Summary of Contents for Ryobi REPRUA20
- Page 1 REPRUA20...
-
Page 2: Intended Use
The pole pruner attachment is approved for use with the parts. Damaged or entangled cords increase the risk of following RYOBI power heads: electric shock. ■ battery-driven power heads of RLT36BS, RLT36BL, ■... - Page 3 POWER TOOL USE AND CARE ■ Do not expose a battery pack or tool to fire or excessive temperature. Exposure to fire or temperature ■ Do not force the power tool. Use the correct power above 130 °C may cause explosion. tool for your application.
- Page 4 ■ To reduce the risk of injury associated with contacting ■ Hold the product by insulated gripping surfaces only, moving parts, always power off the product, remove because the saw chain may contact hidden wiring. Saw the battery pack or disconnect it from the power supply. chains contacting a “live”...
-
Page 5: Transportation And Storage
result of tool misuse or incorrect operating procedures TRANSPORTATION AND STORAGE or conditions, and can be avoided by taking the following ■ Power off the product, and remove the battery pack or precautions: disconnect it from the power supply. Allow both to cool ●... -
Page 6: Symbols On The Product
■ Power off the product, and remove the battery pack or disconnect it from the power supply. Make sure that all moving parts have come to a complete stop before any Keep sufficient distance away from cleaning or maintenance work. electrical power lines. - Page 7 REPRUA20 Knob Extension pole Hanger cap Lock button Upper shaft Chain lubricant cap Sprocket cover Chain tensioning screw Bar bolt Ribbed bumper Saw chain Guide bar Harness Blade cover Wrench Harness hanger Operator's manual Bar and chain lubricant Know your product...
- Page 8 Always wear eye, ear and head Push the lock button and remove the hanger cap from the upper shaft and extension pole. protection, non-slip heavy-duty gloves, and substantial footwear while operating the product. Do not operate the product when barefoot or wearing open sandals.
- Page 9 Insert the upper shaft into the extension pole until the lock button clicks into place. Turn the knob clockwise to secure the upper shaft and extension pole. Insert the extension pole to the power head and secure into place using the knob. Attach the harness to the harness hanger.
- Page 10 Operating the p.11 product Adjusting the p.12 chain tension 3-4 mm Replacing the saw p.13 chain Cleaning the Storing the p.15 p.16 product product...
-
Page 11: Operating The Product
≤60˚ ≥15m (50') OPERATING THE PRODUCT WARNING: Risk of electrocution! Do not operate the product within 10 m of overhead electrical power lines. Position the product at an angle of 60° or less, depending on the specific situation. Keep bystanders at least 15 m away. -
Page 12: Adjusting The Chain Tension
3-4 mm ADJUSTING THE CHAIN TENSION 1. Using the wrench, loosen the bar bolt of the sprocket cover. 2. Adjust the saw chain tension until the gap 3-4 mm between the drive teeth and guide bar is between 3 and 4 mm. To increase the chain tension, turn the chain tensioning screw clockwise. -
Page 13: Replacing The Saw Chain
REPLACING THE SAW CHAIN 1. Using the wrench, loosen the bar bolt of the sprocket cover. 2. Remove the sprocket cover and guide bar. 3. Dispose of the old chain and prepare the new one. 4. Fit the saw chain into the bar groove. NOTE: The cutters on the top of the guide bar should face towards the bar tip, in the direction of the saw chain rotation. - Page 14 NOTE: Place the saw chain so that the cutters face the correct direction, the drive links are aligned and inside the bar groove, and there is a loop at the back of the guide bar. 6. Install the sprocket cover. 7.
-
Page 15: Cleaning The Product
CLEANING THE PRODUCT Remove all foreign materials from the product with a soft, dry brush. WARNING: Do not use water when cleaning the product. Maintenance... -
Page 16: Storing The Product
STORING THE PRODUCT WARNING: Cover the guide bar with the blade cover. 1. Loosen the knob to release the power head from the extension pole. 2. Loosen the knob to release the extension pole from the upper shaft. 3. Store the product in a cool, dry, and well-ventilated place that is inaccessible to children and away from sources of ignition. -
Page 17: Product Specifications
PRODUCT SPECIFICATIONS No-load speed High speed 5400 min Pole pruner attachment Low speed 4900 min Model REPRUA20 Weight (without battery pack) 5 kg Chain pitch 6.35 mm (0.25 in.) Weight (with the heaviest battery 6.55 kg Lubricant tank volume 109 ml... -
Page 18: Replacement Parts
= 3.0 dB Weight (without battery pack) 5.1 kg REPLACEMENT PARTS Weight (with the heaviest battery 7.8 kg pack) Manufacturer TRILINK RYOBI Vibration level (in accordance with IEC 62841-1) Chain Q4356PB 682803001 Front handle = 2.1 m/s MQ431056-1041 682802001 Rear handle = 2.7 m/s... - Page 20 Techtronic Industries N.Z. Limited Unit C, 70 Business Parade South, Highbrook, Auckland 2013, New Zealand RYOBI is a trade mark of Ryobi Limited, and is used under license. TRILINK is a registered trade mark of Trilink Saw Chain, LLC. 961087652-01...
