- Page 1 Synology RackStation RS818+ / RS818RP+ Hardware Installation Guide...
-
Page 2: Table Of Contents
Table of Contents Chapter 1: Before You Start Package Contents Synology RackStation at a Glance System Fans Safety Instructions Chapter 2: Hardware Setup Tools and Parts for Drive Installation Install Drives Add a RAM Module on RackStation Attach Network Interface Card to the RackStation... -
Page 3: Before You Start
Chapter Before You Start Thank you for purchasing this Synology product! Before setting up your new RackStation, please check the package contents to verify that you have received the items below. Also, make sure to read the safety instructions carefully to avoid harming yourself or damaging your RackStation. -
Page 4: Synology Rackstation At A Glance
Synology RackStation at a Glance RS818+ RS818RP+ Article Name Location Description Displays power status of the RackStation. For more information, see Power Indicator "Appendix B: LED Indicator Table". 1. Press to power on the RackStation. Power Button 2. To power off the RackStation, press and hold until you hear a beep sound and the Power LED starts blinking. -
Page 5: System Fans
You can keep the current admin password unchanged by ticking the "Keep current admin password unchanged" checkbox in DSM Control Panel > Update & Restore > Reset. For more information about Synology Expansion Unit supported by your RackStation, please visit www.synology.com. 5 Chapter 1: Before You Start... -
Page 6: Safety Instructions
Safety Instructions Keep away from direct sunlight and away from chemicals. Make sure the environment does not experience abrupt changes in temperature or humidity. Place the product right side up at all times. Do not place near any liquids. Before cleaning, unplug the power cord. Wipe with damp paper towels. Do not use chemical or aerosol cleaners. -
Page 7: Chapter 2: Hardware Setup
Tools and Parts for Drive Installation • A screwdriver • At least one 3.5” or 2.5” SATA drive (please visit www.synology.com for compatible drive models.) Warning: If you install a drive that contains data, the system will format the drive and erase all existing data. Please back up any important data before installation. - Page 8 3 Insert the loaded drive tray into the empty drive bay. Note: Make sure the tray is pushed in all the way. Otherwise, the drive might not be able to function properly. 4 Push the handle inward to secure the drive tray. 5 Insert the drive tray key into the drive tray lock, turn the key clockwise to lock the handle of the drive tray, and then remove the key.
-
Page 9: Add A Ram Module On Rackstation
1. Always install or replace the RAM module from slot 1 first. 2. When two RAM modules are installed, the capacity of them must be identical. 3. Synology will not provide complete product warranty or technical support if non-Synology RAM modules are used for memory upgrade. - Page 10 3 Insert the new memory module in the slot: a Align the notch on the gold edge of the module with the notch in the memory slot. b Tilt the card and push the memory into the slot. Make sure the module is pushed in all the way. c Use two fingers to apply firm, even pressure and push the memory module downward.
- Page 11 To remove the RAM Module: 1 Follow step 1 and 2 of the “Add a RAM Module on RackStation” section to shut down your RackStation, disconnect the cables, and then remove the top cover. 2 Disengage the memory retaining clips by pushing them outwards, and the module will pop out of the slot. 3 Follow step 4 of the “Return the top cover into the RackStation”...
-
Page 12: Attach Network Interface Card To The Rackstation
Make sure the connector is fully inserted. Otherwise, the network interface card might not be able to function Note: properly. 4 Put back the top cover by following step 4 of Add a RAM Module on RackStation. For more information about supported 10GbE or Gigabit network interface cards, please visit www.synology.com. 12 Chapter 2: Hardware Setup... -
Page 13: Replace Redundant Power Supplies On Rackstation
Replace Redundant Power Supplies on RackStation 1 Push the lever of the redundant power supply in the rear-end of the RackStation in the indicated direction. 2 Pull out the redundant power supply from the RackStation. 3 Prepare a new power supply, and push it back to the slot unit until you hear a click. Start Up the RackStation 1 Connect one end of each power cord to the power ports located on the back of the RackStation and the other end to a power outlet. -
Page 14: Chapter 3: Install Dsm On Rackstation
Chapter Install DSM on RackStation After hardware setup is finished, please install DiskStation Manager (DSM) – Synology’s browser-based operating system – on your RackStation. Install DSM with Web Assistant Your RackStation comes with a built-in tool called Web Assistant that helps you download the latest version of DSM from the Internet and install it on your RackStation. -
Page 15: Specifications
• Basic • JBOD • RAID 0 • RAID 1 Supported RAID Type • RAID 5 • RAID 6 • RAID 10 • Synology Hybrid RAID (Up to 2-Disk Fault Tolerance) Agency Certification • FCC Class A • CE Class A • BSMI Class A... -
Page 16: Led Indicator Table
Please try to restart your RackStation or re-insert the drive(s), and then run the HDD/SSD manufacturer's diagnostic tool to check the health status of the drive(s). If you can log into DSM, please run the built-in S.M.A.R.T. test to scan the drive(s). If the problem remains unresolved, please contact Synology... - Page 17 Section 5. License Limitations. The license set forth in Sections 1, 2 and 3 applies only to the extent that you have ordered and paid for the Product and states the entirety of your rights with respect to the Software. Synology reserves all rights not expressly granted to you in this EULA.
- Page 18 Arbitration Law and related enforcement rules of the country in which Synology Inc. was organized. In such cases, the arbitration will be limited solely to the dispute between you and Synology. The arbitration, or any portion of it, will not be consolidated with any other arbitration and will not be conducted on a class-wide or class action basis.
-
Page 19: Section 1. Products
Section 3. Limited Warranty and Remedies 3.1 Limited Warranty. Subject to Section 3.6, Synology warrants to the Customer that each Product (a) will be free of material defects in workmanship and (b) under normal use will perform substantially in accordance with Synology's published specifications for the Product during the Warranty Period. - Page 20 Section 4. Limitations of Liability 4.1 Force Majeure. Synology will not be liable for, or be considered to be in breach of or default under this Warranty on account of, any delay or failure to perform as required by this Warranty as a result of any cause or condition beyond its reasonable control (including, without limitation, any act or failure to act by Customer).
- Page 21 Arbitration Association, except as otherwise provided below. The arbitration will be conducted before a single arbitrator, and will be limited solely to the dispute between Customer and Synology. The arbitration, or any portion of it, will not be consolidated with any other arbitration and will not be conducted on a class-wide or class action basis. The arbitration shall be held in King County, Washington, U.S.A.
- Page 22 5.9 Entire Agreement. This Warranty constitutes the entire agreement, and supersedes any and all prior agreements, between Synology and Customer related to the subject matter hereof. No amendment, modification or waiver of any of the provisions of this Warranty will be valid unless set forth in a written instrument signed by the party to be bound thereby.
-
Page 23: Fcc Declaration Of Conformity
FCC Declaration of Conformity This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
