- Page 1 DESIGN & INSTALLATION GUIDE...
- Page 2 CONTENTS 1. Quick-step Guide 2. Intro to U-Chill 3. Inside the box 4. Design Allowances 5. Ventilation 6. Install: Curved 6.1 Opening Specification 6.2 Installation 7. Power Up & Test 8. Specifications 9. Transport & Handling 10. Safety Notice...
- Page 3 1. QUICK-STEP GUIDE CURVED DESIGNS STEP 1. Lower U-Chill into fabricated opening, STEP 2. Place the Crown on U-Chill. Connect U-Chill cord with the STEP 3. power supply cord. STEP 4. Plug power supply cord into electrical outlet. STEP 5.
- Page 4 2. INTRO TO U-CHILL U-Chill keeps your drink at its opening temperature, so every sip is as cool as the first. It can be easily integrated into any surface. Simply specify an opening, place U-Chill in, then plug into an electrical outlet. We recommend the opening is cut by a countertop fabricator, and installation can be completed by kitchen installers.
- Page 5 3. INSIDE THE BOX U-Chill or Rubber Mat User Guide* U-Chill Plus Power Adapter This Guide Curved Crown *Ensure the User Guide is given to the end-user...
- Page 6 12v supply, particularly if the product is to be used in a marine/battery environment where supply voltage may fluctuate. If designing U-Chill into a yacht or marine environment: Install in-cabin and keep dry Keep away from chlorinated water, such as hot tubs and swimming pools...
- Page 7 We advise that a small vent is included in all installations, to allow sufficient airflow to the U-Chill base unit. Be aware if the ambient air around the U-Chill is above 32 degrees, the unit will not function as intended and shut down.
- Page 8 U-Chill is installed. If installing multiple U-Chills into a single space, ensure 32” that the void allows for at least 4.5 cu. ft. per U-Chill, 800mm otherwise ventilation is required. This example would not require ventilation: 8” x 32” x 32” = 4.7 cu. ft.
- Page 9 6. INSTALL 6.1 O PEN ING SPECIFICAT ION A 6 1/8” opening can be created using CNC or water jet cutting. Ø 6 1/8” opening...
- Page 10 & crown ) 5. 3 5. 2 Crown U-Chill Opening 5. 2 Surface IMPORTANT Always place the Crown onto the U-Chill unit before plugging into the electrical outlet. If not, the touch controls will not calibrate and it will not function correctly...
- Page 11 The power pack generates a small amount of 6.5 POWER UP heat, so place as far away from the U-Chill as the installation space and cable allows Ensure the power pack is not near a surface that might be subject to liquids. Best practice is to...
- Page 12 7. POWER UP & TEST 7.1 POWER UP & ENJOY Once power is detected, the U-Chill will light up. To turn the U-Chill on, simply hold your finger on the Crown For full User Guide instructions, go to u-line.com 7.2 TESTING Once U-Chill is installed, please perform the following tests to ensure optimal performance:...
- Page 13 PLUS ONLY Hold your finger down on the Crown. Check that the lights change from off, to red, to blue then white If the U-Chill is not operating properly, unplug 7.4 TROUBLESHOOT it from the outlet. Ensure the Crown is securely attached to the U-Chill, wait 15 seconds, then plug it back in.
- Page 14 Tap within the last hour to extend Auto Switch Off by an extra hour 10 to 32 º C / 50 to 90 º F Ambient Temp. Limit U-Chill will automatically switch off if the temperature is above 32 º C / 90 º F...
- Page 15 9. TRANSPORT & HANDLING Please only install a U-Chill into a fixed surface or unit that will not be moved. If the surface or unit must be moved, please return the U-Chill to its original packaging and install once the surface/unit is in its final location and position. Damages to the appliance, as a result of transporting while installed are not covered under the U-Chill warranty.
- Page 16 For additional support, please contact: For additional support, please contact: customercare@u-line.com or call us at +1.414.354.0300 This guide is available online at u-line.com/u-chill u-line.com/u-chill...
