GETTING STARTED
Connect Using USB-C
CONNECT USING USB-C
The mosaic-T has a built-in high-speed USB port which
supports Ethernet-over-USB. To take advantage of this
interface, you first need to install the Septentrio drivers.
1. Connect the GNSS antenna. Inside your GNSSDO kit,
you will find the L1/L2/L5 GNSS "UFO" antenna. It has a TNC
connection. Use the supplied TNC-SMA cable to connect
the antenna to the GNSSDO GNSS SMA connection. Make
sure the antenna is securely mounted to a structure so that
it cannot be moved and has a clear view of the sky.
2. Download and install Septentrio RxTools. RxTools
includes the driver for the USB-C port plus several tools
which you can use to control and configure the mosaic-T,
forward data, log data, analyze the log files, convert the log
files to other formats, and configure the module for use
with other GIS software.
