Boardcon Embedded Design MINI3576 Reference User Manual page 25

2.1.3 HDMI TX Circuit
2.2 Mother Board length offset
2.2.1 MIPI CSI1/2 4-Lane Interface length offset
MIPI_DPHY_CSI1_RX_CLKP
/MIPI_DPHY_CSI2_RX_CLKP
Yellow block is MINI3576 CSI1/2 group length difference.
2.2.2 MIPI DSI 4-Lane Interface length offset
MIPI_DPHY_DSI_TX_CLKP
Yellow block is MINI3576 DSI group length difference.
Customize the embedded system based on
MIPI_DPHY_CSI1_RX_D0P
MIPI_DPHY_CSI1_RX_D1P
MIPI_DPHY_CSI1_RX_D2P
MIPI_DPHY_CSI1_RX_D3P
MIPI_DPHY_DSI_TX_D0P
MIPI_DPHY_DSI_TX_D1P
MIPI_DPHY_DSI_TX_D2P
MIPI_DPHY_DSI_TX_D3P
24
Your Idea
(-157) (-160)
(-58) (-60)
(-58) (-60)
(-63) (-70)
Unit: mil
(143) (+150)
(118) (+120)
(132) (+140)
(91) (+100)
