TIME SERVER
OPTION CARDS
OPTION CARDS
NETSILON 7
Installation instructions
BODET Time & Sport
1 rue du Général de Gaulle
49340 TREMENTINES - France
Tel. support France: 02.41.71.72.99
www.bodet-time.com
Tel. support Export: +33 2 41 71 72 33
On receipt, make sure that the product has not been damaged during transport so that you can make a
reservation to the carrier.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NETSILON 7 and is the answer not in the manual?

Questions and answers

Related Manuals for Bodet NETSILON 7

Summary of Contents for Bodet NETSILON 7

  • Page 1 TIME SERVER OPTION CARDS OPTION CARDS NETSILON 7 Installation instructions BODET Time & Sport 1 rue du Général de Gaulle 49340 TREMENTINES - France Tel. support France: 02.41.71.72.99 www.bodet-time.com Tel. support Export: +33 2 41 71 72 33 On receipt, make sure that the product has not been damaged during transport so that you can make a...

  • Page 2: Table Of Contents

    Table of contents SAFETY INFORMATION 1. GENERAL INFORMATION 1.1 Using the instructions 1.2 Introduction 1.3 List of recommendations 2. INTRODUCTION 2.1 Checking the package 2.2 Saving the configuration 2.3 Security 3. MECHANICAL INSTALLATION 4. ELECTRICAL CONNECTIONS 4.1 Option cards 5. QUICK CONFIGURATION 5.1 Web server access 5.2 Factory configuration 5.3 Upload the configuration 5.4 Detecting an option card...

  • Page 3: Safety Information

    SAFETY INFORMATION The following icons are used to indicate risks or sources of danger when installing, using and maintaining this product. Symbol Description IEC60417 - 1641 Operating instructions IEC60417 - 5031 Direct current IEC60417 - 5032 Alternating current IEC60417 - 6042 Caution, risk of electric shock IEC60417 - 6151 Caution, infrared radiation...

  • Page 4: General Information

    1. GENERAL INFORMATION Thank you for choosing an option card for the BODET Netsilon 7 time server. This product has been carefully designed for your satisfaction according to the rules of our ISO9001 and ISO14001 quality system. We recommend that you read these instructions carefully before opening the Netsilon time server or installing an option card.

  • Page 5: Introduction

    These instructions refer to the installation of one or several option cards. The operation and use of these option cards are explained in the Netsilon time server full user manual (available on our website www.bodet-time.com). 2.1 Checking the package Carefully unpack and check the content of the package. This must include: >...

  • Page 6: Mechanical Installation

    3. MECHANICAL INSTALLATION The installation method is the same regardless of the option card installed. However, there are some specific operations to carry out depending on the option card. Make sure to observe the following locations: - Slot A / B / C: NETWORK (RJ45 port), FIBRE NETWORK (SFP port) option cards, If the new option card is installed in place of an existing option card (that has been relocated), it is then necessary to uninstall the relocated option card from the web server (please refer to chapter 5.5 Deleting an option card).
  • Page 7 6) Clip the electronic board onto the connector and secure it using the two Torx T8 screws 7) Fix the aluminium plate in order to close the space around the option card: Repeat these 5 steps as many times as there are option cards to install. Do not use screws other that those supplied, since screws of inappropriate lengths may damage some components.

  • Page 8: Electrical Connections

    LC-Duplex Fibre connector Wavelength = 1310 nm We recommend that you use the Bodet SX and LX modules. It is possible to use other SFP modules compatible with MSA (Multi-Source Agreement), without any guarantee of operation (RJ45 module not compatible).
  • Page 9 AFNOR option card (IRIG B 127), ref: 907 940. > Outputs A and B can assign two independent time zones from the web server. > The power supply can power up to two Bodet DHF V1 transmitters. > A maximum of four option cards can be installed. >...
  • Page 10 > ASCII option card, ref: 907 926. > Outputs A and B can distribute two different serial links (RS232/422/485). > Both outputs are dependent. > Configuration of the output frame via the embedded Netsilon web server. ASCII ASCII ASCII AC IN ALARM OUT ANTENNA ALARM IN...

  • Page 11: Quick Configuration

    4) Enter your username and password to access the web server. > For more information on the product and how to configure it from the web server, download the full user manual https://www.bodet-time.com/support/documents-database.html 5.2 Factory configuration To return to factory configuration from the Netsilon web server, please follow these steps: 1) SYSTEM menu >...

  • Page 12: Detecting An Option Card

    > To request technical support for this equipment, fill in the contact page at: https://www.bodet-time.com/support.html The hotline support is available from Monday to Friday from 8.00 to 12.00 am and 1.30 to 5.00 pm. To speed up the diagnosis of your Netsilon, please make a system backup and have your Netsilon MAC address...
