Tritech T15 Owner's Manual

Professional airless sprayer, maximum working pressure 3300psi 227bar 22.7 mpa
Hide thumbs

Advertisement

Table of Contents

15
T
TriTech Industries, Inc., 610 Rahway Avenue, Union NJ 07083
PH: 908-378-1080 FAX: 908-378-1659
!! SAFETY AND OPERATING INSTRUCTIONS INSIDE !!
Read all warnings and safe operating information inside and retain this manual for future reference.
/
Owners Manual
302-124
6/2024 REV H
PROFESSIONAL AIRLESS SPRAYER
MAXIMUM WORKING PRESSURE 3300PSI 227BAR 22.7 MPa
VOLTS
VOLTS
CYCLES
110V
50 / 60
220V
50 / 60
FOR THE APPLICATION OF ARCHITECTURAL PAINTS AND COATINGS
15
T
TX
AMPS
PHASE
13
SINGLE
7
SINGLE
www.tritechindustries.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T15 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tritech T15

Summary of Contents for Tritech T15

  • Page 1 220V 50 / 60 SINGLE FOR THE APPLICATION OF ARCHITECTURAL PAINTS AND COATINGS TriTech Industries, Inc., 610 Rahway Avenue, Union NJ 07083 PH: 908-378-1080 FAX: 908-378-1659 www.tritechindustries.com !! SAFETY AND OPERATING INSTRUCTIONS INSIDE !! Read all warnings and safe operating information inside and retain this manual for future reference.
  • Page 2 602-934 T15 HI CART COMPLETE 110V 602-944 T15 HI CART COMPLETE 220V 602-951 T15 HI CART COMPLETE 220V AUSTRALIA 602-953 T15 HI CART COMPLETE 110V UK 602-955 T15 HI CART COMPLETE 110V CANADA 602-987 T15 HI CART COMPLETE 220V UK...

  • Page 3: Important Safety Information

    IMPORTANT SAFETY INFORMATION SAVE THESE INSTRUCTIONS - To reduce the risk of fire or explosion, electrical shock and the injury to persons, read and understand all instruc�ons. Become familiar with setup and opera�on before using this equipment. GROUNDING This product must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current.
  • Page 4 All parts of the spray system, including the pump, hose assembly, spray gun, and objects in and around the spray area shall be properly grounded to protect against sta�c discharge and sparks. Use only conduc�ve or grounded high-pressure airless paint spray hoses specified by TriTech Industries, Inc.
  • Page 5 � Check hoses and parts for signs of damage. Replace any damaged hoses or parts. � This system is capable of producing 3300 psi. Only use replacement parts or accessories that are specified by TriTech Industries, Inc. and that are rated at a minimum of 3300 psi.
  • Page 6 � Do not alter or modify this equipment. � Use equipment only for its intended purpose. Call TriTech Industries, Inc. customer service or your TriTech Industries, Inc. distributor for informa�on. � Route hoses, cords, extension cords away from high traffic areas, sharp edges, moving parts and hot surfaces. If spray hose is required to be replaced only replace with iden�cal hose supplied with sprayer.

  • Page 7: Tip And Guard Assembly

    START UP 1. Connect TriTech airless hose to sprayer. Tighten securely. 2. Connect other end of the hose to gun. 3. Tighten securely. 4. Remove �p guard. 5. Check inlet strainer for clogs and debris. 6. Fill upper retainer with TriLube to prevent premature packing wear. Do this each �me you spray.
  • Page 8 12. Open prime / spray valve. Then close. Do not store with prime / spray valve open. 13. Remove filter from gun and sprayer, if installed. Clean and inspect. Reinstall filters. 14. If flushing with water, flush again with mineral spirits or TriTech Pump Cleaner to leave a protective coa�ng to prevent freezing or corrosion.
  • Page 9 ELECTRICAL SHOCK WARNING To reduce risk of serious injury, including electric shock, do not touch moving or electrical parts with fingers or tools while tes�ng repair. Shut off and unplug sprayer when inspec�on is complete. Install all covers, guards, gaskets, screws and washers before opera�ng sprayer. PROBLEM WHAT TO CHECK REMEDY...
  • Page 10 EC - DECLARATION OF CONFORMITY Models T15, T15TX Part Number 602-934, 602-944, 602-951, 602-953, 602-955, 602-964, 602-674, 602-981, 602-983 602-985, 602-987, 602-989 Complies with the EC Directives: 2006/42/EC Machinery Directive Standards Used: ISO 1200, ISO 3744 Approved by: Rollan Henderson...
  • Page 11 507-150, 507-151, 507-152, 507-153, 503-400, 503-402 Complies with the EC Directives: 2006/42/EC Machinery Directive Standards Used: ISO 1200, ISO 3744 Approved by: Rollan Henderson National Sales Manager Manufactured by: January 30, 2024 TriTech Industries, Inc. 610 Rahway Avenue Union, NJ 07083 U.S.A.
  • Page 12 Users should contact their supplier and check the terms and condi�ons of the purchase contract. When purchased directly from TriTech Industries, or a TriTech Industries Distributor you may contact technical support for disposal arrangements.
  • Page 13 EXTENSION CORD VOLTAGE DROP 120V 15 AMP 100' 200' 300' 14 AWG 110.6 101.2 91.8 12 AWG 114.1 108.1 102.2 10 AWG 116.3 112.5 108.8 LINE LOSS 1/4" HOSE STANDARD LATEX PAINT HORIZONTAL AT PUMP AT TIP 227 BAR 3300PSI 3150 217 BAR 227 BAR...

  • Page 14: Pressure Relief Procedure

    PRESSURE RELIEF PROCEDURE !! IMPORTANT !! The sprayer’s pressure must be manually relieved to prevent sprayer from starting or spraying fluid accidentally. Fluid under high pressure can be injected through skin and cause serious injury. To reduce risk of injury from injection, splashing fluid, or moving parts, please use the following Pressure Relief Procedure whenever you: •...
  • Page 15 FLUID MANIFOLD <<< T15 >>> DIAGRAM PLEASE REMOVE THE BLACK PACKING HOLDER PRIOR TO PACKING INSTALLATION. PLEASE REMOVE THE BLACK PACKING HOLDER PRIOR TO PACKING INSTALLATION. REV A 9/2023...
  • Page 16 T15 FLUID MANIFOLD NOTE: Items in bold are included in 602-688 packing kit PARTS LIST ITEM # PART # DESCRIPTION 602-178 FILTER HOUSING 600-255 FILTER SPRING 600-141-02 MANIFOLD FILTER, 20 MESH 600-240 FILTER CORE 600-353 O-RING 602-244 UPPER RETAINER 602-485...
  • Page 17 FLUID MANIFOLD <<< T15TX >>> DIAGRAM PLEASE REMOVE THE BLACK PACKING HOLDER PRIOR TO PACKING INSTALLATION. PLEASE REMOVE THE BLACK PACKING HOLDER PRIOR TO PACKING INSTALLATION. 9/2023 REV A...
  • Page 18 NOTE: Items in bold are included in 602-688 packing kit T15TX FLUID MANIFOLD PARTS LIST ITEM # PART # DESCRIPTION 602-178 FILTER HOUSING 600-255 FILTER SPRING 600-141-02 MANIFOLD FILTER, 20 MESH 600-240 FILTER CORE 600-353 O-RING 602-244 UPPER RETAINER 602-485 UPPER GUIDE 602-277 UPPER PACKING...
  • Page 19 (T15) FLUID MANIFOLD SERVICE AND REPAIR REPACKING FLUID MANIFOLD IMPORTANT! FOLLOW THE PRESSURE RELIEF PROCEDURE AS STATED ON PAGE 47 IMPORTANT! UNPLUG THE UNIT. 1. Remove the suction set by unthreading the nut (#1) in Diagram H. Then pull the elbow straight down out of the inlet valve housing (#23) in Diagram A.

  • Page 20: Replacing The Prime / Spray Valve

    (T15) FLUID MANIFOLD SERVICE AND REPAIR REPACKING FLUID MANIFOLD (CON'T) 21. Insert a pair of needle nose pliers into the slots on the top of the piston rod. Pry up on the Piston Rod and turn it to align the slots front to back.
  • Page 21 (T15TX) FLUID MANIFOLD SERVICE AND REPAIR REPACKING THE FLUID MANIFOLD IMPORTANT! FOLLOW THE PRESSURE RELIEF PROCEDURE AS STATED ON PAGE 47. IMPORTANT! UNPLUG THE UNIT. 1. Remove the suction set by unthreading the nut (#1) in Diagram H. Then pull the elbow straight down out of the inlet valve housing (#23) in Diagram A.
  • Page 22 (T15TX) FLUID MANIFOLD SERVICE AND REPAIR REPACKING FLUID MANIFOLD (CON'T) 21. Insert a pair of needle nose pliers into the slots on the top of the piston rod. Pry up on the piston rod and turn it to align the slots front to back. 22.
  • Page 23 B MOTOR & GEARBOX T15 / T15TX DIAGRAM ITEM # PART NUMBER DESCRIPTION 599-459 SCREW 602-0186 REAR PLATE 602-151 BAFFLE 602-190 COVER 602-298 SCREW 600-582 BRUSHES (Set of 2) 602-756 MOTOR (Includes 6,16 & 17) 602-030 REDUCER GEAR 602-553 CRANK HOUSING (( T15 ))
  • Page 24 REPLACING CONNECTING ROD Always Follow the pressure relief procedures before a�emp�ng to service an airless pump. See Page 47. If the troubleshoo�ng guide suggests replacing the gears or the connec�ng rod, follow the instruc�ons below. 1. Remove six screws (#1) Diagram B, and remove the front cover (#13) Diagram B. 2.
  • Page 25 REPLACING REDUCER GEAR / CRANK HOUSING Always Follow the pressure relief procedures before a�emp�ng to service an airless pump. See Page 47. If the troubleshoo�ng guide suggests replacing the gears or the connec�ng rod, follow the instruc�ons below. 1. Remove six screws (#1) Diagram B, and remove the front cover (#13) Diagram B. 2.

  • Page 26: C Control Box

    C CONTROL BOX <<< T15 >>> DIAGRAM ITEM # PART # DESCRIPTION ITEM # PART # DESCRIPTION 599-459 SCREW 600-419 O-RING 602-319 COVER PLATE 600-592 LOCK WASHER 602-417 GASKET 600-123 KNOB 602-459 INDUCTOR FILTER (110V Only) 600-264-1 EDGE LINER TOP (7.125” Long)
  • Page 27 C2 CONTROL BOX <<< T15TX >>> DIAGRAM ITEM # PART # DESCRIPTION ITEM # PART # DESCRIPTION 599-459 SCREW 600-419 O-RING 602-319 COVER PLATE 600-592 LOCK WASHER 602-417 GASKET 600-123 KNOB 602-459 INDUCTOR FILTER (110V Only) 600-264-1 EDGE LINER TOP (7.125” Long) 602-446 NUT (110V Only) 600-264-2...
  • Page 28 REPLACE THE CONTROL ASSEMBLY Follow pressure relief procedure before a�emp�ng to service or repair the unit. See Page 47. If the trouble shoo�ng guide suggest replacing the control assembly, follow the direc�ons below. 1. Remove 6 screws (#1) and the control box cover (#2) in Diagram C/C2. 2.
  • Page 29 REPLACE POTENTIOMETER Follow pressure relief procedure before a�emp�ng to service or repair unit. See Page 47. If trouble shoo�ng guide suggests replacing the poten�ometer, follow the direc�ons below. 1. Remove 6 screws (#1) and the control box cover (#2) both in Diagram C/C2. 2.

  • Page 30: Install Motor

    REPLACE / REMOVE MOTOR Follow pressure relief procedure before a�emp�ng to service or repair unit. See Page 47. If trouble shoo�ng guide suggests replacing the motor, follow the direc�ons below. 1. Remove 3 screws (#5) Diagram B and remover the motor cover (#4) Diagram B. 2.
  • Page 31 REPLACE MOTOR BRUSHES Follow pressure relief procedure before a�emp�ng to service or repair unit. See Page 47. If trouble shoo�ng guide suggests replacing the motor brushes, follow the direc�ons below. 1. Remove 3 screws (#5) Diagram B from motor cover and slide the motor cover back off the motor. 2.
  • Page 32 POTENTIOMETER T15/T15TX 110V WIRING DIAGRAM DIAGRAM 602-407 THERMISTOR 602-359 THERMISTOR 602-360 MOTOR LEAD THERMAL PROTECTION BLACK 602-492 1 OF 2 602-465 Switch BLACK / Circuit Breaker 120V MOTOR MOTOR THERMAL PROTECTOR 602-492 MOTOR 2 OF 2 602-464 WHITE Power Cord...
  • Page 33 DESCRIPTION 600-543 HOSE CLAMP ( T15 & T15TX ) 602-238 PRIME HOSE ( T15 & T15TX ) 600-471 HOSE CLIP (T15 ONLY) (T15TX SEE PAGE 50 & 51) 600-406 O-RING 602-533 SUCTION TUBE 600-085-10 SUCTION FILTER, 10 MESH OPTIONAL SUCTION FILTERS...
  • Page 34 55 GALLON SUCTION SET T15 DIAGRAM ITEM # PART # DESCRIPTION 600-233 600-168 WASHER 600-236 SNAP RING 600-164 O-RING 600-234 GASKET 602-156 SUCTION HOSE 602-544 HOSE CLAMP 602-157 SUCTION TUBE 600-471 HOSE CLIP 600-087-10 SUCTION FILTER, 10 MESH 602-153 PRIME HOSE...
  • Page 35 I FRAME ASSEMBLY T15 / T15TX DIAGRAM ITEM # PART NUMBER DESCRIPTION ITEM # PART NUMBER DESCRIPTION 602-598 HANDLE 602-399 SNAP RING 602-529 WASHER (3 Per Side) 600-382 SCREW 602-524 602-562 KICK STAND HANDLE 602-513 WHEEL 602-373 WHEEL 602-523 SCREW...
  • Page 36 NOTES...
