USER MANUAL
Submersible Pump
Product Code:
Serial Number Range:
From:
To:
Year Of Manufacture:
*Please note, when ordering online via our website if the part number is not recognised,
please Email spares@hscgroupuk.co.uk or Telephone 0115 946 1988
KEEP THIS BOOKLET FOR FUTURE REFERENCE
Nottingham: 0115 946 1988 • London: 0208 830 3333
The Hire Supply Company Terms & Conditions Apply At All Time E&OE
110v 2"
SPT500
Nottingham: sales@hscgroupuk.co.uk • London: sean@hscgroupuk.co.uk
www.hscgroupuk.co.uk

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ELITE SPT500 and is the answer not in the manual?

Questions and answers

Summary of Contents for HSC ELITE SPT500

  • Page 1 USER MANUAL 110v 2” Submersible Pump Product Code: SPT500 Serial Number Range: From: Year Of Manufacture: *Please note, when ordering online via our website if the part number is not recognised, please Email spares@hscgroupuk.co.uk or Telephone 0115 946 1988 KEEP THIS BOOKLET FOR FUTURE REFERENCE Nottingham: 0115 946 1988 •...
  • Page 2 SPT500 / SPT500F Operation Manual...
  • Page 3 WARNINGS Please pay careful attention to the following warnings, signs and indications 1. Only qualified, licensed personnel should install this pump. The electrical installation shall be in accordance with the national wiring regulations applicable to the country of intended use. 2.
  • Page 4: Usage Limitations

    CONSTRUCTION HT200 Pump Housing Stainless Iron Pump Shaft Mechanical Seal Graphite to ceramic Rubber and plastic Pump Base H07RN-F 2.5mm Power Cable H07RN-F 1.5mm Float Cable Motor Housing AlSi12 NBR with stainless inserted Impeller USAGE LIMITATIONS Clean water with no suspended abrasive material, PH value 6.5-8.5 Type Of Liquid 40°C Max.
  • Page 5: Preparing For Installation

    PREPARING FOR INSTALLATION 1. Ensure pump is in a good position Inspect your pump, ensuring that it is not damaged. If the pump is damaged report it to where thepump has been purchased or hired from. Warranty of these pumps is void unless they are operatedin accordance with these instructions.
  • Page 6: Installation

    INSTALLATION 1. Ensure that the pump submerged in water before connecting power. 2. Connect power plug to a suitable outlet. Then the pump will start to work. 3. During the running of the pump, if any abnormal phenomena, such as unusual sound, lowwater drawn out or intermittent water flow etc., you should immediately switch off the powersupply and make an inspection to investigate the fault.
  • Page 7: Warranty

    • Inadequate or complete lack of maintenance THANK YOU FOR CHOOSING ELITE PUMPS! THE HIRE SUPPLY COMPANY (UK) LIMITED 7-10 Eldon Road Trading Estate,Attenborough,Nottingham NG9 6DZ,UK HSC INDUSTRIAL AND COMMERCIAL EQUIPMENT(EU) LIMITED First Floor, Penrose 1, Penrose Dock, CORK. T23 KW81. IRELAND Registered No: 68932 WWW.HSCGROUPUK.CO.UK...
  • Page 8 EU/UKCA Declara�on of Conformity Reference: 00030DoCJW0820V2 Product Elite Submersible Pumps SPK450 / SPK450M / SPK450AF / Model(s) / SPK530 / SPK530M / SPT500 / SPT500F The Hire Supply Company (UK) 7-10 Eldon Road Trading Estate, Address A�enborough, No�ngham, NG9 6DZ (UK) This declara�on is issued under the sole responsibility of the manufacturer The object of the declara�on described above is in conformity with the relevant union harmonisa�on legisla�on: 2006/42/EU...
  • Page 9 The Hire Supply Company 7-10 Eldon Road Trading Estate, A�enborough, No�ngham. NG9 6DZ, UK 0115 946 1988 www.hscgroupuk.co.uk HSC INDUSTRIAL AND COMMERCIAL EQUIPMENT(EU) LIMITED First Floor, Penrose 1, Penrose Dock, CORK. T23 KW81. IRELAND Registered No: 68932 Controlled Document No.: 00094UIRS0321V1 WWW.HSCGROUPUK.CO.UK...
  • Page 10 Recycling ENVIRONMENTAL PROTECTION: Please recycle any unwanted materials as opposed to disposing them as general waste. It is recommended the original is retained and used to store the product when not in use for prolonged periods of time. If this is not applicable ensure the materials are sorted and recycled in accordance with local regulations.
