor activities. Pay attention in particular to dangerous weather events (storms, blocked passages, etc.).
  • Page 24 3.8 Substance hazards The VECTOR X contains SVHCs (substances of very high concern) per Article 33 of the EU REACH Regulation (1907/2006). ▪ Alloys with a lead concentration above 0.1% w/w are present. There is no risk to the user’s health because bare skin will not touch the lead-containing component in question.
  • Page 25 3.9 Environmental hazards NOTICE Avoid environmental hazards Do not dispose of used batteries in household waste. At the end of the service life of the VECTOR X or its parts or accessories, do not dispose of these items in household waste. Dispose of used batteries at a suitable collection point in compliance with legal regulations.
  • Page 26 4 PROTECTION AGAINST DAMAGE Observe the following instructions to ensure that your VECTOR X will remain your reliable and faithful companion for a long time to come. The device components, setting elements, and operating elements described in this manual are shown in the "Device description" [} 32] chapter. 4.1 Storage and transport instructions ▪...
  • Page 27 4.2 Instructions for use ▪ Do not adjust the following setting elements of the VECTOR X beyond their end positions: Risk of damage – Focus wheel – Diopter adjustment ring – Display adjustment ring – Hinge for adjusting the interpupillary distance ▪...
  • Page 28 ▪ When using the device in a very cold environment, make sure that your breath does not condense and freeze on the glass surfaces. If there are long intervals between measurements, keep the VECTOR X near your body so the warmth can prevent an excessive drop in the battery capacity. ▪...
  • Page 29 4.5 Notes on the battery The terms “battery” and “lithium-ion battery” are used as general terms for all battery sizes and types that are suitable for the VECTOR X. A primary lithium-ion battery is a non-rechargeable battery. A rechargeable lithium-ion battery can be recharged.
  • Page 30 NOTICE The VECTOR X can be seriously damaged by a leaking battery. The leaking electrolyte can destroy the electrical contacts in the battery compartment through corrosion. Do not touch escaped electrolyte. This presents the risk of chemical burns. Remove the leaking battery and dispose of it properly (see "Disposal" [} 133]). Clean the battery compartment and battery compartment cover with cotton swabs and a damp cloth.
  • Page 31 ▪ Only use name-brand batteries of the specified battery types (see "Suitable batteries" [} 58]). ▪ Do not use a damaged, deformed, bulging, or leaking battery. ▪ Do not use expired batteries. ▪ Never try to charge a non-rechargeable, primary lithium-ion battery in a charger. This presents the risk of explosion.
  • Page 32 – Applied Ballistics Elite (depending on type, size, and reflectiveness of ▪ Bluetooth connection capability target) – VECTRONIX SHOOTING SOLUTIONS smartphone app ▪ Digital compass – External devices from third-party manufac- – Displays magnetic north or azimuth in degrees turers such as weather gauges and ballistic (°), mrad, or mil...
  • Page 33 5.1 Scope of supply 33 / 144...
  • Page 34 SOLUTIONS logo patch Available for download are ▪ User manual in multiple languages at www.vectronix-shooting-solutions.com ▪ VECTRONIX SHOOTING SOLUTIONS app in the App Store or Google Play Store For information on replacement parts, see "Spare parts" [} 131]. 34 / 144...
  • Page 35 5.2 Device overview a) Diopter adjustment ring, left b) Multi-selector with arrow keys and Menu button c) Hinge d) Measurement button e) Eyepieces (2×) f) Focus wheel with laser-engraved model code (e.g., 10×42) and serial number g) Eyecups (2×), adjustable with click latch h) Diopter adjustment ring, right (for focusing heads-up display and reticle) Neck strap attachment point (2×)
  • Page 36 k) Two openings in the housing for brightness, tem- perature, air pressure, and humidity sensors Attachment clip with retention strap m) Objective lens, laser beam inlet opening n) Barrel with integrated reticle and display o) Objective lens, laser beam outlet opening p) CR123A battery compartment cover (standard) q) Objective lens thread (M46×0.75) for attaching accessories*...
  • Page 37 – Optimized for using the Range Enhancers The integrated reticle is designed based on the magnification of the device and cannot be changed later. See our website for a detailed view of the reticles with notes for use: www.vectronix-shooting-solutions.com 37 / 144...
  • Page 38 MSR-SMR reticle The MSR-SMR milliradian reticle is coordinated to the base magnification of the VECTOR X model it’s installed in. 38 / 144...
  • Page 39 Display area 0.35 0.35 0.125 Zoom in on this page in your PDF viewer to see the details. 39 / 144...
  • Page 40 MSR-DMR reticle 12 x x 17 The MSR-DMR milliradian reticle has two parts. The left side of the reticle is coordinated with the base magnifi- cation of the VECTOR X. If the Range Enhancers are attached, use the right side of the reticle. The respective magnification values can be seen on both sides below the reticle (circled in red).
  • Page 41 12 x x 17 Display area Zoom in on this page in your PDF viewer to see the details. 41 / 144...
  • Page 42 5.2.2 Heads-up display (HUD) This HUD screen appears after the Measurement button is pressed. Its location is ▪ To the right on the MSR-SMR reticle ▪ In the center of the MSR-DMR reticle YARDS ELEVATION WINDAGE 1 WINDAGE 2 7.29 U 0.39 R 0.74 R MRAD...
  • Page 43 5.3 Technical specifications Optics Model name VECTOR X 8×42 VECTOR X 10×42 VECTOR X 12×42 Observation Optical viewfinder, binocular Objective lens diameter 42 mm Magnification 8× 10× 12× Reticle MSR-SMR, or MSR-DMR for Range Enhancers Field of view in m/ft at 130 m/387 ft 110 m/330 ft 91 m/272 ft 1000 m/1000 yd Field of view in degrees 7.4°...
  • Page 44 Model name VECTOR X 8×42 VECTOR X 10×42 VECTOR X 12×42 Interpupillary distance 58 mm to 78 mm Close focus 8 m/9 yd Diopter adjustment ±4 diopters Twilight factor 18.3 20.5 22.45 Rangefinder Laser type 905 nm, Class 1M per IEC/EN 60825-1 Range information Maximum range From 2 m/3 yd to 6400 m/7000 yd Tree From 2 m/3 yd to 2800 m/3000 yd...
  • Page 45 Error rate <2% Beam divergence (changes slightly with focus) VECTOR X 8×42 / 10×42 1.8 × 0.1 mrad VECTOR X 12×42 1.5 × 0.1 mrad Acquisition time <0.25 s Mechanical specifications Model name VECTOR X 8×42 VECTOR X 10×42 VECTOR X 12×42 Housing Magnesium die casting...
  • Page 46 Garmin smartwatches with Foretrex 701/901 ® tactical functions Tactix Delta ® Tactix ® Instinct Descent Mk 2i Marq Commander Carbon D2 Mach 1 Pro, etc. The list of compatible devices is continually updated on our website: www.vectronix-shooting-solutions.com 46 / 144...
  • Page 47 Additional programs for smartphones (apps) VECTRONIX SHOOTING SOLUTIONS app For Android, iOS Supported map services for integrated map navigation Google Maps, Basemap, CivTAC (plug-in required) Digital magnetic compass with inclinometer Units 360°/6283 mrad/6400 mil Azimuth accuracy (1σ) ±5° Maximum inclination ±89°/±1553 mrad/±1582 mil...
  • Page 48 Battery supply Standard, as supplied (1) 3 V CR123A primary lithium-ion battery Battery capacity (CR123A) >10,000 measurements (at 20°C/68°F) Optional, rechargeable (1) 3.7 V 18650 rechargeable lithium-ion battery Battery capacity (18650) >18,000 measurements (at 20°C/68°F) Environmental conditions Protection class IP67 (waterproof up to 1 m/3.3 ft for 30 min) Operating temperature -20°C/-4°F to +50°C/122°F Storage temperature...
  • Page 49 5.4 Available accessories a) 917 239 Range Enhancers 42 b) 917 806 Anti-Reflection Devices (ARD) 42 Model-specific accessories have an additional designation (e.g., 42). 49 / 144...
  • Page 50 ▪ Increase the magnification of the VECTOR X ▪ Slightly improve the performance of the laser for distance measurement Range Enhancers are an original VECTRONIX SHOOTING SOLUTIONS accessory and are not included in the scope of supply. These magnification values can be achieved with the Range Enhancers 42:...
  • Page 51 Attachment of the Range Enhancers is described here: "Attaching/removing the Range Enhancers" [} 120]. A VECTOR X with the MSR-DMR reticle (see "Reticle types" [} 37]) enables optimal use of the Range Enhancers. The objective lens caps can also clip onto the Range Enhancers.
  • Page 52 5.4.2 Anti-Reflection Devices (ARD) a) Connection thread (M46×0.75) b) Objective lens cap c) Honeycomb filter The installed Anti-Reflection Devices ▪ Reduce incident light ▪ Prevent sunlight or other light sources from re- flecting into the objective lenses of the VECTOR X and revealing its location Attachment of the Anti-Reflection Devices is described here: "Attaching/removing the Anti-Reflection Devices...
  • Page 53 5.4.3 Tripod The VECTOR X has an attachment point for a tripod connection (see "Attaching the tripod adapter" [} 122]). NOTICE Azimuth measurement error due to tripod Metal parts on the tripod can affect the magnetic compass of the VECTOR X. Only use a tripod made of nonmagnetic/non-magnetizable materials (carbon, aluminum). 53 / 144...
  • Page 54 6.1 Using the case effectively a) Detachable protective covers for hook-and-loop closures. b) Hook-and-loop surface for name patch and VECTRONIX SHOOTING SOLUTIONS logo patch. In- cludes MOLLE-compatible system for attaching the storage case for the Range Enhancers (optional – see end of section).
  • Page 55 This makes it easier to read a target card or range card inserted in the viewing window when shooting prone. You can create and print a target card or range card with the VECTRONIX SHOOTING SOLUTIONS app. 55 / 144...
  • Page 56 Attaching the storage case 1. Place the storage case in front of the hook-and- loop surface of the case. 2. Undo the snaps of the attachment loops. 3. Alternately thread the attachment loops through the openings in the hook-and-loop surface and the bracket on the back of the storage case.
  • Page 57 6.1.1 Fastening the neck strap 1. Guide the end of the neck strap through the brackets 3. Repeat the previous steps for the other end on the eyepiece cap and VECTOR X housing. of the neck strap. 2. Thread the end of the strap into the adjustment loop 4.
  • Page 58 The neck strap can also be fastened to the case. 6.2 Changing the battery NOTICE Azimuth measurement error after battery change The battery affects the magnetic compass of the VECTOR X. Changing the battery changes the magnetic field, especially if the new battery is a different type. Recommendation: To ensure azimuth measurement accuracy, recalibrate the magnetic compass after changing the battery (see "Performing compass calibration (Chicken Dance)"...
  • Page 59 Some models of 18650 rechargeable lithium-ion battery are thicker because of the integrated protective electronics. These might barely fit in the battery compartment or not fit at all. To avoid this problem, visit our website for a list of suitable name-brand 18650 rechargeable lithium-ion batteries: www.vectronix-shooting-solutions.com 59 / 144...
  • Page 60 6.2.2 Inserting/replacing a CR123A primary lithium-ion battery a) Battery compartment with battery symbols b) 3 V CR123A primary lithium-ion battery c) Retention strap d) CR123A battery compartment cover 1. Turn the battery compartment cover counter- clockwise by hand and take it off the battery compartment.
  • Page 61 6.2.3 Preparing, inserting, and replacing the 18650 rechargeable lithium-ion battery The VECTOR X comes with a CR123A battery compartment cover. This must first be replaced to enable use of a 18650 rechargeable lithium-ion battery. 6.2.3.1 Replacing the battery compartment cover a) Attachment clip c) CR123A battery compartment cover b) Retention strap d) 18650 battery compartment cover...
  • Page 62 The 18650 battery compartment cover is considerably longer than the standard CR123A battery compartment cover. 1. Turn the CR123A battery compartment cover counterclockwise by hand and take it off the battery compartment. 2. Pull the attachment clip off the CR123A battery compartment cover. Store the CR123A battery compartment cover somewhere it won’t be lost.
  • Page 63 a) Battery compartment with battery symbols b) 3.7 V 18650 rechargeable lithium-ion battery c) Retention strap d) 18650 battery compartment cover 1. Turn the 18650 battery compartment cover coun- terclockwise by hand and take it off the battery compartment. 2. If applicable, remove the dead rechargeable lithium-ion battery from the battery compartment.
  • Page 64 6.3 Turning on the device/automatic power-off 1. Sight an object with the reticle. 2. Briefly press the Measurement button. ð The heads-up display lights up. 3. Briefly press the Measurement button again. YARDS ELEVATION WINDAGE 1 WINDAGE 2 7.29U 0.39R 0.74R MRAD MRAD...
  • Page 65 6.4 Personal settings After another person has used the VECTOR X or if it is not used for a long period of time, enter or check the personal settings again, especially the diopter setting. 6.4.1 Adjusting the eyecups The rotating eyecups can be used to adjust the eye relief to the eyepiece.
  • Page 66 To thoroughly clean or replace a damaged eyecup, see "Cleaning/replacing the eyecups" [} 126]. 6.4.2 Setting the interpupillary distance 1. Look through the VECTOR X and sight something, such as a feature in the landscape. 2. Slowly pivot both barrels of the binoculars around the center axis (hinge).
  • Page 67 6.4.3 Setting the diopters Basic setting for equal focus of both eyes There are adjustment marks on the bottom of the eyepieces (see image detail). 1. Turn the VECTOR X over. 2. Turn both diopter adjustment rings to their zero positions. Diopter adjustment Adjust the diopters to ▪...
  • Page 68 1. Turn both diopter adjustment rings to their zero positions (see basic setting on previous page). 2. Sight an object farther than 100 m/100 yd. 3. To improve the accuracy of what you see, close your left eye or cover the left objective lens with your hand or with the objective lens cap.
  • Page 69 6.4.4 Adjusting the focus 1. Sight an object with the VECTOR X. 2. Turn the focus wheel until the object looks as sharp as possible. The focus wheel can focus from 8 m/9 yd to infinity. 69 / 144...
  • Page 70 The buttons on the top of the VECTOR X housing can be used to call up all device and menu functions. Many settings can also be made easily and conveniently in the VECTRONIX SHOOTING SOLUTIONS app and sent to the VECTOR X via Bluetooth.
  • Page 71 Scan mode is intended for use with moving objects – see "Scan mode" [} 110]. Scan mode consumes more battery power. It automatically turns off after 20 seconds. Scan mode can then be restarted. 6.5.2 Multi-selector 6.5.2.1 Menu button on the multi-selector Use the center Menu button to ▪...
  • Page 72 6.5.2.2 Arrow keys on the multi-selector Use the arrow keys to navigate the menus, adjust settings, and activate shortcuts. 6.6 Using shortcuts Pressing and holding an arrow key on the multi-selector enables the following functions: Arrow key Shortcut Arrow key Shortcut Up arrow Stopwatch/timer...
  • Page 73 The shortcuts make important functions and menu settings easy to access. 6.6.1 Stopwatch/timer Using the stopwatch/timer STOP WATCH / TIMER 1. Press and hold the up arrow key to call up the HOLD MENU TO EXIT shortcut. 00:00 2. Enter the start time for the timer using the up/ down arrow keys.
  • Page 74 6.6.2 Changing the laser mode After exiting the shortcut, an abbreviation for the se- LASER MODE lected setting is displayed in the Measurement menu. HOLD MENU TO EXIT Procedure LASER MODE 1. Press and hold the down arrow key to call up the shortcut.
  • Page 75 4. When the search is complete, select the VECTOR X in the device list and initiate pairing. ð The VECTOR X will send a pin code to the VECTRONIX SHOOTING SOLUTIONS app. This needs to be entered in the device being paired with upon initial pair- ing –...
  • Page 76 ID or the next empty target ID. The target card you created can be viewed in the 3. Perform the distance measurement. Target Card main menu and in the VECTRONIX ð The current target data will appear in the target SHOOTING SOLUTIONS app.
  • Page 77 Menu button to exit the shortcut. You can also enter target data into the target card with the VECTRONIX SHOOTING SOLUTIONS app by remotely triggering a distance measurement. Export the target card created with the VECTRONIX SHOOTING SOLUTIONS app (e.g., to an E-DOPE card from Down Range Systems), save it as a PDF, and print it.
  • Page 78 6.7 Downloading the VECTRONIX SHOOTING SOLUTIONS app and connecting it to the VECTOR X Procedure 1. Download the free VECTRONIX SHOOTING SOLUTIONS app onto your smartphone or tablet. ð The app is available in the following app download stores, based on the operating system of your device:...
  • Page 79 VECTOR X PIN CODE PRESS ANY BUTTON TO EXIT. 7. A two-digit pin code will appear on the heads-up display of the VECTOR X. 5. Start the pairing 6. Select the VECTOR X in If the VECTOR X is in standby, briefly press the Mea- process.
  • Page 80 8. Enter the pin code and The pairing process is confirm by tapping complete. “OK.” After pairing, synchronization between the smartphone and VECTOR X can take up to 15 seconds. All features of the VECTRONIX SHOOTING SOLUTIONS app are available only after synchronization. 80 / 144...
  • Page 81 Troubleshooting connection problems Please check the following if there are issues establishing a connection: ▪ Charge the smartphone or tablet before it gets too low, and pay attention to the battery display on the VECTOR X. The energy management program might turn Bluetooth off when the battery level is too low. ▪...
  • Page 82 7 MENU DESCRIPTION 7.1 Menu symbols and abbreviations Menu symbols Page indicator in Measurement menu (HUD screens 1 through 3) Lithium-ion battery, full charge Lithium-ion battery, sufficient charge Lithium-ion battery, low charge Lithium-ion battery, very low charge – only a few more measurements possible Compass calibration (Chicken Dance) required 82 / 144...
  • Page 83 Abbreviations Bluetooth is active and ready for connection Bluetooth connection to external device Bluetooth connection to VECTRONIX SHOOTING SOLUTIONS app on smartphone Bluetooth connection to external Calypso Instruments device (e.g., Ultrasonic Portable AB Mini wind meter) CLPS Bluetooth connection to external Garmin device (e.g., tactix 7 AMOLED) GRMN Bluetooth connection to external Kestrel device (e.g., Kestrel 5700 Elite AB)
  • Page 84 7.2.1 Special features of the Measurement menu a. Page indicator with three squares. The marked square indicates the current HUD screen (1 through 3). b. Abbreviation of the active device function(s) – laser mode and Bluetooth connection (see "Menu symbols and abbreviations" [} 82]). YARDS c.
  • Page 85 7.2.2 Measurement menu/HUD screens The data and information related to the current distance measurement are displayed on three HUD screens. Measurement menu – HUD screen 1 a. “Elevation”/height adjustment value b. Target distance c. “Windage 1” – lateral correction value 1, applies to wind measurement 1 d.
  • Page 86 The scale of the compass indication and azimuth (degrees (°)/mrad/mil) can be selected in the "Settings" [} 96] menu. Use the arrow keys (up/down) to change the brightness of HUD screen 1. This will also change the brightness of HUD screens 2 and 3. For information about the brightness setting, see "Settings" [} 96].
  • Page 87 Measurement menu – HUD screen 2 a. “Wind 1”/wind measurement 1: average wind speed with wind direction arrow – The value displayed can be adjusted with the up/down arrow keys. b. Target distance YARDS c. “Wind 2”/wind measurement 2: maximum wind speed with wind direction arrow WIND 1 WIND 2...
  • Page 88 Measurement menu – HUD screen 3 a. “DEMO GUN”/selected gun profile b. Target distance c. “Rem. velocity”/remaining projectile velocity at target d. “Rem. energy”/remaining projectile energy at YARDS target DEMO GUN MM-6.5-CM-ELDM REM. VELOCITY REM. ENERGY 1549 FT-LB 88 / 144...
  • Page 89 Measurement menu – HUD screen without ballistics a. “EHR”/horizontal range b. Target distance c. “Inclination”/angle of inclination to target d. Azimuth Only a HUD screen without ballistic data is shown in YARDS the following cases: ▪ If the entry “Ballistics” is set to “OFF” in the INCLINATION "Settings"...
  • Page 90 7.3 Main menus 7.3.1 Buttons used with the main menus Pressing and holding the Menu button brings up the menu bar with the current main menu. Briefly press the Menu button to confirm an entry, setting, or selection. Use the four arrow keys on the multi-selector to navigate through the menu and adjust settings. Exit button: Highlight this button in the menu bar and briefly press the Menu button to exit the main menu and display HUD screen 1 of the Measurement menu.
  • Page 91 7.3.2 Special features of the main menus a. Menu bar (current main menu is highlighted) b. Selection field c. Indication of the arrow keys used for selection d. Scroll bar if there are more entries (scroll up/ SETTINGS down with the arrow keys) LASER MODE BALLISTICS BRIGHTNESS...
  • Page 92 7.3.3 Menu bar The menu bar has icons for all available main menus and an exit button. BACK TO HUD The active main menu is highlighted in red in the menu bar. Icon Main menu/button Environmental Conditions Target Card Gun Profiles Settings Exit button (back to HUD screen 1) 92 / 144...
  • Page 93 – Measurement of the relative humidity with the tered in this main menu or transmitted via the internal sensor VECTRONIX SHOOTING SOLUTIONS app. ▪ “Wind direction” – The wind direction entered is displayed in the Measurement menu/HUD screen 2 with a direc- tion arrow.
  • Page 94 7.5 Target Card This main menu displays the target card with all distance measurements saved and the associated ballistic data. TARGET CARD ▪ “Delete all targets” DELETE ALL TARGETS – Select the deletion command with the red DIST WNDG 1 WNDG 2 selection field.
  • Page 95 4 DRPH-AI-308-RDF 175GR .308 The gun profiles are compiled from projectile databases and are transferred to the VECTOR X via the VECTRONIX SHOOTING SOLUTIONS app. The VECTOR X comes with a demo gun profile (“DEMO GUN”) with an example load for demonstration purposes.
  • Page 96 Misses due to incorrect correction values An incorrect gun profile or selecting the wrong gun profile can lead to incorrect ballistic output values and miscalculations, for which Safran Vectronix AG assumes no liability. The user is responsible for the proper gun profile configuration and selection.
  • Page 97 ▪ “Laser mode”: LRM/ULM – Indicated in the Measurement menu SETTINGS – See "Changing the laser mode" [} 74] ▪ “Ballistics”: ON/OFF LASER MODE – When OFF, the VECTOR X does not send ballistic BALLISTICS output values ▪ “Brightness”: Auto/NV 1, NV 2, 3 – 15 BRIGHTNESS AUTO –...
  • Page 98 Scroll down with the arrow keys to display the last submenu. SETTINGS ▪ “Language”: EN (English) – Language for the heads-up display. BRIGHTNESS AUTO ▪ “Target ID”: Alpha./Numer. UNITS ENTER – Indicate targets on the target card with letters BATTERY CR123A or numbers.
  • Page 99 7.7.1 Units submenu To call up this submenu 1. Use the up/down arrow keys to place the red SETTINGS selection field on “Units.” 2. Briefly press the right arrow key. LASER MODE BALLISTICS BRIGHTNESS AUTO UNITS ENTER BATTERY CR123A LANGUAGE TARGET ID ALPHA.
  • Page 100 ▪ “Units”: Exit – Exit the submenu and return to the Settings SETTINGS menu by pressing the left arrow key. UNITS EXIT ▪ “Distance”: m/yd ▪ “Azimuth”: degrees (°)/mil/mrad DISTANCE METER ▪ “Inclination”: degrees (°)/mil/mrad MILS AZIMUTH ▪ “Elv/wnd”/height correction value/lateral correc- INCLINATION DEGREE tion value: mrad/mil...
  • Page 101 7.7.2 Device Info submenu To call up this submenu 1. Use the up/down arrow keys to place the red SETTINGS selection field on “Device info.” 2. Briefly press the right arrow key. BRIGHTNESS AUTO UNITS ENTER BATTERY CR123A LANGUAGE TARGET ID ALPHA.
  • Page 102 ▪ “Device info”: Exit – Exit the submenu and return to the Settings SETTINGS menu by pressing the left arrow key. ▪ “Device name” DEVICE INFO EXIT ▪ “Serial number" DEVICE NAME: VECSS-6B4CD6 ▪ “Firmware version”/software version SERIAL NUMBER: C0842000… ▪...
  • Page 103 7.7.3 Factory Reset submenu 2. Briefly press the right arrow key to call up the submenu. SETTINGS The submenu has a confirmation prompt: ▪ “Cancel” BRIGHTNESS AUTO – Cancel the process and return to the Settings UNITS ENTER menu. BATTERY CR123A ▪...
  • Page 104 8 MEASUREMENTS NOTICE Risk of damage to the laser diode The laser diode can be overloaded by performing distance measurements close to mirrors, mirror- like surfaces, or highly reflective objects. Never aim at reflective surfaces/objects. 8.1 Measurement parameters Azimuth INCL Inclination Equivalent horizontal range North Range/line-of-sight range...
  • Page 105 8.2 Preparing for measurement Compass calibration It is a good idea to calibrate the compass before measuring in a new environment (see "Compass calibration (Chicken Dance)" [} 114]). Otherwise, potential compass deviations can cause incorrect azimuth values and in- correctly calculated ballistic values. Tips for steady distance measurements ▪...
  • Page 106 8.3 Factors influencing measurement accuracy 8.3.1 Factors influencing distance measurement Reflectiveness Target size Sloped surfaces Weather Vibration Lighting 106 / 144...
  • Page 107 8.3.2 Factors influencing azimuth measurement accuracy and compass calibration The VECTOR X has a digital compass that works like a magnetic compass. Metal objects, magnetic fields, and electronic devices (e.g., smartwatches, smartphones, tablets) can cause errors during azimuth measurement or compass calibration. Non-magnetic metals and alloys do not affect the compass.
  • Page 108 8.4 Single measurement Procedure 1. Sight the object with the reticle. 2. Briefly press the Measurement button. ð The heads-up display lights up. 3. Briefly press the Measurement button again. ð The distance measurement is triggered and the heads-up display shows HUD screen 1 with the current measurements.
  • Page 109 Menu button. 8.4.1 Additional measurement functions The following additional measurement functions are available with the VECTRONIX SHOOTING SOLUTIONS app: ▪ Remote measurement triggering ▪ Measurement and display of the equivalent horizontal and vertical distance ▪...
  • Page 110 8.5 Scan mode The distance to a moving object is continually measured in scan mode. Procedure 1. Briefly press the Measurement button. ð The heads-up display lights up. 2. Press the Measurement button for longer than 1 second and then release it. ð...
  • Page 111 All you need to do with the VECTOR X is activate Bluetooth via the shortcut – see "Activating/deactivating Blue- tooth" [} 75]. Making the connection then takes places on the device being paired with. It is only possible to establish a Bluetooth connection with the VECTRONIX SHOOTING SOLUTIONS app or a single device that can be paired with.
  • Page 112 9.1 Establishing a data connection to a Kestrel device Procedure 1. Activate Bluetooth on the VECTOR X – see "Activating/ deactivating Bluetooth" [} 75]. 2. Keep the Kestrel device near the VECTOR X for the following steps. 3. Turn on the Kestrel device using the On/off button. 4.
  • Page 113 8. Press the Options button to exit the menu. Conct Device Name VECTOR X Rename Forget exit select Lock exit select 6. Select “New” under “Device” and confirm using the Enter button. 9. Select “Lock” and set it to “On.”...
  • Page 114 10 COMPASS CALIBRATION (CHICKEN DANCE) Perform compass calibration ▪ After each battery change ▪ When the Chicken Dance icon appears in the Measurement menu ▪ If azimuth values are outside specifications during test measurements – see "Technical specifications" [} 43] ▪ If the device status is unknown (borrowed device) 10.1 Notes on compass calibration Suitable locations for compass calibration Compass calibration must be performed in an open outdoor area far away enough from buildings and metal...
  • Page 115 Preparing for measurement ▪ Check whether you are carrying or wearing objects that could interfere with compass calibration. – Examples: glasses with metal frames, rings, wristwatches, smartphones, belt buckles, helmets, etc. ▪ Place all objects that could interfere with magnetic waves elsewhere before compass calibration. 10.2 Performing compass calibration (Chicken Dance) The Chicken Dance icon appears in the Measurement menu/HUD screen 1 to prompt compass calibration.
  • Page 116 180° 180° 180° Fig. 1: Compass calibration – first stage Do not rotate the VECTOR X more than 90° to 180° per second during calibration. 116 / 144...
  • Page 117 Fig. 2: Compass calibration – second stage 8. Find a horizontal surface or a suitable place on the 10. After compass calibration, briefly press the Mea- ground. surement button to turn on the heads-up display. 9. Perform each of the following with the VECTOR X ð...
  • Page 118 11 USING THE ACCESSORIES 11.1 Attaching/removing the objective lens caps Attachment information 1. Clip an objective lens cap onto each objective lens of the VECTOR X or the optional Range Enhancers. 2. Rotate the objective lens caps so that the flip caps will open in the direction desired (e.g., downward).
  • Page 119 Close the objective lens caps when the VECTOR X is not in use or during long intervals between measurements. 11.2 Attaching/removing the Anti-Reflection Devices (ARD) Attachment information 1. Screw one Anti-Reflection Device onto each objective lens of the VECTOR X. 2. Rotate the Anti-Reflection Devices such that the flip caps will open in the direction desired.
  • Page 120 The Anti-Reflection Devices reduce the maximum possible range for distance measurement. Removal information 1. Close the flip caps on the Anti-Reflection Devices. 2. Carefully unscrew one Anti-Reflection Device and then the other. 3. Check the Anti-Reflection Devices for dirt and clean them if necessary. 4.
  • Page 121 Attachment information 1. Screw one Range Enhancer to each objec- tive lens of the VECTOR X. 2. Install the objective lens caps to protect the Range Enhancers (see "Attaching/re- moving the objective lens caps" [} 118]). 3. When using the device, open both objective lens caps fully and fold them against the Range Enhancers.
  • Page 122 11.4 Attaching the tripod adapter To use the VECTOR X with a tripod, a tripod adapter with a ¼” 20 UNC tripod mount (included in the scope of supply) must be installed on the underside of the device. Attachment information 1. Unscrew the cover on the underside of the VECTOR X using the Torx key supplied.
  • Page 123 2. Attach the tripod adapter to the tripod connection with four screws. ð Use the supplied Torx key to do so. 3. Place the VECTOR X with the tripod adapter on the tripod head and screw it down. Two spare screws are included in the scope of supply. 123 / 144...
  • Page 124 12 MAINTENANCE 12.1 Care and cleaning NOTICE Risk of damage to the lens surfaces Do not use cleaning fluids or solvents other than water. Never use chemically treated cleaning cloths such as those used for eyeglasses. The supplied cleaning cloth May only be used for cleaning the glass lenses Must be kept clean and stored in the case Must be immediately washed and dried or replaced with a new microfiber cloth if soiled...
  • Page 125 More information about cleaning ▪ Wipe heavily soiled lenses with a damp lens cleaning cloth using light pressure. ▪ Rinse off salt water residue with fresh water if possible. ▪ Wipe off fingerprints by first using a circular motion with a damp part of the lens cleaning cloth. Then remove the fingerprints completely with the dry part.
  • Page 126 12.1.3 Cleaning/replacing the eyecups Removal information 1. Unscrew the eyecups completely. 2. Lift up the rear edge of the eyecups with your pointer finger. 3. Carefully pull the eyecups off the eyepieces. Attachment information The rear edges of the eyecups must lie against the eyepieces evenly.
  • Page 127 12.2 Troubleshooting There are no parts in the device that can be serviced by the user. Repair and service work may only be performed by customer service or directly by Safran Vectronix AG. Problem Potential cause Solution The field of view through the eye- The eyecups aren’t properly set for...
  • Page 128 Problem Potential cause Solution The heads-up display is difficult to The brightness sensor is covered. When the brightness level is set to read (continued). automatic mode, clean the opening in the housing for the sensor – see "Device overview" [} 35], point (k). The heads-up display is too bright.
  • Page 129 Problem Potential cause Solution The azimuth measurement is inac- There was magnetic interference Repeat the compass calibration curate. during compass calibration. process in a new, interference-free location – see "Factors influencing azimuth measurement accuracy and compass calibration" [} 107]. The magnetic state of the VECTOR X Recalibrate the digital compass –...
  • Page 130 Place the device to be paired with far from the VECTOR X, or the con- closer to the VECTOR X. nection was faulty. For other issues, please contact customer service, which can be done for example through the VECTRONIX SHOOTING SOLUTIONS app. 130 / 144...
  • Page 131 12.3 Spare parts 131 / 144...
  • Page 132 919 004 Eyepiece cap 917 801 Case (Protective Case 42) with VECTRONIX SHOOTING SOLUTIONS logo patch 919 007 Eyecups for 8×42 918 795 Range Enhancers 42 (1.4×) 919 008 Eyecups for 10×42/12×42 919 011 Objective lens set for Range Enhancers 42...
  • Page 133 13 DISPOSAL The following information applies per the Waste from Electrical and Electronic Equipment (WEEE) Directive within the EU and for other European countries with waste sorting systems. ▪ The VECTOR X contains electrical and/or electronic components and may therefore not be disposed of in normal household waste.
  • Page 134 The user documentation has been carefully compiled taking the applicable standards and regulations into account. However, it is not possible to exclude all errors. Safran Vectronix AG therefore reserves the right to periodically revise the user documentation and to modify the content without prior notification.
  • Page 135 The user documentation for the VECTOR X – safety information, Quick Start Guide, and this user manual in elec- tronic form – is protected by copyright. The device software and the VECTRONIX SHOOTING SOLUTIONS app are protected by copyright. 14.3 Protected trademarks ®...
  • Page 136 Google Play logo are trademarks of Google LLC. GET IT ON ® Kestrel is a trademark of Nielsen-Kellerman Co. ® Tenebræx is a trademark of Armament Technology Incorporated. VECTOR X is a brand of Safran Vectronix AG. 136 / 144...
  • Page 137 14.4 Declaration of conformity Safran Vectronix AG hereby declares that VECTOR X of the types A002a and A002b comply with EU directives. Our website contains the complete EU declaration of conformity: www.vectronix-shooting-solutions.com 14.5 FCC/ISED regulations The VECTOR X transmits radio frequency signals (e.g., via Bluetooth) and is therefore subject to the following regulations.
  • Page 138 ▪ Move or realign the receiving antenna. ▪ Increase the distance between the device and receiver. ▪ Contact the dealer or an experienced radio and television technician if assistance is required. FCC warning To ensure continued compliance with provisions, see the "Usage restrictions" [} 16] chapter. If any changes or modifications are made to the device that are not expressly approved by the party responsible for compliance with provisions, this could result in revocation of the user’s permit to use the device.
  • Page 139 Type number: A002a Laser Class 1M Tested for compliance with FCC standards. For home or office use.* * This equipment classification includes outdoor use. Use of the device is subject to the following two restrictions: ▪ This device may not cause harmful interference. ▪...
  • Page 140 14.5.2 ISED regulations for Canada CAN ICES-3 (B)/NMB-3 (B) This device complies with the RSS-210 standard of the IC regulations. Use of the device is subject to the following two restrictions: ▪ This device may not cause harmful interference. ▪ This device must tolerate interference received, including interference that may cause functional distur- bances to the device.
  • Page 141 Device accessories as well as wear parts such as eyecups and rubber reinforcement are excluded from the warranty. Warranty claims are rendered invalid in the event of proven misuse (see "Foreseeable misuse" [} 16]) or if the serial number has been made unrecognizable. 141 / 144...
  • Page 142 15 GLOSSARY Term Definition Description Azimuth Azimuth direction angle The angle between magnetic north and the target, mea- [°/mrad/mil] sured clockwise Equivalent horizontal range Angle-corrected horizontal distance [m/yd] Elevation Height correction [mrad/MOA] Height correction to hit the target at the specified dis- tance Field of view Observable width of terrain at a distance of 1000 m/...
  • Page 143 Term Definition Description Universal laser mode Setting for unobstructed objects with average reflec- tiveness Wind 1 Wind (average), [km/h / mph] Average wind strength Wind 2 Wind (max.), [km/h / mph] Peak value of wind strength (gusts) Windage 1 Lateral correction value for Lateral correction value for the average wind speed to Wind 1 [mrad/MOA] hit the target at the specified distance Windage 2...
  • Page 144 917815_A...
