Smoke diagnostic tool - leak detector

Advertisement

Quick Links

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
Wear eye
instruction
protection
manual
1. SAFETY
WARNING! To prevent the risk of sparking, short circuit and possible explosion, DO NOT drop metal tools in the battery area, or allow
them to touch the battery terminals.
DO NOT cross-connect unit to battery. Ensure positive (RED) clamp is to positive terminal and negative (BLACK) clamp is to negative
8
terminal.
1.2.
GENERAL SAFETY
WARNING! Ensure Health and Safety, local authority and general workshop practice regulations are adhered to when using this unit.
Use in conjunction with manufacturer's workshop manual and or information.
9
Maintain this product in good working order and condition. Take immediate action to repair or replace damaged parts.
9
Use approved parts only. Unapproved parts may be dangerous and will invalidate the warranty.
9
DO NOT use to perform a task for which it is not designed.
8
DO NOT allow untrained persons to use the unit.
8
DO NOT use when tired or under the influence of drugs, alcohol or intoxicating medication.
8
AVOID direct inhalation of smoke.
8
Keep children and unauthorised persons away from the work area.
9
Keep work area clean and tidy and free from unrelated materials.
9
Ensure the work area has adequate lighting.
9
Wear suitable clothing to avoid snagging. DO NOT wear jewellery, and tie back long hair. A full range of personal safety equipment is
9
available from your Sealey stockist.
WARNING! Unit may get HOT!
DO NOT remove filler cap when unit is ON.
8
Keep unit upright at all times, to avoid oil leaking out.
9
When not in use, clean unit and store in a safe, dry, childproof location.
9
Ensure that mineral oil (baby oil) safety data sheet has been read, and that user understands the health risks involved and uses
9
appropriate personal protective equipment.
2. INTRODUCTION
Allows the technician to pinpoint all manner of system leaks, including the air intake, cooling, evaporation, fuel, exhaust and vacuum systems.
High smoke delivery for effective fault diagnoses. Fast and simple to use, maximising earning potential. Features single-button operation and
auto-power-off. 12V battery connection. Accessories included are blanking cone, fixing hook, hose adaptor, hose and filling bottle. Uses mineral
oil (not included).
3. SPECIFICATION
Model No: ................................................................... VS872
Hose Length:............................................................ 1650mm
Weight: ........................................................................ 1.56kg
Maximum Input Pressure: ............................................. 23psi
Oil Reservoir Capacity: .................................................. 30ml
Output Pressure: ........................................................... 23psi
Output Smoke: ............................................................ 8L/min
Rubber Cone Sizes: ....................... Hose adaptor Ø5-27mm,
...................................................... Blanking cone Ø33-84mm
© Jack Sealey Limited
SMOKE DIAGNOSTIC TOOL - LEAK DETECTOR
MODEL NO:
Wear a mask
Original Language Version
VS872
VS872 Issue:4 19/09/24

Advertisement

loading
Need help?

Need help?

Do you have a question about the VS872 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Sealey VS872

  • Page 1 VS872 MODEL NO: Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions, and properly maintained, give you years of trouble free performance. IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED.
  • Page 2 Before filling with fresh oil, pour out the remaining oil in the reservoir. 5.1.4. Fill oil reservoir with 30ml, not over this amount. 5.1.5. Replace oil regularly. Only use Sealey LDO50 Leak Detector Oil. SMOKE OUTLET PORT 5.2. 5.2.1. Connect smoke outlet pipe.
  • Page 3 Important: No Liability is accepted for incorrect use of this product. Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim. Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR 01284 757500 sales@sealey.co.uk...
