- Page 1 MiniFinder Pico ® User manual Updated: 2023/11/10 © 2023 MiniFinder® All rights reserved...
-
Page 2: Package Contents
Thank you! Thank you for purchasing a MiniFinder® product. We believe you made the right choice. MiniFinder® Pico 4G is full of smart features that help you monitor, protect and locate your loved ones remotely. Before you start using your Pico 4G, please read this manual in its entirety. - Page 3 E. TURN OFF the device by pressing and holding SOS and ON/OFF buttons for 2 seconds. Place the magnetic charging cable to the charging pins to charge. See the picture below. Speaker Speaker Magnetic Charging Cable Charging Pins www.minifinder.com 2 av 23...
- Page 4 5 flashes = about 100%, 4 flashes = about 80%, and down to 1 flashes = about 20%. BLUE 3 sec Slow blink = Searching for GPS signal 3 sec Single blink = Connected to satellite www.minifinder.com 3 av 23...
- Page 5 = Pico 4G has low battery level. Voice is repeated 3 times. 4. “Fall alarm has been activated, press the SOS button to stop” = Pico 4G has detected a fall. Click the SOS button to cancel the alarm. Voice is repeated 3 times. 5. “Calling contact number 1”...
-
Page 6: App Overview
App overview App overview After logging in the MiniFinder GO APP, you will see the view as shown below. This consists of 10 different parts: 1. Menu (Device list) 2. Alarm notification 3. Create / Edit GeoFence 4. Applications settings 5. -
Page 7: Device Status
Alarm notification Alarm notification MiniFinder GO APP supports various types of alarms: Geofence alarm, Fall alarm, SOS / Panic alarm, Low battery alarm and speeding alarm. All alarms send an alarm notification to the phone’s or tablet’s screen. Audio alert, vibration and flashing alarm can be activated when opening the APP. -
Page 8: Action Menu
Action menu Action menu At the far right of the row of units is an Action Menu (three vertical points). Pico In the Action Menu you can see history (History), call (Call), activate live tracking (Live tracking) and change settings (Setup). -
Page 9: Live Tracking
Live tracking Live tracking Live tracking allows users to track their MiniFinder Pico 4G in real time in a quick and easy way over a short Pico period of time. By clicking on Action Menu (1) and then Live Tracking (2), the position update intervals change to 10 seconds for 10 minutes. - Page 10 (SOS button). Only phone number 2 receives calls from the call button. - Open MiniFinder GO APP, click the Action Menu (1) and then click on the “Setup” (2). NOTE! All MiniFinder devices include a roaming-free SIM card with a foreign telephone number.
-
Page 11: Make A Call
An accidental fall can cause devastating consequences. When an accidental fall occurs, the MiniFinder remote sensor sends an alarm to the APP in the form of an alarm notification on the mobile device’s screen and an alarm bell in the APP. -
Page 12: Low Battery Alarm
“Apply” to save the settings. After SOS function is activated, an alarm notification is sent to the MiniFinder GO APP if the SOS / panic alarm is activated on the device. The alarm is followed up with telephone calls to author- ized telephone numbers or a local alarm center. -
Page 13: Speeding Alarm
Press and hold the panic / SOS button for 3 seconds. There will be a beep sound and the unit’s green light starts blinking. A SOS message is sent to the MiniFinder GO APP and is displayed as an alarm notification on the mobile device’s screen. - Page 14 - To change the update interval, click on the Action Menu and select “Setup”. - Then click “Position Update Interval”, select a desired interval and click “Apply” to save the settings. www.minifinder.com 13 av 23...
- Page 15 Click “Apply” to save the settings. Comments Comments In the comment section, you can add additional information about your MiniFinder. To create a comment: - Click on the action menu and then click on “Comment”. - Enter your comment in “Write comment” and then click “Save”.
- Page 16 F) Name the area and select which units to connect, select “Enter” or “Leave” or both to create an alarm. Then click “Create” to finish the process. If you are not satisfied with the location of a point, click “Back” to delete or hold to delete all and start over. www.minifinder.com 15 av 23...
- Page 17 A) Click the pushpin (or on the device in the menu) to bring up the properties box. B) Unit name C) Location D) Speed Pico E) Altitude F) Battery level G) Distance between you and the selected device www.minifinder.com 16 av 23...
- Page 18 Tag function (mark places) Tag function (mark places) On the map in the MiniFinder GO APP, you can mark places with particular information. - Long press on the place where you want to mark on the map. (1) - You can give a name (2), a description (3), an icon (4) on the map and even attach an image (5).
-
Page 19: App Settings
App settings App settings - Click on the gear symbol to make settings in the MiniFinder GO APP. Settings menu Settings menu 1. Number of licenses and your username. 2. Change your password. 3. Map selector (Classic, Hybrid, Terrain, Satellite). - Page 20 User manuals User manuals - Click on the “i” symbol to read more information about MiniFinder GO and get access to the user manuals for all our products. - Press on “MiniFinder GO Documentation” (1). - Press on “Select Device” (2) and select which device’s user manual (3) you would likt to read.
-
Page 21: Memory Function
• Do not throw your MiniFinder® in a fire. The battery can explode! • Do not attempt to disassemble a MiniFinder®, it contains non-replaceable components • Never let children under 3 years of age play with MiniFinder®. Small components can be a choking hazard for them. -
Page 22: Recycling Information
• Do not dispose of the MiniFinder® with household waste. • Batteries are not to be disposed of in municipal waste stream and require separate collection. • Disposal of the packaging and your MiniFinder® should be done in accordance with local regulations. EU (European Union) -
Page 23: Technical Specification
Warm -148dBm, Cold -162dBm WiFi 802.11 b/g/n, 2.4G Bluetooth BT5.0 LE Operating temperature -20°C to +60°C Humidity 5% to 95% Non-condensing Standby 72 hours (under normal environmental conditions) Memory Built in 1Mb flash IP class IP67, waterproof Notes Notes www.minifinder.com 22 av 23... - Page 24 23 av 23...
