Leviton SH081-1D1 Installation And Operation Manual

Leviton SH081-1D1 Installation And Operation Manual

Switched
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Firmware Release 7.0
 SH081-1D1
 SH082-1C2
 SV161-1D1
 SV241-1D1
 SV242-1C2
 SV243-1F3
 SV243-1H4
 SV243-1J4
 SV243-1K4
 SV243-1L4
Switched Power
Distribution Unit (PDU)
Installation and Operations Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SH081-1D1 and is the answer not in the manual?

Questions and answers

Related Manuals for Leviton SH081-1D1

Summary of Contents for Leviton SH081-1D1

  • Page 1 Switched Power Distribution Unit (PDU) Installation and Operations Manual Firmware Release 7.0  SH081-1D1  SH082-1C2  SV161-1D1  SV241-1D1  SV242-1C2  SV243-1F3  SV243-1H4  SV243-1J4  SV243-1K4  SV243-1L4...
  • Page 2  direct patient care. Products will not knowingly be sold for use in such applications unless it receives in writing assurances satisfactory to Leviton that:  the risks of injury or damage have been minimized, ...

  • Page 3: Table Of Contents

    Table of Contents ABLE OF ONTENTS 1: I HAPTER NTRODUCTION Quick Installation Checklist ......................4 Technical Support ..........................4 Equipment Overview ........................5 IPv6 and Switched Power Distribution Unit (PDU) Products ............6 2: I HAPTER NSTALLATION Standard Accessories ........................9 Optional Accessories ........................

  • Page 4: Chapter 1: Introduction

    425-485-3373 +57.311.820.7055 33.6.88.69.13.80 +971.4.886.4722 +52.55.5082.1040 www.leviton.com infocolumbia@leviton.com infoeurope@leviton.com infoindia@leviton.com lsamarketing@leviton.com Mexico Middle East & Africa South Korea All other international +52.55.5082.1040 +971.4.886.4722 +82.2.3273.9963 inquiries: lsamarketing@leviton.com lmeinfo@leviton.com infokorea@leviton.com international@leviton.com 4  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...

  • Page 5: Equipment Overview

    A number is printed above each outlet. These numbers may be used in commands that require an outlet name. See Outlet Naming and Grouping in Chapter 3: Operations for more information. Figure 1. Switched Power Distribution Unit (PDU) PK-A3073-10-00-0A Leviton Switched Power Distribution Unit Installation and Operations Manual  5...

  • Page 6: Ipv6 And Switched Power Distribution Unit (Pdu) Products

    The PDU firmware supports the following network IPv4-only protocols:  Cisco EnergyWise  LDAP  Load Shedding *  RADIUS *  TACACS+ * = may work with IPv6 addresses, but not tested. 6  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...

  • Page 7: Network-Enabled Modes

    If a DHCP address cannot be obtained after 90 seconds, the PDU can: (1) optionally fall back to its static IPv4 and/or IPv6 settings, or (2) indefinitely wait to acquire an address based on DHCP configuration settings. PK-A3073-10-00-0A Leviton Switched Power Distribution Unit Installation and Operations Manual  7...
  • Page 8 This allows you to view both static configuration settings and active network settings that can be obtained using DHCP. The DNS addresses may be in IPv4 or IPv6 (based on RFC4291) format at this time. 8  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...

  • Page 9: Chapter 2: Installation

    Chapter 2: Installation Before installing your Leviton Switched Power Distribution Unit (PDU), refer to the following lists to makes sure you have all the items shipped with the unit, as well as other items needed for proper installation. Standard Accessories ...

  • Page 10: Safety Precautions

    Allow for maximum airflow at l'installation de ce produit. Permettre une instalar este producto. Permita, en todo all times. circulation d'air maximale à tout moment. momento, la circulación máxima de aire. 10  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...

  • Page 11: Installing The Power Input Cord

    Push the C19 from the Detachable Input Cord firmly into the C20 inlet to ensure it is properly seated. Figure 2. C20 Inlet without Retention Bracket Assembly Figure 3. Removing a Retention Bracket Assembly Note: Only Leviton self-locking power cords are recommended for use with Leviton PDU’s PK-A3073-10-00-0A Leviton Switched Power Distribution Unit Installation and Operations Manual ...

  • Page 12: Mounting

    Attach buttons to the back of the PDU. Most models have multiple attachment points to accommodate different applications. Mount the PDU by inserting the buttons into the cabinet’s keyhole slots. Figure 5. Button Mounting 12  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...

  • Page 13: Connecting To The Power Source

    Vertical – Bracket Mounting If the PDU is to be mounted to a 2-post or 4-post rack, or if the cabinet does not include keyhole slots, Leviton’s PDU Mounting Bracket Kit (PDURK-RMK) will required. Attach the removable flanges to the mount points on the rear of the enclosure using M4 screws.

  • Page 14: Connecting To The Unit

    NOTE: Contact your system administrator for instructions in reconfiguring the network connection. Reconfiguration of your network connection may require a restart to take effect.  IP address: 192.168.1.x (where x is 2-253)  Subnet Mask: 255.255.255.0 14  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...

  • Page 15: Chapter 3: Operations

    Chapter 3: Operations NTERFACES Outlet Naming and Grouping Models with a Single Power Infeed ..................17 Models with Multiple Power Infeeds ........Error! Bookmark not defined.17 Usernames and Passwords NTERFACE Logging In System Summary Outlet Control Individual ..........................22 Group ........................... 22 Power Monitoring Input Feeds...........................
  • Page 16 Telnet Administration ....................... 7778 FTP Administration ......................7778 SNTP Administration ....................... 8081 UPS Administration ......................8283 Feature Administration ....................8687 16  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...

  • Page 17: Interfaces

    Usernames can contain from 1-16 characters and are not case sensitive; spaces are not allowed. Passwords may contain up to 16 characters, and are case sensitive. PK-A3073-10-00-0A Leviton Switched Power Distribution Unit Installation and Operations Manual  17...

  • Page 18: Web Interface

    You are given three attempts to enter a valid username and password combination. If all three fail, the session ends and a protected page will be displayed. NOTE: The default username/password is admn/admn. 18  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...

  • Page 19: System Summary

    4 concurrent web user sessions are allowed (HTTP or HTTPS). NOTE: Depending on your web browser, multiple web accesses from the same machine are often treated as one user. PK-A3073-10-00-0A Leviton Switched Power Distribution Unit Installation and Operations Manual  19...
  • Page 20 (low limit) and maximum (high limit) values displayed at the left and right of the graph. 20  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A...
  • Page 21 Green = acceptable percentage of relative humidity Yellow = dry; low humidity (threshold configured by user) User configures low/high relative humidity thresholds at Configuration > SNMP/Thresholds > Sensor Traps and Thresholds PK-A3073-10-00-0A Leviton Switched Power Distribution Unit Installation and Operations Manual  21...

  • Page 22: Outlet Control

    Select the group name from the drop-down menu and press Select. The page will refresh to display all outlets associated to the selected group name. To apply an action to a group: Select the desired action from the drop-down menu and click Apply. 22  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...

  • Page 23: Outlet State/Control State Field Values

    Hostname/IP address NOTE: The UPS page displays both IPv4 and IPv6 formats in the Hostname/IP field. Monitor pages (like the UPS page) refresh occasionally to reflect current PDU status. PK-A3073-10-00-0A Leviton Switched Power Distribution Unit Installation and Operations Manual  23...

  • Page 24: Environmental Monitoring

    "Auto" option. However, even if your PDU model does have the sensor for device orientation, you can still select the Normal or Inverted option from the list to override the capability of the hardware. 24  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A...
  • Page 25  When a device with 3-phase input voltage is out-of-balance, efficiency is reduced and the unit is prevented from reaching maximum capacity. When an alert for the out-of-balance condition is received (if the alerting feature is enabled), it may be necessary to adjust distribution of the loads. PK-A3073-10-00-0A Leviton Switched Power Distribution Unit Installation and Operations Manual  25...
  • Page 26 On the subsequent Environmental Monitor Names page, enter a descriptive name and click Apply. Creating descriptive sensor names: Click on the Sensor Names link. On the subsequent Sensor Names page, enter a descriptive name and click Apply. 26  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...

  • Page 27: Network

     The firmware can detect network link integrity and will wait for network connection. This means that if the network is not currently connected, the enabled Boot Delay option will be ignored. PK-A3073-10-00-0A Leviton Switched Power Distribution Unit Installation and Operations Manual  27...

  • Page 28: Telnet/Ssh

    NOTE: At least one authentication method must be enabled. Select the Password checkbox and/or the Keyboard-Interactive checkbox and click Apply. 28  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...

  • Page 29: Http/Ssl

    In the HTTP or SSL section of the page, in the Port field, type the port number, and click Apply. The HTTP default port number is 80; the SSL default port number is 443. PK-A3073-10-00-0A Leviton Switched Power Distribution Unit Installation and Operations Manual  29...

  • Page 30: Serial Ports

    On the following Serial Ports Edit page, select None or MRV from the SCP Emulation drop-down menu and click Apply. Towers The Towers configuration page is used for assignment and/or editing of:  Descriptive names  Serial and Model numbers  Operation voltage types 30  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...
  • Page 31 From the AC/DC drop-down menu, select AC or DC, and click Apply. Setting the operational AC voltage type: From the 3-Phase drop-down menu, select yes or no, and click Apply. PK-A3073-10-00-0A Leviton Switched Power Distribution Unit Installation and Operations Manual  31...

  • Page 32: Input Feeds

    Select the infeed(s) powered by the UPS and click Apply. To remove a UPS: On the Configuration UPS page, under the Action heading, click the Remove link for the UPS you want to remove. 32  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...

  • Page 33: Outlets

    Control actions for a locked outlet will not be available in the web interface, and the outlet will not be affected by group actions or Smart Load Shedding actions. SNMP and CLI control actions will be ignored for a locked outlet. PK-A3073-10-00-0A Leviton Switched Power Distribution Unit Installation and Operations Manual  33...

  • Page 34: Groups

    Click on the Edit link in the Action column for the associated user. On the subsequent User Edit page, select Admin, Power-User, User, Reboot-only, On-only or View-only from the Access Level drop-down menu and click Apply. 34  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...

  • Page 35: Ftp

    Select the desired day for the automatic update from the drop-down menu and click Apply. Setting the automatic update scheduled hour: Select the desired hour for the automatic update from the drop-down menu and click Apply. PK-A3073-10-00-0A Leviton Switched Power Distribution Unit Installation and Operations Manual  35...

  • Page 36: Sntp/Syslog

    NOTE: Both IPv4 and IPv6 formats are accepted in the Primary/Secondary Host fields. Changing the Syslog server port number: In the Syslog Port field, enter the port number and click Apply. 36  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...

  • Page 37: Snmp/Thresholds

    Type a name in the Trap Username field and click Apply. The trap username can be 1-31 alphanumeric characters; spaces are allowed; and the name is case sensitive. PK-A3073-10-00-0A Leviton Switched Power Distribution Unit Installation and Operations Manual  37...
  • Page 38 Configuring Temperature and Relative Humidity sensor traps: Click the Sensor Traps and Thresholds link. On the subsequent Sensor Traps and Thresholds page, select or deselect the desired trap checkboxes and click Apply. 38  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...

  • Page 39: Ldap

    MD5: Provides strong protection using 1-way hash encoding that does not transmit the username-password over the network. From the Bind Type drop-down menu, select Simple, TLS/SSL, or MD5, and click Apply. NOTE: If LDAP over TLS/SSL is enabled, MD5 binding is disabled. PK-A3073-10-00-0A Leviton Switched Power Distribution Unit Installation and Operations Manual  39...
  • Page 40 Click on the Edit link in the Action column for the associated LDAP Group. On the subsequent LDAP Group - Edit page, select Admin, User, On-only or View-only from the Access Level drop-down menu and click Apply. 40  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...
  • Page 41 Click on the Ports link in the Access column for the associated LDAP Group. On the subsequent LDAP Group - Ports page, select or deselect ports to be accessed by the LDAP Group and click Apply. PK-A3073-10-00-0A Leviton Switched Power Distribution Unit Installation and Operations Manual  41...

  • Page 42: Tacacs

    Click on the Ports link in the Access column for the associated TACACS+ Privilege Level. On the subsequent LDAP Group - Ports page, select or deselect ports to be accessed by the TACACS+ Privilege Level and click Apply. 42  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...

  • Page 43: Radius

    Setting the number of retries: Type the number of retries in the Primary and/or Secondary Retries field and click Apply. The valid retries range is 0-10; default is 2. PK-A3073-10-00-0A Leviton Switched Power Distribution Unit Installation and Operations Manual  43...

  • Page 44: Smtp/Email

    Select Enabled or Disabled from the Include…Messages drop-down menus and click Apply. Sending a test email: After providing information in the Email/SMTP web page, click the Test button to send a test email to the target email destinations. 44  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...

  • Page 45: Features

    Select the Restart and generate a new X.509 certificate from the Action drop-down menu and click Apply. Computing new SSH security keys: Select the Restart and compute new SSH keys from the Action drop-down menu and click Apply. PK-A3073-10-00-0A Leviton Switched Power Distribution Unit Installation and Operations Manual  45...

  • Page 46: Command Line Interface

    Grants a user access to one or all outlets Add Porttouser Grants a user access to one or all serial/Pass-Thru ports Create Group Adds a group name Create UPS Adds a UPS association 46  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...

  • Page 47: Administrative Command Summary

    Set Infeed Voltage Specifies the nominal input voltage for the infeed Set Ipaddress Sets the IP address of the PDU Set LDAP UseTLS Enables or disables LDAP over TLS/SSL support PK-A3073-10-00-0A Leviton Switched Power Distribution Unit Installation and Operations Manual  47...
  • Page 48 Specifies the AC voltage type for the tower Set Tower Model Specifies the model number for the tower Set Tower Name Specifies a descriptive field for the tower 48  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...

  • Page 49: Operations Commands

    The following command turns the second outlet on, using the outlet’s absolute name: Switched PDU: on .a2<Enter> The following command turns on all the outlets in the group named ServerGroup_1: Switched PDU: on ServerGroup_1<Enter> PK-A3073-10-00-0A Leviton Switched Power Distribution Unit Installation and Operations Manual  49...
  • Page 50 Type reboot, followed by a group name, and press Enter, or Type reboot all and press Enter. Example The following command reboots all the outlets in the group named ServerGroup_1: Switched PDU: reboot ServerGroup_1<Enter> 50  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...

  • Page 51: Displaying Outlet Status

    The following command displays the on/off status for outlets in the group ServerGroup_1: Switched PDU: status ServerGroup_1<Enter> Group: ServerGroup_1 Outlet Outlet Outlet Control Name State State DataServer_1 WebServer_1 FileServer_1 PK-A3073-10-00-0A Leviton Switched Power Distribution Unit Installation and Operations Manual  51...
  • Page 52 At the Switched PDU: prompt, type list ports and press Enter. Example The follow command displays all accessible serial ports for the current user: Switched PDU: list ports<Enter> Port Port Name Console Console 52  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...
  • Page 53 At the Enter New Password: prompt, type the new password and press Enter. Passwords can contain 1-16 characters. At the Verify Password: prompt, retype the new password and press Enter. PK-A3073-10-00-0A Leviton Switched Power Distribution Unit Installation and Operations Manual  53...

  • Page 54: Administration Commands

    At the Verify Password: prompt, retype the password. Press Enter. Example The following command creates the user account JaneDoe: Switched PDU: create user JaneDoe<Enter> Password: <Enter> Verify New Password: <Enter> For security, password characters are not displayed. 54  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...
  • Page 55 NOTE: Granting access to environmental monitoring (temperature/humidity/sensors) to a non-admin user also grants that user access to power monitoring (outlets, infeeds, towers – all the environmental data of the PDU). PK-A3073-10-00-0A Leviton Switched Power Distribution Unit Installation and Operations Manual  55...
  • Page 56 At the Switched PDU: prompt, type delete outletfromuser, optionally followed by an outlet name and a username. Press Enter, or Type delete outletfromuser all, followed by a username and press Enter. 56  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...
  • Page 57 JaneDoe may access the following outlets, groups and serial ports: outlet A1 which has a descriptive name of DataServer_1, outlet A2 which has a descriptive name of WebServer_1, group ServerGroup_1 group ServerGroup_2, and Console serial port. PK-A3073-10-00-0A Leviton Switched Power Distribution Unit Installation and Operations Manual  57...

  • Page 58: Outlet Administration

    At the Switched PDU: prompt, type set outlet postondelay, followed by a value from 0 to 900 (in seconds) and press Enter. Example The following command set the post-on delay for outlet .a5 to 90 seconds: Switched PDU: set outlet postondelay .a5 90<Enter> 58  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...

  • Page 59: Setting The Outlet Locked (No Control) State

    At the Switched PDU: prompt, type set outlet locked, followed by a locked outlet name, followed by no, and press Enter. Example The following command unlocks outlet TowerA_InfeedA_Outlet1: Switched PDU: set outlet locked TowerA_InfeedA_Outlet1 no<Enter> PK-A3073-10-00-0A Leviton Switched Power Distribution Unit Installation and Operations Manual  59...

  • Page 60: Input Feed Administration

    At the Switched PDU: prompt, type set infeed voltage, followed by the absolute infeed name, and a value from 1 to 480. Press Enter. Example The following commands sets the operational voltage for input .AA to 100V: Switched PDU: set infeed voltage .aa 100<Enter> 60  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...

  • Page 61: Tower Administration

    At the Switched PDU: prompt, type set tower prodsn, followed by the absolute tower name, and the tower serial number. Press Enter. Example The following command sets the serial number for tower .A to ‘AA06F011157’: Switched PDU: set tower prodsn .a AA06F011157<Enter> PK-A3073-10-00-0A Leviton Switched Power Distribution Unit Installation and Operations Manual  61...
  • Page 62 At the Switched PDU: prompt, type show towers and press Enter. Example Switched PDU: show towers<Enter> Tower ID: Name: TowerA Product S/N: AA06F011157 Model No.: test 3-Phase: Power Type: More (Y/es N/o): 62  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...

  • Page 63: Group Administration

    At the Switched PDU: prompt, type delete outletfromgroup, optionally followed by an outlet name and a group name. Press Enter, or Type delete outletfromgroup, followed by all then the group name. Press Enter. PK-A3073-10-00-0A Leviton Switched Power Distribution Unit Installation and Operations Manual  63...

  • Page 64: Environmental Monitor Administration

    To enable or disable active signal checking for serial connections: At the Switched PDU: prompt, type set port dsrcheck console, on or off, and press Enter. 64  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...
  • Page 65 To display serial port information: At the Switched PDU: prompt, type show ports and press Enter. Example The following command displays all serial port information: Switched PDU: show ports<Enter> Serial Port Configuration PK-A3073-10-00-0A Leviton Switched Power Distribution Unit Installation and Operations Manual  65...

  • Page 66: System Administration

    At the Switched PDU: prompt, type set system area, followed by the system area (in square feet) and press Enter. Example The following command sets the total system area to 6.3 square feet: Switched PDU: set system area 6.3<Enter> 66  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...
  • Page 67 Hardware revision code and Flash size  Uptime since last system restart  System location description  Area (footprint) and power factor  3-phase load out-of-balance threshold and alert status PK-A3073-10-00-0A Leviton Switched Power Distribution Unit Installation and Operations Manual  67...
  • Page 68 Set Option Display command with either the Normal or Inverted option to override the capability of the hardware.  If your PDU model does not have the accelerometer chip, you will need to configure the LED display orientation by entering the Normal or Inverted option. 68  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...

  • Page 69: Enabling Or Disabling The 'More' Prompt

    At the Switched PDU: prompt, type set option clitimeout, followed by the session timeout (in minutes), and press Enter. Example: The following command sets the CLI session timeout to 15 minutes: Switched PDU: set option clitimeout 15<Enter> PK-A3073-10-00-0A Leviton Switched Power Distribution Unit Installation and Operations Manual  69...
  • Page 70 Serial Command Protocol (SCP) and the Coldboot Alert feature. Upon a coldboot of the system, if the Coldboot Alert feature is enabled, the system will send a ½ second RS-232 break out to to any SCP-enabled serial ports. 70  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A...
  • Page 71 The limit of the Secret field is 64 characters. A blank secret is also acceptable. At the Switched PDU: prompt, type set energywise secret, then verify the secret, and press Enter. Example Switched PDU: set energywise secret Secret: ******** VerifySecret: ******** PK-A3073-10-00-0A Leviton Switched Power Distribution Unit Installation and Operations Manual  71...
  • Page 72 At the Switched PDU: prompt, type show energywise, and press Enter. Example Switched PDU: show energywise EnergyWise Configuration Endpoint: Enabled* Port: Domain: dominion Refresh Rate: Secret: ******** *Value changed – restart required Command successful 72  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...

  • Page 73: Tcp/Ip Administration

    For a detailed description of the Disabled, IPv4 only, and Dualv6v4 options, see Network-Enabled Modes. At the Smart PDU prompt: type set net; followed by disabled, ipv4only, or dualv6v4; and press Enter PK-A3073-10-00-0A Leviton Switched Power Distribution Unit Installation and Operations Manual  73...
  • Page 74 NOTE: Both IPv4 and IPv6 formats are accepted for DNS IP address. Example The following command sets the primary Domain Name server IP address to 98.76.54.254: Switched PDU: set dns1 98.76.54.254<Enter> 74  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...

  • Page 75: Displaying Network Configuration Information

    This allows you to view both static configuration settings and active network settings that can be obtained using DHCP. The DNS addresses can be IPv4 or IPv6 format at this time (based on RFC4291). PK-A3073-10-00-0A Leviton Switched Power Distribution Unit Installation and Operations Manual  75...

  • Page 76: Http Administration

    At the Switched PDU: prompt, type set http port, followed by the port number and press Enter. Example The following changes the HTTP port number to 2048: Switched PDU: set HTTP port 2048<Enter> 76  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...
  • Page 77 At the Switched PDU: prompt, type set ftp password, followed by the FTP password and press Enter. Example The following command sets the FTP password to test1: Switched PDU: set ftp password test1<Enter> PK-A3073-10-00-0A Leviton Switched Power Distribution Unit Installation and Operations Manual  77...
  • Page 78 The Set FTP Test command validates that the PDU can login to the FTP server and verify/download the firmware file. To test the FTP upload configuration: At the Switched PDU: prompt, type set ftp test, and press Enter. 78  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...
  • Page 79 Switched PDU: show ftp<Enter> FTP Configuration Host: 10.1.2.100 Username: djones Password: ******* Directory: /firmware/7.0d Filename: smpdu-v70d.bin FTP Automatic Updates Configuration Automatic Updates: Disabled Scheduled Day: Everyday Scheduled Hour: 1 PM PK-A3073-10-00-0A Leviton Switched Power Distribution Unit Installation and Operations Manual  79...
  • Page 80 The Set SNTP DST command enables or disables daylight savings time. To set daylight savings time: At the Switched PDU: prompt, type set sntp dst, followed by enabled or disabled, and press Enter. 80  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...
  • Page 81 Primary Host: 204.152.184.72 Secondary Host: 1.pool.ntp.org Local GMT Offset: Use DST: Enabled Start Date: Wednesday in April Start Time: 04:18:06 End Date: Sunday in November End Time: 02:00:00 PK-A3073-10-00-0A Leviton Switched Power Distribution Unit Installation and Operations Manual  81...
  • Page 82 The following command removes the UPS record at index 3: Switched PDU: remove ups<Enter> Type: Liebert Host/IP: DC1Liebert1 Type: Powerware Host/IP: DC1Powerware1 Type: Toshiba Host/IP: DC1Toshiba1 Select UPS(1-8): 3<Enter> 82  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...

  • Page 83: Changing The Ups Type

    The following command changes UPS hostname for the record at index number 2 to ‘DC1MGE1’: Switched PDU: set ups host<Enter> Type: Liebert Host/IP: DC1Liebert1 Type: Host/IP: DC1Powerware1 Select UPS(1-8): 2<Enter> Host/IP: DC1MGE1<Enter> PK-A3073-10-00-0A Leviton Switched Power Distribution Unit Installation and Operations Manual  83...
  • Page 84 The following command disables voltage polling for the record at index number 2: Switched PDU: set ups vpoll<Enter> Voltage Index Type Polling Liebert Select UPS(1-8): 2<Enter> Voltage Polling: Off<Enter> 84  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...

  • Page 85: Adding An Infeed To A Ups

    The following command removes the association of infeed .aa from UPS record at index number 2: Switched PDU: set ups addinfeed<Enter> Infeed Index Type Liebert Select UPS(1-8): 2<Enter> Infeed ID: .aa<Enter> PK-A3073-10-00-0A Leviton Switched Power Distribution Unit Installation and Operations Manual  85...
  • Page 86 The following command displays all activated special features: Switched PDU: show features<Enter> Activated Features: Smart Load Shedding NOTE: A restart of the PDU is required after activating new special features. 86  Leviton Switched Power Distribution Unit PK-A3073-10-00-0A Installation and Operations Manual...

  • Page 87: Chapter 4: Advanced Operations

    Chapter 4: Advanced Operations Enabling and Setting up SSL Support SSL Technical Specifications Enabling and Setting up SSH Support SSH Technical Specifications SNMP/T HRESHOLDS About SNMP Versions Enabling and Setting Up SNMP v1/v2 Support Enabling and Setting up SNMP Support SNMP Traps Configuring Traps LDAP...

  • Page 88: Ssl

    Command Line, you will be prompted for a port number. Example The following changes the SSL port number to 443: Switched PDU: set ssl port 443<Enter> 88  Leviton Switched Power Distribution Unit Installation and Operations Manual...
  • Page 89 Transport Layer Security (TLS) version 1 (RFC 2246) SSL/TLS-enabled HTTPS server (RFC 2818) Self-Signed X.509 Certificate version 3 (RFC 2459) Asymmetric Cryptography: 1024-bit RSA Key Exchange Symmetric Cryptography Ciphers: TLS_RSA_WITH_AES_256_CBC_SHA TLS_RSA_WITH_3DES_EDE_CBC_SHA TLS_RSA_WITH_AES_128_CBC_SHA TLS_RSA_WITH_DES_CBC_SHA Leviton Switched Power Distribution Unit Installation and Operations Manual  89...

  • Page 90: Ssh

    At the Switched PDU: prompt, type set ssh authmethod, followed by password or kbint, followed by enabled or disabled, and press Enter. Example The following example sets the SSH authentication method to keyboard-interactive: Switched PDU: set ssh authmethod kbint enabled<Enter> 90  Leviton Switched Power Distribution Unit Installation and Operations Manual...
  • Page 91 Diffie-Hellman DSA/DSS 512-1024 (random) bits per NIST specification Symmetric Cryptography: AES256-CBC RIJNDAEL256-CBC 3DES-192-CBC AES192-CBC RIJNDAEL192-CBC BLOWFISH-128-CBC AES128-CBC RIJNDAEL128-CBC ARCFOUR-128 Message Integrity: HMAC-SHA1-160 HMAC-SHA1-96 HMAC-MD5-128 HMAC-MD5-96 Authentication: Username/Password Session Channel Break Extension (for RS232 Break) Leviton Switched Power Distribution Unit Installation and Operations Manual  91...

  • Page 92: Snmp/Thresholds

    At the Switched PDU: prompt, type set snmp v2, followed by enabled or disabled and press Enter. NOTE: A restart of the PDU is required after enabling or disabling SNMP support. 92  Leviton Switched Power Distribution Unit Installation and Operations Manual...
  • Page 93 (undefined) Trap Destination 2 : (undefined) Trap format IP Restrictions: No Restrictions Error Trap Repeat Time : 60 seconds SysName: Sentry3_524640 SysLocation: No Location SysContact: No Contact Command successful Leviton Switched Power Distribution Unit Installation and Operations Manual  93...
  • Page 94 1-40 characters. A blank password will clear the string. To set the RO authentication password: At the Switched PDU: prompt, type set snmp v3 roauthpass, and press Enter. 94  Leviton Switched Power Distribution Unit Installation and Operations Manual...
  • Page 95 At the Switched PDU: prompt, type set snmp v3 trapusername, and press Enter. The trap username can be 1-31 alphanumeric characters; spaces are allowed; and the name is case sensitive. Leviton Switched Power Distribution Unit Installation and Operations Manual  95...
  • Page 96 The Set SNMP SysName command is used to set the SNMP MIB-II SysName object. To set the SysName object: At the Switched PDU: prompt, type set snmp sysname, followed by the object name and press Enter. 96  Leviton Switched Power Distribution Unit Installation and Operations Manual...
  • Page 97 Trap Destination 1: <undefined> Trap Destination 2: <undefined> Trap format: IP Restrictions: No Restrictions Error Trap Repeat Time: 60 seconds SysName: Sentry3_524640 SysLocation: No Location SysContact: No Contact Command successful Leviton Switched Power Distribution Unit Installation and Operations Manual  97...
  • Page 98 Communication to the outlet has been lost Environmental Monitor Status traps Status Error Description Normal Environmental Monitor is working correctly NoComm Communication to the Environmental Monitor has been lost 98  Leviton Switched Power Distribution Unit Installation and Operations Manual...
  • Page 99 Temperature at the sensor exceeds preset high threshold ReadError Unable to read Temp status Lost Sensor initially detected but communication to the sensor has been lost NoComm Communication to the sensor has been lost Leviton Switched Power Distribution Unit Installation and Operations Manual  99...

  • Page 100: Humidity Trap

    Set Trap THS Humidhigh Sets a temperature/humidity sensor Humid trap high limit Set Trap THS Humidlow Sets a temperature/humidity sensor Humid trap low limit Show Traps Displays trap configurations 100  Leviton Switched Power Distribution Unit Installation and Operations Manual...
  • Page 101 Type set trap outlet change all, followed by on or off and press Enter. Example The following command enables the Change trap for the third outlet on the first infeed of the second tower, using the outlet’s absolute name: Leviton Switched Power Distribution Unit Installation and Operations Manual  101...
  • Page 102 Enter. Example The following command configures the recovery delta at 2 relative humidity for temperature/humidity sensor .A1: Switched PDU: set trap ths humiddelta temp_humid_sensor_A1 2<Enter> 102  Leviton Switched Power Distribution Unit Installation and Operations Manual...
  • Page 103 0 to 100 in percentage of relative humidity. Press Enter. Example The following command sets the first humidity sensor low threshold limit to 5: Switched PDU: set trap ths humidlow .a1 5<Enter> Leviton Switched Power Distribution Unit Installation and Operations Manual  103...

  • Page 104: Displaying Trap Configuration Information

    Humid Trap: ON Humid Trap: ON Low: 5 % RH Low: 0 % RH High: 100 % RH High: 100 % RH Delta: 2 % RH Delta: 2 % RH 104  Leviton Switched Power Distribution Unit Installation and Operations Manual...

  • Page 105: Ldap

    Sets the access level for an LDAP group Set LDAPGroup Envmon Grants or removes access to environmental monitoring Show LDAP Displays LDAP configurations Show Network Displays network configuration information for all IPv4 and IPv6 settings Leviton Switched Power Distribution Unit Installation and Operations Manual  105...
  • Page 106 To enable or disable LDAP over TLS/SSL support: At the Switched PDU: prompt, type set ldap usetls, followed by yes or no and press Enter. NOTE: If LDAP Over TLS/SSL is enabled, MD5 binding is disabled. 106  Leviton Switched Power Distribution Unit Installation and Operations Manual...
  • Page 107 Enter. Example The following sets the group membership attribute for MSAD to ‘memberof’: Switched PDU: set ldap groupattr<Enter> Enter Group Member Attr (Max character 30): memberof<Enter> Leviton Switched Power Distribution Unit Installation and Operations Manual  107...
  • Page 108 DN and press Enter. Example The following sets the DN user search base for MSAD to ‘cn=Users,dc=companyname,dc=com’: Switched PDU: set ldap userbasedn<Enter> Enter User Search Base DN (Max characters 100): cn=Users,dc=companyname,dc=com<Enter> 108  Leviton Switched Power Distribution Unit Installation and Operations Manual...

  • Page 109: Setting The User Search Filter

    Bind request password type and remote authentication order  Search bind distinguished name and password  User search base distinguished name and filter  Group membership attribute and type Leviton Switched Power Distribution Unit Installation and Operations Manual  109...
  • Page 110 Reply from 98.76.54.32: bytes=64 pseq=0 triptime=0 Reply from 98.76.54.32: bytes=64 pseq=1 triptime=0 Reply from 98.76.54.32: bytes=64 pseq=2 triptime=0 Reply from 98.76.54.32: bytes=64 pseq=3 triptime=0 Reply from 98.76.54.32: bytes=64 pseq=4 triptime=0 110  Leviton Switched Power Distribution Unit Installation and Operations Manual...
  • Page 111 NOTE: Granting access to environmental monitoring (temperature/humidity/sensors) to a non-admin user also grants that user access to power monitoring (outlets, infeeds, towers – all the environmental data of the PDU). Leviton Switched Power Distribution Unit Installation and Operations Manual  111...
  • Page 112 Type add outlettoldap all, followed by a group name and press Enter. Examples The following commands grant the LDAP group PowerUser access to outlets A1 and Webserver_1: Switched PDU:add outlettoldap .a1 poweruser<Enter> Switched PDU:add outlettoldap WebServer_1 poweruser<Enter> 112  Leviton Switched Power Distribution Unit Installation and Operations Manual...
  • Page 113 To delete serial port access for a user: At the Switched PDU: prompt, type delete portfromldap console and a group name. Press Enter. Leviton Switched Power Distribution Unit Installation and Operations Manual  113...

  • Page 114: Displaying Ldap Group Access

    Members of the PowerUser LDAP group may access the following outlets, outlet groups and serial ports: outlet A1 which has a descriptive name of DataServer_1, outlet A2 which has a descriptive name of WebServer_1, group ServerGroup_1 group ServerGroup_2 and Console serial port. 114  Leviton Switched Power Distribution Unit Installation and Operations Manual...
  • Page 115 TLS_RSA_WITH_DEX_CBC_SHA (56-bit) TLS_RSA_WITH_AES_128_CBC_SHA (128-bit) TLS_RSA_WITH_AES_256_CBC_SHA (256-bit) Server certificates are accepted and used on –the-fly A NULL client certificate is sent to the server if a client certificate is requested Leviton Switched Power Distribution Unit Installation and Operations Manual  115...

  • Page 116: Logging

    [6] Jul 24 18:54:00 CONFIG: Silkscreen to UI mapping changed to 3 for tower "Master" [A] by user "ADMN" More (Y/es N/o): NOTE: To terminate from the Show Log command, press <Esc>. 116  Leviton Switched Power Distribution Unit Installation and Operations Manual...
  • Page 117 The following command displays the Syslog configuration information: Switched PDU: show syslog<Enter> SYSLOG Configuration Primary Syslog Server IP Address: 56.47.38.29 Secondary Syslog Server IP Address: 0.0.0.0 Syslog Server Port: Leviton Switched Power Distribution Unit Installation and Operations Manual  117...

  • Page 118: Enabling Or Disabling Email Notification Support

    The following command sets the SMTP server address to 55.55.55.55: Switched PDU: set email smtp 55.55.55.55<Enter> The following command sets the SMTP server address to email.companyname.com: Switched PDU: set email smtp email.companyname.com<Enter> 118  Leviton Switched Power Distribution Unit Installation and Operations Manual...
  • Page 119 The following command sets the primary ‘to’ email address to DayAdmin@companyname.com: Switched PDU: set email primaryto DayAdmin@companyname.com<Enter> The following command sets the secondary ‘to’ email address to NiteAdmin@companyname.com: Switched PDU: set email secondaryto NiteAdmin@companyname.com<Enter> Leviton Switched Power Distribution Unit Installation and Operations Manual  119...
  • Page 120 Sending a test email: The Set Email Test command sends a test email to the target email destinations. At the Switched PDU: prompt, type set email test, and press Enter. 120  Leviton Switched Power Distribution Unit Installation and Operations Manual...
  • Page 121 Password: ******** 'From' Address: Sentry3_50e021@ Primary 'Send To' Addr: appeng@leviton.com Secondary 'Send To' Addr: Subject ID: [Sentry3_5246401] EVENT Messages: Enabled AUTH Messages: Disabled POWER Messages: Disabled CONFIG Messages: Disabled Leviton Switched Power Distribution Unit Installation and Operations Manual  121...

  • Page 122: Upload/Download

    ‘plain text’ file. NOTE: The CONFIG.BIN file while encoded is not encrypted and susceptible to decoding using simple tools. The recommendations is for a secure storage of CONFIG.BIN backup images. 122  Leviton Switched Power Distribution Unit Installation and Operations Manual...
  • Page 123 At the prompt, type put, followed by the filename and press Enter. FTP> put network.ini<Enter> At the prompt, type close to close the connection to the PDU and force a restart of the device. FTP> close Leviton Switched Power Distribution Unit Installation and Operations Manual  123...

  • Page 124: Remote Shutdown

    NOTE: Remote Shutdown is also supported by the extended feature set of Smart Load Shedding. Graceful shutdown is initiated by Smart Load-Shedding events such as high temperature, high infeed load and UPS ‘On Battery’ conditions. Figure 5. Diagram of Remote Shutdown 124  Leviton Switched Power Distribution Unit Installation and Operations Manual...

  • Page 125: Supported Operating Systems

    For additional security, when prompted enter the IP address of the PDU that will be sending the shutdown signal. NOTE: If left blank, any PDU can send a shutdown signal to the server. Leviton Switched Power Distribution Unit Installation and Operations Manual  125...
  • Page 126 At the Switched PDU: prompt, type set outlet script, followed by yes or no, and the outlet ID. Press Enter. Example The following command enables Remote Shutdown from outlet .a1: Switched PDU: set outlet script yes .a1<Enter> 126  Leviton Switched Power Distribution Unit Installation and Operations Manual...

  • Page 127: Outlet Control Inhibit

    The Outlet Control Inhibit feature is a key-activated feature to disable all outlet control. With the Outlet Control Inhibit feature activated, outlets will sequence on after power-up and recovery from a downed branch (fuse/breaker), but all control capability is disabled. Leviton Switched Power Distribution Unit Installation and Operations Manual  127...

  • Page 128: Chapter 5: Appendices

    On the Restart page in the Tools section of the Web interface, select Restart and reset to factory defaults, except network from the drop-down menu and click Apply. From the command line At the Switched PDU: prompt, type restart factory keepnet and press Enter. 128  Leviton Switched Power Distribution Unit Installation and Operations Manual...

  • Page 129: Appendix B: Uploading Firmware

    Accessing Updates from the website Periodically software and firmware updates are required. To check for or perform a software or firmware update, first download the required file(s) from the Leviton website www.leviton.com/pdu. Leviton Switched Power Distribution Unit Installation and Operations Manual  129...

  • Page 130: Appendix C: Technical Specifications

    (18) IEC C13, (6) C19 SV243-1J4 208V/50A/18.01Kw CS8365C (18) IEC C13, (6) C19 SV243-1K4 208V/60A/21.62Kw 460P9 (18) IEC C13, (6) C19 SV243-1L4 208V/60A/21.62Kw 560P9 (18) IEC C13, (6) C19 130  Leviton Switched Power Distribution Unit Installation and Operations Manual...

  • Page 131: Physical Specifications

    Time-Delay Fuses – Class G Amperes Bussman Part Number SC-20 CooperBussman product data-sheet #1024 NOTE: Outlet Relay Inrush Specification: Switched PDU relays are rated with an inrush up to 110A. Leviton Switched Power Distribution Unit Installation and Operations Manual  131...

  • Page 132: Data Connections

    Units are equipped with a status LED for each power receptacle. A lit/on LED indicates that power is being supplied at the port and a darkened/off LED indicates that there is no power at the port. 132  Leviton Switched Power Distribution Unit Installation and Operations Manual...

  • Page 133: Usa Notification

    表示该有毒有害物质至少在该部件的某一均质材料中的含量超出SJ/T 11363-2006 标准 规定的限量要求。 Indicates that this hazardous substance contained in at least one of the homogeneous materials of this part is above the limit requirement in SJ/T 11363-2006. Leviton Switched Power Distribution Unit Installation and Operations Manual  133...

  • Page 134: Appendix D: Warranty, Product Registration, And Support

    It should be deposited at an appropriate facility to enable recovery and recycling. Appendix D: Warranty, Product Registration, and Support Warranty For information regarding Leviton’s product warranty go to www.leviton.com/warranty Technical Support For Product Support or Technical Issues: ...
