- Page 1 SLAP HAPPY Operation Manual WARNING Be sure to read this Operation Manual before use. Bromley Incorporated 420 Crossen Avenue ELK Grove Village IL 60007 847-427-0639...
- Page 2 SLAP HAPPY Before using the product, be sure to read the follow: To maintain the safety: To ensure the safe usage of the product, be sure to read the following before using the product. The following instructions are intended for the users, operators and the personnel in charge of the operation of the product.
- Page 3 SLAP HAPPY High Voltage Warning: High voltage can cause an electric shock. Turn off power before servicing. No Touching Warning: This part may cause an electric shock or the surface is overheating. Do not touch this part. High Temperature Warning: This part may caused by scalding if somebody inadvertent to do something.
-
Page 4: Table Of Contents
SLAP HAPPY CONTENTS Specifications………….………………….………. …….…………….…5 Package Contents……………………………….. …….…………….….6 Installation, Fix and Transport………………………….……….…….…7 Connecting the power cord and grounding………….…………..….….10 Game description…………………………………….………………..….11 Switch…………..…………………………….. …….…………….……..12 Adjustment..……………………………….………….…….………..……13 Maintenance and inspections..………..……….………………….…….17 Troubleshooting………………………………………………………...…19 Overall Construction...………………………….…………………..…..20 I/O chart Wiring Diagram - 3 -... - Page 5 SLAP HAPPY DEFINITION OF LOCATION’S MAINTENANCE MAN AND SERVICEMAN WARNING Non-technical personnel who do not have technical knowledge and expertise should refrain from performing such work that this manual requires the location’s maintenance man or a serviceman to carry out, or work which is not explained in this manual.
-
Page 6: Specifications
SLAP HAPPY 1. Specifications Specifications 1 Rated power supply： AC110V 50/60Hz 2 Power Consumption： Min power consumption 80W Max power consumption 110W 3 Dimensions： (L)43.31 ×(W)27.95 × (H)89.17 (inch) 4 Weight： NW: 269 pounds GW: 337 pounds 5 Environment Condition: Temperature(indoor):-10F～+40F... -
Page 7: Package Contents
SLAP HAPPY 2. Package contents 3.1 Body Assembly: 1 unit ● Make sure that all the parts shown below are included in product package. ● If any parts are missing, contact your distributor. 3.2 Accessories Part No. Name Specification Illustration... -
Page 8: Installation, Fix And Transport
SLAP HAPPY 3. Installation and transport WARNING This product is an indoor game machine. Do not install it outside. Even indoors, Avoid installing in places mentioned below. ● Places subject to rain or water leakage, or places subject to high humidity in the proximity of an indoor swimming pool and or shower, etc. - Page 9 SLAP HAPPY Play zone Space for Operation and Maintenance This machine requires space for playing the game (play zone) and for maintenance (maintenance zone) as shown below. Be sure to leave enough space when installing the machine. About 19.69 inches...
- Page 10 SLAP HAPPY Moving and transport Notice: ● Be careful not to damage the machine during transport. ● Do not give a shock to the molded parts. These parts are fragile. ● Be careful not to give a shock to the machine when bringing it down from a higher level.
-
Page 11: Connecting The Power Cord And Grounding
SLAP HAPPY 4. Connecting the power cord and grounding The connection: Insert the plug of power cord into the power socket of the machine. Warning: ★ Do not put heavy items on power cord. ★ Do not touch the power plug with a wet hand. -
Page 12: Game Description
SLAP HAPPY 5．Game description The instruction of how to play When you see the number you want, tap the button to freeze it. You have 8 seconds…. GOOD LUCK! 1. LED: Display the score. 2. LED: Display the spare time. -
Page 13: Switch
SLAP HAPPY 6. Switches The Main board: The DIP SW Locations Game parameters are controlled by a dip switch banks labeled SW. Each bank eight switches where in the SW1-2 for example refers to bank 2 switch position 1. Note: Game parameters are subject change without notice. -
Page 14: Adjustment
SLAP HAPPY 7. Adjustment 1. Coin per game: This switch is used for the coin Mech, adjusting it to setting how many coins in one game. There have 4 options. It is controlled by SW11~SW12. Coin per game Options SW11... - Page 15 SLAP HAPPY 3. Continue shoot: Adjust the mode of shooting. There are 2 option for user to select. It is controlled by SW15. Mode Options SW15 Note SW16 4. Playing Time: Adjust the geme time. There are 4 options for user to select. It is controlled by SW16~SW17.
- Page 16 SLAP HAPPY 6. Average Ticket per game. SW24 SW25 Payout Content SW21 SW22 SW23 Note SW21~ SW25 7. Fault display When starting the game machine or entering the test condition, the related contents show as the below information. Content Content...
- Page 17 SLAP HAPPY The following form represents that the related output in the list should be checked when any devices of the machine couldn’t work. Content Conent OUTPUT OUTPUT 1#Coin amount MarqueeLamp1 J31-1 J33-17 1#Ticket amount MarqueeLamp2 J31-2 J33-18 1#Button Lamp...
-
Page 18: Maintenance And Inspections
SLAP HAPPY 8. Maintenance and inspections Safety checks Check the points listed before operating the machine. These checks are necessary for safe machine operation. 1. Is there sufficient play zone around the machine? HANDLING PRECAUTIONS When installing or inspecting the machine, be very careful of the following points and pay attention to ensure that the player can enjoy the game safely. - Page 19 SLAP HAPPY OPERATION WARNING Should a problem occur, switch OFF the power immediately and stop operating the machine. Then unplug the power cord the service outlet. Operating the machine without correcting the problem may cause a fire or accident. Dust accumulated on the power plug may cause a fire. Check the plug regularly and remove any dust.
-
Page 20: Troubleshooting
SLAP HAPPY 9. Troubleshooting Malfunction Cause Settlement 1. No power or wrong voltage 1. Power on. Check the voltage. The machine 2. Plug is poor contacted 2. Plug on again. can’t open. 3. The electric circuit was short 3. Check the electric circuit. -
Page 21: Overall Construction
SLAP HAPPY 10. Overall construction 10.1 Game components 20 22 - 20 -... - Page 22 SLAP HAPPY Parts list: Item Part NO. Code Content Q’ty Specification Note T107 -001-000 YJSK2-01-00A Marquee assemble Assy. T107 -401-000 Lock T107 -101-000 YJSK2-00-04 Light belt holder A Stainless steel T107 -102-000 YJSK2-00-03A Coin Chute Q235 T107 -103-000 YJSK2-00-05 Base(Coin Chute)
- Page 23 SLAP HAPPY 10.2 Control Panel Assemble Parts list: Item Part NO. Code Content Q’ty Specification Note T 107 -604-000 YJSK2-02-01A Control Panel PC PC(δ=5) T 107 -110-000 YJSK2-02-02A Fixation Frame Q235 T 107 -605-000 YJSK2-02-03 Green Plastic T 107 -501-000 YJSK2-02-04M Wooden piece-1 δ=18...
- Page 24 SLAP HAPPY 10.3 Marquee Assemble Parts list: Item Part NO. Code Content Q’ty Specification Note T 107 -607-000 YJSK2.01-01A Flambeau plastic (δ=10) T 107 -608-000 YJSK2-01-02A Graphic Plastic plastic (δ=4) T 107 -111-000 YJSK2-01-03A Marquee bracket Q235(δ=２) T 107 -112-000 LJF.02-06...
- Page 25 SLAP HAPPY 10.4 Electric Part: Parts list: Part NO. Code Content Q’ty Specification Note T 107 -803-000 LED board(Score displays) 2 LED50B3RG.PCB T 107 -804-000 LED board YJSK-16LED.PCB T 107 -805-000 LED board(Time displays) YJSK.LED50B1.PCB T 107 -806-000 Lamp board LED-YJSK.PCB...
- Page 26 SLAP HAPPY Part list: Part NO. Code Content Q’ty Specification Note T 107 -811-000 Ticket Board Tick-CH.PCB T 107 -113-000 Counter Assy. T 107 -812-000 LED lamp(ticket indicate) LMP001.PCB T 107 -412-000 Ticket Assy TD963CR T 107 -413-000 LED lamp...
- Page 27 SLAP HAPPY 10.5 Game decal: - 26 -...
- Page 28 SLAP HAPPY Part NO. Code Content Q’ty Specification Note T 107 -801-000 Marquee Lamp board-1 4 YJSK-LEDDXac.PCB T 107 -701-000 YJSK2-HM-06A Marquee decal 21.50X13.78(δ3 Plastic) T 107 -802-000 Marquee Lamp board-2 4 YJSK-LEDDXbd.PCB T 107 -813-000 Marquee Lamp board-3 1 LED48-NC.PCB...
