Sealey VS870.V3 Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY.
Refer to Instruction Wear Eye
Manual Protection
1. SAFETY
1.1. PERSONAL PRECAUTIONS
Wear safety eye protection and protective clothing. Avoid touching eyes while working near battery.
9
Wash immediately with soap and water if battery acid contacts skin or clothing. If acid enters eye, flush eye immediately with cool,
9
clean running water for at least 15 minutes and seek immediate medical attention.
Remove personal metallic items such as rings, bracelets, necklaces and watches.
9
A lead-acid battery can produce a short-circuit current which is high enough to weld such items to the vehicle and cause severe burns.
DO NOT smoke or allow a spark or flame in the vicinity of the battery or engine.
8
WARNING! To prevent the risk of sparking, short circuit and possible explosion. DO NOT drop metal tools in the battery area, or allow
‰
them to touch the battery terminals.
DO NOT cross-connect unit to battery. Ensure positive (RED) clamp is to positive terminal and negative (BLACK) clamp is to negative
8
terminal.
1.2. GENERAL SAFETY.
WARNING! Ensure Health and Safety, local authority and general workshop practice regulations are adhered to when using this unit.
‰
Maintain this product in good working order and condition, take immediate action to repair or replace damaged parts.
9
Use approved parts only. Unapproved parts may be dangerous and will invalidate the warranty.
9
DO NOT use to perform a task for which it is not designed.
8
DO NOT allow untrained persons to use the unit.
8
DO NOT use when tired or under the influence of drugs, alcohol or intoxicating medication.
8
AVOID direct inhalation of smoke.
8
WARNING! DO NOT pollute the environment by allowing uncontrolled discharge of fluids.
‰
Keep children and unauthorised persons away from the work area.
9
Keep work area clean and tidy and free from unrelated materials.
9
Ensure the work area has adequate lighting.
9
Wear suitable clothing to avoid snagging. DO NOT wear jewellery, and tie back long hair. A full range of personal safety equipment is
9
available from your Sealey stockist.
WARNING! Unit may get HOT!
‰
Power Supply: 12V dc.
9
Maximum input pressure: 14psi (1bar).
9
Use mineral oil (baby oil) ONLY.
9
DO NOT remove filler cap when unit is ON.
‰
Keep unit upright at all times to avoid oil leaking out.
9
When not in use, clean unit and store in a safe, dry, childproof location.
9
Ensure that mineral oil (baby oil) safety data sheet has been read, and that user understands the health risks involved and uses
9
appropriate personal protective equipment.
2. INTRODUCTION
Allows the technician to pinpoint all manner of system leaks including the air intake, cooling, evaporation, fuel, exhaust and vacuum systems.
Fast and simple-to-use, maximising earning potential. Features single button operation, flow control valve and auto-power-off. Uses mineral
oil and workshop air to generate smoke at low pressure while connected to a vehicle. System is clean and quick to use and connects to a 12V
vehicle battery. Supplied with four different sizes of blanking cones. Mineral oil not included.
3. SPECIFICATION
Hose Length:............................................................ 2600mm
Maximum Input pressure: ................................... 14psi (1 bar)
Oil Reservoir Capacity: .................................................. 75ml
Rubber Cone Sizes: .......... Ø10-45, 30-65, 50-85, 70-100mm
© Jack Sealey Limited
SMOKE DIAGNOSTIC TOOL- LEAK DETECTOR
VS870.V3
MODEL N o :
Wear Protective
Gloves
Original Language Version
VS870.V3 Issue 1 13/07/23
