HANECO LED LINEAR BATTEN INSTALLATION GUIDE
Thanks for choosing our UNO LED Linear batten.
We strongly recommend that you read this manual carefully before installation.
Product Specifications
PRODUCT CODE POWER
UNO30W09WH
UNO40W12WH
UNO50W15WH
UNO30W09BK
UNO40W12BK
UNO50W15BK
Installation Instructions for suspension
1
Switch-off main power.
3
Remove end cap to put both suspension kits in.
5
Plug into power socket.
UNO
COLOUR
TEMPERATURE
30W
40W
50W
3000K / 4000K /
5000K
30W
40W
50W
For more information
www.haneco.com.au
1300 001 LED (533)
VOLTAGE/
PF IP RATING
FREQUENCY
220 – 240V
>0.9
50/60Hz
2
Mount the suspension sling on desired surface.
4
Put the end cap back on, adjust to desired height.
6
Switch-on main power.
OPERATING
TEMPERATURE
IP20 - 20 - 45°C
NET
WEIGHT
1.4kg
1.7kg
2.0kg
1.4kg
1.7kg
2.0kg
